NISSAN TIIDA 2010 Service Repair Manual

INSTRUMENT PANEL ASSEMBLYIP-17
< ON-VEHICLE REPAIR >
C
DE
F
G H
J
K L
M A
B
IP
N
O P
5. Insert a remover into upper space of instrument mask. : Pawl
6. Disengage pawls, and then remove instrument side mask.
7. Insert a remover into space of instrument side finisher. : Metal clip
8. Disengage metal clips, and then remove instrument side fin- isher.
9. Insert suitable tool into the bottom gap of side ventilator assem- bly after removing the instrument side mask, push against A and
B as shown to disengage the pawls.
: Pawl
10. Lift the side ventilator up from the bottom, pull backward while disengaging the side ventilator assembly's upper pawls, and
then remove the side ventilator.
: Pawl
11. Remove screws, and disengage pawls.
12. Remove steering column cover upper.
PIIB2448E
PIIB2440E
WIIA1226E
PIIB3976E
Revision: January 20102010 Versa

IP-18
< ON-VEHICLE REPAIR >
INSTRUMENT PANEL ASSEMBLY
13. Remove screws from instrument upper panel right side.
14. Lift the instrument upper panel up, disengage metal clips.: Metal clip
: Clip
15. Pull backward and disengage clips.
16. Remove cluster lid A.
Installation
Installation is in the reverse order of removal.
CLUSTER LID C
Removal
1. Pull instrument finisher E backward by approximately 30 degrees while disengaging the metal clips and pawl.
: Metal clip
: Pawl
2. Remove screws.
3. Pull back, and disengage pawls and metal clips.
4. Disconnect harness connector, and then remove cluster lid C.
Installation
Installation is in the reverse order of removal.
COMBINATION METER
Removal
PIIB3969E
PIIB2880E
WIIA1224E
WIIA1225E
Revision: January 20102010 Versa

INSTRUMENT PANEL ASSEMBLYIP-19
< ON-VEHICLE REPAIR >
C
DE
F
G H
J
K L
M A
B
IP
N
O P
1. Pull instrument finisher E backward by approximately 30 degrees while disengaging the metal clips and pawl.
: Metal clip
: Pawl
2. Remove front pillar garnish. Refer to EI-39
.
3. Pull up instrument side panel and disengage pawls. : Pawl
4. Remove instrument side panel.
5. Insert a remover into upper space of instrument mask. : Pawl
6. Disengage pawls, and then remove instrument side mask.
7. Insert a remover into space of instrument side finisher. : Metal clip
: Pawl
8. Disengage metal clips, and then remove instrument side fin- isher.
WIIA1224E
PIIB2439J
PIIB2448E
PIIB2440E
Revision: January 20102010 Versa

IP-20
< ON-VEHICLE REPAIR >
INSTRUMENT PANEL ASSEMBLY
9. Insert suitable tool into the bottom gap of side ventilator assem-bly after removing the instrument side mask, push against A and
B as shown to disengage the pawls.
: Pawl
10. Lift the side ventilator up from the bottom, pull backward while disengaging the side ventilator assembly's upper pawls, and
then remove the side ventilator.
: Pawl
11. Remove screws, and disengage pawls.
12. Remove steering column cover upper.
13. Remove screws from instrument upper panel right side.
14. Lift the instrument upper panel up, disengage metal clips. : Metal clip
: Clip
15. Pull backward and disengage clips.
16. Remove cluster lid A.
WIIA1226E
PIIB3976E
PIIB3969E
PIIB2880E
Revision: January 20102010 Versa

INSTRUMENT PANEL ASSEMBLYIP-21
< ON-VEHICLE REPAIR >
C
DE
F
G H
J
K L
M A
B
IP
N
O P
17. Remove screws (A) and metal clip (B), and remove combination meter.
Installation
Installation is in the reverse order of removal.
GLOVE BOX ASSEMBLY
Removal
1. Remove glove box screws.
2. Pull backward while disengaging the glove box assembly pawls.
3. Remove glove box assembly.
Installation
Installation is in the reverse order of removal.
INSTRUMENT LOWER FINISHER
Removal
1. Pull backward while disengage the instrument lower finisher'sclip and pawls.
: Metal clip
2. Disconnect in-vehicle sensor and harness connector, and then remove instrument lower finisher.
Installation
Installation is in the reverse order of removal.
CENTER CONSOLE ASSEMBLY
Removal
PKIC0703E
PIIB3404E
LIIA2544E
Revision: January 20102010 Versa

IP-22
< ON-VEHICLE REPAIR >
INSTRUMENT PANEL ASSEMBLY
1. Insert a suitable tool into front side space of console mask, anddisengage metal clips.
: Metal clip
2. Disconnect harness connector, and then remove console mask.
3. Place the shift lever in "D" position (A/T and CVT only). : Metal clip
4. Remove shift lever handle (A/T and CVT only). Refer to CVT-
160, "Removal and Installation" (CVT), AT-213, "A/T Shift Selec-
tor Removal and Installation" (A/T).
5. Pull up and disengage A/T and CVT console finisher metal clips (A/T and CVT only).
6. Remove A/T and CVT console finisher (A/T and CVT only).
7. Remove shift lever handle (M/T only). Refer to MT-94
.
8. Pull up and disengage M/T console boot metal clips (M/T only).
9. Remove M/T console boot (M/T only).
10. Disengage console rear finisher metal clips and pawl. : Metal clip
: Pawl
11. Remove console rear finisher.
12. Disengage console mask cover metal clips and pawls, and then remove console mask cover (with armrest).
: Metal clip
: Pawl
PIIB6386E
PIIB2454J
PIIB2452J
PIIB6387E
Revision: January 20102010 Versa

