EC-42Revision: June 2006
ON BOARD REFUELING VAPOR RECOVERY (ORVR)
2007 Versa
Component InspectionUBS00QBE
REFUELING EVAP VAPOR CUT VALVE
With CONSULT-II
1. Remove fuel tank. Refer to FL-9, "FUEL TANK" .
2. Drain fuel from the tank as follows:
a. Remove fuel feed hose located on the fuel gauge retainer.
b. Connect a spare fuel hose, one side to fuel gauge retainer where the hose was removed and the other
side to a fuel container.
c. Drain fuel using “FUEL PUMP RELAY” in “ACTIVE TEST” mode with CONSULT-II.
3. Check refueling EVAP vapor cut valve for being stuck to close as follows.
Blow air into the refueling EVAP vapor cut valve (from the end of EVAP/ORVR line hose), and check that
the air flows freely into the tank.
4. Check refueling EVAP vapor cut valve for being stuck to open as follows.
a. Connect vacuum pump to hose end.
b. Remove fuel gauge retainer with fuel gauge unit.
Always replace O-ring with new one.
c. Put fuel tank upside down.
d. Apply vacuum pressure to hose end [−13.3 kPa (−100 mmHg, −3.94 inHg)] with fuel gauge retainer
remaining open and check that the pressure is applicable.
1. Filler tube 2. Recirculation line 3. EVAP/ORVR line
4. Vacuum/pressure handy pump 5. Fuel tank
BBIA0694E

ON BOARD REFUELING VAPOR RECOVERY (ORVR)
EC-43
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 Versa
Without CONSULT-II
1. Remove fuel tank. Refer to FL-9, "FUEL TANK" .
2. Drain fuel from the tank as follows:
a. Remove fuel gauge retainer.
b. Drain fuel from the tank using a handy pump into a fuel container.
3. Check refueling EVAP vapor cut valve for being stuck to close as follows.
Blow air into the refueling EVAP vapor cut valve (from the end of EVAP/ORVR line hose), and check that
the air flows freely into the tank.
4. Check refueling EVAP vapor cut valve for being stuck to open as follows.
a. Connect vacuum pump to hose end.
b. Remove fuel gauge retainer with fuel gauge unit.
Always replace O-ring with new one.
c. Put fuel tank upside down.
d. Apply vacuum pressure to hose end [−13.3 kPa (−100 mmHg, −3.94 inHg)] with fuel gauge retainer
remaining open and check that the pressure is applicable.
1. Filler tube 2. Recirculation line 3. EVAP/ORVR line
4. Vacuum/pressure handy pump 5. Fuel tank
BBIA0694E

EC-44Revision: June 2006
POSITIVE CRANKCASE VENTILATION
2007 Versa
POSITIVE CRANKCASE VENTILATIONPFP:11810
DescriptionUBS00PK1
SYSTEM DESCRIPTION
This system returns blow-by gas to the intake manifold.
The positive crankcase ventilation (PCV) valve is provided to conduct crankcase blow-by gas to the intake
manifold. During partial throttle operation of the engine, the intake manifold sucks the blow-by gas through the
PCV valve. Normally, the capacity of the valve is sufficient to handle any blow-by and a small amount of venti-
lating air. The ventilating air is then drawn from the air inlet tubes into the crankcase. In this process the air
passes through the hose connecting air inlet tubes to rocker cover.
Under full-throttle condition, the manifold vacuum is insufficient to draw the blow-by flow through the valve.
The flow goes through the hose connection in the reverse direction.
On vehicles with an excessively high blow-by, the valve does not
meet the requirement. This is because some of the flow will go
through the hose connection to the air inlet tubes under all condi-
tions.
Component InspectionUBS00PK2
PCV (POSITIVE CRANKCASE VENTILATION) VALVE
With engine running at idle, remove PCV valve from rocker cover. A
properly working valve makes a hissing noise as air passes through
it. A strong vacuum should be felt immediately when a finger is
placed over valve inlet.
PBIB2962E
PBIB1588E
PBIB1589E

POSITIVE CRANKCASE VENTILATION
EC-45
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 Versa
PCV VALVE VENTILATION HOSE
1. Check hoses and hose connections for leaks.
2. Disconnect all hoses and clean with compressed air. If any hose
cannot be freed of obstructions, replace.
S-ET 27 7

EC-46Revision: June 2006
NVIS (NISSAN VEHICLE IMMOBILIZER SYSTEM-NATS)
2007 Versa
NVIS (NISSAN VEHICLE IMMOBILIZER SYSTEM-NATS)PFP:25386
DescriptionUBS00RWM

If the security indicator lights up with the ignition switch in
the ON position or “NATS MALFUNCTION” is displayed on
“SELF-DIAG RESULTS” screen, perform self-diagnostic
results mode with CONSULT-II using NATS program card.
Refer to BL-212, "
NATS (Nissan Anti-Theft System)" .

