Page 7 of 135
7YOUR AT A GLANCE
72
Starting the engine
Do not press the accelerator.
Operate the starter, without
releasing the key, until theengine turns. THE KEYS The keys operate independently the locks for the doors, the boot(opening), the fuel filler flap, thesteering lock and the glove boxas well as operating the passen-ger air bag disarming switch.Never race a coldengine.
Never run the engine in anenclosed space. Do not make any modications to the steering lock. Central locking
From the driver's door, the keys allow you to:
- simultaneously lock the doors
and the boot,
- simultaneously unlock the doors alone.
You can only unlock the boot by using the boot lock. The remote control Pressing button A
allows you to lock the doors and bootby remote control. This is confirmed by the fixed lighting ofthe direction indica-tors for approximate-ly two seconds. Pressing button B
allows you to unlock the doors alone. This is confirmed by the rapid flashing of the direction indicatorsfor approximately two seconds.
STARTING The four positions of the key in the ignition:
STOP position:
the ignition is off.
1st notch, Accessories position:
the ignition is off but the acces-sories can be used. 2nd notch, Running position: the ignition is on. Starting position:
operates the starter. Steering lock Before starting, unlock the steer-
ing if necessary, by gently turningthe steering wheel at the same
time as you turn the key. It is advisable to press the clutch pedal while operating the starter
to make starting easier.
30-06-2003
Page 33 of 135
30-06-2003
YOUR 206 CC IN DETAIL
33
DISPLAY C This enables the following informa- tion to be displayed:
Ð the time,
Ð the date,
Ð the outside temperature (thisflashes when there is a risk of ice),
Ð the radio displays,
Ð the status of the doors. The dis- play shows you, by means of a graphic, whether a door is open, Ð the warning messages are displayed temporarily (e.g. "low fuel level") and can
be cleared using the remote control,
Ð the trip computer (see corresponding section),
Ð the satellite navigation system (see corresponding section). Setting the parameters
The remote control allows you to access the settings. Accessing the different menus is described in the section "Satellite Navigation System".
Page 45 of 135
30-06-2003
YOUR 206 CC IN DETAIL
45
Direction arrows: These enable you to move around the screen and thus select a function.
On the welcome screen only, the up and down arrows enable the brightness of the screen to beadjusted. The right and left arrows enable the complete
name of the road to be displayed temporarily, dur-ing guidance, if the name exceeds the capacity ofthe screen.
menu : this button allows access to the main menu. It canbe used at any time.
esc : escape button "Short press": cancels the current operation and returns to the previous screen. "Press for more than 2 seconds": returns to the welcome screen. This button can be used in any menu. It is inactive during guidance.
mod : mode button"Short press": changes between date, navigation,radio and permanent locating.
val : Validation button Confirms the function selected.
Reference of the 2 batteries: 1.5 volts type LR03.
THE SATELLITE NAVIGATION SYSTEM Introduction The satellite navigation system guides you to the destination of your choice bymeans of vocal and visual instructions. The heart of the system lies in the use of a map database and a GPS system.The latter enables your position to belocated by means of several satellites. The satellite navigation system con- sists of the following components:
- the remote control,
- the display,
- the control unit,
- the last voice message recall con- trol,
- the CD ROM,
- the multifunction aerial. The remote control Pointing this at the screen enables the information contained in the various menus to be selected.
A special compartment in the glove box permits storage of the remote control.
Some functions or services described may vary depending onthe CD-ROM version or the countrywhere the vehicle is sold.
Page 47 of 135
30-06-2003
YOUR 206 CC IN DETAIL
47
The last voice message recall controlPressing the button on the end of the lights stalkallows the last voice mes-
sage to be repeated, or, ifappropriate, a voice mes-sage to be heard and amore detailed display ofthe approaching land-scape to be displayed.
The CD-ROM This contains all the map-ping data. It must be inserted with the printed face upwards.
Use only CD-ROMs approved by PEUGEOT. The satellite navigation system is active when the globe is lit with a full outline.
The control unit This is located in the glove box. 1.