INSTRUMENT PANEL ASSEMBLYIP-23
< ON-VEHICLE REPAIR >
C
DE
F
G H
J
K L
M A
B
IP
N
O P
13. Disengage rear cup holder metal clips and pawls (without arm- rest).
: Metal clip
: Pawl
14. Remover rear cup holder (without armrest).
15. Remove console body assembly screws and nut.
16. Disconnect harness connector, and then remove console body assembly.
17. Remove both of the instrument lower cover LH and RH clips. : Metal clip
18. Disengage instrument lower cover LH and RH metal clips and remove both of the instrument lower cover LH and RH.
19. Remove screws and then remove center console.
Installation
Installation is in the reverse order of removal.
Disassembly and AssemblyINFOID:0000000005396858
GLOVE BOX ASSEMBLY
PIIB6388E
PIIB2882J
Revision: January 20102010 Versa

IP-24
< ON-VEHICLE REPAIR >
INSTRUMENT PANEL ASSEMBLY
Disassembly
1. Remove screws of damper, and then remove damper.
2. Remove screws of glove box striker, and then remove glove box striker.
3. Remove screws of glove box latch, and then remove glove box latch.
Assembly
Assembly is in the reverse order of disassembly.
CENTER CONSOLE ASSEMBLY
1. Glove box striker2. Glove box 3. Glove box latch
4. Damper
LIIA2555E
Revision: January 20102010 Versa

INSTRUMENT PANEL ASSEMBLYIP-25
< ON-VEHICLE REPAIR >
C
DE
F
G H
J
K L
M A
B
IP
N
O P
Disassembly
Remove the four screws, and then remove
front cup holder from center console.
Assembly
Assembly is in the reverse order of disassembly.
COMBINATION METER
Disassembly
Disengage the eight tabs to separate front cover (1) from the unified
meter control unit assembly (2).
Assembly
Assembly is in the reverse order of disassembly.
1. Center console 2. Front cup holder
LIIA2556E
LIIA2582E
Revision: January 20102010 Versa

LAN-1
ELECTRICAL
C
DE
F
G H
I
J
L
M
SECTION LAN
A
B
LAN
N
O P
CONTENTS
LAN SYSTEM
CAN FUNDAMENTAL
SERVICE INFORMATION .. ..........................
6
PRECAUTIONS .............................................. .....6
Precautions for Trouble Diagnosis ...................... ......6
Precautions for Harness Repair ................................6
CAN COMMUNICATION SYSTEM ................ .....7
System Description ............................................. ......7
System Diagram ........................................................7
CAN Communication Control Circuit .........................8
DIAG ON CAN .....................................................9
Description .......................................................... ......9
System Diagram ........................................................9
TROUBLE DIAGNOSIS .....................................10
Condition of Error Detection ................................ ....10
Symptom When Error Occurs in CAN Communi-
cation System ...................................................... ....
10
CAN Diagnosis with CONSULT-III ..........................13
Self-Diagnosis .........................................................14
CAN Diagnostic Support Monitor ............................14
How to Use CAN Communication Signal Chart ......16
DIAGNOSIS AND REPAIR WORKFLOW .........17
Trouble Diagnosis Flow Chart ............................. ....17
Trouble Diagnosis Procedure ..................................17
CAN
SERVICE INFORMATION .. .........................
22
HOW TO USE THIS SECTION ....................... ....22
Caution ................................................................ ....22
Abbreviation List ......................................................22
PRECAUTIONS ..................................................23
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ....
23
Precautions for Trouble Diagnosis ..........................23
Precautions for Harness Repair .......................... ....23
DIAGNOSIS AND REPAIR WORKFLOW ........25
Interview Sheet ........................................................25
CAN COMMUNICATION SYSTEM ...................26
CAN System Specification Chart .............................26
CAN Communication Signal Chart ..........................27
CAN COMMUNICATION SYSTEM ...................29
Component Parts Location ......................................29
Schematic ................................................................30
Wiring Diagram - CAN - ...........................................31
MALFUNCTION AREA CHART ........................33
Main Line .................................................................33
Branch Line .............................................................33
Short Circuit .............................................................33
MAIN LINE BETWEEN DLC AND ABS CIR-
CUIT ..................................................................
34
Diagnosis Procedure ...............................................34
MAIN LINE BETWEEN DLC AND TCM CIR-
CUIT ..................................................................
35
Diagnosis Procedure ...............................................35
ECM BRANCH LINE CIRCUIT .........................36
Diagnosis Procedure ...............................................36
BCM BRANCH LINE CIRCUIT .........................37
Diagnosis Procedure ...............................................37
DLC BRANCH LINE CIRCUIT ..........................38
Diagnosis Procedure ...............................................38
EPS BRANCH LINE CIRCUIT ..........................39
Diagnosis Procedure ...............................................39
I-KEY BRANCH LINE CIRCUIT ........................40
Diagnosis Procedure ...............................................40
M&A BRANCH LINE CIRCUIT .........................41