Confirm no self-diagnostic results of NVIS (NATS) is dis-
played before touching “ERASE” in “SELF-DIAG RESULTS”
mode with CONSULT-II.

When replacing ECM, initialization of NVIS (NATS) system
and registration of all NVIS (NATS) ignition key IDs must be
carried out with CONSULT-II using NATS program card.
Therefore, be sure to receive all keys from vehicle owner.
Regarding the procedures of NVIS (NATS) initialization and all NVIS (NATS) ignition key ID regis-
tration, refer to CONSULT-II Operation Manual, IVIS/NVIS.
SEF 5 43 X

ON BOARD DIAGNOSTIC (OBD) SYSTEM
EC-47
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 Versa
ON BOARD DIAGNOSTIC (OBD) SYSTEMPFP:00028
IntroductionUBS00QBF
The ECM has an on board diagnostic system, which detects malfunctions related to engine sensors or actua-
tors. The ECM also records various emission-related diagnostic information including:
The above information can be checked using procedures listed in the table below.
×: Applicable —: Not applicable
*: When DTC and 1st trip DTC simultaneously appear on the display, they cannot be clearly distinguished from each other.
The malfunction indicator lamp (MIL) on the instrument panel lights up when the same malfunction is detected
in two consecutive trips (Two trip detection logic), or when the ECM enters fail-safe mode.
(Refer to EC-91, "
Fail-Safe Chart" .)
Two Trip Detection LogicUBS00QBG
When a malfunction is detected for the first time, 1st trip DTC and 1st trip Freeze Frame data are stored in the
ECM memory. The MIL will not light up at this stage. <1st trip>
If the same malfunction is detected again during the next drive, the DTC and Freeze Frame data are stored in
the ECM memory, and the MIL lights up. The MIL lights up at the same time when the DTC is stored. <2nd
trip> The “trip” in the “Two Trip Detection Logic” means a driving mode in which self-diagnosis is performed
during vehicle operation. Specific on board diagnostic items will cause the ECM to light up or blink the MIL,
and store DTC and Freeze Frame data, even in the 1st trip, as shown below.
×: Applicable —: Not applicable
When there is an open circuit on MIL circuit, the ECM cannot warn the driver by MIL lighting up when there is
malfunction on engine control system.
Emission-related diagnostic information Diagnostic service
Diagnostic Trouble Code (DTC) Service $03 of SAE J1979
Freeze Frame data Service $02 of SAE J1979
System Readiness Test (SRT) code Service $01 of SAE J1979
1st Trip Diagnostic Trouble Code (1st Trip DTC) Service $07 of SAE J1979
1st Trip Freeze Frame data
Test values and Test limits Service $06 of SAE J1979
Calibration ID Service $09 of SAE J1979
DTC 1st trip DTCFreeze Frame
data1st trip Freeze
Frame dataSRT code SRT status Test value
CONSULT-II××××××—
GST×× ×—×××
ECM××*———×—
ItemsMIL DTC 1st trip DTC
1st trip 2nd trip
1st trip
displaying2nd trip
displaying1st trip
displaying2nd trip
display-
ing BlinkingLighting
upBlinkingLighting
up
Misfire (Possible three way cata-
lyst damage) — DTC: P0300 -
P0304 is being detected×———— —×—
Misfire (Possible three way cata-
lyst damage) — DTC: P0300 -
P0304 is being detected——×——×——
One trip detection diagnoses
(Refer to EC-48, "
EMISSION-
RELATED DIAGNOSTIC INFOR-
MATION ITEMS" .)—×——×———
Except above — — —×—××—

