NISSAN XTERRA 2006 N50 / 2.G Quick Reference Guide
Manufacturer: NISSAN, Model Year: 2006, Model line: XTERRA, Model: NISSAN XTERRA 2006 N50 / 2.GPages: 11, PDF Size: 2.14 MB
Page 1 of 11
REMOTE KEYLESS ENTRY SYSTEM
(if so equipped)
LOCK DOORS
Press the LOC k button to lock all doors.
UNLOCK DOORS
Press the UNLOCk button once to unlock the driver’s door only. Press the button again within 5 seconds to unlock all doors.
USING THE PANIC ALARM
Press and hold the PANIC button for longer than 0.5 seconds. The panic alarm will sound and the headlights will stay on for 25 seconds. The panic alarm stops when it has run for 25 seconds, or when any button is pressed on the keyfob.
SILENCING THE HORN BEEP FEATURE
To deactivate – Press and hold the LOC k and UNLOC k buttons for at least 2 seconds.
To activate – Press and hold the LOC k and UNLOC k buttons for at least 2 seconds once more.
10
CHILD SAFET Y RE AR DOOR LOCK
Child safety locks help prevent the rear doors from being opened accidentally, especially when small children are in the vehicle. The child safety lock levers are located on the edge of the rear doors. When the lever is in the LOCK position, the door can be opened only from the outside.
PRESET A · B · C BUTTONPress the PRESET A·B·C button until you reach the desired setting. The radio isequipped with three separate banks, each with six station presets. You may storeany combination of AM, FM or SAT* radio presets on each bank.
CLOCK BUTTON To set the clock, press and hold the CLOCK button until it beeps. The hours will start flashing. Press CAT FOLDER or SEEK/TRACK to adjust the hours. Press the CLOCK button to switch to the minute adjustment. Press CAT FOLDER or SEEK/TRACK to adjust the minutes.
SEEK/TRACK BUTTON To scan quickly through each broadcasting station, press the SEEK/TRACK button. To skip from one track to another on a CD, press the SEEK/TRACK button. Each time the button is pressed, the CD will advance or skip back one track.
SCAN RPT BUTTONPress the SCAN RPT button to stop at each broadcasting station (AM, FM or SAT if so equipped) for 5 seconds. Pressing the button again during this 5-second period will stop scan tuning and the radio will remain tuned to that station. If the SCAN RPT button is not pressed within 5 seconds, scan tuning moves to the next station.
CAT FOLDER BUTTONTo manually tune the radio, press the CAT FOLDER tune button (< or >) or turn the tuning knob to the right or left. To move quickly through the channels, hold either the < or > button down for more than 1.5 seconds.
LOAD BUTTON To insert a CD, press the LOAD button for less than 1.5 seconds. Select the
loading slot by pressing the CD insert select button (1-6), then insert the CD.
To insert 6 CDs in the CD changer, press and hold the LOAD button for more than 1.5 seconds. The slot numbers (1-6) will illuminate on the display when the CDs are loaded in the changer.
STATION AND CD SELECT BUTTON STo store a radio station in a preset you must first select A, B, or C memory bank by pressing the PRESET A·B·C button and tuning to the desired AM, FM, or SAT* station. Then, press and hold the desired station select button for at least
2 seconds. When the preset indicator illuminates, a beep will sound, indicating memorization is complete. To retrieve a previously set station, select the memory bank where the preset was set, then press the corresponding station select button.
AM/FM/SAT* RADIO WITH CD PLAYER (if so equipped)
FRONT SEAT ADJUSTMENTS
Pull up on the lever under the front of the seat and slide backward or forward. Release the lever to lock the seat in position.
Lift the lever on the side of the seat to adjust your seatback backward or forward; release when you have found a comfortable angle and the seat belt fits properly. 01
SEAT LIFTER (if so equipped)
Turn either dial to adjust the angle and height of the seat cushion to the desired position. 02
FOLDING THE SECOND ROW BENCH SEAT
To fold the 2nd row bench seat flat for maximum cargo hauling:
Lower the head restraints to the full “down” position. Pull the strap located in the center of each seat cushion forward, and fold each seat cushion toward the front of the vehicle. 01
Then pull the straps located on the outside edge of each seatback to fold the seatbacks forward. 02
This easy-to-use Quick Reference Guide is intended to help you more fully appreciate
some of the unique features and functions of your new vehicle. However, it is not
intended to replace your Owner’s Manual. The Owner’s Manual contains more detailed
information to help you better understand the important safety warnings, features,
operation, and maintenance of your vehicle.
QR6E-0N50U1 Printing: April 2006 (04)
Nissan, the Nissan Brand Symbol, “SHIFT_” tagline, Z and Nissan model names are Nissan trademarks. ©2006 Nissan North America, Inc.
Sh ift_
TIRE PRESSURE MONITORING SYSTEM (TPMS)
This system monitors tire pressure. Please remember, this system does not detect a sudden drop in tire pressure (for example, a blowout while driving). It also does not monitor the air pressure in the spare tire.
Tire pressure is affected by temperature. Low outside temperature causes lower tire pressure. This may cause the low tire pressure warning light to illuminate.
If the low tire pressure warning light illuminates, check the tire pressure in all four tires. Adjust the low tire pressure to the recommended COLD tire pressure shown on the Tire and Loading Information label to turn the low tire pressure warning light off.
If TPMS is not functioning properly, the low tire pressure warning light will flash for approximately 60 seconds when the key is turned on. After 60 seconds, the light will remain on. Have the system checked by a NISSAN dealer.* SAT presets are only available on SAT equipped vehicles.
0201
0405
07
03
06
05
04
07
06
03
02
01
HILL D ESCENT C ONTROL (HDC) SWITCH
(if so equipped)
The hill descent control system is designed to reduce driver workload when going down steep hills. The HDC system helps to control vehicle speed so the driver can concentrate on steering the vehicle.
To activate the HDC system:
The automatic transmission selector lever must be in forward or reverse gear,
The 4WD switch must be in the 4L position and the vehicle speed must be under 15 MPH (25 km/h), or
The 4WD switch must be in the 4H position and the vehicle speed must be under 21 MPH (35 km/h), and
The HDC system switch must be ON.
The HDC indicator light will come on when the system is activated. Also, the stop/tail lights illuminate while the HDC system applies the brakes to control vehicle speed. To turn off the HDC system, push the switch to the off position. The HDC system is temporarily disabled when the brake or accelerator pedal is depressed.
Refer to your Owner’s Manual for detailed information.
HILL START ASSIST (HSA) (if so equipped)
The hill start assist system automatically keeps the brakes applied to help prevent the vehicle from rolling backwards in the time it takes the driver to release the brake pedal and apply the accelerator when the vehicle is stopped on a hill.
HSA will operate automatically under the following conditions:
The selector lever is shifted to a forward or reverse gear.
The vehicle is stopped completely on a hill by applying the brake.
The maximum holding time is 2 seconds.
FOLD FLAT FRONT PASSENGER SEAT
(if so equipped)
To fold the front passenger’s seatback flat for extra storage length when transporting long items:
Slide the seat to the rearmost position. Lift up on the recline lever, located on the outside edge of the seat, and fold the seatback forward as far as it will go. 01
Lift up on the latch located on the upper corner of the seatback to release the back of the seat. 02
Once the seatback is released, it will enable you to fold the front passenger seatback flat over the seat cushion.
08
01
02
08
E-LOCK SWITCH (if so equipped)
The Electronic Locking Rear Differential (E-Lock) system can help provide added traction if the vehicle is stuck or becoming stuck.
To activate the E-Lock system:
The 4WD switch must be in the 4LO position (4-wheel drive vehicles),
The vehicle must be stopped or moving at 4 MPH (7 km/h) or less, and
The E-Lock system switch must be turned on.
Once the vehicle is moving or under way, the system should be turned off.
CHANNEL TIE-DOWN HOOKS
The adjustable channel tie-down hook
system allows you to move the tie-down
hooks in the cargo area to the best location
to secure a load.
Refer to your Owner’s Manual for loading
limits and tie-down recommendations.
AD D ITIONAL FEATU R E S (continued)
MP3 P LAyBACK In addition to playing audio CDs, this radio can play MP3 files recorded on CD-ROM, CD-R, and CD-RW discs. Each disc can have a maximum of 8 folder levels and 255 folders. A total of up to 512 MP3 files can be played back. During MP3 playback, any recorded ID3 tag information can be displayed by pressing the DISP button. Use the CAT FOLDER button to navigate the MP3 files.
Sh ift_your limits
2006
XTE R RA
Q U I C K R E F E R E N C E G U I D E
01
SEAT BELT WARNING LIGHT AND CHIME
The light and chime remind you to fasten your seat belts. The light illuminates whenever the ignition key is turned to the ON or START position and remains illuminated until the driver’s seat belt is fastened. At the same time, the chime sounds for about 6 seconds unless the driver’s seat belt is securely fastened.
The seat belt warning light may also illuminate if the front passenger’s seat belt is not fastened when the front passenger’s seat is occupied (if so equipped). For 5 seconds after the ignition switch is in the ON position, the system does not activate the warning light for the front passenger.
Refer to the Owner’s Manual for detailed information regarding seat belt usage.
AD D ITIONAL FEATU R E S
01
02
01
02
Page 2 of 11
01
06
FRONT-PASSENGER
AIR BAG STATUS LIGHT
WINDSHIELD WIPER/
WASHER SWITCH
INSTRUMENT
BRIGHTNESS
CONTROL/ TRIP
CHANGE BUT TON ( BEHIND STEERING WHEEL)
TRIP COMPUTER
HE ADLIGHT AND TURN SIGNAL CONTROLCRUISE CONTROL05
CLIMATE
CONTROLS
03
CRUISE CONTROL (if so equipped)
To activate the cruise control, push the ON/OFF
switch. The indicator light in the instrument panel
will illuminate.
To set cruising speed, accelerate the vehicle to
the desired speed, push the COAST/SET switch
and release it. The SET indicator light in the
instrument panel will illuminate.
To reset at a faster cruising speed, push and hold
the ACCEL/RES switch. When the vehicle attains the speed you desire, release
the switch.
To reset at a slower cruising speed, push and hold the COAST/SET switch.
Release the switch when the vehicle slows to the desired speed.
To cancel cruise control, push the CANCEL switch or tap the brake pedal. The
SET indicator light in the instrument panel will go out.
To turn off cruise control, push the ON/OFF switch. Both the CRUISE indicator
light and the SET indicator light in the instrument panel will go out.
05
WINDSHIELD WIPER/WASHER SWITCH
The ignition switch must be in the ON position to activate the windshield wipers.
Push the lever down to operate the windshield wipers.
Switch operation includes:
Intermittent – Wipers operate intermittently and can be adjusted by
turning the time control.
Low speed – Wipers operate at a continuous low speed.
High speed – Wipers operate at a continuous high speed.
