Page 277 of 336
yellowblue
6-63
Refrigerant, Air Conditioning. . . . . . . . . . . . . . . . .
See refrigerant charge label under the hood.
Wheel Nut Torque100 lb
-ft (140 N´m) . . . . . . . . . .
Tire Pressures, Sizes. . . . . . . . . . . . . . . . . . . . . . . .
See Tire
-Loading Information label on the driver's
side rear passenger door.
Cooling System13.6 quarts (12.9 L) . . . . . . . . . . . . .
Engine Crankcase4.5 quarts (4.3 L) . . . . . . . . . . .
Fuel Tank15.0 gallons (56.8 L) . . . . . . . . . . . . . . . .
NOTE: All capacities are approximate. When adding, be
sure to fill to the appropriate level or as recommended in
this manual.
See ªFluids and Lubricantsº in the Index.
Air Conditioning Refrigerants
Not all air conditioning refrigerants are the same. If the air
conditioning system in your vehicle needs refrigerant, be
sure the proper refrigerant is used. If you're not sure, ask
your dealer.
Normal Maintenance
Replacement Parts
Air Cleaner ElementAC Type A-1279C . . . . . . . . .
Engine Oil FilterAC Type PF
-47 . . . . . . . . . . . . . . . .
Spark PlugsAC Type41
-940 (Platinum Plug) . . . . .
Gap: 0.060 inch (1.52 mm)
Windshield Wiper Blades
Driver's Side 22.0 inches (56.0 cm). . . . . . . . . . . . . .
Passenger's Side 19.0 inches (48.0 cm). . . . . . . . . . . .
Vehicle Dimensions
Length 192 inches (487.8 cm). . . . . . . . . . . . . . . . . . .
Width 69.4 inches (176.3 cm). . . . . . . . . . . . . . . . . . .
Height 56.4 inches (143.2 cm). . . . . . . . . . . . . . . . . . .
Wheelbase 107 inches (271.9 cm). . . . . . . . . . . . . . . .
Front Tread 59 inches (149.9 cm). . . . . . . . . . . . . . . . .
Rear Tread 59.3 inches (150.5 cm). . . . . . . . . . . . . . .
Page 296 of 336
Short Trip/City Scheduled Maintenance
yellowblue
7-18
100,000 Miles (166 000 km)
Inspect spark plug wires.
An Emission Control Service.
Replace spark plugs.
An Emission Control Service.
Change automatic transaxle fluid and filter if the vehicle is mainly driven
under one or more of these conditions:
± In heavy city traffic where the outside temperature regularly reaches 90F
(32C) or higher.
± In hilly or mountainous terrain.
± When doing frequent trailer towing.
± Uses such as found in taxi, police or delivery service.
If you do not use your vehicle under any of these conditions, the fluid and
filter do not require changing.
150,000 Miles (240 000 km)
Drain, flush and refill cooling system (or every 60 months since last service,
whichever occurs first). See ªEngine Coolantº in the Index for what to use.
Inspect hoses. Clean radiator, condenser, pressure cap and neck. Pressure test
cooling system and pressure cap.
An Emission Control Service.
ACTUAL
SERVICED BY:MILEAGE
DATE
ACTUAL
SERVICED BY:MILEAGE
DATE
Page 303 of 336
Long Trip/Highway Scheduled Maintenance
yellowblue
7-25
100,000 Miles (166 000 km)
Inspect spark plug wires.
An Emission Control Service.
Replace spark plugs.
An Emission Control Service.
Change automatic transaxle fluid and filter if the vehicle is mainly driven
under one or more of these conditions:
± In heavy city traffic where the outside temperature regularly reaches 90F
(32C) or higher.
± In hilly or mountainous terrain.
± When doing frequent trailer towing.
± Uses such as found in taxi, police or delivery service.
If you do not use your vehicle under any of these conditions, the fluid and
filter do not require changing.
150,000 Miles (240 000 km)
Drain, flush and refill cooling system (or every 60 months since last service,
whichever occurs first). See ªEngine Coolantº in the Index for what to use.
Inspect hoses. Clean radiator, condenser, pressure cap and neck. Pressure test
the cooling system and pressure cap.
An Emission Control Service.
ACTUAL
SERVICED BY:MILEAGE
DATE
ACTUAL
SERVICED BY:MILEAGE
DATE
