Page 231 of 304

NISSAN VERSA HATCHBACK 2008 1.G Owners Manual When performing any inspection or maintenance
work on your vehicle, always take care to prevent
serious accidental injury to yourself or damage to
the vehicle. The following are general precau-
tions

Page 232 of 304

NISSAN VERSA HATCHBACK 2008 1.G Owners Manual 1. Engine oil filler cap
2. Brake and clutch (*1) fluid reservoir
3. Air cleaner
4. Battery
5. Fuse/Fusible link box
6. Automatic Transmission Fluid (ATF)
dipstick (*2)
7. Radiator cap
8. Engine coola

Page 233 of 304

NISSAN VERSA HATCHBACK 2008 1.G Owners Manual The engine cooling system is filled at the factory
with Genuine NISSAN Long Life
Antifreeze/Coolant to provide year-round anti-
freeze and coolant protection. The anti-freeze
solution contains rust an

Page 234 of 304

NISSAN VERSA HATCHBACK 2008 1.G Owners Manual CHANGING ENGINE COOLANT
A NISSAN dealer can change the engine coolant.
The service procedure can be found in the
NISSAN Service Manual.
Improper servicing can result in reduced
heater performance and

Page 235 of 304

NISSAN VERSA HATCHBACK 2008 1.G Owners Manual CAUTION
Oil level should be checked regularly. Op-
erating the engine with an insufficient
amount of oil can damage the engine, and
such damage is not covered by warranty.
CHANGING ENGINE OIL
1. Park

Page 236 of 304

NISSAN VERSA HATCHBACK 2008 1.G Owners Manual Drain plug tightening torque:
22 - 29 ft-lb (29 - 39 N·m)
7. Refill engine with recommended oil through
the oil filler opening, then install the oil filler
cap securely.
See “Capacities and recomme

Page 237 of 304

NISSAN VERSA HATCHBACK 2008 1.G Owners Manual WARNING
cWhen the engine is running, keep
hands, jewelry and clothing away from
any moving parts such as the cooling
fan and drive belts.
cAutomatic transmission fluid is poison-
ous and should be sto

Page 238 of 304

NISSAN VERSA HATCHBACK 2008 1.G Owners Manual 4. Remove the dipstick by pushings1and
pulling out
s2.
5. Wipe the dipstick clean with lint-free paper.
6. Reinsert the dipstick into the dipstick tube
as far as it will go.
7. Remove the dipstick and

Page 239 of 304

NISSAN VERSA HATCHBACK 2008 1.G Owners Manual For further brake and clutch fluid specification
information, refer to “Capacities and recom-
mended fuel/lubricants” in the “Technical and
consumer information” section of this manual.
WARNIN

Page 240 of 304

NISSAN VERSA HATCHBACK 2008 1.G Owners Manual WINDOW WASHER FLUID
RESERVOIR
To check the fluid level, use your finger to plug the
center hole of the cap/tube assembly, then re-
move it from the reservoir. If there is no fluid in the
tube, add flu