Mist – Lift the lever up for one sweep operation of the wiper.
Wash – Pull the lever toward you. Wipers automatically wipe several times.
Rear wiper and washer switch – The rear window wiper and washer operates when the ignition switch is in the ON position. Switch operation includes:
Intermittent (not adjustable) – Wipers operate intermittently.
On – Wipers operate at a continuous low speed.
Wash — Push the lever away from you. The wipers automatically wipe
several times.
STEERING WHEEL SWITCHES
FOR AUDIO CONTROL
AUDIO SYSTEM
01
FOUR-WHEEL
DRIVE (4WD)
SHIF T SWITCH
02
03
07
08
09
10
HEADLIGHT AND TURN SIGNAL CONTROL
HEADLIGHT SWITCH
Turn the headlight switch to the position to turn on the front parking, tail, license plate and instrument panel lights.
Turn the headlight switch to the position to turn on the headlights. All other lights remain on.
HIGH BEAM
Push the headlight switch forward to select the high beam function. The blue indicator light illuminates. Pull the headlight switch back to the original position to select the low beam. The blue indicator light goes off.
Pull and release the headlight switch to flash the headlight high beams on and off.
TURN SIGNAL SWITCH
Move the headlight control switch up or down to signal the turning direction. When the turn is completed, the turn signals cancel automatically.
To signal a lane change, move the headlight control switch up or down to the point where the indicator light begins to flash, but the headlight control switch does not latch.
FOG LIGHT OPERATION (if so equipped)
Note: The headlights must be on and the low beams selected for the fog lights to operate.
Turn the switch to the position to turn on the fog lights.
Turn the switch to the OFF position to turn off the fog lights.
STEERING WHEEL SWITCHES FOR
AUDIO CONTROL (if so equipped)
POWER button – To turn the audio system on
or off with the steering wheel controls, press
the POWER button.
To choose preset radio stations A, B, C and CD
press MODE repeatedly.
The tuning up or down < > switch can be used to
perform the following:
• Push the < > switch for less than 1.5 seconds to change to a preset station.
• Push and hold the < > switch for more than 1.5 seconds to seek to the next or
previous broadcasting radio station.
• Push the < > switch while playing a CD (if so equipped) for less than 1.5
seconds to change tracks on the CD.
• If the vehicle is equipped with a CD changer, push and hold the
< > switch
for more than 1.5 seconds to change between CDs.
02
TRIP COMPUTER (if so equipped)
The trip computer readout is in the speedometer display. It can show the following items:
TRIP “A” – Measures the distance of one specific trip.
TRIP “B” – Measures the distance of a second specific trip.
DISTANCE TO EMPTY (dte) – Estimates the distance that can be driven before refueling.
AVERAGE SPEED – (MPH or km/h) Shows the average speed since the last reset.
AVERAGE FUEL CONSUMPTION – (mpg or l/100 km) Shows the average fuel consumption since the last reset.
JOURNEY TIME – Shows the time since the last reset.
RESET – Press the Instrument Brightness Control/Change button on the instrument panel for more than 1 second to reset the trip odometer to zero.
With the ignition key in the ON position or the vehicle running, you can select an item by pressing the CHANGE button on the instrument panel.
06
FOUR-WHEEL DRIVE (4WD) SHIFT SWITCH
(if so equipped)
This system provides three positions so the driver can select the desired drive mode according to driving conditions.
2WD – Dry, paved roads.
4H – Rocky, sandy or snow-covered roads. (Before placing 4WD shift switch in 4H position from 2WD, ensure vehicle speed is less than 62.5 mph [100 km/h]).
4LO – When maximum power and traction are required (steep grades, rocky, sandy or muddy roads).
08
E-LOCK SWITCH
HILL DESCENT
CONTROL ( HDC )
SWITCH
04
INSTRUMENT BRIGHTNESS CONTROL/
TRIP CHANGE BUTTON
The instrument brightness control operates when the headlight control switch is in the orposition.
Turn the control to adjust the brightness of the instrument panel lights.
Press the change button to select trip computer features. See above for more information on the trip computer.
0407FRONT-PASSENGER AIR BAG STATUS LIGHT
This vehicle is equipped with the Nissan Advanced Air Bag system. Under some conditions, depending on pressure detected on the passenger seat and how the seat belt is used, the front-passenger air bag is designed to automatically turn OFF. When the front-passenger air bag is OFF, the front-passenger air bag status light will illuminate*. For example:
When the system detects that the front-passenger’s seat is occupied by a small adult, child or child restraint as outlined in the Owner’s Manual, the will illuminate to indicate that the front-passenger air bag is OFF and will not inflate in a crash.
When the front-passenger’s seat is occupied and the passenger meets the conditions outlined in the Owner’s Manual, the will not illuminate to indicate that the front-passenger air bag is operational.
*When the system detects that the front-passenger’s seat is unoccupied, the passenger air bag status light will not illuminate even though the front-passenger air bag is OFF.
Refer to the Owner’s Manual for detailed information regarding the Nissan Advanced Air Bag System.
INT
LO
HI
MIST
LCN0042
INT
ON
Please see reverse side for 10.
MANUAL CLIMATE CONTROL09
FAN SPEED CONTROL DIAL Turn the fan speed control dial to the left (slow) or right (fast) to control fan speed.
TEMPERATURE CONTROL DIAL Turn the temperature control dial for the desired temperature. Turn the control dial to the left for cold air or right for hot air.
AIR FLOW CONTROL DIAL Turn the dial to select the following air flow outlets:
Air flows from center and side vents with maximum cooling (air conditioning).
Air flows from center and side vents.
Air flows from center and side vents and the front and rear floor outlets.
Air flows mainly from the front and rear floor outlets.
Air flows from defroster outlets and the front and rear floor outlets.
Air flows mainly from defroster outlets.
DEFROSTING/DEFOGGING FRONT AND SIDE WINDOWS
Turn the air flow control dial to the front window defroster mode . The A/C automatically turns on when the defroster mode is selected.
Turn the temperature control dial left or right to set the desired temperature.
To set the defroster on high, turn the fan speed dial all the way to the right.
DEFROSTING/DEFOGGING REAR WINDOW AND OUTSIDE HEATED MIRROR (if so equipped) Push the rear window defroster switch on. Push the switch again to manually turn the defroster off. Note: The rear window defroster automatically turns off in approximately 15 minutes.
A/C ON/OFF BUTTON Press the A/C button to turn the A/C on or off.
A IR R ECIRCULATION BUTTON (if so equipped)
Press the air recirculation button to recirculate air inside the vehicle.
Press the air recirculation button again to turn air recirculation off.
The air recirculation mode cannot be selected if the air flow control dial is in the defrost position .
05
04
06
03
02
01
030201
07
0705
04
06
MAXA/C
Page 3 of 11
01
06
FRONT-PASSENGER
AIR BAG STATUS LIGHT
WINDSHIELD WIPER/
WASHER SWITCH
INSTRUMENT
BRIGHTNESS
CONTROL/ TRIP
CHANGE BUT TON ( BEHIND STEERING WHEEL)
TRIP COMPUTER
HE ADLIGHT AND TURN SIGNAL CONTROLCRUISE CONTROL05
CLIMATE
CONTROLS
03
CRUISE CONTROL (if so equipped)
To activate the cruise control, push the ON/OFF
switch. The indicator light in the instrument panel
will illuminate.
To set cruising speed, accelerate the vehicle to
the desired speed, push the COAST/SET switch
and release it. The SET indicator light in the
instrument panel will illuminate.
To reset at a faster cruising speed, push and hold
the ACCEL/RES switch. When the vehicle attains the speed you desire, release
the switch.
To reset at a slower cruising speed, push and hold the COAST/SET switch.
Release the switch when the vehicle slows to the desired speed.
To cancel cruise control, push the CANCEL switch or tap the brake pedal. The
SET indicator light in the instrument panel will go out.
To turn off cruise control, push the ON/OFF switch. Both the CRUISE indicator
light and the SET indicator light in the instrument panel will go out.
05
WINDSHIELD WIPER/WASHER SWITCH
The ignition switch must be in the ON position to activate the windshield wipers.
Push the lever down to operate the windshield wipers.
Switch operation includes:
Intermittent – Wipers operate intermittently and can be adjusted by
turning the time control.
Low speed – Wipers operate at a continuous low speed.
High speed – Wipers operate at a continuous high speed.
Mist – Lift the lever up for one sweep operation of the wiper.
Wash – Pull the lever toward you. Wipers automatically wipe several times.
Rear wiper and washer switch – The rear window wiper and washer operates when the ignition switch is in the ON position. Switch operation includes:
Intermittent (not adjustable) – Wipers operate intermittently.
On – Wipers operate at a continuous low speed.
Wash — Push the lever away from you. The wipers automatically wipe
several times.
STEERING WHEEL SWITCHES
FOR AUDIO CONTROL
AUDIO SYSTEM
01
FOUR-WHEEL
DRIVE (4WD)
SHIF T SWITCH
02
03
07
08
09
10
HEADLIGHT AND TURN SIGNAL CONTROL
HEADLIGHT SWITCH
Turn the headlight switch to the position to turn on the front parking, tail, license plate and instrument panel lights.
Turn the headlight switch to the position to turn on the headlights. All other lights remain on.
HIGH BEAM
Push the headlight switch forward to select the high beam function. The blue indicator light illuminates. Pull the headlight switch back to the original position to select the low beam. The blue indicator light goes off.
Pull and release the headlight switch to flash the headlight high beams on and off.
TURN SIGNAL SWITCH
Move the headlight control switch up or down to signal the turning direction. When the turn is completed, the turn signals cancel automatically.
To signal a lane change, move the headlight control switch up or down to the point where the indicator light begins to flash, but the headlight control switch does not latch.
FOG LIGHT OPERATION (if so equipped)
Note: The headlights must be on and the low beams selected for the fog lights to operate.
Turn the switch to the position to turn on the fog lights.
Turn the switch to the OFF position to turn off the fog lights.
STEERING WHEEL SWITCHES FOR
AUDIO CONTROL (if so equipped)
POWER button – To turn the audio system on
or off with the steering wheel controls, press
the POWER button.
To choose preset radio stations A, B, C and CD
press MODE repeatedly.
The tuning up or down < > switch can be used to
perform the following:
• Push the < > switch for less than 1.5 seconds to change to a preset station.
• Push and hold the < > switch for more than 1.5 seconds to seek to the next or
previous broadcasting radio station.
• Push the < > switch while playing a CD (if so equipped) for less than 1.5
seconds to change tracks on the CD.
• If the vehicle is equipped with a CD changer, push and hold the
< > switch
for more than 1.5 seconds to change between CDs.
02
TRIP COMPUTER (if so equipped)
The trip computer readout is in the speedometer display. It can show the following items:
TRIP “A” – Measures the distance of one specific trip.
