• BCM receives the sleep-ready signal (ready) from IPDM E/R and combination meter via CAN communica-
tion.
• BCM tran](/img/5/57390/w960_57390-27.png "NISSAN TEANA 2014 Service Manual
BCS
SYSTEMBCS-13
< SYSTEM DESCRIPTION > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N
• BCM receives the sleep-ready signal (ready) from IPDM E/R and combination meter via CAN communica-
tion.
• BCM tran")
BCS
SYSTEMBCS-13
< SYSTEM DESCRIPTION > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N
• BCM receives the sleep-ready signal (ready) from IPDM E/R and combination meter via CAN communica-
tion.
• BCM transmits the sleep wake up signal (sleep) to each unit when all of the CAN sleep conditions are ful-
filled.
• Each unit stops the transmission of CAN communication with the sleep wakeup signal. BCM is in CAN com- munication sleep mode.
• BCM is in the low power consumption mode and performs the low power consumption control when all of the
BCM sleep conditions are fulfilled with CAN sleep condition.
Sleep condition
Wake-up operation
• BCM changes from the low power consumption m ode to the CAN communication sleep mode when the any
of the BCM wake-up conditions are fulfilled. Only the control with BCM is activated.
• BCM transmits the sleep wake up signal (wake up) to each unit when any of the CAN wake-up conditions are fulfilled. It changes from the low power consum ption mode or the CAN communication sleep mode to the
normal mode.
• Each unit starts the transmission of CAN communicati on with the sleep wake up signal. In addition, the com-
bination meter transmits the wake up signal to BCM via CAN communication to report the CAN communica-
tion start.
CAN sleep condition BCM sleep condition
• Receiving the sleep-ready signal (ready) from all units
• Ignition switch: OFF
• Vehicle security system alarm and panic alarm : No operation
• Warning lamp: Not operation
• Intelligent Key system buzzer: No operation
• Brake switch: OFF
• Turn signal indicator lamp: No operation
• Exterior lamp: OFF
• Door lock status: No change
• CONSULT communication status: No communication
• Meter display signal : Non-transmission
• Door switch status: No change
• Rear window defogger: OFF • Interior room lamp batte
ry saver: Time out
• RAP system: OFF
• Power window switch communication: No transmission
• Push-button ignition switch (push switch) illumination: OFF
• NATS: No operation
• Remote keyless entry receiver communication status: No
communication
• Tire pressure monitoring system: Stop
BCM wake-up condition CAN wake-up condition
• Door unlock sensor: OFF →ON, ON →OFF
• Door lock assembly LH (key cylinder switch): Lock or unlock
• Door lock switch: OFF →ON
• Door unlock switch: OFF →ON
• Trunk opener switch: OFF →ON
• Power window serial link communication: Receiving
• Remote keyless entry receiver: Receiving valid keyfob • Receiving the sleep-ready signal (Not-ready) from any units
• Push-button ignition switch (push switch): OFF →ON
• Hazard switch: OFF →ON
• PASSING switch: OFF →ON, ON →OFF
• TAIL LAMP switch: OFF →ON
• Driver door switch: OFF →ON, ON →OFF
• Passenger door switch: OFF → ON, ON → OFF
• Trunk switch: OFF →ON, ON →OFF
• Driver door request swit ch (if equipped): OFF→ON
• Passenger door request switch (if equipped): OFF →ON
• Stop lamp switch 2 signal: ON
• Remote keyless entry receiver: Receiving valid keyfob
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 29 of 4801
![NISSAN TEANA 2014 Service Manual
BCS-14
< SYSTEM DESCRIPTION >[BCM]
DIAGNOSIS SYSTEM (BCM)
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT Fu
nction (BCM - COMMON ITEM)INFOID:0000000009461996
CAUTION:
After disconnecting t](/img/5/57390/w960_57390-28.png "NISSAN TEANA 2014 Service Manual
BCS-14
< SYSTEM DESCRIPTION >[BCM]
DIAGNOSIS SYSTEM (BCM)
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT Fu
nction (BCM - COMMON ITEM)INFOID:0000000009461996
CAUTION:
After disconnecting t")
BCS-14
< SYSTEM DESCRIPTION >[BCM]
DIAGNOSIS SYSTEM (BCM)
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT Fu
nction (BCM - COMMON ITEM)INFOID:0000000009461996
CAUTION:
After disconnecting the CONSULT vehicle interface (VI) from the data link connector, the ignition must
be cycled OFF → ON (for at least 5 seconds) → OFF. If this step is not performed, the BCM may not go
to ”sleep mode”, potentially causing a di scharged battery and a no-start condition.
