INDEX FOR DTC
2007 Versa
Alphabetical IndexUBS00QB2
NOTE:

If DTC U1000 or U1001 is displayed with other DTC, first perform the trouble diagnosis for DTC
U1000, U1001. Refer to EC-151, "
DTC U1000, U1001 CAN COMMUNICATION LINE" .

If DTC U1010 is displayed with other DTC, first perform the trouble diagnosis for DTC U1010.
Refer to EC-154, "
DTC U1010 CAN COMMUNICATION" .
Items
(CONSULT-II screen terms)DTC*1
Reference page
CONSULT-II
GST*
2ECM*3
A/F SENSOR1 (B1) P0130 0130EC-220
A/F SENSOR1 (B1) P0131 0131EC-227
A/F SENSOR1 (B1) P0132 0132EC-233
A/F SENSOR1 (B1) P0133 0133EC-239
A/F SENSOR1 (B1) P2A00 2A00EC-540
A/F SEN1 HTR (B1) P0031 0031EC-161
A/F SEN1 HTR (B1) P0032 0032EC-161
A/T 1ST GR FNCTN P0731 0731AT- 11 7
A/T 2ND GR FNCTN P0732 0732AT-121
A/T 3RD GR FNCTN P0733 0733AT-124
A/T 4TH GR FNCTN P0734 0734AT-128
A/T TCC S/V FNCTN P0744 0744AT-139 (A/T),
CVT-110
(CVT)
APP SEN 1/CIRC P2122 2122EC-513
APP SEN 1/CIRC P2123 2123EC-513
APP SEN 2/CIRC P2127 2127EC-519
APP SEN 2/CIRC P2128 2128EC-519
APP SENSOR P2138 2138EC-532
ASCD BRAKE SW P1572 1572EC-473
ASCD SW P1564 1564EC-466
ASCD VHL SPD SEN P1574 1574EC-483
ATF TEMP SEN/CIRC P0710 0710AT-102 (A/T),
CVT-85
(CVT)
BRAKE SW/CIRCUIT P1805 1805EC-488
CAN COMM CIRCUIT U1000
1000*4EC-151
CAN COMM CIRCUIT U1001
1001*4EC-151
CKP SEN/CIRCUIT P0335 0335EC-319
CLOSED LOOP-B1 P1148 1148EC-442
CMP SEN/CIRC-B1 P0340 0340EC-327
COLD START CONTROL P1421 1421EC-464
CONTROL UNIT(CAN) U1010 1010EC-154
CTP LEARNING P1225 1225EC-460
CTP LEARNING P1226 1226EC-462
CYL 1 MISFIRE P0301 0301EC-308
CYL 2 MISFIRE P0302 0302EC-308
CYL 3 MISFIRE P0303 0303EC-308
CYL 4 MISFIRE P0304 0304EC-308