TRIP “B” – Measures the distance of a second specific trip.
DISTANCE TO EMPTY (dte) – Estimates the distance that can be driven before refueling.
AVERAGE SPEED – (MPH or km/h) Shows the average speed since the last reset.
AVERAGE FUEL CONSUMPTION – (mpg or l/100 km) Shows the average fuel consumption since the last reset.
JOURNEY TIME – Shows the time since the last reset.
RESET – Press the Instrument Brightness Control/Change button on the instrument panel for more than 1 second to reset the trip odometer to zero.
With the ignition key in the ON position or the vehicle running, you can select an item by pressing the CHANGE button on the instrument panel.
06
FOUR-WHEEL DRIVE (4WD) SHIFT SWITCH
(if so equipped)
This system provides three positions so the driver can select the desired drive mode according to driving conditions.
2WD – Dry, paved roads.
4H – Rocky, sandy or snow-covered roads. (Before placing 4WD shift switch in 4H position from 2WD, ensure vehicle speed is less than 62.5 mph [100 km/h]).
4LO – When maximum power and traction are required (steep grades, rocky, sandy or muddy roads).
08
E-LOCK SWITCH
HILL DESCENT
CONTROL ( HDC )
SWITCH
04
INSTRUMENT BRIGHTNESS CONTROL/
TRIP CHANGE BUTTON
The instrument brightness control operates when the headlight control switch is in the orposition.
Turn the control to adjust the brightness of the instrument panel lights.
Press the change button to select trip computer features. See above for more information on the trip computer.
0407FRONT-PASSENGER AIR BAG STATUS LIGHT
This vehicle is equipped with the Nissan Advanced Air Bag system. Under some conditions, depending on pressure detected on the passenger seat and how the seat belt is used, the front-passenger air bag is designed to automatically turn OFF. When the front-passenger air bag is OFF, the front-passenger air bag status light will illuminate*. For example:
When the system detects that the front-passenger’s seat is occupied by a small adult, child or child restraint as outlined in the Owner’s Manual, the will illuminate to indicate that the front-passenger air bag is OFF and will not inflate in a crash.
When the front-passenger’s seat is occupied and the passenger meets the conditions outlined in the Owner’s Manual, the will not illuminate to indicate that the front-passenger air bag is operational.
*When the system detects that the front-passenger’s seat is unoccupied, the passenger air bag status light will not illuminate even though the front-passenger air bag is OFF.
Refer to the Owner’s Manual for detailed information regarding the Nissan Advanced Air Bag System.
INT
LO
HI
MIST
LCN0042
INT
ON
Please see reverse side for 10.
MANUAL CLIMATE CONTROL09
FAN SPEED CONTROL DIAL Turn the fan speed control dial to the left (slow) or right (fast) to control fan speed.
TEMPERATURE CONTROL DIAL Turn the temperature control dial for the desired temperature. Turn the control dial to the left for cold air or right for hot air.
AIR FLOW CONTROL DIAL Turn the dial to select the following air flow outlets:
Air flows from center and side vents with maximum cooling (air conditioning).
Air flows from center and side vents.
Air flows from center and side vents and the front and rear floor outlets.
Air flows mainly from the front and rear floor outlets.
Air flows from defroster outlets and the front and rear floor outlets.
Air flows mainly from defroster outlets.
DEFROSTING/DEFOGGING FRONT AND SIDE WINDOWS
Turn the air flow control dial to the front window defroster mode . The A/C automatically turns on when the defroster mode is selected.
Turn the temperature control dial left or right to set the desired temperature.
To set the defroster on high, turn the fan speed dial all the way to the right.
DEFROSTING/DEFOGGING REAR WINDOW AND OUTSIDE HEATED MIRROR (if so equipped) Push the rear window defroster switch on. Push the switch again to manually turn the defroster off. Note: The rear window defroster automatically turns off in approximately 15 minutes.
A/C ON/OFF BUTTON Press the A/C button to turn the A/C on or off.
A IR R ECIRCULATION BUTTON (if so equipped)
Press the air recirculation button to recirculate air inside the vehicle.
Press the air recirculation button again to turn air recirculation off.
The air recirculation mode cannot be selected if the air flow control dial is in the defrost position .
05
04
06
03
02
01
030201
07
0705
04
06
MAXA/C
Page 4 of 11
01
06
FRONT-PASSENGER
AIR BAG STATUS LIGHT
WINDSHIELD WIPER/
WASHER SWITCH
INSTRUMENT
BRIGHTNESS
CONTROL/ TRIP
CHANGE BUT TON ( BEHIND STEERING WHEEL)
TRIP COMPUTER
HE ADLIGHT AND TURN SIGNAL CONTROLCRUISE CONTROL05
CLIMATE
CONTROLS
03
CRUISE CONTROL (if so equipped)
To activate the cruise control, push the ON/OFF
switch. The indicator light in the instrument panel
will illuminate.
To set cruising speed, accelerate the vehicle to
the desired speed, push the COAST/SET switch
and release it. The SET indicator light in the
instrument panel will illuminate.
To reset at a faster cruising speed, push and hold
the ACCEL/RES switch. When the vehicle attains the speed you desire, release
the switch.
To reset at a slower cruising speed, push and hold the COAST/SET switch.
Release the switch when the vehicle slows to the desired speed.
To cancel cruise control, push the CANCEL switch or tap the brake pedal. The
SET indicator light in the instrument panel will go out.
To turn off cruise control, push the ON/OFF switch. Both the CRUISE indicator
light and the SET indicator light in the instrument panel will go out.
05
WINDSHIELD WIPER/WASHER SWITCH
The ignition switch must be in the ON position to activate the windshield wipers.
Push the lever down to operate the windshield wipers.
Switch operation includes:
Intermittent – Wipers operate intermittently and can be adjusted by
turning the time control.
Low speed – Wipers operate at a continuous low speed.
High speed – Wipers operate at a continuous high speed.
Mist – Lift the lever up for one sweep operation of the wiper.
Wash – Pull the lever toward you. Wipers automatically wipe several times.
Rear wiper and washer switch – The rear window wiper and washer operates when the ignition switch is in the ON position. Switch operation includes:
Intermittent (not adjustable) – Wipers operate intermittently.
On – Wipers operate at a continuous low speed.
Wash — Push the lever away from you. The wipers automatically wipe
several times.
STEERING WHEEL SWITCHES
FOR AUDIO CONTROL
AUDIO SYSTEM
01
FOUR-WHEEL
DRIVE (4WD)
SHIF T SWITCH
02
03
07
08
09
10
HEADLIGHT AND TURN SIGNAL CONTROL
HEADLIGHT SWITCH
Turn the headlight switch to the position to turn on the front parking, tail, license plate and instrument panel lights.
Turn the headlight switch to the position to turn on the headlights. All other lights remain on.
HIGH BEAM
Push the headlight switch forward to select the high beam function. The blue indicator light illuminates. Pull the headlight switch back to the original position to select the low beam. The blue indicator light goes off.
Pull and release the headlight switch to flash the headlight high beams on and off.
TURN SIGNAL SWITCH
Move the headlight control switch up or down to signal the turning direction. When the turn is completed, the turn signals cancel automatically.
To signal a lane change, move the headlight control switch up or down to the point where the indicator light begins to flash, but the headlight control switch does not latch.
FOG LIGHT OPERATION (if so equipped)
Note: The headlights must be on and the low beams selected for the fog lights to operate.
Turn the switch to the position to turn on the fog lights.
Turn the switch to the OFF position to turn off the fog lights.
STEERING WHEEL SWITCHES FOR
AUDIO CONTROL (if so equipped)
POWER button – To turn the audio system on
or off with the steering wheel controls, press
the POWER button.
To choose preset radio stations A, B, C and CD
press MODE repeatedly.
The tuning up or down < > switch can be used to
perform the following:
• Push the < > switch for less than 1.5 seconds to change to a preset station.
• Push and hold the < > switch for more than 1.5 seconds to seek to the next or
previous broadcasting radio station.
• Push the < > switch while playing a CD (if so equipped) for less than 1.5
seconds to change tracks on the CD.
• If the vehicle is equipped with a CD changer, push and hold the
< > switch
for more than 1.5 seconds to change between CDs.
02
TRIP COMPUTER (if so equipped)
The trip computer readout is in the speedometer display. It can show the following items:
TRIP “A” – Measures the distance of one specific trip.
TRIP “B” – Measures the distance of a second specific trip.
DISTANCE TO EMPTY (dte) – Estimates the distance that can be driven before refueling.
AVERAGE SPEED – (MPH or km/h) Shows the average speed since the last reset.
AVERAGE FUEL CONSUMPTION – (mpg or l/100 km) Shows the average fuel consumption since the last reset.
JOURNEY TIME – Shows the time since the last reset.
RESET – Press the Instrument Brightness Control/Change button on the instrument panel for more than 1 second to reset the trip odometer to zero.
With the ignition key in the ON position or the vehicle running, you can select an item by pressing the CHANGE button on the instrument panel.
06
FOUR-WHEEL DRIVE (4WD) SHIFT SWITCH
(if so equipped)
This system provides three positions so the driver can select the desired drive mode according to driving conditions.
2WD – Dry, paved roads.
4H – Rocky, sandy or snow-covered roads. (Before placing 4WD shift switch in 4H position from 2WD, ensure vehicle speed is less than 62.5 mph [100 km/h]).
4LO – When maximum power and traction are required (steep grades, rocky, sandy or muddy roads).
08
E-LOCK SWITCH
HILL DESCENT
CONTROL ( HDC )
SWITCH
04
INSTRUMENT BRIGHTNESS CONTROL/
TRIP CHANGE BUTTON
The instrument brightness control operates when the headlight control switch is in the orposition.
Turn the control to adjust the brightness of the instrument panel lights.
Press the change button to select trip computer features. See above for more information on the trip computer.
0407FRONT-PASSENGER AIR BAG STATUS LIGHT
This vehicle is equipped with the Nissan Advanced Air Bag system. Under some conditions, depending on pressure detected on the passenger seat and how the seat belt is used, the front-passenger air bag is designed to automatically turn OFF. When the front-passenger air bag is OFF, the front-passenger air bag status light will illuminate*. For example:
When the system detects that the front-passenger’s seat is occupied by a small adult, child or child restraint as outlined in the Owner’s Manual, the will illuminate to indicate that the front-passenger air bag is OFF and will not inflate in a crash.
When the front-passenger’s seat is occupied and the passenger meets the conditions outlined in the Owner’s Manual, the will not illuminate to indicate that the front-passenger air bag is operational.
*When the system detects that the front-passenger’s seat is unoccupied, the passenger air bag status light will not illuminate even though the front-passenger air bag is OFF.
Refer to the Owner’s Manual for detailed information regarding the Nissan Advanced Air Bag System.
INT
LO
HI
MIST
LCN0042
INT
ON
Please see reverse side for 10.
