OPEL INSIGNIA BREAK 2017.5 Priručnik za vlasnika (in Croatian)

Tehnički podaci289KarakteristikeMotorB15XHLB15XHTMaksimalna brzina [km/h]Ručni mjenjač210/2133)222/2253)Automatski mjenjač–2183)
ECOMotorB16DTEB16DTHB20DTHMaksimalna brzina [km/h]Ručni mjenjač201/205 3)211226Automatski mjenjač–203–3)
ECO

290Tehnički podaciMasa vozila
Masa praznog vozila, osnovni model bez opcijske opremeMotorRučni mjenjačAutomatski mjenjač[kg]B15XHL1440/1456 3)–B15XHT14401472[kg]B16DTE1503–B16DTH15031522B20DTH1582–3)
ECO
Opcijska i dodatna oprema povećavaju masu praznog vozila.
Informacije o opterećenju 3 76.
Dimenzije vozilaDuljina [mm]4897Širina sa sklopljenim vanjskim ogledalima [mm]1941Širina s rasklopljenim vanjskim ogledalima [mm]2093Visina (bez antene) [mm]1455Visina vozila - dok je stražnji odjeljak otvoren [mm]1893Duljina poda prtljažnika [mm]1133

Tehnički podaci291Duljina prtljažnika s preklopljenim stražnjim sjedalima [mm]1940Širina prtljažnika [mm]1030Visina prtljažnika [mm]497Razmak osovina [mm]2829Promjer kruga okretanja [m]11.75

292Tehnički podaciKoličineUlje motoraMotorB15XHLB15XHTuključujući filter [l]4,04,0između MIN i MAX [l]1,01,0MotorB16DTEB16DTHB20DTHuključujući filter [l]5,05,05,25između MIN i MAX [l]1,01,01,0
Spremnik goriva
Benzin/dizel, količina za ponovno punjenje [l]61
Spremnik sredstva AdBlue
AdBlue, količina za punjenje [l]15

Tehnički podaci293Tlak u gumamaUdobnost s do 3 osobeECO s do 3 osobeS punim opterećenjemMotorGumeprednjestražnjeprednjestražnjeprednjestražnje[kPa/bar]
([psi])[kPa/bar]
([psi])[kPa/bar]
([psi])[kPa/bar]
([psi])[kPa/bar]
([psi])[kPa/bar]
([psi])B15XHL,
B15XHT,
B16DTE,
B16DTH215/60 R16,220/2,2 (32)220/2,2 (32)270/2,7 (39)270/2,7 (39)240/2,4
(35)270/2,7 (39)225/55 R17,245/45 R18,235/45 R18215/55 R17,
225/55 R17 M+S240/2,4 (35)240/2,4 (35)270/2,7 (39)270/2,7 (39)240/2,4
(35)270/2,7 (39)

294Tehnički podaciUdobnost s do 3 osobeECO s do 3 osobeS punim opterećenjemMotorGumeprednjestražnjeprednjestražnjeprednjestražnje[kPa/bar]
([psi])[kPa/bar]
([psi])[kPa/bar]
([psi])[kPa/bar]
([psi])[kPa/bar]
([psi])[kPa/bar]
([psi])B20DTH225/55 R17,220/2,2 (32)220/2,2 (32)270/2,7 (39)270/2,7 (39)260/2,6
(38)290/2,9 (42)245/45 R18,235/50 R18235/45 R18,240/2,4 (35)240/2,4 (35)270/2,7 (39)270/2,7 (39)260/2,6
(38)290/2,9 (42)245/35 R20,
225/55 R17 M+SSviPrivremeni rezervni
kotač
125/80 R16,
125/70 R17420/4,2 (61)420/4,2 (61)––420/4,2
(61)420/4,2 (61)

Informacije stranke295Informacije strankeInformacije stranke....................295
Izjava o sukladnosti .................295
Popravak oštećenja od sudara 297
Potvrda softvera ......................297
Ažuriranje softvera ..................300
Registrirani zaštitni znakovi .....301
Bilježenje i tajnost podataka
vozila .......................................... 302
Snimači podataka događaja ....302
Identifikacija radijske frekvencije (RFID) ..................................... 302Informacije stranke
Izjava o sukladnosti Sustavi radijskog prijenosa Ovo vozilo ima sustave koji odašilju
i/ili primaju radio valove sukladno
Direktivi 1999/5/EC ili2014/53/EU. Ti sustavi zadovoljavaju osnovne
zahtjeve i druge važne propise
Direktive 1999/5/EC ili 2014/53/EU.
Kopije originalnih izjava o sukladnosti
možete preuzeti na našoj web-
stranici.