APPLICATION ITEM
CONSULT performs the following functions via CAN communication with BCM.
SYSTEM APPLICATION
BCM can perform the following functions.
Direct Diagnostic Mode Description
Ecu Identification The BCM part number is displayed.
Self Diagnostic Result The BCM self diagnostic results are displayed.
Data Monitor The BCM input/output data is displayed in real time.
Active Test The BCM activates outputs to test components.
Work support The settings for BCM functions can be changed.
Configuration • The vehicle specification can be read and saved.
• The vehicle specification can be written when replacing BCM.
CAN Diag Support Mntr The result of transmit/receive diagnosis of CAN communication is displayed.
System Sub System Direct Diagnostic Mode
Ecu Identification
Self Diagnostic Result
Data Monitor
Active Test
Work support
Configuration
CAN Diag Su pport Mntr
Door lock DOOR LOCK ××××
Rear window defogger REAR DEFOGGER ×××
Warning chime BUZZER ××
Interior room lamp timer INT LAMP ×××
Remote keyless entry system MULTI REMOTE ENT ×××
Exterior lamp HEADLAMP ×××
Wiper and washer WIPER ×××
Turn signal and hazard warning lamps FLASHER ××
Air conditioner AIR CONDITIONER ×
Intelligent Key system INTELLIGENT KEY ××××
Combination switch COMB SW ×
BCM BCM × × ×××
Immobilizer IMMU ×××
Interior room lamp battery saver BATTERY SAVER ××
Trunk open TRUNK ×
Vehicle security system THEFT ALM ×××
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 38 of 4801
![NISSAN TEANA 2014 Service Manual
BCS
DIAGNOSIS SYSTEM (BCM)BCS-23
< SYSTEM DESCRIPTION > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N
ACTIVE TEST
DOOR STAT -AS [LOCK/READY/UNLK]
×Indicates condition of passenger side door status.
DOOR STA](/img/5/57390/w960_57390-37.png "NISSAN TEANA 2014 Service Manual
BCS
DIAGNOSIS SYSTEM (BCM)BCS-23
< SYSTEM DESCRIPTION > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N
ACTIVE TEST
DOOR STAT -AS [LOCK/READY/UNLK]
×Indicates condition of passenger side door status.
DOOR STA")
BCS
DIAGNOSIS SYSTEM (BCM)BCS-23
< SYSTEM DESCRIPTION > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N
ACTIVE TEST
DOOR STAT -AS [LOCK/READY/UNLK]
×Indicates condition of passenger side door status.
DOOR STAT -RR [LOCK/READY/UNLK] ×Indicates condition of rear right side door status.
DOOR STAT -RL [LOCK/READY/UNLK] ×Indicates condition of rear left side door status.
ID OK FLAG [Set/Reset] Indicates condition of Intelligent Key ID.
PRMT ENG STRT [Set/Reset] Indicates condition of engine start possibility.
PRMT RKE STRT [Set/Reset] Indicates condition of engine start possibility from Intelligent Key.
I-KEY OK FLAG [Key ON/Key OFF] ×Indicates condition of Intelligent Key OK flag.
PRBT ENG STRT [Set/Reset] Indicates condition of engine start prohibit.
ID AUTHENT CANCEL TIMER [STOP] Indicates condition of Intelligent Key ID authentication.
ACC BATTERY SAVER [STOP] Indicate s condition of battery saver.
CRNK PRBT TMR [On/Off] In dicates condition of crank prohibit timer.
AUT CRNK TMR [On/Off] Indicates condition of automatic engine crank timer from Intelligent Key.
CRNK PRBT TME [sec] I ndicates condition of engine crank prohibit time.
AUTO CRNK TME [sec] Indicates co ndition of automatic engine crank time from Intelligent Key.
CRANKING TME [sec] Indicates condition of engine cranking time from Intelligent Key.
DETE SW PWR [On/Off] Indicates condition of detent switch voltage.
ACC RLY -REQ [On/Off] Indicates condition of accessory relay control request.
