AV-54
TELEPHONE
Revision: June 20062007 Versa
Bluetooth Control Unit Harness Connector Terminal LayoutEKS00I9H
Terminals and Reference Value for Bluetooth Control UnitEKS00I9I
LKIA0753E
Te r m i n a l
(Wire color)
ItemSignal
input/
outputCondition
Reference value
(Approx.)Example of symptom
+–Ignition
switchOperation
1 (R) GroundBattery
powerInput – – Battery voltageSystem does not
work properly.
2 (L) Ground ACC power InputACC/
ON–Battery voltageSystem does not
work properly.
3 (LG) Ground IGN power InputON/
START–Battery voltageSystem does not
work properly.
4 (B) – Ground – – – – –
6 – Shield – – – – –
7 (R/W) 8 (R/L) Mic-in signal Input – – –Bluetooth Micro-
phone inoperative.
9 (LG) 10 (V) Audio out OutputACC/
ONBluetooth control
unit sends audio
signalAudio can not be
heard.
11(O) – Mute Output – – 5V Mute inoperative.
12 (W) GroundRemote
control
switch 1InputACC/
ONPress MODE
switch 0V
Steering wheel audio
control switches do
not function. Press SEEK UP
switch0.75V
Press VOL UP
switch2V
Except for above 5V
13 (L) GroundRemote
control
switch 2InputACC/
ONPress POWER
switch 0V
Steering wheel audio
control switches do
not function. Press SEEK
DOWN switch0.75V
Press VOL
DOWN switch2V
Except for above 5V
14 (B) –Remote
control
groundInput – – –Steering wheel audio
control switches do
not function.
SKIB3609E
Page 452 of 2896

TELEPHONE
AV-55
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: June 20062007 Versa
15 (G) GroundBluetooth
ON indica-
tor LEDOutput –Bluetooth control
unit initialized
and paired with
phoneBattery voltageBluetooth ON indica-
tor inoperative.
17 (GR) GroundAudio unit
switch 1OutputACC/
ONPress Phone/End
switch 0V
Steering wheel audio
controls do not func-
tion. Press SEEK UP
switch0.75V
Press VOL UP
switch2V
Except for above 5V
18 (P) GroundAudio unit
switch 2OutputACC/
ONPress Phone/
Send switch 0V
Steering wheel audio
controls do not func-
tion. Press SEEK
DOWN switch0.75V
Press VOL
DOWN switch2V
Except for above 5V
19 (B) GroundAudio unit
switch
groundOutput – – –Steering wheel audio
controls do not func-
tion.
20 (B) – Cont-1 – – – – –
21 (B) – Cont-2 – – – – –
23 (B) – Cont-4 – – – – –
28 (O) GroundVehicle
speed sig-
nal (8–
pulse)Input ONWhen vehicle
speed is approx.
40 km/h (25
MPH)Speed sensitive vol-
ume is inoperative.
29 (B) GroundBluetooth
Microphone
powerOutput – – 5VBluetooth Micro-
phone inoperative.
33 –Bluetooth
antenna sig-
nalInput – – – – Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference value
(Approx.)Example of symptom
+–Ignition
switchOperation
PKIC0643E
Page 453 of 2896

