Page 231 of 271
Service and maintenance229protection or seal against minor leaks
can cause function problems. Liability
for consequences resulting from the
use of additional coolant additives will be rejected.
Washer fluid Use only washer fluid approved for
the vehicle to prevent damage of
wiper blades, paintwork, plastic and
rubber parts. Consult a workshop.
Brake fluid Over time, brake fluid absorbs
moisture which will reduce braking
effectiveness. The brake fluid should
therefore be replaced at the specified
interval.
AdBlue Only use AdBlue to reduce the
nitrogen oxides in the exhaust
emission 3 147.
Page 232 of 271
230Technical dataTechnical dataVehicle identification..................230
Vehicle Identification Number ..230
Identification plate ...................231
Engine identification ................231
Vehicle data ............................... 232
Recommended fluids and lubricants ................................ 232
Engine data ............................. 233
Vehicle weight ......................... 235
Vehicle dimensions .................242
Capacities ................................ 250
Tyre pressures ........................ 252Vehicle identification
Vehicle IdentificationNumber
The Vehicle Identification Number
(VIN) is visible through the
windscreen.
The VIN is also displayed behind a
removable plastic cover on the front
right hand door step. Unclip the
covers using a flat blade screwdriver
to access.
Page 233 of 271

Technical data231Identification plate
The identification plate is located on
the right hand door pillar.
Information on identification plate:1:manufacturer's name2:type approval number3:vehicle identification number4:permissible gross vehicle
weight rating in kg5:permissible gross train weight
in kg6:maximum permissible front axle load in kg7:maximum permissible rear axle
load in kg8:engine type9:engine identification code10:fabrication number11:vehicle paint code
Note
The identification plate on your
vehicle may differ from the
illustration shown.
The combined total of front and rear
axle loads must not exceed the
permissible gross vehicle weight. For
example, if the front axle is bearing its
maximum permissible load, the rear
axle can only bear a load that is equal
to the gross vehicle weight minus the front axle load.
The technical data is determined in
accordance with European
Community standards. We reserve
the right to make modifications.
Specifications in the vehicle
documents always have priority over
those given in this manual.
Engine identifier code and enginenumber
Stamped on the engine cylinder block
and on a label attached to the timing
chain cover, depending on variant.
Engine identification
The technical data tables show the
engine identifier code.
Engine data 3 233.
To identify the respective engine,
refer to the engine power in the EEC
Certificate of Conformity provided with your vehicle or other national
registration documents.
Page 234 of 271
232Technical dataVehicle dataRecommended fluids andlubricants
Required engine oil qualityEngine oil quality: Europedexos 2✔
For countries with International
service interval 3 226, you may use
the oil qualities listed below:
Engine oil quality: Internationaldexos 2✔ACEA C3
diesel engines with DPF✔ACEA A3/B4
diesel engines without DPF✔Engine oil viscosity gradesAmbient temperaturedown to
-25 °CSAE 0W-30 or
SAE 0W-40
SAE 5W-30 or
SAE 5W-40below
-25 °CSAE 0W-30 or
SAE 0W-40
Page 235 of 271
Technical data233Engine data
Sales designation
2.3 CDTI 1252.3 CDTI 110,
2.3 CDTI 110
ecoFLEX2.3 CDTI
BITURBO 1352.3 CDTI
1502.3 BITURBO
1632.3 BITURBO
163Engine identifier
codeM9TMH,
M9TMD,
M9TMJM9TMRM9TMNM9TMFM9TMPM9TMUNumber of
cylinders444444Piston
displacement [cm 3
]229822982298229822982298Engine power [kW]9281100110120120at rpm350035003500350035003500Torque [Nm]310285340/350 1)350360380at rpm1250-20001250-20001500-250015001500-27501500-2750Fuel typeDieselDieselDieselDieselDieselDiesel1)
Front-wheel drive / Rear-wheel drive.
Page 236 of 271
234Technical dataSales designation2.3 CDTI 1102.3 CDTI 1302.3 BITURBO 1302.3 BITURBO 1452.3 BITURBO 170Engine identifier codeM9TMWM9TMYM9TM1M9TMS, M9TMTM9TMLNumber of cylinders44444Piston displacement [cm3
]22982298229822982298Engine power [kW]819696107125at rpm35003500350035003500Torque [Nm]290320330360380at rpm1250150015001500-27501500-2750Fuel typeDieselDieselDieselDieselDiesel
Page 237 of 271
Technical data235Vehicle weightKerb weight, basic model without any optional equipment
Optional equipment and accessories increase the kerb weight.
VanDrive wheelsLengthRoof height
Gross vehicle weight
[kg]Kerb weight
[kg]Front-wheel driveL1H1280018063300181135001816H2280018343300183935001844L2H23300188535001890H33300192135001931L3H235001970H335002010
Page 238 of 271
236Technical data
Drive wheelsLengthRoof height
Gross vehicle weight
[kg]Kerb weight
[kg]Rear-wheel driveL3H23500 2)215935003)224645002246H33500 2)214835003)227945002279L4H23500 2)227035003)232445002324H33500 2)230035003)2366450023662)
With Single rear wheels.
3) With Twin rear wheels.
Page 239 of 271
Technical data237Crew van
Drive wheelsLengthRoof height
Gross vehicle weight
[kg]Kerb weight
[kg]Front-wheel driveL1H13300197035001975L1H23300199535002000L2H23300209435002102L3H235002177Rear-wheel driveL3H23500 2)23243500 3)245345003)24532)
With Single rear wheels.
3) With Twin rear wheels.
Page 240 of 271
238Technical dataCombi
Drive wheelsLengthRoof height
Gross vehicle weight
[kg]Kerb weight
[kg]Front-wheel driveL1H133002002L2H235002149
Bus
Drive wheelsLengthRoof height
Gross vehicle weight
[kg]Kerb weight
[kg]Front-wheel driveL3H239002493
