1. Map lights (P. 2-46)
2. Sun visors (P. 3-11)
3. Inside mirror (P.3-12)
4. Glove box (P. 2-35)
5. Console box (P. 2-34)
6. Front seats (P. 1-2)
7. Rear seats (P.1-7)
8. Storage (P. 2-33)
See the page number indicated in paren-
theses for operating details.
WII0056
PASSENGER COMPARTMENT
Illustrated table of contents0-5
ZREVIEW COPYÐ2008 Xterra(xtr)
Owners ManualÐUSA_English(nna)
06/26/07Ðdebbie
X
Page 12 of 320
1. Ventilators (P. 4-2)
2. Headlight/fog light (if so equipped)/turn
signal switch (P. 2-25)
3. Steering wheel switch for audio control
(if so equipped)/BluetoothTHands-
Free Phone System (if so equipped)
(P. 4-26, P. 4-28)
4. Driver supplemental air bag/horn
(P. 1-42, P. 2-29)
5. Meters, gauges and warning/indicator
lights (P. 2-3, 2-12)
6. Cruise control main/set switches
(P. 5-18)
7. Windshield wiper/washer switch and
rear window wiper/washer switch
(P. 2-23, P. 2-24)
8. Storage (P. 2-33)
9. Audio system controls (P. 4-10)
10. Front passenger supplemental air bag
(P. 1-42)
11. Upper and lower glove box (P. 2-35)
12. Passenger air bag status light (P. 1-51)
13. Power outlets or Aux jack
(if so equipped) and power outlet
(P. 2-32, P. 4-25)
WIC1325
INSTRUMENT PANEL
0-6Illustrated table of contents
ZREVIEW COPYÐ2008 Xterra(xtr)
Owners ManualÐUSA_English(nna)
06/26/07Ðdebbie
X
Page 13 of 320
14. Electronic locking rear differential
(E-Lock) system switch
(if so equipped) (P. 2-30)
Hill descent control switch
(if so equipped) (P. 2-29)
Vehicle Dynamic Control (VDC) OFF
switch (P. 2-29)
15. Shift selector lever (P. 5-12)
16. 4WD shift switch (if so equipped)
(P. 5-21)
17. Climate controls (P. 4-2)
18. Hazard warning flasher switch (P. 2-28)
19. Ignition switch (P. 5-8)
20. Tilt steering wheel control (P. 3-11)
21. Clutch interlock (clutch start) switch
(if so equipped) (P. 2-31)
22. Power outside mirror controls
(if so equipped) (P. 3-13)
See the page number indicated in paren-
theses for operating details.
Illustrated table of contents0-7
ZREVIEW COPYÐ2008 Xterra(xtr)
Owners ManualÐUSA_English(nna)
06/26/07Ðdebbie
X
Page 14 of 320
VQ40DE engine
1. Windshield washer fluid reservoir
(P. 8-12)
2. Fuse/fusible link box (P. 8-21)
3. Fuse and relay box (P. 8-21)
4. Engine oil filler cap (P. 8-8)
5. Engine oil dipstick (P. 8-8)
6. Brake and clutch fluid reservoir
(P. 8-11)
7. Air cleaner (P. 8-17)
8. Drive belt location (P.8-15)
9. Radiator cap (P. 8-7)
10. Power steering fluid reservoir (P. 8-11)
11. Battery (P. 8-13)
12. Engine coolant reservoir (P. 8-7)
See the page number indicated in paren-
theses for operating details.
WDI0633
ENGINE COMPARTMENT CHECK
LOCATIONS
0-8Illustrated table of contents
ZREVIEW COPYÐ2008 Xterra(xtr)
Owners ManualÐUSA_English(nna)
06/26/07Ðdebbie
X
Page 15 of 320
Warning
lightName Page
or
Anti-lock Braking
System (ABS) warn-
ing light2-13
Automatic transmis-
sion oil temperature
warning light (if so
equipped)2-13
Automatic transmis-
sion park warning
light (
model)2-13
or
Brake warning light 2-13
Charge warning
light2-14
Door open warning
light2-14
Warning
lightName Page
Engine oil pressure
warning light2-14
4WD warning light
(
model)2-15
Low fuel warning
light2-15
Low tire pressure
warning light2-15
Low windshield
washer fluid warning
light2-16
Seat belt warning
light and chime2-16
Supplemental air
bag warning light2-17
Indicator
lightName Page
Automatic transmis-
sion position indica-
tor light2-17
Cruise main switch
indicator light (if so
equipped)2-17
Cruise set switch
indicator light (if so
equipped)2-17
Electronic locking
rear differential (E-
Lock) system on
indicator light (if so
equipped)2-17
4WD shift indicator
light (
model)2-18
Front passenger air
bag status light2-18
WARNING/INDICATOR LIGHTS
Illustrated table of contents0-9
ZREVIEW COPYÐ2008 Xterra(xtr)
Owners ManualÐUSA_English(nna)
06/26/07Ðdebbie
X
Page 16 of 320
Indicator
lightName Page
High beam indicator
light (Blue)2-18
Hill descent control
system on indicator
light (if so equipped)2-29
Malfunction Indica-
tor Lamp (MIL)2-18
Overdrive off indica-
tor light (automatic
transmission only)2-19
Security indicator
light (if so equipped)2-19
Slip indicator light
for VDC2-19
Transfer 4LO posi-
tion indicator light
(
model)2-20
Turn signal/hazard
indicator lights2-20
Indicator
lightName Page
Vehicle Dynamic
Control off indicator
light2-20
0-10Illustrated table of contents
ZREVIEW COPYÐ2008 Xterra(xtr)
Owners ManualÐUSA_English(nna)
06/26/07Ðdebbie
X
Page 17 of 320
1 Safety—Seats, seat belts and
supplemental restraint system
Seats............................................1-2
Front manual seat adjustment....................1-2
Head restraint adjustment.......................1-4
Front-Seat Active Head Restraints................1-5
Flexible seating.................................1-5
Seat belts.......................................1-10
Precautions on seat belt usage..................1-10
Child safety...................................1-12
Pregnant women..............................1-14
Injured persons................................1-14
Three-point type seat belt with retractor..........1-14
Seat belt extenders............................1-21
Seat belt maintenance.........................1-21
Child restraints...................................1-22
Precautions on child restraints..................1-22Lower Anchors and Tethers for CHildren
system (LATCH)...............................1-24
Top tether strap child restraint..................1-26
Child restraint installation using LATCH..........1-27
Child restraint installation using the seat
belts.........................................1-31
Booster seats....................................1-37
Precautions on booster seats...................1-37
Booster seat installation........................1-39
Supplemental restraint system.....................1-42
Precautions on supplemental restraint
system.......................................1-42
Supplemental air bag warning labels.............1-57
Supplemental air bag warning light..............1-57
