traction control OPEL MOKKA X 2019.5 Manual user

76Instruments and controlsInstruments and
controlsControls ....................................... 77
Steering wheel adjustment ........77
Steering wheel controls .............77
Heated steering wheel ...............77
Horn ........................................... 78
Windscreen wiper and washer ..78
Rear window wiper and washer ...................................... 80
Outside temperature ..................80
Clock ......................................... 81
Power outlets ............................. 83
Warning lights, gauges and indi‐ cators ........................................... 84
Speedometer ............................. 84
Odometer .................................. 84
Trip odometer ............................ 84
Tachometer ............................... 85
Fuel gauge ................................ 85
Fuel selector .............................. 86
Engine coolant temperature gauge ....................................... 87
Service display .......................... 87
Control indicators ......................88
Turn lights .................................. 92Seat belt reminder.....................92
Airbag and belt tensioners .........92
Airbag deactivation ....................93
Charging system .......................93
Malfunction indicator light ..........93
Brake and clutch system ...........93
Antilock brake system (ABS) .....94
Gear shifting .............................. 94
Descent control system .............94
Lane departure warning ............94
Electronic Stability Control off ...94
Electronic Stability Control and Traction Control system ...........94
Traction Control system off .......95
Preheating ................................. 95
AdBlue ....................................... 95
Tyre pressure monitoring system ...................................... 95
Engine oil pressure ....................95
Low fuel ..................................... 95
Immobiliser ................................ 96
Exterior light .............................. 96
High beam ................................. 96
High beam assist .......................96
Adaptive forward lighting ...........96
Front fog lights ........................... 96
Rear fog light ............................. 96
Cruise control ............................ 96
Vehicle detected ahead .............97
Speed limiter ............................. 97Traffic sign assistant ..................97
Door open .................................. 97
Displays ....................................... 97
Driver Information Centre ..........97
Info Display .............................. 102
Vehicle messages ......................104
Warning chimes .......................105
Battery voltage ........................ 105
Vehicle personalisation ..............106

Instruments and controls91Control indicators in the centre
console
Overview
OTurn signal 3 92XSeat belt reminder, driver
3 92kSeat belt reminder, front
passenger 3 92vAirbag and belt tensioners
3 92V /
*Airbag deactivation 3 93pCharging system 3 93ZMalfunction indicator light
3 93RBrake and clutch system
3 93uAntilock brake system (ABS)
3 94RGear shifting 3 94uDescent control system
3 94)Lane departure warning
3 94nElectronic Stability Control off
3 94bElectronic Stability Control
and Traction Control system
3 94kTraction Control system off
3 95!Preheating 3 95ùAdBlue 3 95wTyre pressure monitoring
system 3 95IEngine oil pressure 3 95YLow fuel 3 95dImmobiliser 3 968Exterior light 3 96CHigh beam 3 96fHigh beam assist 3 96fAdaptive forward lighting
3 96>Fog light 3 96rRear fog light 3 96mCruise control 3 96AVehicle detected ahead
3 97LSpeed limiter 3 97LTraffic sign assistant 3 97hDoor open 3 97

94Instruments and controls9Warning
Stop. Do not continue your
journey. Consult a workshop.
Illuminates when the manual parking
brake is applied and ignition is
switched on 3 146.
Antilock brake system (ABS)
u illuminates yellow.
Illuminates for a few seconds after the ignition is switched on. The system is
ready for operation when the control
indicator extinguishes.
If the control indicator does not
extinguish after a few seconds, or if it illuminates while driving, there is a
fault in the ABS. The brake system
remains operational but without ABS
regulation.
Antilock brake system 3 146.
Gear shifting
R or S with the number of a higher or
lower gear is indicated, when up- or
downshifting is recommended for fuel
saving reasons.
Descent control system u illuminates or flashes green.
Illuminates green
The system is ready for operation.
Flashes green
The system is in operation.
Lane departure warning
) illuminates green or flashes yellow.
Illuminates green
System is switched on and ready to
operate.
Flashes yellow
System recognises an unintended
lane change.
Lane departure warning 3 163.Electronic Stability Control
off
n illuminates yellow.
The system is deactivated.
Electronic Stability Control
and Traction Control system
b illuminates or flashes yellow.
Illuminates A fault in the system is present.
Continued driving is possible. Driving
stability, however, may deteriorate depending on road surface
conditions.
Have the cause of the fault remedied
by a workshop.
Flashes
The system is actively engaged.
Engine output may be reduced and
the vehicle may be braked
automatically to a small degree.
Electronic Stability Control 3 148.
Traction Control system 3 147.