INDEX FOR DTC
EC-13
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 VersaECM P0605 0605EC-427
ECT SEN/CIRC P0117 0117EC-200
ECT SEN/CIRC P0118 0118EC-200
ECT SENSOR P0125 0125 EC-212
ENG OVER TEMP P1217 1217EC-443
ENGINE SPEED SIG P0725 0725AT - 11 3
ETC ACTR P2119 2119EC-511
ETC FUNCTION/CIRC P2101 2101EC-499
ETC MOT P2118 2118EC-506
ETC MOT PWR P2100 2100EC-493
ETC MOT PWR P2103 2103EC-493
EVAP GROSS LEAK P0455 0455EC-398
EVAP PURG FLOW/MON P0441 0441EC-340
EVAP SMALL LEAK P0442 0442EC-346
EVAP SYS PRES SEN P0451 0451EC-382
EVAP SYS PRES SEN P0452 0452EC-385
EVAP SYS PRES SEN P0453 0453EC-391
EVAP VERY SML LEAK P0456 0456EC-406
FTT SEN/CIRCUIT P0182 0182EC-297
FTT SEN/CIRCUIT P0183 0183EC-297
FTT SENSOR P0181 0181EC-291
FUEL LEV SEN SLOSH P0460 0460EC-415
FUEL LEVEL SENSOR P0461 0461EC-417
FUEL LEVL SEN/CIRC P0462 0462EC-419
FUEL LEVL SEN/CIRC P0463 0463EC-419
FUEL SYS-LEAN-B1 P0171 0171EC-276
FUEL SYS-RICH-B1 P0172 0172EC-284
HO2S2 (B1) P0137 0137EC-248
HO2S2 (B1) P0138 0138EC-257
HO2S2 (B1) P0139 0139EC-267
HO2S2 HTR (B1) P0037 0037EC-166
HO2S2 HTR (B1) P0038 0038EC-166
IAT SEN/CIRCUIT P0112 0112EC-195
IAT SEN/CIRCUIT P0113 0113EC-195
IAT SENSOR P0127 0127EC-215
INPUT SPD SEN/CIRC P0715 0715EC-486
IN PULY SPEED P1715 1715EC-485 (A/T),
EC-486
(CVT)
INT/V TIM CONT-B1 P0011 0011EC-156
INT/V TIM V/CIR-B1 P0075 0075EC-173
ISC SYSTEM P0506 0506EC-423
ISC SYSTEM P0507 0507EC-425
KNOCK SEN/CIRC-B1 P0327 0327EC-315
Items
(CONSULT-II screen terms)DTC*1
Reference page
CONSULT-II
GST*
2ECM*3

EC-14Revision: June 2006
INDEX FOR DTC
2007 Versa
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by SAE J2012.KNOCK SEN/CIRC-B1 P0328 0328EC-315
LU-SLCT SOL/CIRC P1740 1740CVT-158
L/PRESS SOL/CIRC P0745 0745AT-145
MAF SEN/CIRCUIT P0101 0101EC-178
MAF SEN/CIRCUIT P0102 0102EC-187
MAF SEN/CIRCUIT P0103 0103EC-187
MULTI CYL MISFIRE P0300 0300EC-308
NATS MALFUNCTION P1610 - P1615 1610 - 1615BL-212
NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED.P0000 0000 —
O/R CLTCH SOL/CIRC P1760 1760AT-161
P-N POS SW/CIRCUIT P0850 0850EC-436
PNP SW/CIRC P0705 0705AT- 9 7 (A/T),
CVT-78
(CVT)
PRS CNT SOL/A FCTN P0746 0746CVT-118
PRS CNT SOL/B CIRC P0778 0778CVT-124
PRS CNT SOL/B FCTN P0776 0776CVT-121
PURG VOLUME CONT/V P0443 0443EC-354
PURG VOLUME CONT/V P0444 0444EC-362
PURG VOLUME CONT/V P0445 0445EC-362
SENSOR POWER/CIRC P0643 0643EC-430
SFT SOL A/CIRC P0750 0750 AT-151
SFT SOL B/CIRC P0755 0755AT-156
STEP MOTR CIRC P1777 1777CVT-164
STEP MOTR FNC P1778 1778CVT-168
TCC SOLENOID/CIRC P0740 0740AT-134
THERMSTAT FNCTN P0128 0128EC-218
TP SEN 1/CIRC P0222 0222EC-302
TP SEN 1/CIRC P0223 0223EC-302
TP SEN 2/CIRC P0122 0122EC-206
TP SEN 2/CIRC P0123 0123EC-206
TP SENSOR P2135 2135EC-526
TP SEN/CIRC A/T P1705 1705CVT-150
TR PRS SENS/A CIRC P0840 0840CVT-129
TR PRS SENS/B CIRC P0845 0845CVT-137
TW CATALYST SYS-B1 P0420 0420EC-334
VEH SPD SEN/CIR AT*5P0720 0720AT-107 (A/T).
CVT-95
(CVT)
VEH SPEED SEN/CIRC*
5P0500 0500EC-421
VENT CONTROL VALVE P0447 0447EC-369
VENT CONTROL VALVE P0448 0448EC-376
Items
(CONSULT-II screen terms)DTC*1
Reference page
CONSULT-II
GST*
2ECM*3

INDEX FOR DTC
EC-15
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 Versa
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
*4: The troubleshooting for this DTC needs CONSULT-II.
*5: When the fail-safe operations for both self-diagnoses occur, the MIL illuminates.