RKE OPE COUN1 [0-19] ×When remote keyless entry receiver receives the signal transmitted while
operating on Intelligent Key, the numerical value start changing.
RKE OPE COUN2 [0-19] ×When remote keyless entry receiver receives the signal transmitted while
operating on Intelligent Key, the numerical value start changing.
TRNK/HAT MNTR [On/Off] Indicates condition of trunk room lamp switch.
RKE-LOCK [On/Off] Indicates condition of lock signal from Intelligent Key.
RKE-UNLOCK [On/Off] Indicates condition of unlock signal from Intelligent Key.
RKE-TR/BD [On/Off] Indicates condition of trunk open signal from Intelligent Key.
RKE-PANIC [On/Off] Indicates condition of panic signal from Intelligent Key.
RKE-MODE CHG [On/Off] Indicates condition of mode change signal from Intelligent Key. Monitor Item [Unit] Main Description
Test Item Description
INTELLIGENT KEY LINK (CAN) This test is able to check Intelligent Key iden
tification number [Off/ID No1/ID N02/ID No3/ID
No4/ID No5].
INT LAMP This test is able to check interior room lamp operation [On/Off].
FLASHER This test is able to check hazard lamp operation [LH/RH/Off].
HORN This test is able to check horn operation [On].
BATTERY SAVER This test is able to check battery saver operation [On/Off].
TRUNK/BACK DOOR This test is able to check trunk actuator operation [Open].
OUTSIDE BUZZER This test is able to check In telligent Key warning buzzer operation [On/Off].
INSIDE BUZZER This test is able to check combination meter warning chime operation [Take Out/Knob/Key/
Off].
INDICATOR This test is able to check combination meter warning lamp operation [KEY ON/KEY IND/Off].
IGN CONT2 This test is able to check ignition relay-2 control operation [On/Off].
ENGINE SW ILLUMI This test is able to check push-bu tton ignition switch START indicator operation [On/Off].
PUSH SWITCH INDICATOR This test is able to check push-button ignition switch indicator operation [On/Off].
ACC CONT This test is able to check ac cessory relay control operation [On/Off].
IGN CONT1 This test is able to check ignition relay-1 control operation [On/Off].
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 63 of 4801
![NISSAN TEANA 2014 Service Manual
BCS-48
< ECU DIAGNOSIS INFORMATION >[BCM]
BCM (BODY CONTROL MODULE)
11 9
(G) Ground
Remote keyless entry
receiver signal Input/
Output Push-button igni-
tion switch ON Standby state
When receiving](/img/5/57390/w960_57390-62.png "NISSAN TEANA 2014 Service Manual
BCS-48
< ECU DIAGNOSIS INFORMATION >[BCM]
BCM (BODY CONTROL MODULE)
11 9
(G) Ground
Remote keyless entry
receiver signal Input/
Output Push-button igni-
tion switch ON Standby state
When receiving")
BCS-48
< ECU DIAGNOSIS INFORMATION >[BCM]
BCM (BODY CONTROL MODULE)
11 9
(G) Ground
Remote keyless entry
receiver signal Input/
Output Push-button igni-
tion switch ON Standby state
When receiving the signal
from the transmitter
121 (R) Ground Outside key antenna
LH B OutputWhen the front
door LH request
switch is operat-
ed with push-but-
ton ignition switch
OFF When Intelligent Key is in
the antenna detection area
When Intelligent Key is not
in the antenna detection
area
122 (P) Ground Outside key antenna
LH A OutputWhen the front
door LH request
switch is operat-
ed with push-but-
ton ignition switch
OFF When Intelligent Key is in
the antenna detection area
When Intelligent Key is not
in the antenna detection
area
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