AV-56
TELEPHONE
Revision: June 20062007 Versa
Bluetooth Control Unit Self-Diagnosis FunctionEKS00I9J
The Bluetooth control unit has two diagnostic checks. The first diagnostic check is performed automatically
every ignition cycle during control unit initialization. The second diagnostic check is performed by the techni-
cian using the steering wheel audio control switches prior to trouble diagnosis.
BLUETOOTH CONTROL UNIT INITIALIZATION CHECKS
Internal control unit failure
Bluetooth antenna connection open or shorted
Steering wheel audio control switches (SEND/END) stuck closed
Vehicle speed pulse count
Bluetooth Microphone connection test (with playback to operator)
Bluetooth inquiry check
SELF-DIAGNOSIS MODE
1. Turn ignition switch to ACC or ON.
2. Wait for the Bluetooth system to complete initialization and the Bluetooth ON indicator to stop flashing.
This may take up to 10 seconds.
3. Press and hold the steering wheel audio control switch SEND
button for at least 5 seconds. The Bluetooth system will begin to
play a verbal prompt.
4. While the prompt is playing, momentarily press both the steering
wheel audio control switches SEND and END buttons simulta-
neously. The Bluetooth system will sound a 5 second beep.
5. While the beep is sounding, momentarily press both the steering
wheel audio control switches SEND and END buttons simulta-
neously again.
6. The Bluetooth system has now entered into the diagnostic
mode. Results of the diagnostic checks will be verbalized to the
technician and the Bluetooth ON indicator will flash. Refer to AV-
57, "Workflow" .
7. If there are no failure records to report, the speed pulse count
will be reported next.
8. After the speed pulse count is reported, an interactive Bluetooth microphone test will be performed. Fol-
low the voice prompt. If the Bluetooth microphone test fails refer to AV- 5 7 , "
Workflow" .
9. Self-diagnosis mode is complete when the voice prompt says "All diagnostic functions completed". A short
beep is heard.
WKIA5431E
WKIA5432E
Page 454 of 2896

TELEPHONE
AV-57
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: June 20062007 Versa
WorkflowEKS00I9K
Power Supply and Ground Circuit Check for Bluetooth Control UnitEKS00I9L
1. CHECK FUSES
Make sure the following fuses for the Bluetooth control unit are not blown.
OK or NG
OK >> GO TO 2.
NG >> If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse. Refer to PG-
4, "POWER SUPPLY ROUTING CIRCUIT" .
2. CHECK POWER SUPPLY CIRCUIT
1. Disconnect Bluetooth control unit connector B121.
2. Check voltage between connector terminals and ground as fol-
lows.
OK or NG
OK >> GO TO 3.
NG >> Check harness for open between Bluetooth control unit and fuse.
Flashing Pattern
(Bluetooth ON indicator)Failure Message Action
1 "Internal failure"Replace Bluetooth control unit. Refer to
AV- 6 3 , "
BLUETOOTH CONTROL UNIT" .
2 "Bluetooth antenna open" 1. Inspect harness connection.
2. Replace Bluetooth antenna. Refer to AV-
63, "BLUETOOTH CONTROL UNIT" . 3 "Bluetooth antenna shorted"
4"Phone/Send for the Hands Free Phone
System is stuck"Check steering wheel audio control
switches. Refer to AV- 3 0 , "
Steering Switch
Check (With Bluetooth)" .
5"Phone/End for the Hands Free Phone
System is stuck"
–"Bluetooth Microphone test" (failed interac-
tive test)1. Inspect harness between Bluetooth con-
trol unit and Bluetooth microphone.
2. Replace Bluetooth microphone. Refer to
AV- 6 5 , "
BLUETOOTH MICROPHONE" .
Terminals
Ignition Switch Fuse No.
Connector Terminal
B1211 All positions 27
2ACC/ON20
3ON/START3
Terminals Ignition switch position
(+)
(–) OFF ACC ON
Connector Terminal
B1211
GroundBattery
voltageBattery
voltageBattery
voltage
20VBattery
voltageBattery
voltage
30V0VBattery
voltage
WKIA4389E
Page 455 of 2896