CD-ROM eject button.
2. CD-ROM compartment.
3. ON indicator light indicates that the control unit is
supplied with power.
4. CD indicator light shows that there is a CD-ROM in theunit.
5. Remote control storage compartment.
The use of copied compact discs may cause faults.
Page 48 of 135
30-06-2003
YOUR 206 CC IN DETAIL
48
Main menu Switch on the ignition. Press the "Menu"button to access the main menu.
Select a function using the direction arrows, then confirm ( "VAL" button). Navigation / Guidance Following selection of the
"Navigation/guidance"menu,
a screen warns you about the use of the navigation system. Follow the regulations in force and do not use theremote control while driving. Press the "VAL"button to access the next screen.
The "Navigation/guidance" menu offers the following
options:
- entering of the address of a new destination;
- selection of a service (hotel, station, airport...) available in a town;
- selection of an address stored in one of the two directo- ries;
- access to the "Navigation options" menu.
- Radio functions are suspended when the system is in guidance mode.
Page 49 of 135
30-06-2003
YOUR 206 CC IN DETAIL
48
Main menu Switch on the ignition. Press the "Menu"button to access the main menu.
Select a function using the direction arrows, then confirm ( "VAL" button). Navigation / Guidance Following selection of the
"Navigation/guidance"menu,
a screen warns you about the use of the navigation system. Follow the regulations in force and do not use theremote control while driving. Press the "VAL"button to access the next screen.
The "Navigation/guidance" menu offers the following
options:
- entering of the address of a new destination;
- selection of a service (hotel, station, airport...) available in a town;
- selection of an address stored in one of the two directo- ries;
- access to the "Navigation options" menu.
- Radio functions are suspended when the system is in guidance mode.
Page 71 of 135
30-06-2003
YOUR 206 CC IN DETAIL
72
Changing the battery of the remote control
Warning that the battery is flat is given by an audible signal accompa-nied by the message
''Remote
control battery low'' on the multi-
function display.
To replace the battery, remove the screw then unclip the casing using acoin at the ring (CR 2016/3 volt battery). If the remote control does not work after the battery has been changed,reprogramme the remote control.
THE KEYS The keys allow you to
independent-
ly operate the locks on the doors,
the tailgate (opening), the fuel filler cap, the steering lock, the glove boxand the passenger air bag disarmingcontrol and to switch on the ignition. Central locking From the driver's door the keys allow you:
Ðto lock or unlock the doors and tail-
gate simultaneously,
Ð to unlock simultaneously just thedoors.
Unlocking the boot is possible
only by using the boot key. If one of the doors is open, the cen- tral locking does not work. The remote control This fulfils the same functions as the
key, at a distance. Locking Pressing button
Alocks the vehicle
by remote control. This is displayed by the continuouslighting of the direction indicators forapproximately two seconds. Unlocking Pressing button Bunlocks just the
doors. This is shown by the rapid flashingof the direction indicators. Notes: if the vehicle is locked and
the unlocking control is pressed inadvertently without the doorsbeing opened within 30 seconds, the
vehicle will lock again automatically.
Avoid pressing the buttons of your remote control out of range of your
vehicle. You risk causing it not towork and the remote control wouldhave to be reprogrammed.
Key in ignition
A buzzer sounds on opening the dri-
ver's door, if the key has been left inthe ignition. Locating your car
To locate your car in a car park, if you have locked it:
press button A, the courtesy light
comes on and the direction indi- cators flash for a few seconds.Programming the remote control Switch off the ignition.
Switch the ignition on again.
Press button Aimmediately.
Switch off the ignition and remove the remote control key from the
ignition lock. The remote control isnow working again.
Page 72 of 135
30-06-2003
YOUR 206 CC IN DETAIL73
Make a careful note of the number on each key. The key number is
coded on the label attached to the key. If the keys are lost, your PEUGEOT dealer can rapidly supply you with new keys.
