2009 Nissan Towing Guide 20 HILLS – UPGRADES
As the incline increases, your vehicle — if equipped with an automatic transmission — is
designed to automatically select the correct gear for the best towing comfort and
performance. To maintain speed or avoid up and down shifts, manually shift to a lower gear as
needed.
The added weight of a trailer places an increased load on the engine and cooling system,
so monitor your coolant temperature gauge and automatic transmission fluid temperature
gauge (if equipped) very carefully. At the first sign of overheating, pull to the side of the road.
See IF YOUR ENGINE OVERHEATS later in this section for more information.
HILLS – DOWNGRADES
While going downhill, the weight of the trailer pushing on the tow vehicle may decrease
overall stability. Therefore, to maintain adequate control, reduce your speed and shift to a
lower gear. If your vehicle is equipped with Tow Mode, see your vehicle owner’s manual for
information about the use of this function.
Avoid long or repeated use of the brakes when descending a hill, as this reduces their
effectiveness and could cause overheating. Shifting to a lower gear instead provides “engine
braking” and reduces the need to brake as frequently.
AUTOMATIC CRUISE CONTROL
Do not use cruise control while towing a trailer.
IF YOUR ENGINE OVERHEATS
A moderate increase in engine operating temperature is normal when towing a trailer. If,
however, the coolant temperature gauge reading is abnormally high, or if you are experiencing
a significant loss of power, or if you hear unusual engine noises,* the engine may be
overheating and you should immediately take the following steps:
1. Pull your vehicle safely over to the side of the road, out of traffic. Apply the parking brake
and move the gearshift lever to NEUTRAL (manual) or PARK (automatic). DO NOT STOP
THE ENGINE.
2. Turn off the air conditioning and, after opening all the windows, turn the heater on to
maximum hot and the fan to its highest speed. The heater core in your vehicle is just like a
miniature engine radiator and will provide an extra cooling surface to help reduce engine
temperature.
3. If the temperature does not drop or continues to increase, stop the engine immediately.
*See your vehicle owner’s manual for additional indications that your vehicle may be overheating.
Page 22 of 32
2009 Nissan Towing Guide 21 4. Being cautious of traffic, step out of the vehicle and, from a safe distance, look for steam
underneath the engine. If you see steam or leaking coolant, stand clear to avoid being
burned and shut off your engine immediately and allow it to cool. If there is no steam, open
the hood. Never remove the radiator cap when the radiator is hot. If the cap is removed
under these conditions, hot water/coolant under high pressure may spurt out, possibly
causing serious injury.
5. As soon as the engine has cooled to its normal operating temperature, visually inspect the
drive belts for damage or looseness. A loose belt reduces water pump efficiency. Be
careful to keep your hands, hair, jewelry, and clothing clear of the running drive belt and
other moving parts when inspecting the engine and radiator. Also check to see if the
cooling fan is running, and inspect the water pump, radiator, and radiator hoses for leaks.
Keep in mind, too, that if your vehicle is equipped with an electric fan motor, it may start
without warning any time the coolant temperature is high. If you find leaking coolant, a
loose or missing drive belt, or an inoperable fan, turn off the engine immediately.
6. If no leaks are apparent and all other components appear to be operating properly with
the engine cooled to its normal operating temperature, check the coolant level in the
reservoir tank with the engine running. Add coolant to the reservoir tank if needed. At this
point, if repairs are required, go to the nearest Nissan dealer. See the IN CASE OF
EMERGENCY section of your vehicle owner’s manual for additional information on
overheating.
NOTE – All Nissan vehicles have an engine protection mode, which helps reduce the chance
of engine damage if the engine coolant reaches a specified temperature. See your vehicle
owner’s manual for details.
TOWING
GLOSSARY
5TH WHEEL
HITCH Located just forward of the rear axle centerline, this hitch uses a king pin to
serve as the pivot point for the trailer.
BALL MOUNT A bar that holds the hitch ball and is inserted into the hitch receiver. Also
commonly called a drawbar.
BREAKAWAY SWITCH A safety device using a trailer battery that automatically applies the trailer’s
brakes if it should accidentally become separated from the tow vehicle.
