OPEL KARL 2019 Infotainment system

Phone101PhoneGeneral information...................101
Bluetooth connection .................102
Emergency call .......................... 103
Operation ................................... 104
Text messages .......................... 105
Mobile phones and CB radio
equipment .................................. 106General information
The Phone portal provides you with
the possibility of having mobile phone conversations via a vehicle
microphone and the vehicle
loudspeakers as well as operating the
most important mobile phone
functions via the Infotainment system in the vehicle. To be able to use the
Phone portal, the mobile phone must
be connected to the Infotainment
system via Bluetooth.
Not all Phone functions are supported by every mobile phone. The usable
phone functions depend on the
relevant mobile phone and network
provider. You will find further
information on this in the operating
instructions for your mobile phone, or you can enquire about them with your
network provider.Important information for
operation and traffic safety9 Warning
Mobile phones have effects on
your environment. For this reason, safety regulations and directions
have been prepared. You should
be familiar with the related
directions before you use the
telephone function.
9 Warning
Use of the hands-free facility while
driving can be dangerous because
your concentration is reduced
when telephoning. Park your
vehicle before you use the hands- free facility. Follow the stipulations
of the country in which you find
yourself at present.
Do not forget to follow the special
regulations that apply in specific
areas and always switch off the
mobile phone if the use of mobile
phones is prohibited, if

102Phoneinterference is caused by the
mobile phone or if dangerous
situations can occur.
Bluetooth
The Phone portal is certified by the
Bluetooth Special Interest Group
(SIG).
You will find further information about the specification on the internet at
http://www.bluetooth.com.
Bluetooth connection
Bluetooth is a radio standard for the
wireless connection of e.g. mobile
phones or other devices.
To be able to set up a Bluetooth
connection to the Infotainment
system, the Bluetooth function of the
Bluetooth device must be activated.
For further information, please
consult the operating instructions for
the Bluetooth device.
Via the Phone portal, pairing (PIN
code exchange between Bluetooth
device and Infotainment system) and
connecting of the Bluetooth devices
with the Infotainment system are
carried out.
Pairing a device
Important information ● Up to five devices can be paired to the system.
● Only one paired device can be connected to the Infotainment
system at a time.
● Pairing only needs to be carried out once, unless the device is
deleted from the list of paired
devices. If the device has been connected previously, the
Infotainment system establishes
the connection automatically.
● Bluetooth operation considerably
drains the device's battery.
Therefore, connect the device to
the USB port for charging.
Pairing the first device 1. Press PHONE and then select
Pair .
A message is displayed on the
Infotainment system indicatingthe name and PIN code of the
Infotainment system.
2. Start Bluetooth searching on the Bluetooth device to be paired.
3. Confirm pairing: ● If SSP (secure simple pairing) is supported:
Compare the PIN code (if
demanded) and confirm the
messages on the
Infotainment system and the
Bluetooth device.
● If SSP (secure simple pairing) is not supported:
Enter the Infotainment PIN
code on the Bluetooth device and confirm your input.
4. The Infotainment system and the device are paired. The phonemenu is displayed.
5. If available on the Bluetooth device, phone book and calls lists
are downloaded to the
Infotainment system. If required,
confirm the respective message
on your smartphone.

Phone103Note
For the contacts to be read by the
Infotainment system, they must be
stored in the phone memory of the mobile phone.
Pairing another device
Press PHONE , scroll through the list
and select Bluetooth Devices .
Press Add to start the pairing process
of another device.
Proceed from step 2 of "Pairing the
first device" (see above).
Connecting a paired device Press PHONE , scroll through the list
and select Bluetooth Devices .
Mark the desired device and select Connect .
If necessary, the device currently
connected is disconnected. The
selected device is connected.
Disconnecting a device Press PHONE , scroll through the list
and select Bluetooth Devices .
Mark the device currently connected and select Disconnect .The device is disconnected.
Deleting a device Press PHONE , scroll through the list
and select Bluetooth Devices .
Mark the device you wish to delete
from the device list and select Delete.
The device is deleted.
Emergency call9 Warning
Connection setup cannot be
guaranteed in all situations. For
this reason you should not rely
exclusively on a mobile phone
when a vitally important
communication (e.g. a medical
emergency) is concerned.
In some networks it may be
necessary for a valid SIM card to
be properly inserted in the mobile
phone.
9 Warning
Bear in mind that you can make
and receive calls with the mobile
phone if it is in a service area with a sufficiently strong signal. Under
certain circumstances,
emergency calls cannot be made
on all mobile phone networks; it is
possible that they cannot be made when certain network services
and/or telephone functions are
active. You can enquire about this
with the local network operators.
The emergency call number can
differ depending on the region and country. Please enquire
beforehand about the correct
emergency call number for the
relevant region.
Making an emergency call
Dial the emergency call number (e.g.
112 ).
The telephone connection to the
emergency call centre is set up.
Answer when the service personnel
questions you about the emergency.

