mirror controls OPEL CROSSLAND X 2017.75 Owner's Manual

In brief111Power windows .....................38
2 Exterior mirrors .....................35
3 Cruise control .....................147
Speed limiter ....................... 149
4 Turn and lane-change
signals, headlight flash,
low/high beam, high beam
assist ................................... 108
Exit lighting ......................... 114
Parking lights ...................... 112
Buttons for Driver
Information Centre ................93
5 Side air vents ...................... 124
6 Instruments .......................... 83
Driver Information Centre ...... 93
7 Buttons for Driver
Information Centre ................93
8 Windscreen wiper and
washer, rear wiper and
washer ................................. 75
9 Head-up display ....................97
10 Centre air vents .................. 124
11 Hazard warning flashers ....110
12 Info-Display .......................... 9513Centre air vent ......................95
14 Light sensor
15 Central locking system ..........25
16 Glovebox .............................. 64
Fuse box ............................ 193
17 Controls for Info-Display
operation ............................... 95
18 Climate control system ........ 116
19 USB charging port ................ 78
20 Parking assist/Advanced
parking assist .....................151
Lane departure warning .....165
Eco button for stop-start
system ................................. 132
Electronic Stability Control and Traction Control ...........146
21 Power outlet .......................... 78
22 Manual transmission ..........143
Automatic transmission ......140
23 Manual parking brake .........145
24 Power button ....................... 129
25 Ignition switch .....................128
26 Steering wheel adjustment ..7427 Horn ..................................... 75
28 Bonnet release lever ..........177
29 Storage ................................. 64
30 Head-up display ....................97
31 Light switch ........................ 107
Headlight range
adjustment ......................... 109
Front/rear fog lights ............111
Instrument illumination .......112

Climate control115Climate controlClimate control systems.............115
Heating and ventilation system 115
Air conditioning system ...........116
Electronic climate control system .................................... 119
Auxiliary heater ........................123
Air vents ..................................... 124
Adjustable air vents .................124
Fixed air vents ......................... 125
Maintenance .............................. 125
Air intake ................................. 125
Air conditioning regular operation ................................ 126
Service .................................... 126Climate control systems
Heating and ventilation system
Controls for: ● temperature £
● air distribution l, M and K
● fan speed Z
● demisting and defrosting à
● heated rear window and exterior mirrors b
● heated seats ß
Temperature £
Adjust the temperature by turning
£ to the desired temperature.red area:warmerblue area:colder
Heating will not be fully effective until
the engine has reached normal
operating temperature.
Air distribution l M K
Press:
l:to windscreen and front door
windowsM:to head area and rear seats via
adjustable front air ventsK:to front and rear foot well and
windscreen
Combinations are possible.
Fan speed Z
Adjust the air flow by turning Z to the
desired speed.
to the right:increaseto the left:decrease

116Climate controlDemisting and defrosting the
windows á
● Press á: the air distribution is
directed towards the windscreen.
● Set temperature controller £ to
warmest level.
● Set fan speed Z to highest level.
● Switch on heated rear window b.
● Open side air vents as required and direct them towards the doorwindows.
Heated rear window and exterior
mirrors b
3 39
Heated seats ß
3 47.
Air conditioning system
Illustration shows functions which
may not be available for your
particular vehicle.
Controls for: ● temperature £
● air distribution l, M and K
● fan speed Z
● demisting and defrosting à
● air conditioning A/C
● air recirculation 4
● heated rear window and exterior
mirrors b
● heated windscreen ,
● heated seats ß
Some changes of settings are
indicated briefly in the Info-Display.
Activated functions are indicated by the LED in the respective button.
Temperature £
Adjust the temperature by turning £ to the desired temperature.
red area:warmerblue area:colder

Climate control119Heated rear window, windscreen
and exterior mirrors b
3 39
Heated seats ß
3 47.
Electronic climate control system
The dual zone climate control allows
different temperatures for driver side
and front passenger side.
In automatic mode, temperature, fan
speed and air distribution are
regulated automatically.Illustration shows functions which
may not be available for your
particular vehicle.
Controls for: ● temperature on driver side £
● MENU enters the Climate setting
menu in the Info-Display
● fan speed Z
● automatic mode AUTO
● temperature on front passenger side £
● cooling A/C
● manual air recirculation 4
● demisting and defrosting à
● heated rear window and exterior mirrors b
● heated windscreen ,
● heated seats ß
Activated functions are indicated by the LED in the respective control.
The electronic climate control system
is only fully operational when the
engine is running.Climate settings menu (MENU
button)
Settings for
● air distribution l, M , K
● fan speed Z
● temperature for driver and passenger side 19°/21°
● dual zone temperature synchronisation MONO
● air conditioning ON/OFF
● automatic mode AUTO
can be triggered manually in the
Climate setting menu. Press MENU to
enter the menu and follow the touch
buttons.

239Collision damage repair..............233
Control indicators.......................... 86
Control of the vehicle .................128
Controls ........................................ 74
Convex shape .............................. 35
Coolant and antifreeze ...............215
Cruise control ...................... 92, 147
Cupholders .................................. 64
Curtain airbag system .................. 56
D
Danger, Warnings and Cautions ...4
Daytime running lights ...............109
Declaration of conformity ............231
DEF ............................................ 137
Deflation detection system ...........91
Diesel exhaust fluid ....................137
Diesel fuel system bleeding .......182
Diesel particle filter ...............90, 136
Door open .................................... 92
Doors ............................................ 31
Driver alert .................................. 166
Driver assistance systems ..........147
Driver Information Centre .............93
Driving characteristics and towing tips .............................. 170
Driving hints ................................ 128
E Electric adjustment ......................35
Electrical system......................... 190Electronic climate control system 119
Electronic driving programmes ..142
Electronic key system ...................24
Electronic Stability Control and Traction Control system ....90, 146
Electronic Stability Control and Traction Control system off .......90
End-of-life vehicle recovery .......176
Engine compartment fuse box ...191
Engine coolant ........................... 179
Engine coolant temperature ........90
Engine coolant temperature gauge ....................................... 85
Engine data ............................... 223
Engine exhaust .......................... 136
Engine identification ...................219
Engine oil ................... 178, 215, 220
Engine oil pressure ......................91
Entry lighting .............................. 114
Event data recorders ..................236
Exit lighting ................................ 114
Exterior care .............................. 211
Exterior light ................................. 91
Exterior lighting ....................13, 107
Exterior mirrors ............................. 35
F
Fault ........................................... 142
First aid ......................................... 70
First aid kit ................................... 70Fixed air vents ........................... 125
Fog light ....................................... 92
Fog lights ................................... 185
Folding mirrors ............................. 36
Front airbag system .....................55
Front fog lights ........................... 111
Front seats.................................... 44
Fuel............................................. 167
Fuel consumption - CO 2-
Emissions ............................... 169
Fuel for diesel engines ..............168
Fuel for petrol engines ...............167
Fuel gauge ................................... 85
Funnel......................................... 168
Fuses ......................................... 190
G Gauges ......................................... 83
Gear shifting ................................. 89
General information ...................170
Glass panel .................................. 41
Glovebox ..................................... 64
H
Halogen headlights ....................183
Hand brake ......................... 144, 145
Hazard warning flashers ............110
Headlight flash ........................... 108
Headlight range adjustment ......109
Headlights................................... 107 Head restraint adjustment .............8