(+) (-)
OCC3881D
OCC3880D
JMKIA0062GB
JMKIA0063GB
JMKIA0062GB
JMKIA0063GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 68 of 4801
![NISSAN TEANA 2014 Service Manual
BCS
BCM (BODY CONTROL MODULE)BCS-53
< ECU DIAGNOSIS INFORMATION > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N
B2196: DONGLE UNIT — — —
SEC-90, "Description"
B2198: NATS ANTENNA AMP. — — — SEC-9](/img/5/57390/w960_57390-67.png "NISSAN TEANA 2014 Service Manual
BCS
BCM (BODY CONTROL MODULE)BCS-53
< ECU DIAGNOSIS INFORMATION > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N
B2196: DONGLE UNIT — — —
SEC-90, \"Description\"
B2198: NATS ANTENNA AMP. — — — SEC-9")
BCS
BCM (BODY CONTROL MODULE)BCS-53
< ECU DIAGNOSIS INFORMATION > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N
B2196: DONGLE UNIT — — —
SEC-90, "Description"
B2198: NATS ANTENNA AMP. — — — SEC-92, "DTC Logic"
B2555: STOP LAMP — — —SEC-94, "DTC Logic"
B2556: PUSH-BTN IGN SW —×— SEC-97, "DTC Logic"
B2557: VEHICLE SPEED — ×— SEC-99, "DTC Logic"
B2560: STARTER CONT RELAY ××—SEC-100, "Description"
B2562: LOW VOLTAGE ×—— BCS-71, "DTC Logic"
B259A: ROOM LAMP FUSE — — — BCS-72, "DTC Logic"
B2601: SHIFT POSITION —×—SEC-101, "DTC Logic"
B2602: SHIFT POSITION — ×—SEC-104, "DTC Logic"
B2603: SHIFT POSI STATUS — ×—SEC-106, "DTC Logic"
B2604: PNP SW — ×—SEC-110, "DTC Logic"
B2605: PNP SW — ×—SEC-113, "DTC Logic"
B2608: STARTER RELAY ××—SEC-116, "DTC Logic"
B260A: IGNITION RELAY ××—PCS-58, "DTC Logic"
B2614: ACC RELAY CIRC — ×— PCS-60, "DTC Logic"
B2615: BLOWER RELAY CIRC — ×— PCS-62, "DTC Logic"
B2616: IGN RELAY CIRC — ×— PCS-64, "DTC Logic"
B2617: STARTER RELAY CIRC ××—SEC-118, "Description"
B2618: BCM ××—PCS-66, "DTC Logic"
B261A: PUSH-BTN IGN SW — ×— PCS-68, "DTC Logic"
B261B: RES ENG RUN — — — DLK-87, "DTC Logic"
B261E: VEHICLE TYPE××
(Turn ON for
15 seconds) —
SEC-120, "Description"
B2621: INSIDE ANTENNA — — — DLK-88, "DTC Logic"
B2622: INSIDE ANTENNA — — —DLK-90, "DTC Logic"
B26F1: IGNITION RELAY — — —PCS-70, "DTC Logic"
B26F2: IGNITION RELAY — — —PCS-72, "DTC Logic"
B26F6: BCM — — —PCS-74, "DTC Logic"
B26FD: SHIFT LOCK SOLENOID — — — DLK-92, "DTC Logic"
B26FE: HOOD SWITCH — — —DLK-95, "DTC Logic"
B26FF: REMOTE KEYLESS ENTRY RE-
CEIVER —— —
DLK-97, "DTC Logic"
C1704: LOW PRESSURE FL — — ×
WT-28, "DTC Logic"
C1705: LOW PRESSURE FR — — ×
C1706: LOW PRESSURE RR — — ×
C1707: LOW PRESSURE RL — — ×
C1708: [NO DATA] FL — — ×
WT-30, "DTC Logic"
C1709: [NO DATA] FR — — ×
C1710: [NO DATA] RR — — ×
C1711: [NO DATA] RL — — ×
CONSULT display Fail-safe
Intelligent Key
warning lamp
ON Tire pressure
monitor warning
lamp ON Reference page
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 733 of 4801
DEF-8
< SYSTEM DESCRIPTION >
DIAGNOSIS SYSTEM (BCM)
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT Function (BCM - COMMON ITEM)INFOID:0000000009956271
CAUTION:
After disconnecting the CONSULT vehicle interface (VI) from the data link connector, the ignition must
be cycled OFF → ON (for at least 5 seconds) → OFF. If this step is not performed, the BCM may not go
to ”sleep mode”, potentially causing a di scharged battery and a no-start condition.
APPLICATION ITEM
CONSULT performs the following functions via CAN communication with BCM.
SYSTEM APPLICATION
BCM can perform the following functions.
Direct Diagnostic Mode Description
Ecu Identification The BCM part number is displayed.
Self Diagnostic Result The BCM self diagnostic results are displayed.