104Phone9Warning
Do not end the call until you are
requested to do so by the
emergency call centre.
Operation
As soon as a connection via
Bluetooth has been set up between
your mobile phone and the
Infotainment system, you can operate many functions of your mobile phone
via the Infotainment system.
Note
Not every mobile phone supports all
functions of the Phone portal.
Therefore, deviations from the range
of functions described below are
possible.
Initiating a phone call
Keypad
Press PHONE to display the phone
menu.Scroll through the list and select
Keypad . The keypad is displayed.
Turn MENU to highlight the digit you
wish to enter and then press MENU to
select the respective digit. Enter the
desired number.
Select k or press BACK to delete
digits.
Select Call to initiate the phone call.
Contacts
Press PHONE to display the phone
menu.
Select Contacts . The contacts list is
displayed.
Scroll through the list and select the
desired contacts entry. The contact is displayed.
Select one of the phone numbers
stored under that contact. The
number is dialled.
Calls lists
Press PHONE to display the phone
menu.
Select Recent Calls . The recent calls
list is displayed.
Depending on which call you are searching for, select Missed,
Received or Sent .
Select one of the phone numbers
stored in the recent calls list. The
number is dialled.
Incoming phone call
Taking a phone call
If a radio or media source is active
when a call comes in, the audio
source is muted and remains muted
until the call is ended.
A message with the caller's name or
number is displayed.

Phone105
To answer the call, select Answer.
Rejecting a phone call
To reject the call, select Ignore in the
message.
Functions during a phone call During a phone call, the in-call view is displayed.
Ending a phone call
Select End to end the call.
Deactivating the microphone
Select Mute to temporarily deactivate
the microphone.
The screen button changes to
Unmute .
To reactivate the microphone, select
Unmute .
Deactivating the hands-free function
To continue the conversation on your mobile phone, select Handset.
The screen button changes to Hands-
free .
To reactivate the hands-free function,
select Hands-free .
Second incoming phone call If a second phone call comes in,
another message with the caller's
name or number is displayed.
To answer the second call and place
the first call on hold, select Switch.
To reject the call, select Ignore in the
message.
Switching between the phone calls
Press PHONE or qw on the steering
wheel audio control to toggle between the two calls.
Information on the call currently
active is shown on the display.Ending the phone calls
The calls can be ended one at a time.
Select End. The call currently active
is ended.
Text messages
Text messages which are received
while a phone is connected to the
Infotainment system can be displayed on the Info-Display.
Prerequisites The following prerequisites must be
met:
● The Bluetooth function of the respective phone must be
activated (see the operating
instructions for your device).
● Dependent on the phone, it may be required to set the device to
"visible" (see the operating
instructions for your device).

106Phone● The respective phone must bepaired and connected to the
Infotainment system. For a
detailed description 3 102.
● The respective phone must support Bluetooth Message
Access Profile (BT MAP).
Viewing a message Note
If the vehicle is going faster than
8 km/h, the text message is not
displayed on the screen.
When a new text message is
received, a message is displayed.
Select View to read the message.
Mobile phones and CB radio
equipment
Installation instructions and
operating guidelines
The vehicle specific installation
instructions and the operating
guidelines of the mobile phone and
hands-free manufacturer must be
observed when installing and
operating a mobile telephone. Failure to do so could invalidate the vehicletype approval (EU directive 95/54/
EC).
Recommendations for fault-free
operation:
● The exterior antenna must be professionally installed to obtain
the maximum range possible.
● Maximum transmission power: 10 watts.
● The mobile phone must be installed in a suitable spot.
Consider relevant note in the
Owner's Manual, chapter Airbag
system .Seek advice on predetermined
installation points for the external
antenna or equipment holder and
ways of using devices with a
transmission power exceeding
10 watts.
Use of a hands-free attachment
without external antenna with mobile
telephone standards GSM
900/1800/1900 and UMTS is only
permitted if the maximum
transmission power of the mobile
telephone is 2 watts for GSM 900 or 1 watt for the other types.
For reasons of safety, do not use the
phone while driving. Even use of a hands-free set can be a distraction
while driving.9 Warning
Operation of radio equipment and
mobile telephones which fail to
meet above mentioned mobile
telephone standards is only
permitted using an antenna
located outside of the vehicle.