Instruments and controls95Traction Control system off
k illuminates yellow.
The system is deactivated.
Preheating
! illuminates yellow.
Preheating of diesel engine is
activated. Only activates when
outside temperature is low.
AdBlue
ù flashes yellow.
AdBlue level is low. Refill AdBlue soon to avoid prevention of the
engine start.
AdBlue 3 139.
Tyre pressure monitoring system
w illuminates or flashes yellow.
Illuminates
Tyre pressure loss. Stop immediately and check tyre pressure.Flashes
Fault in system or tyre without
pressure sensor mounted (e.g. spare
wheel). After 60-90 seconds the
control indicator illuminates
continuously. Consult a workshop.
Tyre pressure monitor system
3 196.
Engine oil pressure
I illuminates red.
Illuminates when the ignition is
switched on and extinguishes shortly
after the engine starts.
Illuminates when the engine is
runningCaution
Engine lubrication may be
interrupted. This may result in
damage to the engine and/or
locking of the drive wheels.
1. Depress clutch.
2. Select neutral gear, set selector lever to N.
3. Move out of the flow of traffic as
quickly as possible without
impeding other vehicles.
4. Switch off ignition.9 Warning
When the engine is off,
considerably more force is needed
to brake and steer. During an
Autostop the brake servo unit will still be operational.
Do not remove key until vehicle is stationary, otherwise the steeringwheel lock could engage
unexpectedly.
Keep engine turned off and let the
vehicle be towed to a workshop
3 178.
Low fuel Y illuminates or flashes yellow.
Illuminates
Level in fuel tank is too low.

128Driving and operatingDriving and
operatingDriving hints ............................... 129
Control of the vehicle ...............129
Steering ................................... 129
Starting and operating ...............129
New vehicle running-in ............129
Ignition switch positions ...........130
Power button ........................... 131
Retained power off ..................132
Starting the engine ..................132
Overrun cut-off ........................ 134
Stop-start system ....................134
Parking .................................... 136
Engine exhaust .......................... 137
Exhaust filter ............................ 137
Catalytic converter ...................138
AdBlue ..................................... 139
Automatic transmission ..............141
Transmission display ...............141
Selector lever .......................... 142
Manual mode ........................... 143
Electronic driving programmes 143
Fault ........................................ 143
Interruption of power supply ....144Manual transmission ..................144
Drive systems ............................ 145
All-wheel drive ......................... 145
Brakes ........................................ 146
Antilock brake system .............146
Parking brake .......................... 146
Brake assist ............................. 147
Hill start assist ......................... 147
Ride control systems .................147
Traction Control system ..........147
Electronic Stability Control ......148
Descent control system ...........149
Driver assistance systems .........150
Cruise control .......................... 150
Speed limiter ........................... 152
Forward collision alert .............153
Following distance indication ...155
Parking assist .......................... 156
Rear view camera ...................158
Traffic sign assistant ................160
Lane departure warning ..........163
Fuel ............................................ 164
Fuel for petrol engines .............164
Fuel for diesel engines ............166
Fuel for liquid gas operation ....166
Refuelling ................................ 167
Trailer hitch ................................ 171
General information .................171Driving characteristics and
towing tips .............................. 171
Trailer towing ........................... 172
Towing equipment ...................172

Driving and operating1479Warning
Always apply parking brake firmly
without operating the release
button, and apply as firmly as
possible on a downhill or uphill
slope.
To release the parking brake, pull
the lever up slightly, press the
release button and fully lower the
lever.
To reduce the operating forces of
the parking brake, depress the
brake pedal at the same time.
Control indicator R 3 93.
Brake assist
If the brake pedal is depressed
quickly and forcefully, maximum
brake force is automatically applied
(full braking).
Maintain steady pressure on the
brake pedal for as long as full braking is required. Maximum brake force is
automatically reduced when the
brake pedal is released.
Hill start assist
The system helps prevent unintended movement when driving away on
inclines.
When releasing the brake pedal after
stopping on an incline, the brakes
remain on for a further two seconds.
The brakes release automatically as
soon as the vehicle begins to
accelerate.
The hill start assist is not active during
an Autostop.
Stop-start system 3 134.Ride control systems
Traction Control system The Traction Control system (TC) is a component of the Electronic Stability
Control (ESC) 3 148.
TC improves driving stability when necessary, regardless of the type of
road surface or tyre grip, by
preventing the drive wheels from
spinning.
As soon as the drive wheels starts to spin, engine output is reduced and
the wheel spinning the most is braked
individually. This considerably
improves the driving stability of the
vehicle on slippery road surfaces.
TC is operational after each engine
start as soon as the control indicator
b extinguishes.
When TC operates b flashes.