MANUAL CLIMATE CONTROL09
FAN SPEED CONTROL DIAL Turn the fan speed control dial to the left (slow) or right (fast) to control fan speed.
TEMPERATURE CONTROL DIAL Turn the temperature control dial for the desired temperature. Turn the control dial to the left for cold air or right for hot air.
AIR FLOW CONTROL DIAL Turn the dial to select the following air flow outlets:
Air flows from center and side vents with maximum cooling (air conditioning).
Air flows from center and side vents.
Air flows from center and side vents and the front and rear floor outlets.
Air flows mainly from the front and rear floor outlets.
Air flows from defroster outlets and the front and rear floor outlets.
Air flows mainly from defroster outlets.
DEFROSTING/DEFOGGING FRONT AND SIDE WINDOWS
Turn the air flow control dial to the front window defroster mode . The A/C automatically turns on when the defroster mode is selected.
Turn the temperature control dial left or right to set the desired temperature.
To set the defroster on high, turn the fan speed dial all the way to the right.
DEFROSTING/DEFOGGING REAR WINDOW AND OUTSIDE HEATED MIRROR (if so equipped) Push the rear window defroster switch on. Push the switch again to manually turn the defroster off. Note: The rear window defroster automatically turns off in approximately 15 minutes.
A/C ON/OFF BUTTON Press the A/C button to turn the A/C on or off.
A IR R ECIRCULATION BUTTON (if so equipped)
Press the air recirculation button to recirculate air inside the vehicle.
Press the air recirculation button again to turn air recirculation off.
The air recirculation mode cannot be selected if the air flow control dial is in the defrost position .
05
04
06
03
02
01
030201
07
0705
04
06
MAXA/C
Page 5 of 11
01
06
FRONT-PASSENGER
AIR BAG STATUS LIGHT
WINDSHIELD WIPER/
WASHER SWITCH
INSTRUMENT
BRIGHTNESS
CONTROL/ TRIP
CHANGE BUT TON ( BEHIND STEERING WHEEL)
TRIP COMPUTER
HE ADLIGHT AND TURN SIGNAL CONTROLCRUISE CONTROL05
CLIMATE
CONTROLS
03
CRUISE CONTROL (if so equipped)
To activate the cruise control, push the ON/OFF
switch. The indicator light in the instrument panel
will illuminate.
To set cruising speed, accelerate the vehicle to
the desired speed, push the COAST/SET switch
and release it. The SET indicator light in the
instrument panel will illuminate.
To reset at a faster cruising speed, push and hold
the ACCEL/RES switch. When the vehicle attains the speed you desire, release
the switch.
To reset at a slower cruising speed, push and hold the COAST/SET switch.
Release the switch when the vehicle slows to the desired speed.
To cancel cruise control, push the CANCEL switch or tap the brake pedal. The
SET indicator light in the instrument panel will go out.
To turn off cruise control, push the ON/OFF switch. Both the CRUISE indicator
light and the SET indicator light in the instrument panel will go out.
05
WINDSHIELD WIPER/WASHER SWITCH
The ignition switch must be in the ON position to activate the windshield wipers.
Push the lever down to operate the windshield wipers.
Switch operation includes:
Intermittent – Wipers operate intermittently and can be adjusted by
turning the time control.
Low speed – Wipers operate at a continuous low speed.
High speed – Wipers operate at a continuous high speed.
Mist – Lift the lever up for one sweep operation of the wiper.
Wash – Pull the lever toward you. Wipers automatically wipe several times.
Rear wiper and washer switch – The rear window wiper and washer operates when the ignition switch is in the ON position. Switch operation includes:
Intermittent (not adjustable) – Wipers operate intermittently.
On – Wipers operate at a continuous low speed.
Wash — Push the lever away from you. The wipers automatically wipe
several times.
STEERING WHEEL SWITCHES
FOR AUDIO CONTROL
AUDIO SYSTEM
01
FOUR-WHEEL
DRIVE (4WD)
SHIF T SWITCH
02
03
07
08
09
10
HEADLIGHT AND TURN SIGNAL CONTROL
HEADLIGHT SWITCH
Turn the headlight switch to the position to turn on the front parking, tail, license plate and instrument panel lights.
Turn the headlight switch to the position to turn on the headlights. All other lights remain on.
HIGH BEAM
Push the headlight switch forward to select the high beam function. The blue indicator light illuminates. Pull the headlight switch back to the original position to select the low beam. The blue indicator light goes off.
Pull and release the headlight switch to flash the headlight high beams on and off.
TURN SIGNAL SWITCH
Move the headlight control switch up or down to signal the turning direction. When the turn is completed, the turn signals cancel automatically.
To signal a lane change, move the headlight control switch up or down to the point where the indicator light begins to flash, but the headlight control switch does not latch.
FOG LIGHT OPERATION (if so equipped)
Note: The headlights must be on and the low beams selected for the fog lights to operate.
Turn the switch to the position to turn on the fog lights.
Turn the switch to the OFF position to turn off the fog lights.
STEERING WHEEL SWITCHES FOR
AUDIO CONTROL (if so equipped)
POWER button – To turn the audio system on
or off with the steering wheel controls, press
the POWER button.
To choose preset radio stations A, B, C and CD
press MODE repeatedly.
The tuning up or down < > switch can be used to
perform the following:
• Push the < > switch for less than 1.5 seconds to change to a preset station.
• Push and hold the < > switch for more than 1.5 seconds to seek to the next or
previous broadcasting radio station.
• Push the < > switch while playing a CD (if so equipped) for less than 1.5
seconds to change tracks on the CD.
• If the vehicle is equipped with a CD changer, push and hold the
< > switch
for more than 1.5 seconds to change between CDs.
02
TRIP COMPUTER (if so equipped)
The trip computer readout is in the speedometer display. It can show the following items:
TRIP “A” – Measures the distance of one specific trip.
TRIP “B” – Measures the distance of a second specific trip.
DISTANCE TO EMPTY (dte) – Estimates the distance that can be driven before refueling.
AVERAGE SPEED – (MPH or km/h) Shows the average speed since the last reset.
AVERAGE FUEL CONSUMPTION – (mpg or l/100 km) Shows the average fuel consumption since the last reset.
JOURNEY TIME – Shows the time since the last reset.
RESET – Press the Instrument Brightness Control/Change button on the instrument panel for more than 1 second to reset the trip odometer to zero.
With the ignition key in the ON position or the vehicle running, you can select an item by pressing the CHANGE button on the instrument panel.
06
FOUR-WHEEL DRIVE (4WD) SHIFT SWITCH
(if so equipped)
This system provides three positions so the driver can select the desired drive mode according to driving conditions.
2WD – Dry, paved roads.
4H – Rocky, sandy or snow-covered roads. (Before placing 4WD shift switch in 4H position from 2WD, ensure vehicle speed is less than 62.5 mph [100 km/h]).
4LO – When maximum power and traction are required (steep grades, rocky, sandy or muddy roads).
08
E-LOCK SWITCH
HILL DESCENT
CONTROL ( HDC )
SWITCH
04
INSTRUMENT BRIGHTNESS CONTROL/
TRIP CHANGE BUTTON
The instrument brightness control operates when the headlight control switch is in the orposition.
Turn the control to adjust the brightness of the instrument panel lights.
Press the change button to select trip computer features. See above for more information on the trip computer.
0407FRONT-PASSENGER AIR BAG STATUS LIGHT
This vehicle is equipped with the Nissan Advanced Air Bag system. Under some conditions, depending on pressure detected on the passenger seat and how the seat belt is used, the front-passenger air bag is designed to automatically turn OFF. When the front-passenger air bag is OFF, the front-passenger air bag status light will illuminate*. For example:
When the system detects that the front-passenger’s seat is occupied by a small adult, child or child restraint as outlined in the Owner’s Manual, the will illuminate to indicate that the front-passenger air bag is OFF and will not inflate in a crash.
When the front-passenger’s seat is occupied and the passenger meets the conditions outlined in the Owner’s Manual, the will not illuminate to indicate that the front-passenger air bag is operational.
*When the system detects that the front-passenger’s seat is unoccupied, the passenger air bag status light will not illuminate even though the front-passenger air bag is OFF.
Refer to the Owner’s Manual for detailed information regarding the Nissan Advanced Air Bag System.
INT
LO
HI
MIST
LCN0042
INT
ON
Please see reverse side for 10.
MANUAL CLIMATE CONTROL09
FAN SPEED CONTROL DIAL Turn the fan speed control dial to the left (slow) or right (fast) to control fan speed.
TEMPERATURE CONTROL DIAL Turn the temperature control dial for the desired temperature. Turn the control dial to the left for cold air or right for hot air.
AIR FLOW CONTROL DIAL Turn the dial to select the following air flow outlets:
Air flows from center and side vents with maximum cooling (air conditioning).
Air flows from center and side vents.
Air flows from center and side vents and the front and rear floor outlets.
Air flows mainly from the front and rear floor outlets.
Air flows from defroster outlets and the front and rear floor outlets.
Air flows mainly from defroster outlets.
DEFROSTING/DEFOGGING FRONT AND SIDE WINDOWS
Turn the air flow control dial to the front window defroster mode . The A/C automatically turns on when the defroster mode is selected.
Turn the temperature control dial left or right to set the desired temperature.
To set the defroster on high, turn the fan speed dial all the way to the right.
DEFROSTING/DEFOGGING REAR WINDOW AND OUTSIDE HEATED MIRROR (if so equipped) Push the rear window defroster switch on. Push the switch again to manually turn the defroster off. Note: The rear window defroster automatically turns off in approximately 15 minutes.
A/C ON/OFF BUTTON Press the A/C button to turn the A/C on or off.
A IR R ECIRCULATION BUTTON (if so equipped)
Press the air recirculation button to recirculate air inside the vehicle.
Press the air recirculation button again to turn air recirculation off.
The air recirculation mode cannot be selected if the air flow control dial is in the defrost position .
05
04
06
03
02
01
030201
07
0705
04
06
MAXA/C
Page 6 of 11
01
06
FRONT-PASSENGER
AIR BAG STATUS LIGHT
WINDSHIELD WIPER/
WASHER SWITCH
INSTRUMENT
BRIGHTNESS
CONTROL/ TRIP
CHANGE BUT TON ( BEHIND STEERING WHEEL)
TRIP COMPUTER
HE ADLIGHT AND TURN SIGNAL CONTROLCRUISE CONTROL05
CLIMATE
CONTROLS
03
CRUISE CONTROL (if so equipped)
To activate the cruise control, push the ON/OFF
switch. The indicator light in the instrument panel
will illuminate.
To set cruising speed, accelerate the vehicle to
the desired speed, push the COAST/SET switch
and release it. The SET indicator light in the
instrument panel will illuminate.
