6-76
Capacities and Specifications
The following approximate capacities are given in English
and metric conversions. Please refer to ªRecommended
Fluids and Lubricantsº in the Index for more information.
Engine Code (LX5) 3.5L V6
Automatic Transaxle (Overdrive)
When draining or replacing torque converter, more
fluid may be needed.
Pan Removal, Drain Plug
and Replacement 7.4 quarts (7.0 L). . . . . . . . . . . .
After Complete Overhaul 10.0 quarts (9.5 L). . . . .
When performing either transaxle procedure, check
fluid level when done. More fluid may be needed.
Cooling System10.0 quarts (9.5 L) . . . . . . . . . . . . . .
Engine Crankcase6.0 quarts (5.7 L) . . . . . . . . . . . .
When changing filter, up to 0.5 quart (0.5 L) more oil
may be needed.Fuel Tank18.5 U.S. gallons (70.0 L) . . . . . . . . . . . .
Air Conditioning RefrigerantSee refrigerant . . . . . .
charge label under the hood.
Power Steering
Pump Only 1.0 pint (0.5 L). . . . . . . . . . . . . . . . . . .
Complete System 1.5 pints (0.7 L). . . . . . . . . . . . .
Tire Pressures
See Tire-Loading Information . . . . . . . .
label on the rear edge of the driver's door.
Wheel Nut Torque100 lb-ft (140 N´m) . . . . . . . . . .
Engine Code (L47) 4.0L V8
Automatic Transaxle (Overdrive)
When draining or replacing torque converter, more
fluid may be needed.
Pan Removal, Drain Plug
and Replacement 11.0 quarts (10.4 L). . . . . . . . . . .
After Complete Overhaul 12.6 quarts (12.0 L). . . .
When performing either transaxle procedure, check
fluid level when done. More fluid may be needed.

6-77
Cooling System13.0 quarts (10.5 L) . . . . . . . . . . . . .
Engine Crankcase7.0 quarts (6.6 L) . . . . . . . . . . . .
When changing filter, up to 0.5 quart (0.5 L) more oil
may be needed.
Fuel Tank17.5 U.S. gallons (66.2 L) . . . . . . . . . . . .
Air Conditioning Refrigerant
See refrigerant . . . . . .
charge label under the hood.
Power Steering
Pump Only 1.0 pint (0.5 L). . . . . . . . . . . . . . . . . . .
Complete System 1.5 pints (0.7 L). . . . . . . . . . . . .
Tire Pressures
See Tire-Loading Information . . . . . . . .
label on the rear edge of the driver's door.
Wheel Nut Torque100 lb-ft (140 N´m) . . . . . . . . . .
All capacities are approximate. When adding, be sure
to fill to the appropriate level as recommended in
this manual.
Engine Specifications
The following engine specifications are for the
(LX5) 3.5L V6.
VIN Engine Code H. . . . . . . . . . . . . . . . . . . . . . . . . . .
Type V6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displacement 212 cubic inches (3.5L). . . . . . . . . . . .
Horsepower 215. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compression Ratio 9.3:1. . . . . . . . . . . . . . . . . . . . . . .
Firing Order 1
-2-3-4-5-6 . . . . . . . . . . . . . . . . . . . . . .
Thermostat Temperature
Specification 180
F (82
C) . . . . . . . . . . . . . . . . . .
The following engine specifications are for
the (L47) 4.0L V8.
VIN Engine Code C. . . . . . . . . . . . . . . . . . . . . . . . . . .
Type V8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displacement 279 cubic inches (4.0L). . . . . . . . . . . .
Horsepower 250. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compression Ratio 10.3:1. . . . . . . . . . . . . . . . . . . . . .
Firing Order 1
-2-7-3-4-5-6-8 . . . . . . . . . . . . . . . . . . .
Thermostat Temperature
Specification 180
F (82
C) . . . . . . . . . . . . . . . . . .