Data Monitor The BCM input/output data is displayed in real time.
Active Test The BCM activates outputs to test components.
Work support The settings for BCM functions can be changed.
Configuration • The vehicle specification can be read and saved.
• The vehicle specification can be written when replacing BCM.
CAN Diag Support Mntr The result of transmit/receive diagnosis of CAN communication is displayed.
System Sub System Direct Diagnostic Mode
Ecu Identification
Self Diagnostic Result
Data Monitor
Active Test
Work support
Configuration
CAN Diag Su pport Mntr
Door lock DOOR LOCK ××××
Rear window defogger REAR DEFOGGER ×××
Warning chime BUZZER ××
Interior room lamp timer INT LAMP ×××
Remote keyless entry system MULTI REMOTE ENT ×××
Exterior lamp HEADLAMP ×××
Wiper and washer WIPER ×××
Turn signal and hazard warning lamps FLASHER ××
Air conditioner AIR CONDITIONER ×
Intelligent Key system INTELLIGENT KEY ××××
Combination switch COMB SW ×
BCM BCM × × ×××
Immobilizer IMMU ×××
Interior room lamp battery saver BATTERY SAVER ××
Trunk open TRUNK ×
Vehicle security system THEFT ALM ×××
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 769 of 4801
DLK-1
BODY EXTERIOR, DOORS, ROOF & VEHICLE SECURITY
C
D E
F
G H
I
J
L
M
SECTION DLK
A
B
DLK
N
O P
CONTENTS
DOOR & LOCK
PRECAUTION ................ ...............................6
PRECAUTIONS .............................................. .....6
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
6
Precaution for Procedure without Cowl Top Cover ......6
Precaution for Servicing Doors and Locks .......... ......6
PREPARATION ............................................8
PREPARATION .............................................. .....8
Special Service Tools .......................................... ......8
Commercial Service Tools ........................................9
CLIP LIST ...........................................................10
Descriptions for Clips .......................................... ....10
SYSTEM DESCRIPTION .............................14
COMPONENT PARTS ................................... ....14
POWER DOOR LOCK SYSTEM ........................... ....14
POWER DOOR LOCK SYSTEM :
Component Parts Location ................................ ....
14
POWER DOOR LOCK SYSTEM :
Component Description ...................................... ....
15
INTELLIGENT KEY SYSTEM ...................................15
INTELLIGENT KEY SYSTEM : Component Parts
Location ............................................................... ....
16
INTELLIGENT KEY SYSTEM :
Component Description ...................................... ....
19
INTEGRATED HOMELINK TRANSMITTER ......... ....19
INTEGRATED HOMELINK TRANSMITTER :
Component Parts Location .................................. ....
19
INTEGRATED HOMELINK TRANSMITTER :
Component Description ....................................... ....
19
TRUNK LID OPENER SYSTEM ............................ ....19
TRUNK LID OPENER SYSTEM :
Component Parts Location ................................ ....
20
TRUNK LID OPENER SYSTEM :
Component Description ...................................... ....
20
SYSTEM (POWER DOOR LOCK SYSTEM) ....21
System Diagram .................................................. ....21
System Description ..................................................21
SYSTEM (INTELLIGENT KEY SYSTEM) .........23
INTELLIGENT KEY SYSTEM ......................... ...........23
INTELLIGENT KEY SYSTEM : System Diagram ....23
INTELLIGENT KEY SYSTEM : System Descrip-
tion ....................................................................... ....
23
DOOR LOCK FUNCTION ...................................... ....24
DOOR LOCK FUNCTION : System Diagram ..........24
DOOR LOCK FUNCTION : System Description . ....24
REMOTE KEYLESS ENTRY FUNCTION ..................26
REMOTE KEYLESS ENTRY FUNCTION : Sys-
tem Diagram ........................................................ ....
27
REMOTE KEYLESS ENTRY FUNCTION : Sys-
tem Description .................................................... ....
27
KEY REMINDER FUNCTION ................................ ....29
KEY REMINDER FUNCTION : System Diagram ....29
KEY REMINDER FUNCTION : System Descrip-
tion ....................................................................... ....
29
REMOTE ENGINE START FUNCTION ................. ....30
REMOTE ENGINE START FUNCTION : System
Diagram ............................................................... ....