AV-58
TELEPHONE
Revision: June 20062007 Versa
3. CHECK GROUND CIRCUITS
1. Turn ignition switch OFF.
2. Check continuity between the following Bluetooth control unit
terminals and ground.
OK or NG
OK >> Inspection End.
NG >> Repair or replace harness.
Basic Inspection of Hands-Free PhoneEKS00IB8
1. CHECK INDICATOR OPERATION
1. Turn ignition switch ACC.
2. Check that the indicator is blinking.
OK or NG
OK >> GO TO 2
NG >> GO TO 3
2. CHECK STEERING WHEEL AUDIO CONTROL SWITCH OPERATION
1. Press the SEND switch.
2. Check the indicator is blinking.
OK or NG
OK >> INSPECTION END
NG >> Check steering wheel audio control switch circuit.
3. CHECK BLUETOOTH INDICATOR OUTPUT VOLTAGE
1. Disconnect Bluetooth microphone connector.
2. Check voltage between Bluetooth microphone connector R15
terminal 4 and ground.
OK or NO
OK >> Replace Bluetooth indicator. Refer to AV- 6 5 , "BLUE-
TOOTH MICROPHONE" .
NG >> GO TO 4.
Te r m i n a l s
Continuity
Connector Terminal —
B1214
Ground Yes 20
21
23
LKIA0794E
4 - Ground : Approx. 12 V
LKIA0774E
Page 456 of 2896

TELEPHONE
AV-59
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: June 20062007 Versa
4. CHECK BLUETOOTH INDICATOR CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect Bluetooth control unit connector B121 and Bluetooth microphone connector R15.
3. Check continuity between Bluetooth control unit connector B121
(A) terminal 15 and Bluetooth microphone connector R15 (B)
terminal 4.
OK or NO
OK >> Replace Bluetooth control unit. Refer to AV-63, "BLUE-
TOOTH CONTROL UNIT" .
NG >> Repair or replace harness.
Steering Wheel Audio Control Switch Does Not OperateEKS00IB9
1. CHECK STEERING WHEEL AUDIO CONTROL SWITCH RESISTANCE
1. Turn ignition switch OFF.
2. Disconnect steering wheel audio control switch connector.
3. Check steering wheel audio control switch. Refer to AV- 3 0 , "
Steering Switch Check (With Bluetooth)" .
OK or NG
OK >> GO TO 2.
NG >> Replace steering wheel audio control switch. AV- 4 6 , "
STEERING WHEEL AUDIO CONTROL
SWITCHES" .
2. CHECK AUDIO UNIT
1. Turn ignition switch ON.
2. Check voltage between audio unit harness connector M43 ter-
minals 6, 16 and ground.
OK or NG
OK >> Replace audio unit. Refer to AV- 4 3 , "AUDIO UNIT" .
NG >> GO TO 5.
3. CHECK BLUETOOTH CONTROL UNIT
1. Turn ignition switch ON.
2. Check voltage between Bluetooth control unit harness connec-
tor B121 terminals 17, 18 and ground.
OK or NG
OK >> Repair or replace harness.
NG >> Replace Bluetooth control unit. AV- 6 3 , "
BLUETOOTH
CONTROL UNIT" . 15 - 4 : Continuity should exist
LKIA0775E
6 - Ground : Approx. 5 V
16 - Ground : Approx. 5 V
LKIA0776E
17 - Ground : Approx. 5 V
18 - Ground : Approx. 5 V
LKIA0777E
Page 457 of 2896

AV-60
TELEPHONE
Revision: June 20062007 Versa
Voice Activated Control Function Does Not OperateEKS00IBA
NOTE:
Even under the normal condition, Bluetooth voice guidance may not occur when pressing steering wheel
audio control switch.
BLUETOOTH VOICE GUIDANCE IS HEARD WHEN PRESSING STEERING WHEEL AUDIO
CONTROL SWITCH
1. CHECK HARNESS BETWEEN BLUETOOTH CONTROL UNIT AND BLUETOOTH MICROPHONE
1. Turn ignition switch OFF.
2. Disconnect Bluetooth control unit connector and Bluetooth microphone connector.
3. Check continuity between Bluetooth control unit connector B121
(A) and Bluetooth microphone connector R15 (B).
4. Check continuity between Bluetooth control unit harness con-
nector B121 and ground.
OK or NG
OK >> GO TO 2.
NG >> Repair harness or connector.
2. CHECK BLUETOOTH MICROPHONE POWER SUPPLY
1. Connect Bluetooth control unit connector and Bluetooth microphone connector.
2. Turn ignition switch ON.
3. Check voltage between Bluetooth microphone connector R15
terminal 5 and ground.
YES or NO
YES >> GO TO 3.
NO >> Replace Bluetooth control unit. Refer to AV- 6 3 , "
BLUE-
TOOTH CONTROL UNIT" .
Terminals
Continuity
Connector Terminal Connector Terminal
A: B1216
B: R156
Ye s 78
87
29 5
Te r m i n a l s
Continuity
Connector Terminal —
A: B1217
Ground No 8
29
LKIA0778E
5 - Ground : Approx. 5 V
LKIA0779E
Page 458 of 2896