To reset at a faster cruising speed, push and hold
the ACCEL/RES switch. When the vehicle attains the speed you desire, release
the switch.
To reset at a slower cruising speed, push and hold the COAST/SET switch.
Release the switch when the vehicle slows to the desired speed.
To cancel cruise control, push the CANCEL switch or tap the brake pedal. The
SET indicator light in the instrument panel will go out.
To turn off cruise control, push the ON/OFF switch. Both the CRUISE indicator
light and the SET indicator light in the instrument panel will go out.
05
WINDSHIELD WIPER/WASHER SWITCH
The ignition switch must be in the ON position to activate the windshield wipers.
Push the lever down to operate the windshield wipers.
Switch operation includes:
Intermittent – Wipers operate intermittently and can be adjusted by
turning the time control.
Low speed – Wipers operate at a continuous low speed.
High speed – Wipers operate at a continuous high speed.
Mist – Lift the lever up for one sweep operation of the wiper.
Wash – Pull the lever toward you. Wipers automatically wipe several times.
Rear wiper and washer switch – The rear window wiper and washer operates when the ignition switch is in the ON position. Switch operation includes:
Intermittent (not adjustable) – Wipers operate intermittently.
On – Wipers operate at a continuous low speed.
Wash — Push the lever away from you. The wipers automatically wipe
several times.
STEERING WHEEL SWITCHES
FOR AUDIO CONTROL
AUDIO SYSTEM
01
FOUR-WHEEL
DRIVE (4WD)
SHIF T SWITCH
02
03
07
08
09
10
HEADLIGHT AND TURN SIGNAL CONTROL
HEADLIGHT SWITCH
Turn the headlight switch to the position to turn on the front parking, tail, license plate and instrument panel lights.
Turn the headlight switch to the position to turn on the headlights. All other lights remain on.
HIGH BEAM
Push the headlight switch forward to select the high beam function. The blue indicator light illuminates. Pull the headlight switch back to the original position to select the low beam. The blue indicator light goes off.
Pull and release the headlight switch to flash the headlight high beams on and off.
TURN SIGNAL SWITCH
Move the headlight control switch up or down to signal the turning direction. When the turn is completed, the turn signals cancel automatically.
To signal a lane change, move the headlight control switch up or down to the point where the indicator light begins to flash, but the headlight control switch does not latch.
FOG LIGHT OPERATION (if so equipped)
Note: The headlights must be on and the low beams selected for the fog lights to operate.
Turn the switch to the position to turn on the fog lights.
Turn the switch to the OFF position to turn off the fog lights.
STEERING WHEEL SWITCHES FOR
AUDIO CONTROL (if so equipped)
POWER button – To turn the audio system on
or off with the steering wheel controls, press
the POWER button.
To choose preset radio stations A, B, C and CD
press MODE repeatedly.
The tuning up or down < > switch can be used to
perform the following:
• Push the < > switch for less than 1.5 seconds to change to a preset station.
• Push and hold the < > switch for more than 1.5 seconds to seek to the next or
previous broadcasting radio station.
• Push the < > switch while playing a CD (if so equipped) for less than 1.5
seconds to change tracks on the CD.
• If the vehicle is equipped with a CD changer, push and hold the
< > switch
for more than 1.5 seconds to change between CDs.
02
TRIP COMPUTER (if so equipped)
The trip computer readout is in the speedometer display. It can show the following items:
TRIP “A” – Measures the distance of one specific trip.
TRIP “B” – Measures the distance of a second specific trip.
DISTANCE TO EMPTY (dte) – Estimates the distance that can be driven before refueling.
AVERAGE SPEED – (MPH or km/h) Shows the average speed since the last reset.
AVERAGE FUEL CONSUMPTION – (mpg or l/100 km) Shows the average fuel consumption since the last reset.
JOURNEY TIME – Shows the time since the last reset.
RESET – Press the Instrument Brightness Control/Change button on the instrument panel for more than 1 second to reset the trip odometer to zero.
With the ignition key in the ON position or the vehicle running, you can select an item by pressing the CHANGE button on the instrument panel.
06
FOUR-WHEEL DRIVE (4WD) SHIFT SWITCH
(if so equipped)
This system provides three positions so the driver can select the desired drive mode according to driving conditions.
2WD – Dry, paved roads.
4H – Rocky, sandy or snow-covered roads. (Before placing 4WD shift switch in 4H position from 2WD, ensure vehicle speed is less than 62.5 mph [100 km/h]).
4LO – When maximum power and traction are required (steep grades, rocky, sandy or muddy roads).
08
E-LOCK SWITCH
HILL DESCENT
CONTROL ( HDC )
SWITCH
04
INSTRUMENT BRIGHTNESS CONTROL/
TRIP CHANGE BUTTON
The instrument brightness control operates when the headlight control switch is in the orposition.
Turn the control to adjust the brightness of the instrument panel lights.
Press the change button to select trip computer features. See above for more information on the trip computer.
0407FRONT-PASSENGER AIR BAG STATUS LIGHT
This vehicle is equipped with the Nissan Advanced Air Bag system. Under some conditions, depending on pressure detected on the passenger seat and how the seat belt is used, the front-passenger air bag is designed to automatically turn OFF. When the front-passenger air bag is OFF, the front-passenger air bag status light will illuminate*. For example:
When the system detects that the front-passenger’s seat is occupied by a small adult, child or child restraint as outlined in the Owner’s Manual, the will illuminate to indicate that the front-passenger air bag is OFF and will not inflate in a crash.
When the front-passenger’s seat is occupied and the passenger meets the conditions outlined in the Owner’s Manual, the will not illuminate to indicate that the front-passenger air bag is operational.
*When the system detects that the front-passenger’s seat is unoccupied, the passenger air bag status light will not illuminate even though the front-passenger air bag is OFF.
Refer to the Owner’s Manual for detailed information regarding the Nissan Advanced Air Bag System.
INT
LO
HI
MIST
LCN0042
INT
ON
Please see reverse side for 10.
MANUAL CLIMATE CONTROL09
FAN SPEED CONTROL DIAL Turn the fan speed control dial to the left (slow) or right (fast) to control fan speed.
TEMPERATURE CONTROL DIAL Turn the temperature control dial for the desired temperature. Turn the control dial to the left for cold air or right for hot air.
AIR FLOW CONTROL DIAL Turn the dial to select the following air flow outlets:
Air flows from center and side vents with maximum cooling (air conditioning).
Air flows from center and side vents.
Air flows from center and side vents and the front and rear floor outlets.
Air flows mainly from the front and rear floor outlets.
Air flows from defroster outlets and the front and rear floor outlets.
Air flows mainly from defroster outlets.
DEFROSTING/DEFOGGING FRONT AND SIDE WINDOWS
Turn the air flow control dial to the front window defroster mode . The A/C automatically turns on when the defroster mode is selected.
Turn the temperature control dial left or right to set the desired temperature.
To set the defroster on high, turn the fan speed dial all the way to the right.
DEFROSTING/DEFOGGING REAR WINDOW AND OUTSIDE HEATED MIRROR (if so equipped) Push the rear window defroster switch on. Push the switch again to manually turn the defroster off. Note: The rear window defroster automatically turns off in approximately 15 minutes.
A/C ON/OFF BUTTON Press the A/C button to turn the A/C on or off.
A IR R ECIRCULATION BUTTON (if so equipped)
Press the air recirculation button to recirculate air inside the vehicle.
Press the air recirculation button again to turn air recirculation off.
The air recirculation mode cannot be selected if the air flow control dial is in the defrost position .
05
04
06
03
02
01
030201
07
0705
04
06
MAXA/C
Page 7 of 11
REMOTE KEYLESS ENTRY SYSTEM
(if so equipped)
LOCK DOORS
Press the LOC k button to lock all doors.
UNLOCK DOORS
Press the UNLOCk button once to unlock the driver’s door only. Press the button again within 5 seconds to unlock all doors.
USING THE PANIC ALARM
Press and hold the PANIC button for longer than 0.5 seconds. The panic alarm will sound and the headlights will stay on for 25 seconds. The panic alarm stops when it has run for 25 seconds, or when any button is pressed on the keyfob.
SILENCING THE HORN BEEP FEATURE
To deactivate – Press and hold the LOC k and UNLOC k buttons for at least 2 seconds.
To activate – Press and hold the LOC k and UNLOC k buttons for at least 2 seconds once more.
10
CHILD SAFET Y RE AR DOOR LOCK
Child safety locks help prevent the rear doors from being opened accidentally, especially when small children are in the vehicle. The child safety lock levers are located on the edge of the rear doors. When the lever is in the LOCK position, the door can be opened only from the outside.
PRESET A · B · C BUTTONPress the PRESET A·B·C button until you reach the desired setting. The radio isequipped with three separate banks, each with six station presets. You may storeany combination of AM, FM or SAT* radio presets on each bank.
CLOCK BUTTON To set the clock, press and hold the CLOCK button until it beeps. The hours will start flashing. Press CAT FOLDER or SEEK/TRACK to adjust the hours. Press the CLOCK button to switch to the minute adjustment. Press CAT FOLDER or SEEK/TRACK to adjust the minutes.
SEEK/TRACK BUTTON To scan quickly through each broadcasting station, press the SEEK/TRACK button. To skip from one track to another on a CD, press the SEEK/TRACK button. Each time the button is pressed, the CD will advance or skip back one track.
SCAN RPT BUTTONPress the SCAN RPT button to stop at each broadcasting station (AM, FM or SAT if so equipped) for 5 seconds. Pressing the button again during this 5-second period will stop scan tuning and the radio will remain tuned to that station. If the SCAN RPT button is not pressed within 5 seconds, scan tuning moves to the next station.
CAT FOLDER BUTTONTo manually tune the radio, press the CAT FOLDER tune button (< or >) or turn the tuning knob to the right or left. To move quickly through the channels, hold either the < or > button down for more than 1.5 seconds.
LOAD BUTTON To insert a CD, press the LOAD button for less than 1.5 seconds. Select the
loading slot by pressing the CD insert select button (1-6), then insert the CD.
To insert 6 CDs in the CD changer, press and hold the LOAD button for more than 1.5 seconds. The slot numbers (1-6) will illuminate on the display when the CDs are loaded in the changer.
STATION AND CD SELECT BUTTON STo store a radio station in a preset you must first select A, B, or C memory bank by pressing the PRESET A·B·C button and tuning to the desired AM, FM, or SAT* station. Then, press and hold the desired station select button for at least
2 seconds. When the preset indicator illuminates, a beep will sound, indicating memorization is complete. To retrieve a previously set station, select the memory bank where the preset was set, then press the corresponding station select button.
AM/FM/SAT* RADIO WITH CD PLAYER (if so equipped)
FRONT SEAT ADJUSTMENTS
Pull up on the lever under the front of the seat and slide backward or forward. Release the lever to lock the seat in position.