148Driving and operating9Warning
Do not let this special safety
feature tempt you into taking risks
when driving.
Adapt speed to the road
conditions.
Control indicator b 3 94.
Deactivation
TC can be switched off when spinning of drive wheels is required: press b
briefly.
Control indicator k illuminates.
A status message appears in the
Driver Information Centre when TC is
deactivated.
When TC is deactivated, ESC
remains active but with higher control threshold.
TC is reactivated by pressing b
again. A status message pops up in the Driver Information Centre when
TC is reactivated.
TC is also reactivated the next time
the ignition is switched on.
Fault
If there is a fault in the system the
control indicator b illuminates
continuously and a message appears in the Driver Information Centre. The
system is not operational.
Have the cause of the fault remedied
by a workshop.
Electronic Stability Control
Electronic Stability Control (ESC)
improves driving stability when
necessary, regardless of the type of
road surface or tyre grip.
As soon as the vehicle starts to
swerve (understeer / oversteer),
engine output is reduced and the wheels are braked individually.
ESC operates in combination with the Traction Control system (TC). It
prevents the drive wheels from
spinning.
ESC is operational after each engine
start as soon as the control indicator
b extinguishes.
When ESC operates b flashes.

Driving and operating151Press m: control indicator m in
instrument cluster illuminates white.
Activation of the functionality
Accelerate to the desired speed and
turn thumb wheel to SET/-: the
current speed is stored and
maintained. Control indicator m in
instrument cluster illuminates green.
On Uplevel display m illuminates
green and set speed is indicated.
Accelerator pedal can be released.
Vehicle speed can be increased by depressing the accelerator pedal.
When the accelerator pedal is
released, the previously stored speed
is resumed.
Cruise control remains activated
while gearshifting.
Increase speed
With cruise control active, hold thumb
wheel turned to RES/+ or briefly turn
to RES/+ repeatedly: speed
increases continuously or in small
increments.
Alternatively accelerate to the desired speed and store by turning to SET/-.
Reduce speed
With cruise control active, hold thumb
wheel turned to SET/- or briefly turn to
SET/- repeatedly: speed decreases
continuously or in small increments.
Deactivation of the functionality
Press y: control indicator m in
instrument cluster illuminates white.
On Uplevel display m changes to
white.
Cruise control is deactivated, but not
switched off. Last stored speed
remains in memory for later speed
resume.
Automatic deactivation: ● Vehicle speed is below approx. 30 km/h.
● Vehicle speed drops more than 25 km/h below the set speed.
● The brake pedal is depressed.
● The clutch pedal is depressed for
a few seconds.
● Selector lever is in N.
● Engine speed is in a very low range.
● The Traction Control system (TC)
or Electronic Stability Control
(ESC) is operating.

