Technical data189Wheelbase
CombiL1L2Roof heightH1H1Sliding side door aperture width - at 100 mm from floor [mm]10301030Sliding side door aperture height [mm]128412847)Depending on number of seats.
Wheelbase
Double cabL1L2Roof heightH1H1Maximum rear door aperture height [mm]13201320Rear door aperture width (at floor) [mm]13911391Maximum load area height [mm]13871387Maximum load area width [mm]16621662Width between wheel arches [mm]12681268Maximum load floor length [mm]20232423Maximum load floor length - behind rear seats [mm]13401740Loading height unladen [mm]552552

190Technical dataWheelbase
Double cabL1L2Roof heightH1H1Sliding side door aperture width [mm]12291229Sliding side door aperture width - at 100 mm from floor [mm]10301030Sliding side door aperture height [mm]12841284

Technical data191CapacitiesEngine oilEngineR9MEngine oil including filter [l]6.3 - 6.5between MIN and MAX [l] (approx.)2.0 - 2.4
Fuel tank
Fuel tank, nominal capacity [l]80

192Technical dataTyre pressuresTyreTyre pressure with full load8)Front
[kPa/bar] (psi)Rear
[kPa/bar] (psi)205/65 R16 C380/3.8 (55)420/4.2 (61)215/65 R16 C310/3.1 (45)340/3.4 (49)195/75 R16 C380/3.8 (55)420/4.2 (61)215/60 R17 C350/3.5 (51) 9)390/3.9 (57)10)8)
The spare wheel should be set to the highest applicable pressure shown in the table.
9) Combi/Bus: 320/3.2 (46) for non-motorway driving below 160 km/h.
10) Combi/Bus: 350/3.5 (51) for non-motorway driving below 160 km/h.

Customer information193Customer informationCustomer information................193
Vehicle data recording and pri‐
vacy ........................................... 193Customer information
Declaration of conformity
This vehicle has systems that
transmit and/or receive radio waves
subject to Directive 1999/5/EC.
These systems are in compliance
with the essential requirements and
other relevant provisions of
Directive 1999/5/EC. Copies of the
original Declarations of Conformity
can be obtained on our website.Vehicle data recording
and privacy
Event data recorders
Data storage modules in the
vehicle
A large number of electronic
components of your vehicle contain
data storage modules temporarily or
permanently storing technical data
about the condition of the vehicle,
events and errors. In general, this
technical information documents the
condition of parts, modules, systems
or the environment:
■ Operating conditions of system components (e.g. filling levels)
■ Status messages of the vehicle and
its single components ( e.g. number
of wheel revolutions / rotational
speed, deceleration, lateral
acceleration)
■ Dysfunctions and defects in important system components

194Customer information
■ Vehicle reactions in particulardriving situations (e.g. inflation of
an airbag, activation of the stability
regulation system)
■ Environmental conditions (e.g. temperature)
These data are exclusively technical
and help identifying and correcting
errors as well as optimizing vehicle
functions.
Motion profiles indicating travelled
routes cannot be created with these
data.
If services are used (e.g. repair
works, service processes, warranty
cases, quality assurance),
employees of the service network
(manufacturer included) are able to
read out this technical information
from the event and error data storage
modules applying special diagnostic
devices. If required, you will receive
further information at these
workshops. After an error has been
corrected, the data are deleted from
the error storage module or they are
constantly overwritten.When using the vehicle, situations
may occur in which these technical
data related to other information
(accident report, damages on the
vehicle, witness statements etc.) may be associated with a specific person -
possibly, with the assistance of an
expert.
Additional functions contractually
agreed upon with the client (e.g.
vehicle location in emergency cases)
allow the transmission of particular vehicle data from the vehicle.Radio Frequency
Identification (RFID) RFID technology is used in somevehicles for functions such as tyre
pressure monitoring and ignition
system security. It is also used in
connection with conveniences such
as radio remote controls for door
locking/unlocking and starting, and in-
vehicle transmitters for garage door
openers. RFID technology in Opel
vehicles does not use or record
personal information or link with any
other Opel system containing
personal information.

Customer information195

196IndexAAccessories and vehicle modifications .......................... 138
Adaptive forward lighting .............97
Adjustable air vents ...................110
AGM (Absorptive Glass Mat) battery ..................................... 144
Airbag and belt tensioners ...........85
Airbag deactivation ................58, 85
Airbag label................................... 53
Airbag system .............................. 53
Air conditioning regular operation ................................ 111
Air conditioning system .............. 102
Air intake .................................... 111
Air recirculation ...................102, 169
Air vents...................................... 110
Alert .............................................. 91
Antifreeze ................................... 142
Antilock brake system ................ 122
Antilock brake system (ABS) .......87
Anti-theft alarm system ................35
Anti-theft bolts............................. 165
Anti-theft locking system .............. 34
Anti-theft security lock ..................25
Appearance care ........................171
Armrest ........................................ 47
Ashtrays ....................................... 80
Automatic anti-dazzle ..................40Automatic fuel cut-off ..................117
Automatic light control .................95
Automatic locking ........................30
Autostop ............................... 89, 116
Auxiliary heater ........................... 106
B Battery ........................................ 144
Battery, jump starting.................. 168
Belts.............................................. 50
Bench seat.................................... 69
Bonnet ....................................... 140
Bottle holders................................ 68
Brake and clutch fluid .................176
Brake assist ............................... 123
Brake fluid .................................. 143 Brakes ............................... 122, 143
Brake system ............................... 87
Breakdown.................................. 169
Bulb replacement ....................... 147
C Capacities .................................. 191
Car Pass ...................................... 21
Catalytic converter .....................120
Central locking system ................25
Centre high-mounted brake light 149
Changing tyre and wheel size ...161
Charging system .......................... 86
Child locks ................................... 30

