remote start Oldsmobile Aurora 2001 Owner's Manuals

2-
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything
is working properly
-- and what to do if you have a problem.
2
-2 Windows
2
-4 Keys
2
-6 Door Locks
2
-9 Remote Lock Control
2
-14 Trunk
2
-16 Theft
2
-17 Universal Theft-Deterrent
2
-18 PASS-Key
III
2
-20 New Vehicle ªBreak-Inº
2
-21 Ignition Positions
2
-22 Starting Your Engine
2
-25 Engine Coolant Heater (If Equipped)
2
-26 Automatic Transaxle Operation
2
-29 Parking Brake
2
-30 Shifting Into PARK (P)
2
-32 Shifting Out of PARK (P)2
-32 Parking Over Things That Burn
2
-33 Engine Exhaust
2
-34 Tilt Wheel
2
-35 Turn Signal/Multifunction Lever
2
-44 Exterior Lamps
2
-46 Interior Lamps
2
-50 Mirrors
2
-53 Storage Compartments
2
-56 Accessory Power Outlet
2
-56 OnStar
System (If Equipped)
2
-57 Sunroof (Option)
2
-58 HomeLink
Transmitter (If Equipped)
2
-62 The Instrument Panel - Your
Information System
2
-66 Warning Lights, Gages and Indicators
2
-78 Driver Information Center (DIC)

2-17
Universal Theft-Deterrent
Your vehicle has a theft-deterrent alarm system. With
this system, if your ignition is off, the SECURITY light
will flash as you open the door.
This light reminds you to
activate the theft
-deterrent
system. To activate it do
the following:
1. Open the door.
2. Lock the door with the power door lock switch or
remote lock control system. The SECURITY light
should come on and stay on.
3. Close all doors. The SECURITY light should go
off after about 30 seconds. The security system is
not armed until the SECURITY light is off. If the
SECURITY light stays on or flashes when the
ignition is turned on, there is a problem with the
system and the vehicle should be serviced.
If the SECURITY light comes on for one minute and
then shuts off while the ignition is on, the security
system has detected a problem. See your dealer
for service.If a door or the trunk is opened without the key or
remote lock control transmitter, the alarm will go off.
Your vehicle's lamps will flash and the horn will sound
for 30 seconds, then will go off to save battery power.
Remember, the theft
-deterrent system won't activate
if you lock the doors with a key or manual door lock.
It only activates if you use the power door lock switch
or remote lock control transmitter. You should also
remember that you can start your vehicle with the
correct ignition key if the alarm has been set off.
This also shuts off the alarm.
Here's how to avoid setting off the alarm by accident:

If you don't want to activate the theft
-deterrent
system, lock the door either using a key or the
manual door lock switch.

Always unlock a door with a key, or use the remote
lock control system. Unlocking a door any other
way will set off the alarm.
If you set off the alarm by accident, unlock any door
with your key.
You can also turn off the alarm by pressing the
unlock symbol on the remote lock control transmitter.
The alarm won't stop if you try to unlock a door any
other way.

5-4
1. Check the other vehicle. It must have a 12-volt
battery with a negative ground system.
NOTICE:
If the other system isn't a 12-volt system with a
negative ground, both vehicles can be damaged.
2. Get the vehicles close enough so the jumper cables
can reach, but be sure the vehicles aren't touching
each other. If they are, it could cause a ground
connection you don't want. You wouldn't be able
to start your vehicle, and the bad grounding could
damage the electrical systems.
To avoid the possibility of the vehicles rolling, set
the parking brake firmly on both vehicles involved in
the jump start procedure. Put an automatic transaxle
in PARK (P) and a manual transaxle in NEUTRAL
before setting the parking brake.3. Turn off the ignition on both vehicles. Unplug
unnecessary accessories plugged into the cigarette
lighter or accessory power outlet. Turn off all lamps
that aren't needed as well as radios. This will avoid
sparks and help save both batteries. In addition, it
could save your radio.
4. Open the hoods and locate the other vehicle's battery
and your vehicle's remote positive (+) jump starting
terminal in the box on the passenger side of the
engine compartment. (Your vehicle's battery isn't
under the hood.)
CAUTION:
An electric fan can start up even when the engine
is not running and can injure you. Keep hands,
clothing and tools away from any underhood
electric fan.

5-7
9. Now connect the black
negative (
-) cable to
the good battery's
negative (
-) terminal.
Don't let the other end of the negative (
-) cable
touch anything until the next step. The other end of
the negative (
-) cable doesn't go to the dead battery.
10. If you have the 3.5L V6 engine, it goes to a heavy,
unpainted metal part on the engine of the vehicle
with the dead battery. Don't allow the red and black
handles in the jumper cable to touch each other.
If you have the 4.0L V8
engine, your vehicle has
a remote negative terminal,
marked ªGNDº, located
near the power steering
fluid reservoir. Attach
the cable to the remote
negative terminal provided.
See ªEngine Compartment Overviewº in the Index
for more information on location.
11. Now start the vehicle with the good battery and run
the engine for a while.
12. Try to start the vehicle with the dead battery.
If it won't start after a few tries, it probably
needs service.
