fuse box OPEL MOKKA X 2019.5 Manual user

In brief111Central locking system ..........25
2 Power windows .....................35
3 Exterior mirrors .....................33
4 Light switch ......................... 111
5 Cruise control ...................... 150
Speed limiter ....................... 152
Forward collision alert .........153
6 Side air vents ...................... 126
7 Turn lights ........................... 118
Headlight flash ....................113
Low beam and high beam ..112
Buttons for Driver
Information Centre ................97
8 Instruments ........................... 84
9 Steering wheel controls .......77
10 Windscreen wiper,
windscreen washer system ...78
Rear window wiper, rear
window washer system .........80
11 Centre air vents ................... 126
12 Anti-theft alarm system
status LED ........................... 31
13 Info Display ........................ 10214Controls for Info Display
operation ............................. 102
15 Glovebox .............................. 59
16 Descent control system ......... 94
Fuel selector ......................... 86
Stop-start system ................134
17 Climate control system ........ 122
18 Electronic Stability Control
(ESC) .................................. 148
19 Control indicator for airbag
deactivation .......................... 93
20 Front storage ......................... 60
Power outlet .......................... 83
USB port, AUX input
21 Selector lever, manual
transmission ....................... 144
Selector lever, automatic
transmission ....................... 141
22 Parking brake ......................146
23 Hazard warning flashers ....117
24 Parking assist ..................... 156
Lane departure warning ......16325Ignition switch with
steering wheel lock ............130
Power button ....................... 131
26 Horn ..................................... 78
Driver airbag ........................ 50
27 Steering wheel adjustment ..77
28 Bonnet release lever ..........177
29 Front storage ......................... 60
Fuse box ............................ 190

Vehicle care175Vehicle careGeneral Information...................175
Accessories and vehicle modifications .......................... 175
Vehicle storage ........................176
End-of-life vehicle recovery .....176
Vehicle checks ........................... 177
Performing work ......................177
Bonnet ..................................... 177
Engine oil ................................. 178
Engine coolant ......................... 179
Power steering fluid .................179
Washer fluid ............................ 180
Brakes ..................................... 180
Brake fluid ............................... 180
Vehicle battery ......................... 181
Diesel fuel system bleeding .....182
Wiper blade replacement ........182
Bulb replacement .......................183
Halogen headlights ..................184
Front fog lights ......................... 185
Tail lights ................................. 186
Number plate light ...................187
Rear fog light ........................... 187
Electrical system ........................188
Fuses ....................................... 188Engine compartment fuse box . 189
Instrument panel fuse box .......190
Load compartment fuse box ....192
Vehicle tools .............................. 194
Tools ........................................ 194
Wheels and tyres .......................194
Winter tyres ............................. 194
Tyre designations ....................195
Tyre pressure .......................... 195
Tyre pressure monitoring system .................................... 196
Tread depth ............................. 200
Changing tyre and wheel size . 201
Wheel covers ........................... 201
Tyre chains .............................. 201
Tyre repair kit .......................... 202
Wheel changing .......................205
Spare wheel ............................ 206
Jump starting ............................. 209
Towing ....................................... 211
Towing the vehicle ...................211
Towing another vehicle ...........212
Appearance care .......................213
Exterior care ............................ 213
Interior care ............................. 215General Information
Accessories and vehicle modifications
We recommend the use of genuine
parts and accessories and factory
approved parts specific for your
vehicle type. We cannot assess or
guarantee reliability of other products
- even if they have a regulatory or
otherwise granted approval.
Any modification, conversion or other
changes made to standard vehicle
specifications (including, without
limitation, software modifications,
modifications of the electronic control units) may invalidate the warrantyoffered by Opel. Furthermore, such
changes may affect driver assistance
systems, fuel consumption, CO 2
emissions and other emissions of the
vehicle. They may also invalidate the
vehicle operating permit.

Vehicle care181
The brake fluid level must be betweenthe MIN and the MAX marks.
If fluid level is below MIN seek the
assistance of a workshop.
Brake and clutch fluid 3 217.
Vehicle battery
The vehicle battery is maintenance-
free provided that the driving profile
allows sufficient charging of the
battery. Short-distance-driving and
frequent engine starts can discharge
the battery. Avoid the use of
unnecessary electrical consumers.
Batteries do not belong in household
waste. They must be disposed of at
an appropriate recycling collection
point.
Laying up the vehicle for more than
four weeks can lead to battery
discharge. Disconnect the clamp from the negative terminal of the vehicle
battery.
Ensure the ignition is switched off
before connecting or disconnecting
the vehicle battery.
Vehicle battery discharge protection
3 121.
Replacing the vehicle battery Note
Any deviation from the instructions
given in this section may lead to
temporary deactivation or
disturbance of the stop-start system.
When the vehicle battery is being
replaced, please ensure that there
are no open ventilation holes in the
vicinity of the positive terminal. If a
ventilation hole is open in this area, it
must be closed off with a dummy cap,
and the ventilation in the vicinity of the negative terminal must be opened.
Only use vehicle batteries that allow the fuse box to be mounted above the
vehicle battery.
Ensure that the battery is always replaced by the same type of battery.
We recommend that you have the
vehicle battery replaced by a
workshop.
Stop-start system 3 134.
Charging the vehicle battery9 Warning
On vehicles with stop-start
system, ensure that the charging
potential does not exceed 14.6 V