Phone107Caution
Mobile telephones and radio
equipment may lead to
malfunctions in the vehicle
electronics when operated inside
the vehicle with no exterior
antenna, unless the above
mentioned regulations are
observed.

108IndexAActivating AUX.............................. 99
Activating Bluetooth music ...........99
Activating radio ............................. 92
Activating the Infotainment system 86
Activating the phone portal .........104
Activating USB.............................. 99
Audio files ..................................... 97
Auto Set ........................................ 89
Auto volume control ......................89
AUX .............................................. 97
B BACK button ................................. 88
Basic operation ............................. 88
Control panel ............................. 88
Bluetooth connection ..................102
Bluetooth music ............................ 97
C Category list.................................. 92
Control elements Infotainment system ..................82
Steering wheel .......................... 82
Control elements overview ...........82
D
DAB .............................................. 94
DAB linking ................................... 94
Digital audio broadcasting ............94E
Emergency call ........................... 103
F
Favourite lists ............................... 93
Retrieving stations..................... 93
Storing stations ......................... 93
File formats Audio files.................................. 97
Frequency list ............................... 92
G General information ......97, 100, 101
AUX ........................................... 97
Bluetooth music......................... 97
Infotainment system ..................80
Phone ...................................... 101
Radio ......................................... 92
USB ........................................... 97
I Infotainment control panel ............82
Intellitext ....................................... 94
L
Language ..................................... 89
L-Band .......................................... 94
M
Maximum startup volume .............89
MENU knob .................................. 88
Menu operation............................. 88

109Mobile phones and CB radioequipment .............................. 106
Mute.............................................. 86
O Operation .................................... 104
AUX ........................................... 99
Bluetooth music......................... 99
Infotainment system ..................86
Menu ......................................... 88
Phone ...................................... 104
Radio ......................................... 92
USB ........................................... 99
P Pairing ........................................ 102
Phone Bluetooth ................................. 101
Bluetooth connection ..............102
Emergency calls ......................103
General information ................101
Hands-free mode ....................104
Phone book ............................. 104
Recent calls............................. 104
Ringtone .................................. 104
Text messages ........................ 105
Phone book ................................ 104Phone call
Initiating ................................... 104
Rejecting ................................. 104
Taking ..................................... 104
Playing audio ................................ 99
R Radio Category list .............................. 92
DAB ........................................... 94
DAB announcements ................94
DAB menu ................................. 94
Digital audio broadcasting .........94
Favourite lists ............................ 93
FM menu ................................... 94
Frequency list ............................ 92
Intellitext .................................... 94
L-Band....................................... 94
Radio data system ....................94
RDS........................................... 94
Region ....................................... 94
Regionalisation ......................... 94
Retrieving stations..................... 93
Station list.................................. 92
Station search ........................... 92
Storing stations ......................... 93
TP.............................................. 94 Traffic programme .....................94
Waveband ................................. 92
Radio data system .......................94Region.......................................... 94
Regionalisation ............................. 94
Restore factory settings ................89
Retrieving stations ........................93
Ringtone ..................................... 104
S
Speech recognition .....................100
Station list ..................................... 92
Station search............................... 92
Storing stations ............................. 93
Switching the Infotainment system on .................................. 86
System settings ............................ 89
Language .................................. 89
Restore factory settings ............89
Time and date ........................... 89
Valet mode ................................ 89
T
Text messages ........................... 105
Theft-deterrent feature ................. 81
Time.............................................. 89
Tone settings ................................ 88
TP ................................................. 94
Traffic programme ........................94
U
Usage ............................. 86, 92, 100
AUX ........................................... 99
Bluetooth music......................... 99

110Infotainment system..................86
Menu ......................................... 88
Phone ...................................... 104
USB ........................................... 99
USB .............................................. 97
V Valet mode Locking ...................................... 89
Unlocking .................................. 89
Voice recognition ........................100
Volume Auto volume control ..................89
Maximum startup volume ..........89
Mute function............................. 86
Setting the volume ....................86
Speed compensated volume ....89
Volume limitation at high
temperatures ............................. 86
Volume settings ............................ 89
W
Waveband selection .....................92