Lift the lever on the side of the seat to adjust your seatback backward or forward; release when you have found a comfortable angle and the seat belt fits properly. 01
SEAT LIFTER (if so equipped)
Turn either dial to adjust the angle and height of the seat cushion to the desired position. 02
FOLDING THE SECOND ROW BENCH SEAT
To fold the 2nd row bench seat flat for maximum cargo hauling:
Lower the head restraints to the full “down” position. Pull the strap located in the center of each seat cushion forward, and fold each seat cushion toward the front of the vehicle. 01
Then pull the straps located on the outside edge of each seatback to fold the seatbacks forward. 02
This easy-to-use Quick Reference Guide is intended to help you more fully appreciate
some of the unique features and functions of your new vehicle. However, it is not
intended to replace your Owner’s Manual. The Owner’s Manual contains more detailed
information to help you better understand the important safety warnings, features,
operation, and maintenance of your vehicle.
QR6E-0N50U1 Printing: April 2006 (04)
Nissan, the Nissan Brand Symbol, “SHIFT_” tagline, Z and Nissan model names are Nissan trademarks. ©2006 Nissan North America, Inc.
Sh ift_
TIRE PRESSURE MONITORING SYSTEM (TPMS)
This system monitors tire pressure. Please remember, this system does not detect a sudden drop in tire pressure (for example, a blowout while driving). It also does not monitor the air pressure in the spare tire.
Tire pressure is affected by temperature. Low outside temperature causes lower tire pressure. This may cause the low tire pressure warning light to illuminate.
If the low tire pressure warning light illuminates, check the tire pressure in all four tires. Adjust the low tire pressure to the recommended COLD tire pressure shown on the Tire and Loading Information label to turn the low tire pressure warning light off.
If TPMS is not functioning properly, the low tire pressure warning light will flash for approximately 60 seconds when the key is turned on. After 60 seconds, the light will remain on. Have the system checked by a NISSAN dealer.* SAT presets are only available on SAT equipped vehicles.
0201
0405
07
03
06
05
04
07
06
03
02
01
HILL D ESCENT C ONTROL (HDC) SWITCH
(if so equipped)
The hill descent control system is designed to reduce driver workload when going down steep hills. The HDC system helps to control vehicle speed so the driver can concentrate on steering the vehicle.
To activate the HDC system:
The automatic transmission selector lever must be in forward or reverse gear,
The 4WD switch must be in the 4L position and the vehicle speed must be under 15 MPH (25 km/h), or
The 4WD switch must be in the 4H position and the vehicle speed must be under 21 MPH (35 km/h), and
The HDC system switch must be ON.
The HDC indicator light will come on when the system is activated. Also, the stop/tail lights illuminate while the HDC system applies the brakes to control vehicle speed. To turn off the HDC system, push the switch to the off position. The HDC system is temporarily disabled when the brake or accelerator pedal is depressed.
Refer to your Owner’s Manual for detailed information.
HILL START ASSIST (HSA) (if so equipped)
The hill start assist system automatically keeps the brakes applied to help prevent the vehicle from rolling backwards in the time it takes the driver to release the brake pedal and apply the accelerator when the vehicle is stopped on a hill.
HSA will operate automatically under the following conditions:
The selector lever is shifted to a forward or reverse gear.
The vehicle is stopped completely on a hill by applying the brake.
The maximum holding time is 2 seconds.
FOLD FLAT FRONT PASSENGER SEAT
(if so equipped)
To fold the front passenger’s seatback flat for extra storage length when transporting long items:
Slide the seat to the rearmost position. Lift up on the recline lever, located on the outside edge of the seat, and fold the seatback forward as far as it will go. 01
Lift up on the latch located on the upper corner of the seatback to release the back of the seat. 02
Once the seatback is released, it will enable you to fold the front passenger seatback flat over the seat cushion.
08
01
02
08
E-LOCK SWITCH (if so equipped)
The Electronic Locking Rear Differential (E-Lock) system can help provide added traction if the vehicle is stuck or becoming stuck.
To activate the E-Lock system:
The 4WD switch must be in the 4LO position (4-wheel drive vehicles),
The vehicle must be stopped or moving at 4 MPH (7 km/h) or less, and
The E-Lock system switch must be turned on.
Once the vehicle is moving or under way, the system should be turned off.
CHANNEL TIE-DOWN HOOKS
The adjustable channel tie-down hook
system allows you to move the tie-down
hooks in the cargo area to the best location
to secure a load.
Refer to your Owner’s Manual for loading
limits and tie-down recommendations.
AD D ITIONAL FEATU R E S (continued)
MP3 P LAyBACK In addition to playing audio CDs, this radio can play MP3 files recorded on CD-ROM, CD-R, and CD-RW discs. Each disc can have a maximum of 8 folder levels and 255 folders. A total of up to 512 MP3 files can be played back. During MP3 playback, any recorded ID3 tag information can be displayed by pressing the DISP button. Use the CAT FOLDER button to navigate the MP3 files.
Sh ift_your limits
2006
XTE R RA
Q U I C K R E F E R E N C E G U I D E
01
SEAT BELT WARNING LIGHT AND CHIME
The light and chime remind you to fasten your seat belts. The light illuminates whenever the ignition key is turned to the ON or START position and remains illuminated until the driver’s seat belt is fastened. At the same time, the chime sounds for about 6 seconds unless the driver’s seat belt is securely fastened.
The seat belt warning light may also illuminate if the front passenger’s seat belt is not fastened when the front passenger’s seat is occupied (if so equipped). For 5 seconds after the ignition switch is in the ON position, the system does not activate the warning light for the front passenger.
Refer to the Owner’s Manual for detailed information regarding seat belt usage.
AD D ITIONAL FEATU R E S
01
02
01
02
Page 8 of 11
REMOTE KEYLESS ENTRY SYSTEM
(if so equipped)
LOCK DOORS
Press the LOC k button to lock all doors.
UNLOCK DOORS
Press the UNLOCk button once to unlock the driver’s door only. Press the button again within 5 seconds to unlock all doors.
USING THE PANIC ALARM
Press and hold the PANIC button for longer than 0.5 seconds. The panic alarm will sound and the headlights will stay on for 25 seconds. The panic alarm stops when it has run for 25 seconds, or when any button is pressed on the keyfob.
SILENCING THE HORN BEEP FEATURE
To deactivate – Press and hold the LOC k and UNLOC k buttons for at least 2 seconds.
To activate – Press and hold the LOC k and UNLOC k buttons for at least 2 seconds once more.
10
CHILD SAFET Y RE AR DOOR LOCK
Child safety locks help prevent the rear doors from being opened accidentally, especially when small children are in the vehicle. The child safety lock levers are located on the edge of the rear doors. When the lever is in the LOCK position, the door can be opened only from the outside.
PRESET A · B · C BUTTONPress the PRESET A·B·C button until you reach the desired setting. The radio isequipped with three separate banks, each with six station presets. You may storeany combination of AM, FM or SAT* radio presets on each bank.
CLOCK BUTTON To set the clock, press and hold the CLOCK button until it beeps. The hours will start flashing. Press CAT FOLDER or SEEK/TRACK to adjust the hours. Press the CLOCK button to switch to the minute adjustment. Press CAT FOLDER or SEEK/TRACK to adjust the minutes.
SEEK/TRACK BUTTON To scan quickly through each broadcasting station, press the SEEK/TRACK button. To skip from one track to another on a CD, press the SEEK/TRACK button. Each time the button is pressed, the CD will advance or skip back one track.
SCAN RPT BUTTONPress the SCAN RPT button to stop at each broadcasting station (AM, FM or SAT if so equipped) for 5 seconds. Pressing the button again during this 5-second period will stop scan tuning and the radio will remain tuned to that station. If the SCAN RPT button is not pressed within 5 seconds, scan tuning moves to the next station.
CAT FOLDER BUTTONTo manually tune the radio, press the CAT FOLDER tune button (< or >) or turn the tuning knob to the right or left. To move quickly through the channels, hold either the < or > button down for more than 1.5 seconds.
LOAD BUTTON To insert a CD, press the LOAD button for less than 1.5 seconds. Select the
loading slot by pressing the CD insert select button (1-6), then insert the CD.
To insert 6 CDs in the CD changer, press and hold the LOAD button for more than 1.5 seconds. The slot numbers (1-6) will illuminate on the display when the CDs are loaded in the changer.
STATION AND CD SELECT BUTTON STo store a radio station in a preset you must first select A, B, or C memory bank by pressing the PRESET A·B·C button and tuning to the desired AM, FM, or SAT* station. Then, press and hold the desired station select button for at least
2 seconds. When the preset indicator illuminates, a beep will sound, indicating memorization is complete. To retrieve a previously set station, select the memory bank where the preset was set, then press the corresponding station select button.
AM/FM/SAT* RADIO WITH CD PLAYER (if so equipped)
FRONT SEAT ADJUSTMENTS
Pull up on the lever under the front of the seat and slide backward or forward. Release the lever to lock the seat in position.
Lift the lever on the side of the seat to adjust your seatback backward or forward; release when you have found a comfortable angle and the seat belt fits properly. 01
SEAT LIFTER (if so equipped)
Turn either dial to adjust the angle and height of the seat cushion to the desired position. 02
FOLDING THE SECOND ROW BENCH SEAT
To fold the 2nd row bench seat flat for maximum cargo hauling:
Lower the head restraints to the full “down” position. Pull the strap located in the center of each seat cushion forward, and fold each seat cushion toward the front of the vehicle. 01
Then pull the straps located on the outside edge of each seatback to fold the seatbacks forward. 02
This easy-to-use Quick Reference Guide is intended to help you more fully appreciate
some of the unique features and functions of your new vehicle. However, it is not
intended to replace your Owner’s Manual. The Owner’s Manual contains more detailed
information to help you better understand the important safety warnings, features,
operation, and maintenance of your vehicle.
QR6E-0N50U1 Printing: April 2006 (04)
Nissan, the Nissan Brand Symbol, “SHIFT_” tagline, Z and Nissan model names are Nissan trademarks. ©2006 Nissan North America, Inc.
Sh ift_
TIRE PRESSURE MONITORING SYSTEM (TPMS)
This system monitors tire pressure. Please remember, this system does not detect a sudden drop in tire pressure (for example, a blowout while driving). It also does not monitor the air pressure in the spare tire.
Tire pressure is affected by temperature. Low outside temperature causes lower tire pressure. This may cause the low tire pressure warning light to illuminate.
If the low tire pressure warning light illuminates, check the tire pressure in all four tires. Adjust the low tire pressure to the recommended COLD tire pressure shown on the Tire and Loading Information label to turn the low tire pressure warning light off.
If TPMS is not functioning properly, the low tire pressure warning light will flash for approximately 60 seconds when the key is turned on. After 60 seconds, the light will remain on. Have the system checked by a NISSAN dealer.* SAT presets are only available on SAT equipped vehicles.