EC-16Revision: June 2006
PRECAUTIONS
2007 Versa
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
UBS00QB3
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WAR NIN G:

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.

Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.

Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for Procedures without Cowl Top CoverUBS00RCH
When performing the procedure after removing cowl top cover, cover
the lower end of windshield with urethane, etc.
On Board Diagnostic (OBD) System of Engine and A/T, CVTUBS00QB4
The ECM has an on board diagnostic system. It will light up the malfunction indicator lamp (MIL) to warn the
driver of a malfunction causing emission deterioration.
CAUTION:

Be sure to turn the ignition switch OFF and disconnect the battery ground cable before any repair
or inspection work. The open/short circuit of related switches, sensors, solenoid valves, etc. will
cause the MIL to light up.

Be sure to connect and lock the connectors securely after work. A loose (unlocked) connector will
cause the MIL to light up due to the open circuit. (Be sure the connector is free from water, grease,
dirt, bent terminals, etc.)

Certain systems and components, especially those related to OBD, may use a new style slide-
locking type harness connector. For description and how to disconnect, refer to PG-68, "
HAR-
NESS CONNECTOR" .

Be sure to route and secure the harnesses properly after work. The interference of the harness
with a bracket, etc. may cause the MIL to light up due to the short circuit.

Be sure to connect rubber tubes properly after work. A misconnected or disconnected rubber tube
may cause the MIL to light up due to the malfunction of the fuel injection system, etc.

Be sure to erase the unnecessary malfunction information (repairs completed) from the ECM and
TCM (Transmission control module) before returning the vehicle to the customer.
PIIB3706J

PRECAUTIONS
EC-17
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 Versa
PrecautionUBS00QB5

Always use a 12 volt battery as power source.

Do not attempt to disconnect battery cables while engine is
running.

Before connecting or disconnecting the ECM harness con-
nector, turn ignition switch OFF and disconnect negative
battery cable. Failure to do so may damage the ECM
because battery voltage is applied to ECM even if ignition
switch is turned OFF.

Before removing parts, turn ignition switch OFF and then
disconnect negative battery cable.

Do not disassemble ECM.

If battery cable is disconnected, the memory will return to
the initial ECM values.
The ECM will now start to self-control at its initial values.
Engine operation can vary slightly when the cable is dis-
connected. However, this is not an indication of a malfunc-
tion. Do not replace parts because of a slight variation.

If the battery is disconnected, the following emission-
related diagnostic information will be lost within 24 hours.
–Diagnostic trouble codes
–1st trip diagnostic trouble codes
–Freeze frame data
–1st trip freeze frame data
–System readiness test (SRT) codes
–Test values

When connecting ECM harness connector, fasten (B) it
securely with a lever (1) as far as it will go as shown in the
figure.
–ECM (2)
–Loosen (A)

When connecting or disconnecting pin connectors into or
from ECM, take care not to damage pin terminals (bend or
break).
Make sure that there are not any bends or breaks on ECM
pin terminal, when connecting pin connectors.

Securely connect ECM harness connectors.
A poor connection can cause an extremely high (surge)
voltage to develop in coil and condenser, thus resulting in
damage to ICs.

Keep engine control system harness at least 10 cm (4 in)
away from adjacent harness, to prevent engine control sys-
tem malfunctions due to receiving external noise, degraded
operation of ICs, etc.

Keep engine control system parts and harness dry.
SEF 2 89 H
PBIA9222J
PBIB2947E
PBIB0090E

EC-18Revision: June 2006
PRECAUTIONS
2007 Versa

Before replacing ECM, perform “ECM Terminals and Refer-
ence Value” inspection and make sure ECM functions prop-
erly. Refer to EC-105, "
ECM Terminals and Reference Value"
.

Handle mass air flow sensor carefully to avoid damage.

Do not disassemble mass air flow sensor.

Do not clean mass air flow sensor with any type of deter-
gent.

Do not disassemble electric throttle control actuator.

Even a slight leak in the air intake system can cause seri-
ous incidents.