A breakaway switch may be used with both electric or surge trailer brake
systems.
BUMPER HITCH A reinforced bumper designed to accommodate a hitch ball.
Page 23 of 32
2009 Nissan Towing Guide 22
ELECTRIC TRAILER
BRAKES When the brakes on a tow vehicle are applied, an electric current is sent to
an actuator which applies the trailer’s brakes.
ELECTRIC TRAILER
BRAKE CONTROLLER A device that controls the electric trailer brakes.
GOOSENECK HITCH Located just forward of the rear axle centerline, this hitch uses a ball to
serve as the pivot point for the trailer.
GROSS AXLE
WEIGHT RATING (GAWR)
The maximum amount of weight each vehicle axle (front and rear) is
designed to safely carry.
GROSS COMBINED
WEIGHT RATING (GCWR) The maximum allowable combined weight of the vehicle and trailer,
including passengers and all cargo.
GROSS VEHICLE
WEIGHT RATING (GVWR) The maximum allowable weight of the vehicle, including passengers, cargo,
fuel, hitch, trailer tongue load, and any optional equipment.
KING PIN
LOAD The amount of trailer (5th wheel or gooseneck) weight pressing down on
the tow vehicle hitch.
HITCH BALL
A ball that connects the trailer to the tow vehicle hitch and provides the
means by which the trailer pivots during cornering. Available in a number
of sizes and weight capacities, it must correspond to the trailer coupler
size, and have a sufficient capacity rating for the trailer being pulled.
RECEIVER HITCH A frame- or structure-mounted hitch with a receiver that allows removal of
the ball mount.
SAFETY CHAINS/CABLES Provides an emergency connection between the tow vehicle and the trailer,
should the trailer become disengaged for any reason.
SURGE BRAKES
Hydraulic-type braking system activated by inertia. As the tow vehicle
begins to brake, the trailer pushes against the hitch ball, consequently
activating the trailer brakes.
TRAILER TONGUE/COUPLER The part of the trailer that extends forward to meet the tow vehicle, and also
carries the coupler assembly.
TRAILER TONGUE
LOAD The amount of trailer (conventional) weight pressing down on the tow
vehicle hitch.
WEIGHT-DISTRIBUTING
HITCH SYSTEM Type of hitch system that helps shift the trailer tongue weight to all trailer
tires and the tow vehicle front tires. Strongly recommended when towing
trailers with a Maximum Trailer Weight greater than 5,000 lbs.
WIRING HARNESS
Provides an electrical connection linking the tow vehicle’s electrical system
to the trailer’s system.
Page 24 of 32
2009 Nissan Towing Guide 23
SPECIFICATIONS
TOWING CAPACITIES
Crossovers, Minivans, SUVs, and Trucks
2009 ARMADA TOWING DATA
Engine Type 5.6L V8
Transmission A/T
Model(s) 2WD 4WD
without optional tow package 6,500 6,500 Maximum
Trailer Weight1,4 (lbs.) with optional tow package6 9,100 9,000
without optional tow package 650 650 Maximum
Trailer Tongue Load (lbs.) with optional tow package6 910 900
without optional tow package 12,800 13,000 Gross Combined
Weight Rating (lbs.) with optional tow package6 15,100 15,100
2009 FRONTIER TOWING DATA
Engine Type 2.5L
4-Cylinder 4.0L V6
Transmission A/T & M/T
Model(s)
King
Cab
2WD
King
Cab
2WD
King
Cab
4WD
Crew
Cab
2WD
Crew
Cab
4WD
Maximum
Trailer Weight1,3,4 (lbs.) 3,500 6,500 6,300 6,300 6,100
Maximum
Trailer Tongue Load3 (lbs.) 350 650 630 630 610
Gross Combined
Weight Rating (lbs.) 7,936 11,133 11,133 11,133 11,133
Maximum
Trailer Frontal Area 60 sq. ft.
