In brief7Seat adjustmentLongitudinal adjustment
Pull handle, slide seat, release
handle.
Try to move the seat back and forth to ensure that the seat is locked in place.
Seat position 3 36.
Seat adjustment 3 37.
Backrests inclination
Turn handwheel. Do not lean on
backrest when adjusting.
Seat position 3 36.
Seat adjustment 3 37.
Seat height
Lever pumping motion
up:higherdown:lower
Operate lever and adjust body weight
on seat to raise or lower it.
Seat position 3 36.
Seat adjustment 3 37.
Seat folding 3 38.

In brief9Exterior mirrorsManual adjustment
Swivel lever in required direction.
The lower mirrors are not adjustable.
Electric adjustment
Select the relevant exterior mirror by
turning the control to left _ or right 6.
Then swivel the control to adjust the
mirror.
In position o no mirror is selected.
Convex exterior mirrors 3 30.
Electric adjustment 3 30.
Folding exterior mirrors 3 31.
Heated exterior mirrors 3 31.
Steering wheel adjustment
Unlock the lever, adjust the steering
wheel, then engage lever and ensure it is fully locked.
Do not adjust steering wheel unless
the vehicle is stationary and the
steering wheel lock has been
released.
Airbag system 3 48.
Ignition positions 3 114.

In brief111Fixed air vents ..................... 111
2 Side air vents ...................... 110
3 Light switch .......................... 99
High beam, low beam ...........99
Headlight flash ......................99
Daytime running lights ........100
Turn and lane-change
signals ................................. 101
4 Instruments ........................... 76
Driver Information Centre ...... 90
5 Windscreen wiper/washer .....71
Rear window wiper/washer ..71
Headlamp washer .................72
Trip odometer reset ............... 76
6 Centre air vents .................. 110
7 Document holder, pocket
for Personal Navigation
Device .................................. 60
8 Headlight range
adjustment ......................... 100
Driver Information Centre
controls ................................ 90Trip computer........................ 96
Instrument illumination ........102
Hazard warning flashers .....100
Front fog lights ...................101
Rear fog light ...................... 101 Heated rear window ..............34
Heated exterior mirrors .........31
Clock ..................................... 72
Airbag deactivation ...............53
9 Front passenger airbag ........52
10 Glovebox .............................. 61
11 Heating and ventilation
system ................................. 106
Air conditioning system .......107
Electronic climate control
system ................................. 108
12 Selector lever, manual
transmission ....................... 121
Manual transmission
automated ........................... 122
13 Ignition switch with
steering wheel lock ............11414Steering wheel controls .......70
15 Horn ..................................... 70
Driver airbag ........................ 52
16 Steering wheel adjustment ..70
17 Cruise control .....................130
18 Fuse box ............................. 156
19 Bonnet release lever ..........142

In brief13Exterior lighting
Turn light switch:
§:off / daytime running lights9:sidelights / headlights
Lighting 3 99.
Daytime running lights 3 100.
Fog lights
Press light switch:
>:front fog lightsø:rear fog light
Front fog lights 3 101.
Rear fog light 3 101.
Headlight flash, high beam and
low beamheadlight flash:pull leverhigh beam:push leverlow beam:pull lever
Depending on version, pull lever
towards steering wheel to switch
between high and low beam.
High beam 3 99.
Headlight flash 3 99.

18In briefStarting the engine
● Turn key to position 1.
● Move the steering wheel slightly to release the steering wheel
lock.
● Operate clutch and brake.
● Manual transmission automated: operate brake, the transmission
automatically shifts to N (neutral).
● Do not operate accelerator pedal.
● Diesel engines: turn the key to
position 1 for preheating and wait
until control indicator ! goes
out.
● Turn key to position 2 and release.
Starting the engine 3 115.Stop-start system
If the vehicle is at a low speed or at a
standstill and certain conditions are
fulfilled, activate an Autostop as
follows:
● Depress the clutch pedal.
● Engage neutral gear.
● Release the clutch pedal.
An Autostop is indicated when ^ is
displayed in the Driver Information
Centre 3 90.
To restart the engine, depress the
clutch pedal again.
Stop-start system 3 116.