0201
0405
07
03
06
05
04
07
06
03
02
01
HILL D ESCENT C ONTROL (HDC) SWITCH
(if so equipped)
The hill descent control system is designed to reduce driver workload when going down steep hills. The HDC system helps to control vehicle speed so the driver can concentrate on steering the vehicle.
To activate the HDC system:
The automatic transmission selector lever must be in forward or reverse gear,
The 4WD switch must be in the 4L position and the vehicle speed must be under 15 MPH (25 km/h), or
The 4WD switch must be in the 4H position and the vehicle speed must be under 21 MPH (35 km/h), and
The HDC system switch must be ON.
The HDC indicator light will come on when the system is activated. Also, the stop/tail lights illuminate while the HDC system applies the brakes to control vehicle speed. To turn off the HDC system, push the switch to the off position. The HDC system is temporarily disabled when the brake or accelerator pedal is depressed.
Refer to your Owner’s Manual for detailed information.
HILL START ASSIST (HSA) (if so equipped)
The hill start assist system automatically keeps the brakes applied to help prevent the vehicle from rolling backwards in the time it takes the driver to release the brake pedal and apply the accelerator when the vehicle is stopped on a hill.
HSA will operate automatically under the following conditions:
The selector lever is shifted to a forward or reverse gear.
The vehicle is stopped completely on a hill by applying the brake.
The maximum holding time is 2 seconds.
FOLD FLAT FRONT PASSENGER SEAT
(if so equipped)
To fold the front passenger’s seatback flat for extra storage length when transporting long items:
Slide the seat to the rearmost position. Lift up on the recline lever, located on the outside edge of the seat, and fold the seatback forward as far as it will go. 01
Lift up on the latch located on the upper corner of the seatback to release the back of the seat. 02
Once the seatback is released, it will enable you to fold the front passenger seatback flat over the seat cushion.
08
01
02
08
E-LOCK SWITCH (if so equipped)
The Electronic Locking Rear Differential (E-Lock) system can help provide added traction if the vehicle is stuck or becoming stuck.
To activate the E-Lock system:
The 4WD switch must be in the 4LO position (4-wheel drive vehicles),
The vehicle must be stopped or moving at 4 MPH (7 km/h) or less, and
The E-Lock system switch must be turned on.
Once the vehicle is moving or under way, the system should be turned off.
CHANNEL TIE-DOWN HOOKS
The adjustable channel tie-down hook
system allows you to move the tie-down
hooks in the cargo area to the best location
to secure a load.
Refer to your Owner’s Manual for loading
limits and tie-down recommendations.
AD D ITIONAL FEATU R E S (continued)
MP3 P LAyBACK In addition to playing audio CDs, this radio can play MP3 files recorded on CD-ROM, CD-R, and CD-RW discs. Each disc can have a maximum of 8 folder levels and 255 folders. A total of up to 512 MP3 files can be played back. During MP3 playback, any recorded ID3 tag information can be displayed by pressing the DISP button. Use the CAT FOLDER button to navigate the MP3 files.
Sh ift_your limits
2006
XTE R RA
Q U I C K R E F E R E N C E G U I D E
01
SEAT BELT WARNING LIGHT AND CHIME
The light and chime remind you to fasten your seat belts. The light illuminates whenever the ignition key is turned to the ON or START position and remains illuminated until the driver’s seat belt is fastened. At the same time, the chime sounds for about 6 seconds unless the driver’s seat belt is securely fastened.
The seat belt warning light may also illuminate if the front passenger’s seat belt is not fastened when the front passenger’s seat is occupied (if so equipped). For 5 seconds after the ignition switch is in the ON position, the system does not activate the warning light for the front passenger.
Refer to the Owner’s Manual for detailed information regarding seat belt usage.
AD D ITIONAL FEATU R E S
01
02
01
02
Page 9 of 11
REMOTE KEYLESS ENTRY SYSTEM
(if so equipped)
LOCK DOORS
Press the LOC k button to lock all doors.
UNLOCK DOORS
Press the UNLOCk button once to unlock the driver’s door only. Press the button again within 5 seconds to unlock all doors.
USING THE PANIC ALARM
Press and hold the PANIC button for longer than 0.5 seconds. The panic alarm will sound and the headlights will stay on for 25 seconds. The panic alarm stops when it has run for 25 seconds, or when any button is pressed on the keyfob.
SILENCING THE HORN BEEP FEATURE
To deactivate – Press and hold the LOC k and UNLOC k buttons for at least 2 seconds.
To activate – Press and hold the LOC k and UNLOC k buttons for at least 2 seconds once more.
10
CHILD SAFET Y RE AR DOOR LOCK
Child safety locks help prevent the rear doors from being opened accidentally, especially when small children are in the vehicle. The child safety lock levers are located on the edge of the rear doors. When the lever is in the LOCK position, the door can be opened only from the outside.
PRESET A · B · C BUTTONPress the PRESET A·B·C button until you reach the desired setting. The radio isequipped with three separate banks, each with six station presets. You may storeany combination of AM, FM or SAT* radio presets on each bank.
CLOCK BUTTON To set the clock, press and hold the CLOCK button until it beeps. The hours will start flashing. Press CAT FOLDER or SEEK/TRACK to adjust the hours. Press the CLOCK button to switch to the minute adjustment. Press CAT FOLDER or SEEK/TRACK to adjust the minutes.
SEEK/TRACK BUTTON To scan quickly through each broadcasting station, press the SEEK/TRACK button. To skip from one track to another on a CD, press the SEEK/TRACK button. Each time the button is pressed, the CD will advance or skip back one track.
SCAN RPT BUTTONPress the SCAN RPT button to stop at each broadcasting station (AM, FM or SAT if so equipped) for 5 seconds. Pressing the button again during this 5-second period will stop scan tuning and the radio will remain tuned to that station. If the SCAN RPT button is not pressed within 5 seconds, scan tuning moves to the next station.
CAT FOLDER BUTTONTo manually tune the radio, press the CAT FOLDER tune button (< or >) or turn the tuning knob to the right or left. To move quickly through the channels, hold either the < or > button down for more than 1.5 seconds.
LOAD BUTTON To insert a CD, press the LOAD button for less than 1.5 seconds. Select the
loading slot by pressing the CD insert select button (1-6), then insert the CD.
To insert 6 CDs in the CD changer, press and hold the LOAD button for more than 1.5 seconds. The slot numbers (1-6) will illuminate on the display when the CDs are loaded in the changer.
STATION AND CD SELECT BUTTON STo store a radio station in a preset you must first select A, B, or C memory bank by pressing the PRESET A·B·C button and tuning to the desired AM, FM, or SAT* station. Then, press and hold the desired station select button for at least
2 seconds. When the preset indicator illuminates, a beep will sound, indicating memorization is complete. To retrieve a previously set station, select the memory bank where the preset was set, then press the corresponding station select button.
AM/FM/SAT* RADIO WITH CD PLAYER (if so equipped)
FRONT SEAT ADJUSTMENTS
Pull up on the lever under the front of the seat and slide backward or forward. Release the lever to lock the seat in position.
Lift the lever on the side of the seat to adjust your seatback backward or forward; release when you have found a comfortable angle and the seat belt fits properly. 01
SEAT LIFTER (if so equipped)
Turn either dial to adjust the angle and height of the seat cushion to the desired position. 02
FOLDING THE SECOND ROW BENCH SEAT
To fold the 2nd row bench seat flat for maximum cargo hauling:
Lower the head restraints to the full “down” position. Pull the strap located in the center of each seat cushion forward, and fold each seat cushion toward the front of the vehicle. 01
Then pull the straps located on the outside edge of each seatback to fold the seatbacks forward. 02
This easy-to-use Quick Reference Guide is intended to help you more fully appreciate
some of the unique features and functions of your new vehicle. However, it is not
intended to replace your Owner’s Manual. The Owner’s Manual contains more detailed
information to help you better understand the important safety warnings, features,
operation, and maintenance of your vehicle.
QR6E-0N50U1 Printing: April 2006 (04)
Nissan, the Nissan Brand Symbol, “SHIFT_” tagline, Z and Nissan model names are Nissan trademarks. ©2006 Nissan North America, Inc.
Sh ift_
TIRE PRESSURE MONITORING SYSTEM (TPMS)
This system monitors tire pressure. Please remember, this system does not detect a sudden drop in tire pressure (for example, a blowout while driving). It also does not monitor the air pressure in the spare tire.
Tire pressure is affected by temperature. Low outside temperature causes lower tire pressure. This may cause the low tire pressure warning light to illuminate.
If the low tire pressure warning light illuminates, check the tire pressure in all four tires. Adjust the low tire pressure to the recommended COLD tire pressure shown on the Tire and Loading Information label to turn the low tire pressure warning light off.
If TPMS is not functioning properly, the low tire pressure warning light will flash for approximately 60 seconds when the key is turned on. After 60 seconds, the light will remain on. Have the system checked by a NISSAN dealer.* SAT presets are only available on SAT equipped vehicles.
0201
0405
07
03
06
05
04
07
06
03
02
01
HILL D ESCENT C ONTROL (HDC) SWITCH
(if so equipped)
The hill descent control system is designed to reduce driver workload when going down steep hills. The HDC system helps to control vehicle speed so the driver can concentrate on steering the vehicle.
To activate the HDC system:
The automatic transmission selector lever must be in forward or reverse gear,
The 4WD switch must be in the 4L position and the vehicle speed must be under 15 MPH (25 km/h), or
The 4WD switch must be in the 4H position and the vehicle speed must be under 21 MPH (35 km/h), and
The HDC system switch must be ON.
The HDC indicator light will come on when the system is activated. Also, the stop/tail lights illuminate while the HDC system applies the brakes to control vehicle speed. To turn off the HDC system, push the switch to the off position. The HDC system is temporarily disabled when the brake or accelerator pedal is depressed.
Refer to your Owner’s Manual for detailed information.
HILL START ASSIST (HSA) (if so equipped)
The hill start assist system automatically keeps the brakes applied to help prevent the vehicle from rolling backwards in the time it takes the driver to release the brake pedal and apply the accelerator when the vehicle is stopped on a hill.
HSA will operate automatically under the following conditions:
The selector lever is shifted to a forward or reverse gear.
The vehicle is stopped completely on a hill by applying the brake.
The maximum holding time is 2 seconds.
FOLD FLAT FRONT PASSENGER SEAT
(if so equipped)
To fold the front passenger’s seatback flat for extra storage length when transporting long items:
Slide the seat to the rearmost position. Lift up on the recline lever, located on the outside edge of the seat, and fold the seatback forward as far as it will go. 01
Lift up on the latch located on the upper corner of the seatback to release the back of the seat. 02
Once the seatback is released, it will enable you to fold the front passenger seatback flat over the seat cushion.