Page 25 of 32
2009 Nissan Towing Guide 24
2009 MURANO TOWING DATA
Engine Type 3.5L V6
Transmission CVT
Maximum Trailer Weight1 (lbs.) 3,500
Maximum Trailer Tongue Load (lbs.) 350
Gross Combined Weight Rating (lbs.) 8,300
2009 PATHFINDER TOWING DATA
Engine Type 4.0L V6 5.6L V8
Transmission A/T
Maximum Trailer Weight1,4 (lbs.) 6,000 7,000
Maximum Trailer Tongue Load (lbs.) 600 700
Gross Combined Weight Rating (lbs.) 11,133 12,570
Maximum Trailer Frontal Area 60 sq. ft.
2009 ROGUE TOWING DATA
Engine Type 2.5L 4-Cylinder
Transmission CVT
Model(s) with
Manual Shift Mode
without
Manual Shift Mode
Maximum Trailer Weight1 (lbs.) 1,500 1,000
Maximum Trailer Tongue Load (lbs.) 150
Gross Combined Weight Rating (lbs.) 5,636 5,136
2009 QUEST TOWING DATA
Engine Type 3.5L V6
Transmission A/T
Maximum Trailer Weight1 (lbs.) 3,500
Maximum Trailer Tongue Load (lbs.) 350
Gross Combined Weight Rating (lbs.) 8,500
Page 26 of 32
2009 Nissan Towing Guide 25
2009 TITAN TOWING DATA - WITH OPTIONAL TOWING PACKAGE 6
Engine Type 5.6L V8
Transmission A/T
KING CAB
XE SE PRO-4X LE Model(s)
2WD 4WD 2WD 4WD 4WD 2WD 4WD
Maximum Trailer Weight1,2,4,5 (lbs.) 9,500 9,400 9,500 9,400 9,300 9,200 9,200
Maximum Trailer Tongue Load2 (lbs.) 950 940 950 940 930 920 920
King Pin Load (lbs.) 1,425 1,410 1,425 1,410 1,395 1,380 1,380
Short Wheel Base Gross Combined Weight Rating5 (lbs.) 15,10015,10015,10015,10015,100 15,100 15,100
Maximum Trailer Weight1,2,4,5 (lbs.) 9,400 9,200 9,400 9,100 - 9,100 8,900
Maximum Trailer Tongue Load2 (lbs.) 940 920 940 910 - 910 890
King Pin Load (lbs.) 1,410 1,380 1,410 1,365 - 1,365 1,335
Long Wheel Base Gross Combined Weight Rating5 (lbs.) 15,10015,10015,10015,100- 15,100 15,100
CREW CAB
XE SE PRO-4X LE Model(s)
2WD 4WD 2WD 4WD 4WD 2WD 4WD
Maximum Trailer Weight1,2,4,5 (lbs.) 9,400 9,400 9,400 9,300 9,300 9,200 9,100
Maximum Trailer Tongue Load2 (lbs.) 940 940 940 930 930 920 910
King Pin Load (lbs.) 1,410 1,410 1,410 1,395 1,395 1,380 1,365
Short Wheel Base Gross Combined Weight Rating5 (lbs.) 15,10015,10015,10015,10015,100 15,100 15,100
Maximum Trailer Weight1,2,4,5 (lbs.) 9,300 9,100 9,300 9,100 9,000 9,100 8,900
Maximum Trailer Tongue Load2 (lbs.) 930 910 930 910 900 910 890
King Pin Load (lbs.) 1,395 1,365 1,395 1,365 1,350 1,365 1,335
Long Wheel Base Gross Combined Weight Rating5 (lbs.) 15,10015,10015,10015,10015,100 15,100 15,100
Page 27 of 32
2009 Nissan Towing Guide 26
2009 TITAN TOWING DATA - WITHOUT OPTIONAL TOWING PACKAGE
Engine Type 5.6L V8
Transmission A/T
KING CAB
XE SE PRO-4X LE Model(s)
2WD 4WD 2WD 4WD 4WD 2WD 4WD
Maximum Trailer Weight1,2,4,5 (lbs.) 6,500 6,500 7,400 7,400 7,200 7,200 7,200
Maximum Trailer Tongue Load2 (lbs.) 650 650 740 740 720 720 720
King Pin Load (lbs.) 975 975 1,110 1,110 1,080 1,080 1,080
Short Wheel Base Gross Combined Weight Rating5 (lbs.) 12,80013,00012,80013,00013,000 12,800 13,000
Maximum Trailer Weight1,2,4,5 (lbs.) 6,500 6,500 7,100 7,100 - 7,000 6,900
Maximum Trailer Tongue Load2 (lbs.) 650 650 710 710 - 700 690
King Pin Load (lbs.) 975 975 1,065 1,065 - 1,050 1,035
Long Wheel Base Gross Combined Weight Rating5 (lbs.) 12,80013,00012,80013,000- 12,800 13,000