Do not shock or jar the camshaft position sensor (PHASE), crankshaft position sensor (POS).

After performing each TROUBLE DIAGNOSIS, perform DTC
Confirmation Procedure or Overall Function Check.
The DTC should not be displayed in the DTC Confirmation
Procedure if the repair is completed. The Overall Function
Check should be a good result if the repair is completed.

When measuring ECM signals with a circuit tester, never
allow the two tester probes to contact.
Accidental contact of probes will cause a short circuit and
damage the ECM power transistor.

Do not use ECM ground terminals when measuring input/
output voltage. Doing so may result in damage to the ECM's
transistor. Use a ground other than ECM terminals, such as
the ground.
MEF040D
SEF 2 17 U
SEF 3 48 N

PRECAUTIONS
EC-19
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 Versa

Do not operate fuel pump when there is no fuel in lines.

Tighten fuel hose clamps to the specified torque.
–Fuel level sensor unit and fuel pump (1)
–Fuel pressure regulator (2)
–Fuel level sensor (3)
–Fuel tank temperature sensor (4)

Do not depress accelerator pedal when starting.

Immediately after starting, do not rev up engine unneces-
sarily.

Do not rev up engine just prior to shutdown.

When installing C.B. ham radio or a mobile phone, be sure
to observe the following as it may adversely affect elec-
tronic control systems depending on installation location.
–Keep the antenna as far as possible from the electronic
control units.
–Keep the antenna feeder line more than 20 cm (8 in) away
from the harness of electronic controls.
Do not let them run parallel for a long distance.
–Adjust the antenna and feeder line so that the standing-
wave radio can be kept smaller.
–Be sure to ground the radio to vehicle body.
BBIA0704E
SEF 7 09 Y
SEF 7 08 Y

EC-20Revision: June 2006
PREPARATION
2007 Versa
PREPARATIONPFP:00002
Special Service ToolsUBS00PJP
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
(Kent-Moore No.)
Tool nameDescription
KV10117100
(J-36471-A)
Heated oxygen sensor
wrenchLoosening or tightening heated oxygen sensor
with 22 mm (0.87 in) hexagon nut
KV10114400
(J-38365)
Heated oxygen sensor
wrenchLoosening or tightening heated oxygen sensor
a: 22 mm (0.87 in)
(J-44321)
Fuel pressure gauge
KitChecking fuel pressure
(J-44321-6)
Fuel pressure adapterConnecting fuel pressure gauge to quick connec-
tor type fuel lines.
EG17550000
Break-out boxMeasuring ECM signals with a circuit tester
EG17680000
Y-cable adapterMeasuring ECM signals with a circuit tester
KV10118400
Fuel tube adapterMeasuring fuel pressure
S-NT379
S-NT636
LEC642
LBIA0376E
ZZA1194D
PBIA9379J
PBIB3043E

PREPARATION
EC-21
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 Versa
Commercial Service ToolsUBS00PJQ
Tool number
(Kent-Moore No.)
Tool nameDescription
Leak detector
i.e.: (J-41416)Locating the EVAP leak
EVAP service port
adapter
i.e.: (J-41413-OBD)Applying positive pressure through EVAP service
port
Fuel filler cap adapter
i.e.: (MLR-8382)Checking fuel tank vacuum relief valve opening
pressure
Socket wrench Removing and installing engine coolant tempera-
ture sensor
Oxygen sensor thread
cleaner
i.e.: (J-43897-18)
(J-43897-12)Reconditioning the exhaust system threads before
installing a new oxygen sensor. Use with anti-
seize lubricant shown below.
a: 18 mm diameter with pitch 1.5 mm for Zirco-
nia Oxygen Sensor
b: 12 mm diameter with pitch 1.25 mm for Tita-
nia Oxygen Sensor
Anti-seize lubricant
i.e.: (Permatex
TM
133AR or equivalent
meeting MIL specifica-
tion MIL-A-907)Lubricating oxygen sensor thread cleaning tool
when reconditioning exhaust system threads.
S-NT703
S-NT704
S-NT815
S-NT705
AEM488
S-NT779