08
01
02
08
E-LOCK SWITCH (if so equipped)
The Electronic Locking Rear Differential (E-Lock) system can help provide added traction if the vehicle is stuck or becoming stuck.
To activate the E-Lock system:
The 4WD switch must be in the 4LO position (4-wheel drive vehicles),
The vehicle must be stopped or moving at 4 MPH (7 km/h) or less, and
The E-Lock system switch must be turned on.
Once the vehicle is moving or under way, the system should be turned off.
CHANNEL TIE-DOWN HOOKS
The adjustable channel tie-down hook
system allows you to move the tie-down
hooks in the cargo area to the best location
to secure a load.
Refer to your Owner’s Manual for loading
limits and tie-down recommendations.
AD D ITIONAL FEATU R E S (continued)
MP3 P LAyBACK In addition to playing audio CDs, this radio can play MP3 files recorded on CD-ROM, CD-R, and CD-RW discs. Each disc can have a maximum of 8 folder levels and 255 folders. A total of up to 512 MP3 files can be played back. During MP3 playback, any recorded ID3 tag information can be displayed by pressing the DISP button. Use the CAT FOLDER button to navigate the MP3 files.
Sh ift_your limits
2006
XTE R RA
Q U I C K R E F E R E N C E G U I D E
01
SEAT BELT WARNING LIGHT AND CHIME
The light and chime remind you to fasten your seat belts. The light illuminates whenever the ignition key is turned to the ON or START position and remains illuminated until the driver’s seat belt is fastened. At the same time, the chime sounds for about 6 seconds unless the driver’s seat belt is securely fastened.
The seat belt warning light may also illuminate if the front passenger’s seat belt is not fastened when the front passenger’s seat is occupied (if so equipped). For 5 seconds after the ignition switch is in the ON position, the system does not activate the warning light for the front passenger.
Refer to the Owner’s Manual for detailed information regarding seat belt usage.
AD D ITIONAL FEATU R E S
01
02
01
02
Page 10 of 11
REMOTE KEYLESS ENTRY SYSTEM
(if so equipped)
LOCK DOORS
Press the LOC k button to lock all doors.
UNLOCK DOORS
Press the UNLOCk button once to unlock the driver’s door only. Press the button again within 5 seconds to unlock all doors.
USING THE PANIC ALARM
Press and hold the PANIC button for longer than 0.5 seconds. The panic alarm will sound and the headlights will stay on for 25 seconds. The panic alarm stops when it has run for 25 seconds, or when any button is pressed on the keyfob.
SILENCING THE HORN BEEP FEATURE
To deactivate – Press and hold the LOC k and UNLOC k buttons for at least 2 seconds.
To activate – Press and hold the LOC k and UNLOC k buttons for at least 2 seconds once more.
10
CHILD SAFET Y RE AR DOOR LOCK
Child safety locks help prevent the rear doors from being opened accidentally, especially when small children are in the vehicle. The child safety lock levers are located on the edge of the rear doors. When the lever is in the LOCK position, the door can be opened only from the outside.
PRESET A · B · C BUTTONPress the PRESET A·B·C button until you reach the desired setting. The radio isequipped with three separate banks, each with six station presets. You may storeany combination of AM, FM or SAT* radio presets on each bank.
CLOCK BUTTON To set the clock, press and hold the CLOCK button until it beeps. The hours will start flashing. Press CAT FOLDER or SEEK/TRACK to adjust the hours. Press the CLOCK button to switch to the minute adjustment. Press CAT FOLDER or SEEK/TRACK to adjust the minutes.
SEEK/TRACK BUTTON To scan quickly through each broadcasting station, press the SEEK/TRACK button. To skip from one track to another on a CD, press the SEEK/TRACK button. Each time the button is pressed, the CD will advance or skip back one track.
SCAN RPT BUTTONPress the SCAN RPT button to stop at each broadcasting station (AM, FM or SAT if so equipped) for 5 seconds. Pressing the button again during this 5-second period will stop scan tuning and the radio will remain tuned to that station. If the SCAN RPT button is not pressed within 5 seconds, scan tuning moves to the next station.
CAT FOLDER BUTTONTo manually tune the radio, press the CAT FOLDER tune button (< or >) or turn the tuning knob to the right or left. To move quickly through the channels, hold either the < or > button down for more than 1.5 seconds.
LOAD BUTTON To insert a CD, press the LOAD button for less than 1.5 seconds. Select the
loading slot by pressing the CD insert select button (1-6), then insert the CD.
To insert 6 CDs in the CD changer, press and hold the LOAD button for more than 1.5 seconds. The slot numbers (1-6) will illuminate on the display when the CDs are loaded in the changer.
STATION AND CD SELECT BUTTON STo store a radio station in a preset you must first select A, B, or C memory bank by pressing the PRESET A·B·C button and tuning to the desired AM, FM, or SAT* station. Then, press and hold the desired station select button for at least
2 seconds. When the preset indicator illuminates, a beep will sound, indicating memorization is complete. To retrieve a previously set station, select the memory bank where the preset was set, then press the corresponding station select button.
AM/FM/SAT* RADIO WITH CD PLAYER (if so equipped)
FRONT SEAT ADJUSTMENTS
Pull up on the lever under the front of the seat and slide backward or forward. Release the lever to lock the seat in position.
Lift the lever on the side of the seat to adjust your seatback backward or forward; release when you have found a comfortable angle and the seat belt fits properly. 01
SEAT LIFTER (if so equipped)
Turn either dial to adjust the angle and height of the seat cushion to the desired position. 02
FOLDING THE SECOND ROW BENCH SEAT
To fold the 2nd row bench seat flat for maximum cargo hauling:
Lower the head restraints to the full “down” position. Pull the strap located in the center of each seat cushion forward, and fold each seat cushion toward the front of the vehicle. 01
Then pull the straps located on the outside edge of each seatback to fold the seatbacks forward. 02
This easy-to-use Quick Reference Guide is intended to help you more fully appreciate
some of the unique features and functions of your new vehicle. However, it is not
intended to replace your Owner’s Manual. The Owner’s Manual contains more detailed
information to help you better understand the important safety warnings, features,
operation, and maintenance of your vehicle.
QR6E-0N50U1 Printing: April 2006 (04)
Nissan, the Nissan Brand Symbol, “SHIFT_” tagline, Z and Nissan model names are Nissan trademarks. ©2006 Nissan North America, Inc.
Sh ift_
TIRE PRESSURE MONITORING SYSTEM (TPMS)
This system monitors tire pressure. Please remember, this system does not detect a sudden drop in tire pressure (for example, a blowout while driving). It also does not monitor the air pressure in the spare tire.
Tire pressure is affected by temperature. Low outside temperature causes lower tire pressure. This may cause the low tire pressure warning light to illuminate.
If the low tire pressure warning light illuminates, check the tire pressure in all four tires. Adjust the low tire pressure to the recommended COLD tire pressure shown on the Tire and Loading Information label to turn the low tire pressure warning light off.
If TPMS is not functioning properly, the low tire pressure warning light will flash for approximately 60 seconds when the key is turned on. After 60 seconds, the light will remain on. Have the system checked by a NISSAN dealer.* SAT presets are only available on SAT equipped vehicles.
0201
0405
07
03
06
05
04
07
06
03
02
01
HILL D ESCENT C ONTROL (HDC) SWITCH
(if so equipped)
The hill descent control system is designed to reduce driver workload when going down steep hills. The HDC system helps to control vehicle speed so the driver can concentrate on steering the vehicle.
To activate the HDC system:
The automatic transmission selector lever must be in forward or reverse gear,
The 4WD switch must be in the 4L position and the vehicle speed must be under 15 MPH (25 km/h), or
The 4WD switch must be in the 4H position and the vehicle speed must be under 21 MPH (35 km/h), and
The HDC system switch must be ON.
The HDC indicator light will come on when the system is activated. Also, the stop/tail lights illuminate while the HDC system applies the brakes to control vehicle speed. To turn off the HDC system, push the switch to the off position. The HDC system is temporarily disabled when the brake or accelerator pedal is depressed.
Refer to your Owner’s Manual for detailed information.
HILL START ASSIST (HSA) (if so equipped)
The hill start assist system automatically keeps the brakes applied to help prevent the vehicle from rolling backwards in the time it takes the driver to release the brake pedal and apply the accelerator when the vehicle is stopped on a hill.
HSA will operate automatically under the following conditions:
The selector lever is shifted to a forward or reverse gear.
The vehicle is stopped completely on a hill by applying the brake.
The maximum holding time is 2 seconds.
FOLD FLAT FRONT PASSENGER SEAT
(if so equipped)
To fold the front passenger’s seatback flat for extra storage length when transporting long items:
Slide the seat to the rearmost position. Lift up on the recline lever, located on the outside edge of the seat, and fold the seatback forward as far as it will go. 01
Lift up on the latch located on the upper corner of the seatback to release the back of the seat. 02
Once the seatback is released, it will enable you to fold the front passenger seatback flat over the seat cushion.
08
01
02
08
E-LOCK SWITCH (if so equipped)
The Electronic Locking Rear Differential (E-Lock) system can help provide added traction if the vehicle is stuck or becoming stuck.
To activate the E-Lock system:
The 4WD switch must be in the 4LO position (4-wheel drive vehicles),
The vehicle must be stopped or moving at 4 MPH (7 km/h) or less, and
The E-Lock system switch must be turned on.
Once the vehicle is moving or under way, the system should be turned off.
CHANNEL TIE-DOWN HOOKS
The adjustable channel tie-down hook
system allows you to move the tie-down
hooks in the cargo area to the best location
to secure a load.
Refer to your Owner’s Manual for loading
limits and tie-down recommendations.
AD D ITIONAL FEATU R E S (continued)
MP3 P LAyBACK In addition to playing audio CDs, this radio can play MP3 files recorded on CD-ROM, CD-R, and CD-RW discs. Each disc can have a maximum of 8 folder levels and 255 folders. A total of up to 512 MP3 files can be played back. During MP3 playback, any recorded ID3 tag information can be displayed by pressing the DISP button. Use the CAT FOLDER button to navigate the MP3 files.
Sh ift_your limits
2006
XTE R RA
Q U I C K R E F E R E N C E G U I D E
01
SEAT BELT WARNING LIGHT AND CHIME
The light and chime remind you to fasten your seat belts. The light illuminates whenever the ignition key is turned to the ON or START position and remains illuminated until the driver’s seat belt is fastened. At the same time, the chime sounds for about 6 seconds unless the driver’s seat belt is securely fastened.
The seat belt warning light may also illuminate if the front passenger’s seat belt is not fastened when the front passenger’s seat is occupied (if so equipped). For 5 seconds after the ignition switch is in the ON position, the system does not activate the warning light for the front passenger.
Refer to the Owner’s Manual for detailed information regarding seat belt usage.
AD D ITIONAL FEATU R E S
01
02
01
02