CREW CAB
XE SE PRO-4X LE Model(s)
2WD 4WD 2WD 4WD 4WD 2WD 4WD
Maximum Trailer Weight1,2,4,5 (lbs.) 6,500 6,500 7,400 7,300 7,300 7,100 7,000
Maximum Trailer Tongue Load2 (lbs.) 650 650 740 730 730 710 700
King Pin Load (lbs.) 975 975 1,110 1,095 1,095 1,065 1,050
Short Wheel Base Gross Combined Weight Rating5 (lbs.) 12,80013,00012,80013,00013,000 12,800 13,000
Maximum Trailer Weight1,2,4,5 (lbs.) 6,500 6,500 7,100 7,000 7,000 6,800 6,700
Maximum Trailer Tongue Load2 (lbs.) 650 650 710 700 700 680 670
King Pin Load (lbs.) 975 975 1,065 1,050 1,050 1,020 1,005
Long Wheel Base Gross Combined Weight Rating5 (lbs.) 12,80013,00012,80013,00013,000 12,800 13,000
Page 28 of 32
2009 Nissan Towing Guide 27
Passenger Vehicles – The towing capacity for Altima (Coupe, Hybrid, and Sedan), Maxima,
and Sentra vehicles is 1,000 lbs.; the maximum trailer tongue load is 100 lbs. DO NOT
tow a
trailer with 350Z Roadster, 370Z Coupe, cube, Versa, or GT-R.
NOTE – For passenger vehicles, the trailer tongue load must be subtracted from the GVWR
as shown on the F.M.V.S.S. certification label located in the driver’s-side door area.
2009 XTERRA TOWING DATA
Engine Type 4.0L V6
Transmission A/T & M/T
Model(s) 2WD & 4WD
Maximum
Trailer Weight1 (lbs.) 5,000
Maximum
Trailer Tongue Load (lbs.) 500
Gross Combined
Weight Rating (lbs.) 9,658
Maximum
Trailer Frontal Area 60 sq. ft.
1 Maximum Trailer Weight values are calculated assuming a base vehicle with driver and any options
required to achieve the rating. Additional passengers, cargo and/or optional equipment will add
weight to the vehicle and reduce your vehicle’s maximum towing capacity and trailer tongue load.
2 The Maximum Trailer Weight when using the Genuine Nissan step bumper in this application as a
ball mount is 5,000 lbs.; the Maximum Trailer Tongue Load is 500 lbs.
3 The Maximum Trailer Weight when using the Genuine Nissan step bumper in this application as a
ball mount is 3,500 lbs.; the Maximum Trailer Tongue Load is 350 lbs. 4 Use of a weight-distributing hitch system is recommended when towing over 5,000 lbs. 5 The Maximum Trailer Weight and Gross Combined Weight ratings for 5th wheel and gooseneck
trailer towing are the same as specified for conventional trailer towing.
6 The vehicle optional tow package does not include a ball mount. Two ball mount options are
available through your Nissan dealer:
Š Class III hitch ball mount for trailers with a Maximum Trailer Weight of 5,000 lbs. or less.
NOTE – A hitch ball is not included with the Class III ball mount. This ball mount can be
used with any hitch ball with a shank diameter of 1” or larger.
Š Class IV weight-distributing hitch ball mount for trailers with a Maximum Trailer Weight
greater than 5,000 lbs. This ball mount can also be used with trailers under 5,000 lbs.
Maximum Trailer Weight.
NOTE – The Class IV ball mount includes a 2
5/16” hitch ball rated for 10,000 lbs. Smaller
hitch ball sizes may be used by following the instructions included in the ball mount kit.
NOTES:
Š Most states require a separate braking system on trailers with a loaded weight above a
specific amount. Check local ordinances.