30
REMOTE ENGINE START FUNCTION : System
Description ........................................................... ....
30
WELCOME LIGHT FUNCTION ............................. ....32
WELCOME LIGHT FUNCTION : System Diagram
....
32
WELCOME LIGHT FUNCTION : System Descrip-
tion ....................................................................... ....
32
WARNING FUNCTION .......................................... ....33
WARNING FUNCTION : System Description ..........33
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 770 of 4801
DLK-2
TRUNK LID OPENER SYSTEM ............................ ...36
TRUNK LID OPENER SYSTEM : System Dia-
gram .................................................................... ...
37
TRUNK LID OPENER SYSTEM : System De-
scription ............................................................... ...
37
SYSTEM (INTEGRATED HOMELINK
TRANSMITTER) ............................................. ...
40
System Description .............................................. ...40
SYSTEM (TRUNK LID OPENER SYSTEM) ......41
System Diagram .................................................. ...41
System Description .................................................41
DIAGNOSIS SYSTEM (BCM) ............................42
COMMON ITEM ..................................................... ...42
COMMON ITEM : CONSULT Function (BCM -
COMMON ITEM) ................................................. ...
42
DOOR LOCK .......................................................... ...43
DOOR LOCK : CONSULT Function (BCM -
DOOR LOCK) ...................................................... ...
43
INTELLIGENT KEY ................................................ ...44
INTELLIGENT KEY : CONSULT Function (BCM -
INTELLIGENT KEY) ........ .......................................
44
TRUNK ................................................................... ...47
TRUNK : CONSULT Function (BCM - TRUNK) .....47
ECU DIAGNOSIS INFORMATION ..............48
ECM, IPDM E/R, BCM .................................... ...48
List of ECU Reference ......................................... ...48
WIRING DIAGRAM .....................................49
HOMELINK UNIVERSAL TRANSCEIVER ..... ...49
Wiring Diagram .................................................... ...49
POWER DOOR LOCK SYSTEM .......................51
Wiring Diagram .................................................... ...51
INTELLIGENT KEY SYSTEM ............................61
Wiring Diagram .................................................... ...61
TRUNK LID OPENER ........................................77
Wiring Diagram .................................................... ...77
BASIC INSPECTION ...................................81
DIAGNOSIS AND REPAIR WORKFLOW ...... ...81
Work Flow ............................................................ ...81
INSPECTION AND ADJUSTMENT ...................84
ADDITIONAL SERVICE WHEN REPLACING
CONTROL UNIT ..................................................... ...
84
ADDITIONAL SERVICE WHEN REPLACING
CONTROL UNIT : Description ............................. ...
84
ADDITIONAL SERVICE WHEN REPLACING
CONTROL UNIT : Special Repair Requirement .....
84
DTC/CIRCUIT DIAGNOSIS ........................85
U1000 CAN COMM CIRCUIT ......................... ...85
Description ........................................................... ...85
DTC Logic ...............................................................85
Diagnosis Procedure ...............................................85
U1010 CONTROL UNIT (CAN) .........................86
DTC Logic ............................................................ ...86
Diagnosis Procedure ...............................................86
Special Repair Requirement ...................................86
B261B REMOTE ENGINE START ....................87
DTC Logic ............................................................ ...87
Diagnosis Procedure ...............................................87
B2621 INSIDE ANTENNA .............................. ...88
DTC Logic ............................................................ ...88
Diagnosis Procedure ...............................................88
B2622 INSIDE ANTENNA .............................. ...90
DTC Logic ............................................................ ...90
Diagnosis Procedure ...............................................90
B26FD SHIFT LOCK SOLENOID .....................92
DTC Logic ............................................................ ...92
Diagnosis Procedure ...............................................92
B26FE HOOD SWITCH .....................................95
DTC Logic ............................................................ ...95
Diagnosis Procedure ..............................................95
Component Inspection ............................................96
B26FF REMOTE KEYLESS ENTRY RECEIV-
ER ................................................................... ...
97
DTC Logic ............................................................ ...97
Diagnosis Procedure ...............................................97
POWER SUPPLY AND GROUND CIRCUIT .....99
Diagnosis Procedure ............................................ ...99
DOOR SWITCH ................................................100
Description ........................................................... .100
Component Function Check ................................100
Diagnosis Procedure .............................................100
Component Inspection ..........................................102
DOOR LOCK AND UNLOCK SWITCH ............103
DRIVER SIDE ......................................................... .103
DRIVER SIDE : Description ..................................103
DRIVER SIDE : Component Function Check ......103
DRIVER SIDE : Diagnosis Procedure (With LH
and RH Anti-Pinch) .............................................. .