EC-48Revision: June 2006
ON BOARD DIAGNOSTIC (OBD) SYSTEM
2007 Versa
Therefore, when electrical controlled throttle and part of ECM related diagnoses are continuously detected as
NG for 5 trips, ECM warns the driver that engine control system malfunctions and MIL circuit is open by means
of operating fail-safe function.
The fail-safe function also operates when above diagnoses except MIL circuit are detected, and demands the
driver to repair the malfunction.
Emission-related Diagnostic InformationUBS00QBH
EMISSION-RELATED DIAGNOSTIC INFORMATION ITEMS
×: Applicable —: Not applicable Engine operating condition in fail-safe mode Engine speed will not rise more than 2,500 rpm due to the fuel cut
Items
(CONSULT-II screen terms)DTC*
1
SRT codeTe s t v a l u e /
Test limit
(GST only)TripMIL light-
ing upReference
page CONSULT-II
GST*
2ECM*3
CAN COMM CIRCUIT U1000
1000*4——1 (CVT)
1 (A/T)
2 (M/T)× (CVT)
× (A/T)
— (M/T)EC-151
CAN COMM CIRCUIT U1001
1001*4——2—EC-151
CONTROL UNIT(CAN) U1010 1010 — —1 (CVT)
1 (A/T)
2 (M/T)× (CVT)
× (A/T)
— (M/T)EC-154
NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED.P0000 0000———
Flashing*5EC-62
INT/V TIM CONT-B1 P0011 0011 — — 2×EC-156
A/F SEN1 HTR (B1) P0031 0031 —×2×EC-161
A/F SEN1 HTR (B1) P0032 0032 —×2×EC-161
HO2S2 HTR (B1) P0037 0037 —×2×EC-166
HO2S2 HTR (B1) P0038 0038 —×2×EC-166
INT/V TIM V/CIR-B1 P0075 0075 — — 2×EC-173
MAF SEN/CIRCUIT P0101 0101 — — 2×EC-178
MAF SEN/CIRCUIT P0102 0102 — — 1×EC-187
MAF SEN/CIRCUIT P0103 0103 — — 1×EC-187
IAT SEN/CIRCUIT P0112 0112 — — 2×EC-195
IAT SEN/CIRCUIT P0113 0113 — — 2×EC-195
ECT SEN/CIRC P0117 0117 — — 1×EC-200
ECT SEN/CIRC P0118 0118 — — 1×EC-200
TP SEN 2/CIRC P0122 0122 — — 1×EC-206
TP SEN 2/CIRC P0123 0123 — — 1×EC-206
ECT SENSOR P0125 0125 — — 1×EC-212
IAT SENSOR P0127 0127 — — 2×EC-215
THERMSTAT FNCTN P0128 0128 — — 2×EC-218
A/F SENSOR1 (B1) P0130 0130 —×2×EC-220
A/F SENSOR1 (B1) P0131 0131 —×2×EC-227
A/F SENSOR1 (B1) P0132 0132 —×2×EC-233
A/F SENSOR1 (B1) P0133 0133××2×EC-239
HO2S2 (B1) P0137 0137××2×EC-248
HO2S2 (B1) P0138 0138××2×EC-257
HO2S2 (B1) P0139 0139××2×EC-267
FUEL SYS-LEAN-B1 P0171 0171 — — 2×EC-276
FUEL SYS-RICH-B1 P0172 0172 — — 2×EC-284

ON BOARD DIAGNOSTIC (OBD) SYSTEM
EC-49
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 VersaFTT SENSOR P0181 0181 — — 2×EC-291
FTT SEN/CIRCUIT P0182 0182 — — 2×EC-297
FTT SEN/CIRCUIT P0183 0183 — — 2×EC-297
TP SEN 1/CIRC P0222 0222 — — 1×EC-302
TP SEN 1/CIRC P0223 0223 — — 1×EC-302
MULTI CYL MISFIRE P0300 0300 — — 2×EC-308
CYL 1 MISFIRE P0301 0301 — — 2×EC-308
CYL 2 MISFIRE P0302 0302 — — 2×EC-308
CYL 3 MISFIRE P0303 0303 — — 2×EC-308
CYL 4 MISFIRE P0304 0304 — — 2×EC-308
KNOCK SEN/CIRC-B1 P0327 0327 — — 2 —EC-315
KNOCK SEN/CIRC-B1 P0328 0328 — — 2 —EC-315
CKP SEN/CIRCUIT P0335 0335 — — 2×EC-319
CMP SEN/CIRC-B1 P0340 0340 — — 2×EC-327
TW CATALYST SYS-B1 P0420 0420× ×2×EC-334
EVAP PURG FLOW/MON P0441 0441××2×EC-340
EVAP SMALL LEAK P0442 0442××2×EC-346
PURG VOLUME CONT/V P0443 0443 — — 2×EC-354
PURG VOLUME CONT/V P0444 0444 — — 2×EC-362
PURG VOLUME CONT/V P0445 0445 — — 2×EC-362
VENT CONTROL VALVE P0447 0447 — — 2×EC-369
VENT CONTROL VALVE P0448 0448 — — 2×EC-376
EVAP SYS PRES SEN P0451 0451 — — 2×EC-382
EVAP SYS PRES SEN P0452 0452 — — 2×EC-385
EVAP SYS PRES SEN P0453 0453 — — 2×EC-391
EVAP GROSS LEAK P0455 0455 — — 2×EC-398
EVAP VERY SML LEAK P0456 0456
×*6×2×EC-406
FUEL LEV SEN SLOSH P0460 0460 — — 2×EC-415
FUEL LEVEL SENSOR P0461 0461 — — 2×EC-417
FUEL LEVL SEN/CIRC P0462 0462 — — 2×EC-419
FUEL LEVL SEN/CIRC P0463 0463 — — 2×EC-419
VEH SPEED SEN/CIRC*7P0500 0500 — — 2×EC-421
ISC SYSTEM P0506 0506 — — 2×EC-423
ISC SYSTEM P0507 0507 — — 2×EC-425
ECM P0605 0605 — — 1 or 2 — or ×EC-427
SENSOR POWER/CIRC P0643 0643 — — 1×EC-430
PNP SW/CIRC P0705 0705 — — 2×AT - 9 7 (A/T),
CVT-78
(CVT)
ATF TEMP SEN/CIRC P0710 0710 — — 2×AT- 1 0 2
(A/T),
CVT-85
(CVT)
INPUT SPD SEN/CIRC P0715 0715 — — 2×CVT-90
VEH SPD SEN/CIR AT*7P0720 0720 — — 2×AT- 1 0 7 (A/T),
CVT-95
(CVT) Items
(CONSULT-II screen terms)DTC*
1
SRT codeTe s t v a l u e /
Te s t l i m i t
(GST only)TripMIL light-
ing upReference
page CONSULT-II
GST*
2ECM*3