In brief19Parking9Warning
● Do not park the vehicle on an
easily ignitable surface. The
high temperature of the
exhaust system could ignite the
surface.
● Always apply parking brake without pressing release
button. Apply as firmly as
possible on a downhill slope or
uphill slope. Depress brake
pedal at the same time to
reduce operating force.
● Switch off the engine.
● If the vehicle is on a level surface or uphill slope, engage
first gear before switching off
the ignition. On an uphill slope,
turn the front wheels away from
the kerb.
If the vehicle is on a downhill
slope, engage reverse gear
before switching off the ignition. Turn the front wheels towardsthe kerb.
● Close the windows.
● Turn the ignition key to position
0 and remove it from the
ignition switch. Turn the
steering wheel until the
steering wheel lock is felt to
engage.
● Lock the vehicle with e on the
remote control.
● The engine cooling fans may run
after the engine has been
switched off 3 142.
Caution
After running at high engine
speeds or with high engine loads,
operate the engine briefly at a low load or run in neutral for approx.30 seconds before switching off, in
order to protect the turbocharger.
Keys, locks 3 20.
Laying the vehicle up for a long period
of time 3 141.

36Seats, restraintsRear head restraints, height
adjustment
Pull the head restraint upwards or
press the release buttons and push
the head restraint downwards.
Removal
Rear head restraints, removal
Press both release buttons, pull the
head restraint upwards and remove.
Stow the removed head restraint
securely in the load compartment. Do not drive with head restraint removed
if the seat is occupied.
Note
Approved accessories may only be
attached if the seat is not in use.Front seats
Seat position9 Warning
Only drive with the seat correctly
adjusted.
9 Danger
Do not sit nearer than 25 cm from
the steering wheel, to permit safe
airbag deployment.
9 Warning
Never adjust seats while driving as
they could move uncontrollably.
9 Warning
Never store any objects under the
seats except in the underseat
storage compartment 3 62.

Seats, restraints37
● Sit with buttocks as far backagainst the backrest as possible.
Adjust the distance between the
seat and the pedals so that legs
are slightly angled when pressing
the pedals. Slide the front
passenger seat as far back as
possible.
● Set seat height high enough to have a clear field of vision on allsides and of all display
instruments. There should be at
least one hand of clearance
between head and the roof
frame. Thighs should rest lightly
on the seat without pressing into
it.
● Sit with shoulders as far back against the backrest as possible.Set the backrest rake so that it is
possible to reach the steering
wheel with arms slightly bent.
Maintain contact between
shoulders and the backrest when turning the steering wheel. Do
not angle the backrest too far
back. We recommend a
maximum rake of approx. 25°.
● Adjust seat and steering wheel in
a way that the wrist rests on top
of the steering wheel while the
arm is fully extended and
shoulders on the backrest.
● Adjust the steering wheel 3 70.
● Adjust the head restraint 3 35.
● Adjust the height of the seat belt 3 46.
● Adjust the lumbar support so that
it supports the natural shape of
the spine 3 37.
Seat adjustment Drive only with seats and backrests
properly engaged.Seat positioning
Pull handle, slide seat, release
handle.
Try to move the seat back and forth to ensure that the seat is locked in place.

38Seats, restraintsSeat backrests
Turn handwheel. Do not lean on
backrest when adjusting.
Seat height
Lever pumping motion
up:higherdown:lower
Operate lever and adjust body weight
on seat to raise or lower it.
Lumbar support
Adjust lumbar support using
handwheel to suit personal
requirements.
Rotate handwheel to increase and
decrease support.
Seat folding Folding front passenger seatDepending on version, the front
passenger seat can be folded flat to
the table position.

Seats, restraints39Slide the front passenger seat as far
back as possible, to avoid contact
with the instrument panel during
folding.
Note
When seat height is in its highest
position, push head restraints down
3 35 before folding backrest.
Ensure that nothing prevents the
seat from folding, e.g. sun visor,
glovebox.
Pull release levers (1), fold backrest
fully forwards then release the levers. Then push the backrest down further
until it is completely flat.
Pull the flap (2) located at the base of
the backrest and simultaneously push
the backrest down as far as possible.
On some versions, there is a single
release lever located on the inboard
side of the front passenger seat. Pull
release lever, fold backrest fully
forwards, release lever then push
backrest down until it is completely
flat. The flap at the base of the
backrest is not present on some
versions.
Note
Do not operate handwheel for
backrest inclination when backrest is
folded forwards.
9 Warning
When the front passenger seat is
in the folded position, the front
passenger airbag system must be deactivated.
Airbag deactivation 3 53.
9 Warning
Always make sure that the load in
the vehicle is securely stowed.
Otherwise objects can be thrown
around inside the vehicle and
cause personal injury or damage
to the load or vehicle.
Unfolding front passenger seat
To restore the seat to the upright
position, pull the flap located at the
base of the backrest and
simultaneously pull up the backrest
as far as it will go.
Pull release levers and raise backrest
fully then release levers.