103
DRIVER SIDE : Diagnosis Procedure (With LH
Anti-Pinch Only) ................................................... .
104
PASSENGER SIDE .................................................105
PASSENGER SIDE : Descripti on .........................105
PASSENGER SIDE :
Component Function Check ............................... .
106
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 771 of 4801
DLK-3
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
PASSENGER SIDE : Diagnosis Procedure (With
LH and RH Anti-Pinch) ........................................ ..
106
PASSENGER SIDE : Diagnosis Procedure (With
LH Anti-Pinch Only) ............................................. ..
107
OUTSIDE KEY ANTENNA (PASSENGER
SIDE) .............................................................. ..
109
Component Function Check ................................ ..109
Diagnosis Procedure .............................................109
OUTSIDE KEY ANTENNA (DRIVER SIDE) .....111
Component Function Check ................................ ..111
Diagnosis Procedure .............................................111
OUTSIDE KEY ANTENNA (REAR BUMPER) ..113
Component Function Check ................................ ..113
Diagnosis Procedure .............................................113
KEY CYLINDER SWITCH ................................115
Description .......................................................... ..115
Component Function Check ..................................115
Diagnosis Procedure (With LH and RH Anti-Pinch)
..
115
Diagnosis Procedure (With LH Anti-Pinch Only) ...116
Component Inspection ..........................................117
UNLOCK SENSOR ..........................................119
Description .......................................................... ..119
Component Function Check ................................119
Diagnosis Procedure .............................................119
Component Inspection ..........................................120
TRUNK LID OPENER SWITCH .......................122
Description .......................................................... ..122
Component Function Check ................................122
Diagnosis Procedure .............................................122
Component Inspection ..........................................123
TRUNK LID OPENER CANCEL SWITCH .......124
Description .......................................................... ..124
Component Function Check ................................124
Diagnosis Procedure .............................................124
Component Inspection ..........................................125
TRUNK LAMP SWITCH ...................................126
Description .......................................................... ..126
Component Function Check ................................126
Diagnosis Procedure .............................................126
Component Inspection ..........................................127
DOOR REQUEST SWITCH ..............................129
Description .......................................................... ..129
Component Function Check ................................129
Diagnosis Procedure .............................................129
Component Inspection ..........................................131
TRUNK OPENER REQUEST SWITCH ............132
Description .......................................................... ..132
Component Function Check ................................132
Diagnosis Procedure .............................................132
Component Inspection ..........................................133
DOOR LOCK ACTUATOR ..............................135
DRIVER SIDE ......................................................... ..135
DRIVER SIDE : Description ...................................135
DRIVER SIDE : Component Function Check ......135
DRIVER SIDE : Diagnosis Procedure ...................135
PASSENGER SIDE ..................................................136
PASSENGER SIDE : Descript ion ..........................136
PASSENGER SIDE :
Component Function Check .............................. ..
136
PASSENGER SIDE : Diagnosis Procedure ..........136
REAR LH ................................................................ ..137
REAR LH : Description ..........................................137
REAR LH : Component Function Check ..............137
REAR LH : Diagnosis Procedure ...........................137
REAR RH ............................................................... ..138
REAR RH : Description .........................................138
REAR RH : Component Function Check .............138
REAR RH : Diagnosis Procedure ..........................138
TRUNK LID OPENER ACTUATOR ................140
Description .............................................................140
Component Function Check ................................140
Diagnosis Procedure .............................................140
INTELLIGENT KEY WARNING BUZZER .......142
Description .............................................................142
Component Function Check ................................142
Diagnosis Procedure .............................................142
Component Inspection ...........................................143
REMOTE KEYLESS ENTRY RECEIVER .......144
Description .............................................................144
Component Function Check ................................144
Diagnosis Procedure .............................................144
INTELLIGENT KEY BATTERY AND FUNC-
TION ................................................................