188Vehicle care
1.Turn the bulb holder anticlockwise
and remove it from reflector.
2. Disengage the bulb socket from the plug connector by pressing
the retaining lug.
3. Remove and replace the bulb socket with bulb and attach the
plug connector.
4. Insert the bulb socket into the reflector and turn clockwise to
engage.Electrical system
Fuses
Data on the replacement fuse must
match the data on the defective fuse.
In a box above the positive terminal of
the battery are some main fuses. If
necessary have them changed by a workshop.
Before replacing a fuse, turn off the
respective switch and the ignition.
A blown fuse can be recognised by its melted wire. Do not replace the fuse
until the cause of the fault has been
remedied.
Some functions are protected by
several fuses.
Fuses may also be inserted without existence of a function.
Note
Not all fuse box descriptions in this
manual may apply to your vehicle.
When inspecting the fuse box, refer
to the fuse box label.

Vehicle care189Fuse extractorA fuse extractor may be located in the fuse box in the engine compartment.
Place the fuse extractor on the
various types of use from the top or
side, and withdraw fuse.
Engine compartment fusebox
The fuse box is in the engine
compartment.
Disengage the cover, lift it upwards
and remove.
Mini FusesNo.Circuit1Sunroof2Exterior mirror switch / Rain
sensor / Power window DRV3–4–5Electrical brake control module6Intelligent battery sensor7Steering column lock8Transmission control module9–10Rear view camera / Interior rear
view mirror / Headlight switch /
Headlight11Rear window wiper12Heated rear window13Seat, lumbar support14Heated exterior mirrors

190Vehicle careNo.Circuit15LPG module / Fuel system
control module16Seat heating17Transmission control module R/ C / Water pump / Auxiliary
heater18Engine control module R/C19Fuel pump20–21Cooling fan22–23Ignition coil / Injectors24Washer pump25Headlamp actuator26Engine control sensors27–28Ignition29Ignition 1/2No.Circuit30Exhaust system31Left-hand high beam32Right-hand high beam33Engine control module34Horn35Air conditioning system36Front fog light
J-cases Fuses
No.Circuit1Electrical brake control module2Front wiper3Linear power module4Power terminal of instrument
panel fuse box5–6Fuel heater7StarterNo.Circuit8Cooling fan9Cooling fan10Engine control module / Glow
plug11Starter
Instrument panel fuse box
In left-hand drive vehicles, the interior fuse box is located on the underside
of the driver's side instrument panel.

Vehicle care191To access the fuses, remove the
storage. To remove the storage, open
and pull it.
In right-hand drive vehicles, the
interior fuse box is located behind a
cover in the glovebox on the
passenger side. To access the fuses, open the glovebox, then open the
cover, fold it down and pull it.
Mini FusesNo.Circuit1Body control module2Body control module3Body control module4Body control module5Body control module6Body control module7Body control module8Body control module9Ignition switch10Safety diagnosis module11Data link connector12Climate control13Tailgate14Central gateway module15Lane departure warning / Inte‐
rior mirror

192Vehicle careNo.Circuit16Adaptive forward lighting17Column lock18Ultrasonic park assist module19Body control module / Regu‐
lated voltage control20Steering wheel21–22Cigarette lighter / DC accessory power outlet (front)23Cigarette lighter / DC accessory
power outlet (rear center
console)24Spare25Telematics service module26Heated steering wheel27Instrument panel cluster / Info‐
tainment system / Auxiliary
heater switch28Trailer socketNo.Circuit29Info Display / Infotainment
system30Transmission control module31Instrument panel cluster32Infotainment system33Trailer socket34Passive entry / Passive start
module
S/B Fuses
No.Circuit01Power seat switch02Spare03Power windows front04Power windows rear05Logistic mode06Power seat switchNo.Circuit07Spare08Spare
Midi Fuse
No.CircuitM01PTC
Load compartment fuse box
Located in the left side of rear
compartment.
To access the fuses, remove the cover.

