PEUGEOT MAINTENANCE13
Services Level
Operations Description of operations for 1st service
ABC
Intermediate visit
DRAIN AND REFILL- Engine drain and refill.∀∀∀- Fuel filter bleeding (Diesel).∀∀∀∀- Oil filter.∀∀∀- Fuel filter (Petrol).∀∀REPLACEMENT- Fuel filter element (Diesel).∀∀- Air filter element.∀- Spark plugs (Petrol).∀∀- Engine oil (check + top up).∀∀- Manual gearbox oil (check + top up).∀∀ ∀- Battery (check + top up) if plug is removable.∀∀∀LEVEL- Front/rear windscreen wash (check + top up).∀∀∀∀∀- Coolant (check + top up).∀∀ ∀∀∀- Brake fluid (check + top up).∀∀ ∀∀- Power steering fluid (check + top up according to specification).∀∀ ∀∀- Operation of lights and indicators.∀∀ ∀∀- Condition of glass, headlamp and light lenses and mirrors.∀∀∀- Horn.∀∀∀- Windscreen washer jets.∀∀∀- Condition of wiper blades.∀∀∀- Condition and tension of ancillary drive belts.∀∀∀- Handbrake.∀∀∀- Condition of hydraulic circuits (hoses and covers), check for leaks.∀∀∀CHECK- Condition of rubber boots and gaiters.∀∀ ∀∀- Brake pad wear.∀∀∀ #- Clearances, hubs, rods, ball joints, flexible mountings.∀- Sealing of dampers.∀- Wear of rear linings.∀- Condition and pressure of tyres (including spare wheel).∀∀ ∀∀- Emission control check according to current legislation (Petrol).∀∀ ∀∀- Smoke opacity (Diesel).∀∀ ∀- Pollen filter check (according to specification).∀∀∀ #- Visual check of the whole vehicle by a PEUGEOT dealer.∀∀
ROAD TEST ∀∀∀
∀: All driving conditions #: Arduous conditions
PEUGEOT SERVICING LEVELS A, B AND C
06-05-2002

INSTRUMENTS AND CONTROLS18
Instrument panel (Petrol) 1-Maximum coolant temperature
2- Display control: - total distance display
- trip recorder - trip recorder reset- service indicator
3- Speedometer
4- Display:
- digital clock- service indicator
- total distance
- trip recorder
5- Left-hand indicator 6-
Low fuel level
7- Fuel gauge
8- Right-hand indicator
9- Rev. counter
10 -
Clock adjustment, lighting rheostat
11 - Oil pressure
12 - Engine autodiagnostics* (petrol)
13 - Front* and side** airbag warning light and passenger airbagdisarm*
14 - ABS* (Anti-lock Braking System)
15 - Handbrake, low brake fluid leveland engine not running 16 -
Battery charge
17 - Rear fog lamp
18 - Front fog lamps*
19 - Main beam
20 - Dipped beam
21 - Passenger airbag disarm
* According to speciÞcation or country. ** According to model.
1234567910118
12
131415161718192021
06-05-2002

INSTRUMENTS AND CONTROLS19
Instrument panel (Petrol) 1-Coolant temperature gauge
2- Maximum coolant temperature
3- Display control:
- total distance display
- trip recorder - trip recorder reset
- service indicator
4- Speedometer
5- Display:
- digital clock
- service indicator - oil level gauge
- total distance
- trip recorder 6-
Left-hand indicator
7- Low fuel level
8- Fuel gauge
9- Right-hand indicator
10 - Rev. counter
11 -
Clock adjustment, lighting rheostat
12 - Oil temperature gauge
13 - Engine autodiagnostics* (petrol)
14 - Front* and side** airbag warning light and passenger airbagdisarm*
15 - Oil pressure 16 -
ABS* (Anti-lock Braking System)
17 - Handbrake, low brake ßuid level and engine not running
18 - Battery charge
19 - Rear fog lamp
20 - Front fog lamps*
21 - Main beam
22 - Dipped beam
23 - Passenger airbag disarm
* According to speciÞcation or country ** According to model
123456781011129
1416171819202122231315
06-05-2002

Instrument panel (Diesel) 1-Maximum coolant temperature
2- Display control: - total distance display
- trip recorder - trip recorder reset- service indicator
3- Speedometer
4- Display:- digital clock- service indicator- total distance- trip recorder
5- Left-hand indicator 6-
Low fuel level
7- Fuel gauge
8- Right-hand indicator
9- Rev. counter
10 - Clock adjustment, lighting rheostat
11 - Oil pressure
12 - Pre-heat (diesel)
13 - Front* and side** airbag warning light and passenger airbagdisarm*
14 - ABS* (Anti-lock Braking System)
15 - Handbrake, low brake fluid leveland engine not running 16 -
Battery charge
17 - Rear fog lamp
18 - Front fog lamps*
19 - Main beam
20 - Dipped beam
21 - Passenger airbag disarm
* According to speciÞcation or country. ** According to model.
INSTRUMENTS AND CONTROLS20
12345910118
13121415161718192021
67
06-05-2002

PRACTICAL INFORMATION93
To tow your 106 without
lifting... A towing bar should always be used. From the front and rear:Ð Attach the towing bar to the towing eye.
T ow-bar
This device must be Þtted by a
PEUGEOT dealer. T
owing (boat, caravan, etc.)
¥ before setting out:
- check the pressure of thetyres, both on the vehicle and
on the trailer.
- check the electrical signals onthe trailer
- practice manoeuvring, in parti-cular reversing.
- grease the tow ball regularly,remove it when you have Þni-shed towing.
¥ In a caravan, distribute the loadinside evenly and do not exceedthe maximum load.
¥ Always drive at a moderate
speed, change gear early, bothgoing uphill and downhill. Payattention to side winds.
¥ When towing, fuel consumptionincreases. Do not forget to use a
roof deßector if necessary.
¥ Braking distance increases.
Brake gradually and gently. Avoidjerky braking. Do not exceed your vehicle’s
towing capacity. T
owing weight: see ÔTechnical dataÕ
section. Recommended nose weight: 50 kg.
06-05-2002