The high frequency remote control is a sensitive system; do not operate itwhile it is in your pocket as there is a possibility that it may unlock your vehicle,without you being aware of it. The remote control does not operate when the key is in the ignition, even when the ignition is switched off, except for reprogramming. Driving with the doors locked may make access to the passenger compart-
ment by the emergency services more difficult in an emergency. As a safety precaution (with children on board), remove the ignition key when you leave the vehicle, even for a short time. Do not repeatedly press the button of your remote control out of range of your vehicle.
You run the risk of stopping it from working and the remote control would have to be reprogrammed. When purchasing a second-hand vehicle:
- ensure that you are given the confidential card;
- have the key codes memorised by a PEUGEOT dealer, to ensure that the keys in your possession are the only ones which can start the vehicle.
Do not make any modifications to the electronic engine immobiliser system.
Confidential card The confidential card contains the identification code necessary for anywork carried out by a PEUGEOT
dealer on the system. This code ishidden by a film, which should be
removed only if necessary. Keep your card in a safe place, never inside the vehicle.ELECTRONIC ENGINE IMMOBILISER This locks the engine management system as soon as the ignition has
been switched off and therefore pre-vents starting of the vehicle by any-
one who does not have the key. The ignition key has an electronic chip which has a special code.When the ignition is switched on, thecode is recognised and starting ispossible. If the system does not function correctly , contact a PEUGEOT
dealer as soon as possible.
Page 73 of 135
30-06-2003
YOUR 206 CC IN DETAIL73
Make a careful note of the number on each key. The key number is
coded on the label attached to the key. If the keys are lost, your PEUGEOT dealer can rapidly supply you with new keys.
The high frequency remote control is a sensitive system; do not operate itwhile it is in your pocket as there is a possibility that it may unlock your vehicle,without you being aware of it. The remote control does not operate when the key is in the ignition, even when the ignition is switched off, except for reprogramming. Driving with the doors locked may make access to the passenger compart-
ment by the emergency services more difficult in an emergency. As a safety precaution (with children on board), remove the ignition key when you leave the vehicle, even for a short time. Do not repeatedly press the button of your remote control out of range of your vehicle.
You run the risk of stopping it from working and the remote control would have to be reprogrammed. When purchasing a second-hand vehicle:
- ensure that you are given the confidential card;
- have the key codes memorised by a PEUGEOT dealer, to ensure that the keys in your possession are the only ones which can start the vehicle.
Do not make any modifications to the electronic engine immobiliser system.
Confidential card The confidential card contains the identification code necessary for anywork carried out by a PEUGEOT
dealer on the system. This code ishidden by a film, which should be
removed only if necessary. Keep your card in a safe place, never inside the vehicle.ELECTRONIC ENGINE IMMOBILISER This locks the engine management system as soon as the ignition has
been switched off and therefore pre-vents starting of the vehicle by any-
one who does not have the key. The ignition key has an electronic chip which has a special code.When the ignition is switched on, thecode is recognised and starting ispossible. If the system does not function correctly , contact a PEUGEOT
dealer as soon as possible.
Page 74 of 135
30-06-2003
Deadlocking Deadlocking of the doors is an additional security device. It disables the exterior and interior door controls. There are two methods of deadlocking :
- with the ignition key, from the driver's door;
- with the remote control, which has two buttons :A. deadlocking/locking of the doors and boot lid.
B. unlocking.
Using the ignition key Deadlocking , turn the key towards the rear of the vehicle.
Locking , within 5 seconds of deadlocking, turn the key again towards the rear
of the vehicle.Unlocking , turn the key towards the front of the vehicle. Using the remote controlDeadlocking
, press button Aonce
to deadlock the vehicle.This is confirmed by fixed lighting of the direction indicators for approxi-mately two seconds.
Press button A again within
5 seconds of deadlocking; this changes deadlocking to normal loc-
king. This is confirmed by fixed ligh-ting of the direction indicators forapproximately two seconds. Unlocking Press button Bto unlock the vehicle.
This is confirmed by the rapid fla- shing of the direction indicators.
To unlock the boot lid Place the ignition key in the boot lock and turn it anti-clockwise.
SPECIAL FEATURES
128