146
Description ........................................................... ..146
Component Function Check ................................146
Diagnosis Procedure .............................................146
WARNING CHIME FUNCTION .......................148
Description .............................................................148
Component Function Check ................................148
Diagnosis Procedure .............................................148
HAZARD FUNCTION ......................................149
Description .............................................................149
Component Function Check ................................149
Diagnosis Procedure .............................................149
HOMELINK UNIVERSAL TRANSCEIVER .....150
Description .............................................................150
Component Function Check ................................150
Diagnosis Procedure .............................................150
SYMPTOM DIAGNOSIS ............................152
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
Page 773 of 4801
DLK-5
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
REAR DOOR LOCK ..............................................
..
204
REAR DOOR LOCK : Exploded View ...................204
REAR DOOR LOCK : Removal and Installation ...205
TRUNK LID ..................................................... ..206
TRUNK LID ASSEMBLY ...... ...................................206
TRUNK LID ASSEMBLY : Exploded View .......... ..206
TRUNK LID ASSEMBLY : Removal and Installa-
tion ...................................................................... ..
206
TRUNK LID ASSEMBLY : Adjustment ................ ..208
TRUNK LID HINGE ............................................... ..209
TRUNK LID HINGE : Removal and Installation ....209
TORSION BAR ...................................................... ..210
TORSION BAR : Removal and Installation ...........210
TRUNK LAMP SWITCH AND TRUNK RELEASE
SOLENOID ............................................................ ..
210
TRUNK LAMP SWITCH AND TRUNK RELEASE
SOLENOID : Removal and Installation .................
210
EMERGENCY LEVER ........................................... ..211
EMERGENCY LEVER : Removal and Installation ..211
TRUNK LID STRIKER ........................................... ..211
TRUNK LID STRIKER : Removal and Installation ..211
FUEL FILLER LID OPENER ............................213
Exploded View .................................................... ..213
FUEL FILLER LID ................................................. ..213
FUEL FILLER LID : Removal and Installation .......213
FUEL FILLER OPENER CABLE ........................... ..214
FUEL FILLER OPENER CABLE : Removal and
Installation ........................................................... ..
214
FUEL FILLER LID LOCK ...................................... ..215
FUEL FILLER LID LOCK : Removal and Installa-
tion ...................................................................... ..
215
KEY CYLINDER ...............................................217
GLOVE BOX LID KEY CYLINDER ....................... ..217
GLOVE BOX LID KEY CYLINDER : Removal and
Installation ........................................................... ..
217
SEATBACK LOCK KEY CYLINDER .................... ..218
SEATBACK LOCK KEY CYLINDER : Removal
and Installation .................................................... ..
218
DOOR SWITCH ................................................219
Removal and Installation .......................................219
INSIDE KEY ANTENNA ..................................220
CONSOLE .............................................................. ..220
CONSOLE : Removal and Installation ...................220
LUGGAGE ROOM ................................................. ..220
LUGGAGE ROOM : Removal and Installation ......220
OUTSIDE KEY ANTENNA ..............................221
DRIVER SIDE ......................................................... ..221
DRIVER SIDE : Removal and Installation .............221
PASSENGER SIDE ..................................................221
PASSENGER SIDE : Removal and Installation .. ..221
REAR BUMPER ..................................................... ..221
REAR BUMPER : Removal and Installation ..........221
DOOR REQUEST SWITCH ............................222
DRIVER SIDE ......................................................... ..222
DRIVER SIDE : Removal and Installation .............222
PASSENGER SIDE ..................................................222
PASSENGER SIDE : Removal and Installation .. ..222
INTELLIGENT KEY WARNING BUZZER .......223
Removal and Installation .......................................223
REMOTE KEYLESS ENTRY RECEIVER .......224
Removal and Installation .......................................224
INTELLIGENT KEY BATTERY .......................225
Removal and Installation .......................................225
TRUNK LID OPENER CANCEL SWITCH ......226
Removal and Installation .......................................226
TRUNK LID OPENER SWITCH ......................227
Removal and Installation .......................................227
TRUNK OPENER REQUEST SWITCH ..........228
Removal and Installation .......................................228
UNIT DISASSEMBLY AND ASSEMBLY ..229
FRONT DOOR .................................................229
Exploded View ..................................................... ..229
Disassembly and Assembly ...................................229
REAR DOOR ...................................................231
Exploded View .......................................................231
Disassembly and Assembly ...................................231
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