296Informacije strankeDizalica

Informacije stranke297Prijevod originalne izjave o
sukladnosti
Izjava o sukladnosti prema EC
direktivi 2006/42/EC
Izjavljujemo da je proizvod:
Oznaka proizvoda: Automobilska
dizalica na škare / vijak
Tip/GM broj dijela: 13592351 dizalica
na škare
u suglasnosti s odredbama direktive 2006/42/EC.
Primijenjeni tehnički standardi:GMW 14337:standardna oprema,
dizalica - provjere
hardveraGMW15005:standardna oprema,
dizalica i rezervna
guma, provjera vozilaOsoba ovlaštena za sakupljanje
tehničke dokumentacije je Hans-
Peter Metzger
Menadžer grupe za inženjering,
šasija i konstrukcija
Adam Opel AG
D-65423 Rüsselsheim
potpisuje
Charu Hayes
Menadžer grupe za inženjering za
sustave kotača i guma
Warren, Michigan, 48090
GMNA, USA
26. lipnja 2016.
Popravak oštećenja od sudara
Debljina laka
Zbog tehnika proizvodnje, debljina
laka može varirati između 50 i 400
µm.
Stoga, različite debljine laka nisu
pokazatelj za popravak oštećenja
uslijed sudara.Potvrda softvera
Određene OnStar komponente
uključuju libcurl i unzip softver i drugi
softver trećih strana. Ispod su
napomene i licence u vezi libcurl i
unzip softvera i drugog softvera od
trećih strana, pogledajte http://
www.lg.com/global/support/
opensource/index.
Prijevod potražite ispod izvornog
teksta.
libcurl Copyright and permission notice
Copyright (c) 1996 - 2010, Daniel
Stenberg, .
All rights reserved.
Permission to use, copy, modify, and
distribute this software for any
purpose with or without fee is hereby
granted, provided that the above
copyright notice and this permission
notice appear in all copies.
The software is provided "as is",
without warranty of any kind, express or implied, including but not limited to
the warranties of merchantability,
fitness for a particular purpose and

298Informacije strankenoninfringement of third party rights.
In no event shall the authors or
copyright holders be liable for any
claim, damages or other liability,
whether in an action of contract, tort
or otherwise, arising from, out of or in connection with the software or the
use or other dealings in the software.
Except as contained in this notice, the
name of a copyright holder shall not
be used in advertising or otherwise to promote the sale, use or other
dealings in this Software without prior
written authorization of the copyright
holder.
unzip This is version 2005-Feb-10 of the
Info-ZIP copyright and license. The
definitive version of this document
should be available at ftp://ftp.info-
zip.org/pub/infozip/license.html
indefinitely.
Copyright (c) 1990-2005 Info-ZIP. All
rights reserved.
For the purposes of this copyright and
license, “Info-ZIP” is defined as the
following set of individuals:Mark Adler, John Bush, Karl Davis,
Harald Denker, Jean-Michel Dubois,
Jean-loup Gailly, Hunter Goatley, Ed
Gordon, Ian Gorman, Chris Herborth, Dirk Haase, Greg Hartwig, Robert
Heath, Jonathan Hudson, Paul
Kienitz, David Kirschbaum, Johnny
Lee, Onno van der Linden, Igor
Mandrichenko, Steve P. Miller, Sergio
Monesi, Keith Owens, George
Petrov, Greg Roelofs, Kai Uwe
Rommel, Steve Salisbury, Dave
Smith, Steven M. Schweda, Christian Spieler, Cosmin Truta, Antoine
Verheijen, Paul von Behren, Rich
Wales, Mike White.
This software is provided “as is,” without warranty of any kind, express or implied. In no event shall Info-ZIP
or its contributors be held liable for
any direct, indirect, incidental, special
or consequential damages arising out
of the use of or inability to use this
software.
Permission is granted to anyone to
use this software for any purpose,
including commercial applications,
and to alter it and redistribute it freely,
subject to the following restrictions:1. Redistributions of source code must retain the above copyright
notice, definition, disclaimer, and
this list of conditions.
2. Redistributions in binary form (compiled executables) must
reproduce the above copyright
notice, definition, disclaimer, and
this list of conditions in
documentation and/or other
materials provided with the
distribution. The sole exception to
this condition is redistribution of a
standard UnZipSFX binary
(including SFXWiz) as part of a
self-extracting archive; that is
permitted without inclusion of this
license, as long as the normal
SFX banner has not been
removed from the binary or
disabled.
3. Altered versions--including, but not limited to, ports to new
operating systems, existing ports
with new graphical interfaces, and dynamic, shared, or static library
versions--must be plainly marked
as such and must not be
misrepresented as being the
original source. Such altered