6-78
Normal Maintenance
Replacement Parts
The following replacement parts are for the
(LX5) 3.5L V6.
Air Cleaner Element AC Type A
-1096C . . . . . . . . . .
Passenger Compartment
Air Filter GM Part # 25654414. . . . . . . . . . . . . . .
Engine Oil Filter AC Type PF
-58 . . . . . . . . . . . . . . . .
Fuel Filter AC Type GF
-627 . . . . . . . . . . . . . . . . . . . .
Spark Plugs PT16EPR
-C13 . . . . . . . . . . . . . . . . . . . .
(GM Part # 12561466)
Gap: 0.050 inch (1.52 mm)
Windshield Wiper Blades
Type Shepard's Hook. . . . . . . . . . . . . . . . . . . . . . . . .
Length 22.0 inches (56.0 cm). . . . . . . . . . . . . . . . . . The following replacement parts are for the
(L47) 4.0L V8.
Air Cleaner Element AC Type A
-1096C . . . . . . . . . .
Passenger Compartment
Air Filter GM Part # 25654414. . . . . . . . . . . . . . .
Engine Oil Filter AC Type PF
-58 . . . . . . . . . . . . . . . .
Fuel Filter AC Type GF
-627 . . . . . . . . . . . . . . . . . . . .
Spark Plugs PT16EPR
-C13 . . . . . . . . . . . . . . . . . . . .
(GM Part # 12561466)
Gap: 0.050 inch (1.52 mm)
Windshield Wiper Blades
Type Shepard's Hook. . . . . . . . . . . . . . . . . . . . . . . . .
Length 22.0 inches (56.0 cm). . . . . . . . . . . . . . . . . .
Vehicle Dimensions
Length 205.4 inches (522.0 cm). . . . . . . . . . . . . . . . .
Width 74.4 inches (189.0 cm). . . . . . . . . . . . . . . . . . .
Height 55.4 inches (141.0 cm). . . . . . . . . . . . . . . . . . .
Wheelbase 113.8 inches (289.1 cm). . . . . . . . . . . . . .
Front Tread 62.5 inches (159.0 cm). . . . . . . . . . . . . . .
Rear Tread 62.5 inches (159.0 cm). . . . . . . . . . . . . . .

7-
7-1
Section 7 Maintenance Schedule
This section covers the maintenance required for your vehicle. Your vehicle needs these services to retain its safety,
dependability and emission control performance.
7
-2 Introduction
7
-3 How this Section is Organized
7
-4 Part A: Scheduled Maintenance Services
7
-5 Scheduled Maintenance7
-15 Part B: Owner Checks and Services
7
-19 Part C: Periodic Maintenance Inspections
7
-21 Part D: Recommended Fluids and Lubricants
7
-23 Part E: Maintenance Record

7-2
Have you purchased the GM Protection Plan? The Plan
supplements your new vehicle warranties. See your
Warranty and Owner Assistance booklet or your dealer
for details.
Introduction
Your Vehicle and the Environment
Proper vehicle maintenance not only helps to keep your
vehicle in good working condition, but also helps the
environment. All recommended maintenance procedures
are important. Improper vehicle maintenance can even
affect the quality of the air we breathe. Improper fluid
levels or the wrong tire inflation can increase the level
of emissions from your vehicle. To help protect our
environment, and to keep your vehicle in good
condition, please maintain your vehicle properly.
Maintenance Requirements
Maintenance intervals, checks, inspections and
recommended fluids and lubricants as prescribed in
this manual are necessary to keep your vehicle in good
working condition. Any damage caused by failure to
follow recommended maintenance may not be covered
by warranty.