197
Child restraint installationlocations ................................... 61
Child restraints.............................. 60
Child restraint systems ................60
Cigarette lighter ........................... 79
Cleaning the vehicle ...................171
Climate control ............................. 17
Climate control systems .............101
Clock ............................................ 78 Coat hooks ................................... 68
Control indicators.......................... 83
Control of the vehicle .................113
Controls ........................................ 75
Controls in steering wheel ............75
Convex shape .............................. 38
Coolant ....................................... 142
Coolant and antifreeze ...............176
Coolant heater ............................ 106
Cooling (AC) ............................... 102
Cornering light .............................. 97
Cruise control ...................... 89, 126
Cupholders .................................. 68
Curtain airbag system .................. 58
D Danger, Warnings and Cautions ...3
Dashboard .................................... 10
Daytime running lights ............95, 97
Declaration of conformity ............193
Demisting and defrosting ..............17Diesel fuel filter .......................... 146
Diesel fuel system bleeding .......146
Diesel particle filter ....................120
Door locks..................................... 25
Door open .................................... 90
Doors ............................................ 31
Double cab ................................... 69
DPF (diesel particle filter) ...........120
Driver assistance systems ..........126
Driver Information Centre .............90
Driving characteristics and towing tips .............................. 136
Driving economically................... 112
Driving hints ................................ 112
E ECO mode .................................. 112
ecoScoring.................................... 92
Electric adjustment ......................38
Electrical system......................... 152
Electronic climate control system 103
Electronic key system ...................23
Electronic Stability Program .....
.................................. 87, 125, 137
Electronic Stability Program off ...88
End-of-life vehicle recovery .......139
Engine air filter............................ 141
Engine air flow indicator .............141
Engine coolant ........................... 142
Engine coolant temperature ........88Engine data ............................... 182
Engine exhaust .......................... 120
Engine identification ...................179
Engine oil ................... 140, 176, 181
Engine oil additives ....................176
Engine oil level ............................ 92
Engine oil pressure ......................88
Engine oil viscosity grades .........176
Enhanced Traction function 124, 125
Entry lighting .............................. 100
Event data recorders ..................193
Exhaust gases ....................120, 169
Exit lighting ................................ 100
Exterior care .............................. 171
Exterior light ................................. 89
Exterior lighting ......................14, 95
Exterior mirrors ............................. 38
F
Fault messages ............................ 91
First aid kit ................................... 72
Fixed air vents ........................... 110
Fog light ....................................... 89
Fog lights .............................. 98, 148
Fog tail light ............................... 151
Folding centre seatback ...............68
Folding front centre passenger seat ........................................... 46
Folding mirrors ............................. 38
Front airbag system .....................57

198
Front door pockets........................ 68
Front fog lights ........................ 95, 98
Front seats.................................... 44 Front storage ................................ 68
Front turn signal lights ...............148
Fuel consumption - CO 2-
Emissions ............................... 135
Fuel cut-off system .....................117
Fuel economy gauge ....................82
Fuel economy mode .....................89
Fuel economy rating ...............91, 92
Fuel for diesel engines ..............134
Fuel gauge ................................... 82 Fuse box ..................................... 153
Fuses ......................................... 152
G Gauges ......................................... 80
General information ...................136
Glovebox ..................................... 67
Glovebox cooler ......................... 110
Glove box lighting .........................99
H Hand brake - see Parking brake. 123
Hazard warning flashers ..............97
Headlight flash ............................. 96
Headlight range adjustment ........96
Headlights ...................... 95, 96, 147
Headlights when driving abroad ..96Head restraint adjustment .............8
Head restraints ............................ 43
Heated exterior mirrors .................17
Heated mirrors ............................. 39
Heated rear window ...............17, 42
Heating ........................................ 47
Heating and ventilation system . 101
High beam ............................. 89, 96
Hill start assist ........................... 123
Horn ....................................... 16, 76
I
Identification plate .....................179
Idle speed control .......................116
Ignition switch positions .............114
Immobiliser .................................. 37
Indicators ...................................... 80
Info-display ................................... 90
Information displays...................... 90
Initial drive information.................... 6 Instrument cluster ........................80
Instrument panel fuse box .........153
Instrument panel illumination .....152
Instrument panel illumination control ...................................... 98
Instrument panel overview ........... 10
Instrument panel storage ..............67
Interior care ............................... 172
Interior lighting .............................. 98
Interior lights ........................ 99, 151Interior mirrors.............................. 39
Introduction .................................... 3
Isofix child restraint systems ........ 66
J Jack ............................................ 156
Journey record.............................. 92
Jump starting ............................. 168
K Keys ............................................. 21
Keys, locks ................................... 21
L
Lashing eyes ............................... 71
Light covers, misted...................... 98
Lighting ......................................... 95
Lighting features .........................100
Light switch .................................. 95
Load compartment ....................... 33
Load compartment cover .............70
Load compartment lighting ...........99
Loading information .....................73
Load-through feature ....................69
Low fuel ....................................... 89
M
Malfunction indicator light ............86
Manual adjustment ......................38
Manual anti-dazzle ......................39