EC-50Revision: June 2006
ON BOARD DIAGNOSTIC (OBD) SYSTEM
2007 Versa
ENGINE SPEED SIG P0725 0725 — — 2×AT- 11 3
A/T 1ST GR FNCTN P0731 0731 — — 2×AT- 11 7
A/T 2ND GR FNCTN P0732 0732 — — 2×AT- 1 2 1
A/T 3RD GR FNCTN P0733 0733 — — 2×AT- 1 2 4
A/T 4TH GR FNCTN P0734 0734 — — 2×AT- 1 2 8
TCC SOLENOID/CIRC P0740 0740 — — 2×AT- 1 3 4
A/T TCC S/V FNCTN P0744 0744 — — 2×AT- 1 3 9
(A/T),
CVT-110

(CVT)
L/PRESS SOL/CIRC P0745 0745 — — 2×AT- 1 4 5
PRS CNT SOL/A FCTN P0746 0746 — — 1×CVT-118
SFT SOL A/CIRC P0750 0750 — — 1×AT- 1 5 1
SFT SOL B/CIRC P0755 0755 — — 1×AT- 1 5 6
PRS CNT SOL/B FCTN P0776 0776 — — 2×CVT-121
PRS CNT SOL/B CIRC P0778 0778 — — 2×CVT-124
TR PRS SENS/A CIRC P0840 0840 — — 2×CVT-129
TR PRS SENS/B CIRC P0845 0845 — — 2×CVT-137
P-N POS SW/CIRCUIT P0850 0850 — — 2×EC-436
C L O S E D L O O P - B 1 P 11 4 8 11 4 8 — — 1×EC-442
ENG OVER TEMP P1217 1217 — — 1×EC-443
CTP LEARNING P1225 1225 — — 2 —EC-460
CTP LEARNING P1226 1226 — — 2 —EC-462
COLD START CONTROL P1421 1421 — — 2×EC-464
ASCD SW P1564 1564 — — 1 —EC-466
ASCD BRAKE SW P1572 1572 — — 1 —EC-473
ASCD VHL SPD SEN P1574 1574 — — 1 —EC-483
NATS MALFUNCTIONP1610 -
P16151610 - 1615 — — 2 —BL-212
TP SEN/CIRC A/T P1705 1705 — — 1×CVT-150
IN PULY SPEED P1715 1715 — — 2 —EC-485 (A/T),
EC-486
(CVT)
LU-SLCT SOL/CIRC P1740 1740 — — 2×CVT-158
O/R CLTCH SOL/CIRC P1760 1760 — — 2×AT- 1 6 1
STEP MOTR CIRC P1777 1777 — — 1×CVT-164
STEP MOTR FNC P1778 1778 — — 2×CVT-168
BRAKE SW/CIRCUIT P1805 1805 — — 2 —EC-488
ETC MOT PWR P2100 2100 — — 1×EC-493
ETC FUNCTION/CIRC P2101 2101 — — 1×EC-499
ETC MOT PWR P2103 2103 — — 1×EC-493
ETC MOT P2118 2118 — — 1×EC-506
ETC ACTR P2119 2119 — — 1×EC-511
APP SEN 1/CIRC P2122 2122 — — 1×EC-513
APP SEN 1/CIRC P2123 2123 — — 1×EC-513
APP SEN 2/CIRC P2127 2127 — — 1×EC-519
Items
(CONSULT-II screen terms)DTC*
1
SRT codeTe s t v a l u e /
Test limit
(GST only)TripMIL light-
ing upReference
page CONSULT-II
GST*
2ECM*3