TELEPHONE
AV-61
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: June 20062007 Versa
3. CHECK MIC. SIGNAL
1. Check signal between Bluetooth control unit harness connector
B121 terminals 7 and 8.
OK or NG
OK >> Replace Bluetooth control unit. Refer to AV- 6 3 , "BLUETOOTH CONTROL UNIT" .
NG >> Replace Bluetooth microphone. Refer to AV-65, "
BLUETOOTH MICROPHONE" .
BLUETOOTH VOICE GUIDANCE IS NOT HEARD WHEN PRESSING STEERING WHEEL AUDIO
CONTROL SWITCH
1. CHECK STEERING WHEEL AUDIO CONTROL SWITCH CIRCUIT
Refer to AV-30, "
Steering Switch Check (With Bluetooth)" .
OK or NG
OK >> GO TO 2.
NG >> Replace applicable parts.
2. CHECK BLUETOOTH VOICE SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect Bluetooth control unit connector and audio unit connector.
3. Check continuity between Bluetooth control unit harness con-
nector B121 (A) and audio unit harness connector M44 (B).
4. Check continuity between Bluetooth control unit harness con-
nector B121 (A) and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair harness or connector.7 – 8:When giving a voice
LKIA0780EPKIB5037J
Te r m i n a l s
Continuity
Connector Terminal Connector Terminal
A: B1219
B: M4431
Ye s 10 33
11 2 7
Te r m i n a l s
Continuity
Connector Terminal —
A: B1219
Ground No 10
11
LKIA0781E
Page 459 of 2896

AV-62
TELEPHONE
Revision: June 20062007 Versa
3. CHECK MUTE SIGNAL
1. Connect Bluetooth control unit connector and audio unit connector.
2. Turn ignition switch ON.
3. Check voltage between Bluetooth control unit connector B121
terminal 11 and ground.
OK or NG
OK >> GO TO 4.
NG >> Replace audio unit. Refer toAV- 4 3 , "
AUDIO UNIT" .
4. CHECK BLUETOOTH VOICE SIGNAL
1. Check signal between Bluetooth control unit harness connector
B121 terminals 9 and 10.
OK or NG
OK >> Replace audio unit. Refer to AV- 4 3 , "AUDIO UNIT" .
NG >> Replace Bluetooth control unit. Refer to AV-63, "
BLUETOOTH CONTROL UNIT" . 11 - Ground : Approx. 5 V
LKIA0782E
9 – 10:When giving a voice
LKIA0783ESKIB3609E
Page 460 of 2896

TELEPHONE
AV-63
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: June 20062007 Versa
Removal and InstallationEKS00I9M
BLUETOOTH CONTROL UNIT
Removal
1. Remove luggage side lower finish (RH). Refer to EI-42, "Removal and Installation" .
2. Disconnect Bluetooth antenna harness clip.
3. Disconnect Bluetooth antenna harness connector.
4. Disconnect Bluetooth control unit harness connector.
5. Remove Bluetooth control unit upper and lower bracket bolts.
6. Unhook the Bluetooth control unit upper and lower brackets and remove Bluetooth control unit.
7. Remove Bluetooth control unit bracket screws and remove the upper and lower brackets from unit.
Installation
Installation is in the reverse order of removal.
1. Bluetooth control unit bracket 2. Bluetooth control unit A. Bolt
B. Harness clip C. Bluetooth antenna harness connector D. Bluetooth control unit connector
E. screw⇐Front
LKIA0762E