241Control indicators.......................... 88
Control of the vehicle .................129
Controls ........................................ 77
Convex shape .............................. 33
Coolant and antifreeze ...............217
Cruise control ...................... 96, 150
Cupholders .................................. 59
Curtain airbag system .................. 51
D Danger, Warnings and Cautions ...4
Daytime running lights ...............115
Declaration of conformity ............231
DEF ............................................ 139
Delayed locking ............................ 28
Descent control system .......94, 149
Diesel exhaust fluid ....................139
Diesel fuel system bleeding .......182
Door open .................................... 97
Doors ............................................ 30
Driver assistance systems ..........150
Driver Information Centre .............97
Driving characteristics and towing tips .............................. 171
Driving hints ................................ 129
E Electric adjustment ......................33
Electrical system......................... 188
Electronic climate control system 124
Electronic driving programmes ..143Electronic key system ...................23
Electronic Stability Control.......... 148
Electronic Stability Control and Traction Control system ............94
Electronic Stability Control off....... 94
End-of-life vehicle recovery .......176
Engine compartment fuse box ...189
Engine coolant ........................... 179
Engine coolant temperature gauge ....................................... 87
Engine data ............................... 224
Engine exhaust .......................... 137
Engine identification ...................220
Engine oil ................... 178, 217, 221
Engine oil pressure ......................95
Entry lighting .............................. 120
Event data recorders ..................236
Exhaust filter ............................... 137
Exit lighting ................................ 121
Exterior care .............................. 213
Exterior light ................................. 96
Exterior lighting ....................13, 111
Exterior mirrors ............................. 33
F
Fault ........................................... 143
First aid kit ................................... 73
Fixed air vents ........................... 127
Flex-Fix system ............................ 61
Folding mirrors ............................. 33Following distance indication ......155
Forward collision alert................. 153
Front airbag system .....................50
Front fog lights .............96, 118, 185
Front seats.................................... 40
Front storage ................................ 60
Fuel............................................. 164
Fuel for diesel engines ..............166
Fuel for liquid gas operation .......166
Fuel for petrol engines ...............164
Fuel gauge ................................... 85
Fuel selector ................................ 86
Fuses ......................................... 188
G
Gauges ......................................... 84
Gear shifting ................................. 94
General information ...................171
Glovebox ..................................... 59
Glove box lighting .......................120
H Halogen headlights ....................184
Hand brake ................................. 146
Hazard warning flashers ............117
Headlight flash ........................... 113
Headlight range adjustment ......114
Headlights when driving abroad 114
Head restraint adjustment .............8
Head restraints ............................ 39
Heated mirrors ............................. 34

242Heated rear window ..................... 37
Heated steering wheel .................77
Heating ........................................ 43
Heating and ventilation system . 122
High beam ........................... 96, 112
High beam assist ..................96, 113
Hill start assist ........................... 147
Horn ....................................... 14, 78
I
Identification plate .....................219
Ignition switch positions .............130
Immobiliser ............................ 32, 96
Indicators ...................................... 84
Info Display ................................. 102
Information displays...................... 97
Initial drive information.................... 6
Instrument panel fuse box .........190
Instrument panel illumination control .................................... 119
Instrument panel overview ........... 10
Interior care ............................... 215
Interior lighting ............................ 119
Interior lights .............................. 119
Interior mirrors .............................. 34
Interruption of power supply ......144
Introduction .................................... 3
J
Jump starting ............................. 209K
Key, memorised settings ..............25
Keys ............................................. 21
Keys, locks ................................... 21
L
Lane departure warning .......94, 163
Lashing eyes ............................... 73
Lighting features .........................120
Light switch ................................ 111
Load compartment ................30, 71
Load compartment cover .............72
Load compartment fuse box ......192
Loading information .....................74
Low fuel ....................................... 95
LPG .............................. 86, 166, 221
M Malfunction indicator light ............93
Manual anti-dazzle ......................34
Manual mode ............................. 143
Manual transmission .................. 144
Manual windows ..........................35
Memorised settings ......................25
Midlevel display ............................ 97
Mirror adjustment ........................... 8
Misted light covers .....................119
N New vehicle running-in ..............129
Number plate light .....................187O
Object detection systems ...........156
Odometer ..................................... 84
Oil, engine .......................... 217, 221
Outside temperature ....................80
Overrun cut-off ........................... 134
P Parking ................................ 19, 136
Parking assist ............................ 156
Parking brake ............................ 146
Particulate filter ........................... 137
Performance .............................. 226
Performing work ........................177
Power button .............................. 131
Power outlets ............................... 83
Power steering fluid ....................179
Power windows ............................ 35
Preheating ................................... 95
Puncture ..................................... 205
R Radio Frequency Identification (RFID) ..................................... 239
Radio remote control ...................22
REACH ....................................... 234
Reading lights ............................ 120
Rear carrier system ......................61
Rear floor storage cover ..............73
Rear fog light ...............96, 118, 187
Rear view camera ...................... 158