ON BOARD DIAGNOSTIC (OBD) SYSTEM
EC-51
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 Versa
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by SAE J2012.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
*4: The troubleshooting for this DTC needs CONSULT-II.
*5: When the ECM in the mode of displaying SRT status, MIL may flash. For the details, refer to EC-56, "
How to Display SRT Status" .
*6: SRT code will not be set if the self-diagnostic result is NG.
*7: When the fail-safe operations for both self-diagnoses occur, the MIL illuminates.
DTC AND 1ST TRIP DTC
The 1st trip DTC (whose number is the same as the DTC number) is displayed for the latest self-diagnostic
result obtained. If the ECM memory was cleared previously, and the 1st trip DTC did not reoccur, the 1st trip
DTC will not be displayed.
If a malfunction is detected during the 1st trip, the 1st trip DTC is stored in the ECM memory. The MIL will not
light up (two trip detection logic). If the same malfunction is not detected in the 2nd trip (meeting the required
driving pattern), the 1st trip DTC is cleared from the ECM memory. If the same malfunction is detected in the
2nd trip, both the 1st trip DTC and DTC are stored in the ECM memory and the MIL lights up. In other words,
the DTC is stored in the ECM memory and the MIL lights up when the same malfunction occurs in two consec-
utive trips. If a 1st trip DTC is stored and a non-diagnostic operation is performed between the 1st and 2nd
trips, only the 1st trip DTC will continue to be stored. For malfunctions that blink or light up the MIL during the
1st trip, the DTC and 1st trip DTC are stored in the ECM memory.
Procedures for clearing the DTC and the 1st trip DTC from the ECM memory are described in EC-60, "
HOW
TO ERASE EMISSION-RELATED DIAGNOSTIC INFORMATION" .
For malfunctions in which 1st trip DTCs are displayed, refer to EC-48, "
EMISSION-RELATED DIAGNOSTIC
INFORMATION ITEMS" . These items are required by legal regulations to continuously monitor the system/
component. In addition, the items monitored non-continuously are also displayed on CONSULT-II.
1st trip DTC is specified in Service $07 of SAE J1979. 1st trip DTC detection occurs without lighting up the MIL
and therefore does not warn the driver of a malfunction. However, 1st trip DTC detection will not prevent the
vehicle from being tested, for example during Inspection/Maintenance (I/M) tests.
When a 1st trip DTC is detected, check, print out or write down and erase (1st trip) DTC and Freeze Frame
data as specified in Work Flow procedure Step 2, refer to EC-84, "
WORK FLOW" . Then perform DTC Confir-
mation Procedure or Overall Function Check to try to duplicate the malfunction. If the malfunction is dupli-
cated, the item requires repair.
How to Read DTC and 1st Trip DTC
DTC and 1st trip DTC can be read by the following methods.
WITH CONSULT-II
WITH GST
CONSULT-II or GST (Generic Scan Tool) Examples: P0340, P0850, P1148, etc.
These DTCs are prescribed by SAE J2012.
(CONSULT-II also displays the malfunctioning component or system.)
NO TOOLS
The number of blinks of the MIL in the Diagnostic Test Mode II (Self-Diagnostic Results) indicates the DTC.
Example: 0340, 0850, 1148, etc.
These DTCs are controlled by NISSAN.

1st trip DTC No. is the same as DTC No.

Output of a DTC indicates a malfunction. However, GST or the Diagnostic Test Mode II do not indi-
cate whether the malfunction is still occurring or has occurred in the past and has returned to nor-
mal. CONSULT-II can identify malfunction status as shown below. Therefore, using CONSULT-II (if
available) is recommended.
APP SEN 2/CIRC P2128 2128 — — 1×EC-519
TP SENSOR P2135 2135 — — 1×EC-526
APP SENSOR P2138 2138 — — 1×EC-532
A/F SENSOR1 (B1) P2A00 2A00 —×2×EC-540
Items
(CONSULT-II screen terms)DTC*
1
SRT codeTe s t v a l u e /
Te s t l i m i t
(GST only)TripMIL light-
ing upReference
page CONSULT-II
GST*
2ECM*3