241Control indicators.......................... 88
Control of the vehicle .................129
Controls ........................................ 77
Convex shape .............................. 33
Coolant and antifreeze ...............217
Cruise control ...................... 96, 150
Cupholders .................................. 59
Curtain airbag system .................. 51
D Danger, Warnings and Cautions ...4
Daytime running lights ...............115
Declaration of conformity ............231
DEF ............................................ 139
Delayed locking ............................ 28
Descent control system .......94, 149
Diesel exhaust fluid ....................139
Diesel fuel system bleeding .......182
Door open .................................... 97
Doors ............................................ 30
Driver assistance systems ..........150
Driver Information Centre .............97
Driving characteristics and towing tips .............................. 171
Driving hints ................................ 129
E Electric adjustment ......................33
Electrical system......................... 188
Electronic climate control system 124
Electronic driving programmes ..143Electronic key system ...................23
Electronic Stability Control.......... 148
Electronic Stability Control and Traction Control system ............94
Electronic Stability Control off....... 94
End-of-life vehicle recovery .......176
Engine compartment fuse box ...189
Engine coolant ........................... 179
Engine coolant temperature gauge ....................................... 87
Engine data ............................... 224
Engine exhaust .......................... 137
Engine identification ...................220
Engine oil ................... 178, 217, 221
Engine oil pressure ......................95
Entry lighting .............................. 120
Event data recorders ..................236
Exhaust filter ............................... 137
Exit lighting ................................ 121
Exterior care .............................. 213
Exterior light ................................. 96
Exterior lighting ....................13, 111
Exterior mirrors ............................. 33
F
Fault ........................................... 143
First aid kit ................................... 73
Fixed air vents ........................... 127
Flex-Fix system ............................ 61
Folding mirrors ............................. 33Following distance indication ......155
Forward collision alert................. 153
Front airbag system .....................50
Front fog lights .............96, 118, 185
Front seats.................................... 40
Front storage ................................ 60
Fuel............................................. 164
Fuel for diesel engines ..............166
Fuel for liquid gas operation .......166
Fuel for petrol engines ...............164
Fuel gauge ................................... 85
Fuel selector ................................ 86
Fuses ......................................... 188
G
Gauges ......................................... 84
Gear shifting ................................. 94
General information ...................171
Glovebox ..................................... 59
Glove box lighting .......................120
H Halogen headlights ....................184
Hand brake ................................. 146
Hazard warning flashers ............117
Headlight flash ........................... 113
Headlight range adjustment ......114
Headlights when driving abroad 114
Head restraint adjustment .............8
Head restraints ............................ 39
Heated mirrors ............................. 34

243Rear window wiper and washer ..80
Recommended fluids and lubricants ........................ 217, 221
Refuelling ................................... 167
Registered trademarks ...............235
Retained power off .....................132
Reversing lights .........................118
Ride control systems ..................147
Roof .............................................. 37
Roof load ...................................... 74
Roof rack ..................................... 74
S Seat adjustment ....................... 6, 41
Seat belt ........................................ 8
Seat belt reminder .......................92
Seat belts ..................................... 44
Seat heating ................................. 43
Seat position ................................ 40
Selective catalytic reduction .......139
Selector lever ............................. 142
Service ....................................... 127
Service display ............................ 87
Service information ....................216
Side airbag system ......................51
Software acknowledgement .......234
Spare wheel ............................... 206
Speed limiter......................... 97, 152
Speedometer ............................... 84
Starting and operating ................129Starting off ................................... 17
Starting the engine ....................132
Steering ...................................... 129
Steering wheel adjustment ......9, 77
Steering wheel controls ...............77
Stop-start system........................ 134
Storage compartments .................59
Sunroof ........................................ 37
Sunvisor lights ........................... 120
Sun visors .................................... 37
Symbols ......................................... 4
T
Tachometer ................................. 85
Tail lights ................................... 186
Three-point seat belt .................... 45
Tools .......................................... 194
Tow bar....................................... 171
Towing ................................ 171, 211
Towing another vehicle .............212
Towing equipment .....................172
Towing the vehicle .....................211
Traction Control system ............. 147
Traction Control system off........... 95
Traffic sign assistant .............97, 160
Trailer towing ............................. 172
Transmission ............................... 17
Transmission display .................141
Tread depth ............................... 200
Trip odometer .............................. 84Turn lights ............................ 92, 118
Tyre chains ................................ 201
Tyre designations ......................195
Tyre pressure ............................ 195
Tyre pressure monitoring system ............................... 95, 196
Tyre pressures ........................... 230
Tyre repair kit ............................. 202
U Ultrasonic parking assist............. 156
Underseat storage .......................60
Upholstery .................................. 215
Uplevel display ............................. 97
Using this manual ..........................3
V Valet mode ................................. 102
Vehicle battery ........................... 181
Vehicle checks............................ 177
Vehicle data ................................ 221
Vehicle data recording and privacy ..................................... 236
Vehicle detected ahead ................97
Vehicle dimensions .................... 228
Vehicle Identification Number ....219
Vehicle jack ................................ 194
Vehicle messages .....................104
Vehicle personalisation .............106
Vehicle security ............................ 31
Vehicle specific data ......................3