7-3 How This Section is Organized
This maintenance schedule is divided into five parts:
ªPart A: Scheduled Maintenance Servicesº shows
what to have done and how often. Some of these
services can be complex, so unless you are technically
qualified and have the necessary equipment, you should
let your dealer's service department or another qualified
service center do these jobs.
CAUTION:
Performing maintenance work on a vehicle can
be dangerous. In trying to do some jobs, you can
be seriously injured. Do your own maintenance
work only if you have the required know
-how
and the proper tools and equipment for the job.
If you have any doubt, have a qualified
technician do the work.
If you want to get the service information, see
ªService and Owner Publicationsº in the Index.ªPart B: Owner Checks and Servicesº tells you what
should be checked and when. It also explains what you
can easily do to help keep your vehicle in good condition.
ªPart C: Periodic Maintenance Inspectionsº explains
important inspections that your dealer's service department
or another qualified service center should perform.
ªPart D: Recommended Fluids and Lubricantsº lists
some recommended products necessary to help keep
your vehicle properly maintained. These products, or
their equivalents, should be used whether you do the
work yourself or have it done.
ªPart E: Maintenance Recordº is a place for you to
record and keep track of the maintenance performed on
your vehicle. Keep your maintenance receipts. They may
be needed to qualify your vehicle for warranty repairs.

7-4
Part A: Scheduled
Maintenance Services
Using Your Maintenance Schedule
We at General Motors want to help you keep your
vehicle in good working condition. But we don't know
exactly how you'll drive it. You may drive very short
distances only a few times a week. Or you may drive
long distances all the time in very hot, dusty weather.
You may use your vehicle in making deliveries.
Or you may drive it to work, to do errands or in
many other ways.
Because of all the different ways people use their
vehicles, maintenance needs vary. You may need more
frequent checks and replacements. So please read the
following and note how you drive. If you have any
questions on how to keep your vehicle in good
condition, see your dealer.This part tells you the maintenance services you should
have done and when you should schedule them. If you
go to your dealer for your service needs, you'll know
that GM
-trained and supported service people will
perform the work using genuine GM parts.
The proper fluids and lubricants to use are listed in Part D.
Make sure whoever services your vehicle uses these. All
parts should be replaced and all necessary repairs done
before you or anyone else drives the vehicle.
This schedule is for vehicles that:

carry passengers and cargo within recommended
limits. You will find these limits on your vehicle's
Tire
-Loading Information label. See ªLoading Your
Vehicleº in the Index.

are driven on reasonable road surfaces within legal
driving limits.

use the recommended fuel. See ªFuelº in the Index.

Scheduled Maintenance
7-5
The services shown in this schedule up to 100,000 miles
(166 000 km) should be performed after 100,000 miles
(166 000 km) at the same intervals. The services shown
at 150,000 miles (240 000 km) should be performed at
the same interval after 150,000 miles (240 000 km).
See ªOwner Checks and Servicesº and ªPeriodic
Maintenance Inspectionsº following.Footnotes

The U.S. Environmental Protection Agency or the
California Air Resources Board has determined that the
failure to perform this maintenance item will not nullify
the emission warranty or limit recall liability prior to
the completion of the vehicle's useful life. We, however,
urge that all recommended maintenance services be
performed at the indicated intervals and the
maintenance be recorded.
+ A good time to check your brakes is during tire
rotation. See ªBrake System Inspectionº under
ªPeriodic Maintenance Inspectionsº in Part C of
this schedule.

Scheduled Maintenance
7-6Engine Oil Scheduled Maintenance
Change engine oil and filter as indicated by the GM
Oil Life System
(or every 12 months, whichever
occurs first). Reset the indicator. The system will
show you when to change the oil
-- usually between
3,000 miles (5 000 km) and 10,000 miles (16 000 km)
since your last oil change. Under severe conditions, the
indicator may come on before 3,000 miles (5 000 km).
Never drive your vehicle more than 10,000 miles
(16 000 km) or 12 months without an oil and
filter change.The system won't detect dust in the oil. So if you drive
in a dusty area, be sure to change your oil and filter
every 3,000 miles (5 000 km) or sooner if the CHANGE
OIL SOON or the CHANGE OIL NOW message
appears. Remember to reset the Oil Life System when
the oil and filter have been changed. See ªOil Life
Systemº in the Index for information on resetting.
An Emission Control Service.

Scheduled Maintenance
7-7