Š A/T – Automatic Transmission, CVT – Continuously Variable Transmission
Page 29 of 32
2009 Nissan Towing Guide 28 Other Recommendations and Information – Towing performance and speed are affected by
vehicle payload, tow weight, road grades, and weather conditions, including high
temperatures. See your vehicle owner’s manual for details.
TOWING EQUIPMENT CLASSES
Class I
Trailer hitch equipment* can be used to tow trailers with a maximum weight of 2,000 lbs.**
Class II
Trailer hitch equipment* can be used to tow trailers with a maximum weight of 3,500 lbs.**
Class III
Trailer hitch equipment* can be used to tow trailers with a maximum weight of 5,000 lbs.**
Class IV
Trailer hitch equipment* can be used to tow trailers with a maximum weight of 10,000 lbs.**
Bumper Towing Receiver Hitch Bumper Towing Receiver Hitch Bumper Towing Receiver Hitch Bumper Towing Receiver Hitch
Armada X
Frontier X X
Murano X
Pathfinder X
Quest X
Rogue X
Titan X X
Xterra X
Passenger
Vehicles† X
NOTES:
Š A weight-distributing hitch system is recommended for Armada, Frontier, Pathfinder,
and Titan vehicles if you plan to tow trailers with a maximum weight over 5,000 lbs.
Š You can tow a trailer with a lower rating than the hitch. For example, a Class IV hitch
can tow a Class II trailer.
*Includes matched receiver, ball mount, and hitch ball.
**Towing capability of the vehicle may be less than the maximum towing rating of the equipment. See
TOWING CAPACITIES earlier in this section or refer to your vehicle owner’s manual for detailed
information regarding the towing capacity of your specific vehicle.
† DO NOT tow a trailer with 350Z Roadster, 370Z Coupe, cube, Versa, or GT-R.
Page 30 of 32
2009 Nissan Towing Guide 29 TOW VEHICLE WIRING HARNESSES
PROTECTION
At Nissan, we back everything we build. So we are proud that every Nissan is protected by
some of the best New Vehicle Limited Warranties, including 3-year/36,000-mile basic
coverage. All 2009 models also feature 5-year/60,000-mile Limited Powertrain Warranty.**
And, Nissan warranties are completely transferable if you should sell your Nissan.
If you want additional peace of mind, we proudly offer the Nissan Security+Plus
® Vehicle
Protection Plan. This plan offers quality mechanical protection long after your New Vehicle
Limited Warranty expires. The Security+Plus Vehicle Protection Plan is backed by Nissan and
designed exclusively for Nissan owners. From a variety of plans available, you can choose the
one that best fits your driving needs (up to 7 years/100,000 miles!). For the maximum
coverage, you will want to opt for Security+Plus Gold® Preferred.
*
Available only for SL models equipped with Manual Shift Mode.
**For complete warranty details, read the Nissan Warranty Information Booklet or see your nearest
Nissan dealer.
Harness Type Trailer Lighting Electric Trailer Brakes
Armada 7-pin connector wiring harness Pre-wired
Receiver hitch: 7-pin connector wiring harness
Pre-wired with 7-pin harness. Requires an electric trailer brake controller (supplied by customer), and an electric trailer brake controller wiring harness (included with vehicle or available from Nissan dealer). Frontier
4-pin connector wiring harness
Tow harness kit available
Murano 4-pin connector wiring harness Tow harness kit with converter available
Standard equipment: 4-pin connector wiring harness
N/A
Pathfinder
7-pin connector wiring harness
Tow harness kit available
Pre-wired with 7-pin harness. Requires an electric trailer brake controller (supplied by customer), and an electric trailer brake controller wiring harness (included with vehicle or available from Nissan dealer).
Rogue 4-pin connector wiring harness SL: Tow harness kit available* N/A
Titan 7-pin connector wiring harness Pre-wired
Xterra Receiver hitch: 7-pin connector wiring harness Tow harness kit available
Pre-wired with 7-pin harness. Requires an electric trailer brake controller (supplied by customer), and an electric trailer brake controller wiring harness (included with vehicle or available from Nissan dealer).
