PRACTICAL INFORMATION
100 -
CHANGING A FUSE
The fuse boxes are located under
the fascia and in the engine compart-
ment.
Correct Incorrect
Pliers A
Fascia fuse box
U n s c r e w t h e c a t c h a q u a r t e r t u r n u s
-
ing a coin then remove the cover to
gain access to the fuses.
The spare fuses and the pliers A are
i t t e d i n s i d e o f t h e f a s c i a f u s e b o x
lid. R e m o v i n g a n d i t t i n g a f u s e
B e f o r e c h a n g i n g a f u s e , t h e c a u s e o f t h e f a u l t m u s t b e f o u n
d a n d r e m e d i e d . T h e
fuse numbers are indicated on the fuse box.
Use the pliers A.
Always replace a faulty fuse with a fuse of the same rating .
Page 112 of 127
101
PRACTICAL INFORMATION
-
Fuse N° Rating Functions
1 15 A Alarm siren
4 20 A M u l t i f u n c t i o n d i s p l a y - B o o t l i g h t i n g - A u d i o e q u i p m e n t - S t e e r i n g w h e e l c o n t r o l s - T r a i l e r
5 15 A Automatic gearbox diagnostics
6 10 A C o o l a n t l e v e l - A u t o m a t i c g e a r b o x - A u d i o e q u i p m e n t - S t e e r i n g w h e e l a n g l e s e n s o r ( E S P )
7 15 A Driving school accessory - Alarm
9 30 A R e a r e l e c t r i c w i n d o w s
10 40 A Rear screen and mirror demisting
11 15 A R e a r w i n d s c r e e n w i p e r
12 30 A F r o n t e l e c t r i c w i n d o w s - S u n r o o f
14 10 A E n g i n e f u s e b o x - A i r b a g s - S t e e r i n g w h e e l c o n t r o l s - R a i n s e n s o r
15 15 A Instrument panel - Multifunction display - Air conditioni ng - Audio equipment
16 30 A L o c k i n g / u n l o c k i n g c o n t r o l s f o r d o o r s , b o n n e t a n d b o o t - D e a d l o c k i n g c o n t r o l s
20 10 A Right-hand brake light
21 15 A Left-hand brake light - 3rd brake light
22 20 A Front courtesy light - Map reader - Glove box lighting - L ighter
S1 Shunt PARC shunt
Page 113 of 127
PRACTICAL INFORMATION
102 -
The electrical circuit of
your vehicle is designed
t o o p e r a t e w i t h s t a n d a r d
or optional equipment.
Before installing other
electrical equipment or acces-
s o r i e s i n y o u r v e h i c l e , c o n s u l t a
PEUGEOT dealer.
Some electrical accessories or
t h e w a y i n w h i c h t h e y a r e i t t e d
may have an adverse effect on the
operation of your vehicle (its elec-
t r o n i c c o n t r o l c i r c u i t s , t h e a u d i o
circuit and the electrical charging
circuit).
PEUGEOT declines any responsi-
bility for expenses incurred in the
repair of your vehicle or for any
malfunctions resulting from the in-
s t a l l a t i o n o f a u x i l i a r y a c c e s s o r i e s ,
not supplied and not recommend-
ed by PEUGEOT and not installed
i n a c c o r d a n c e w i t h P E U G E O T ' s
i n s t r u c t i o n s , i n p a r t i c u l a r f o r a n y
e q u i p m e n t t h e p o w e r c o n s u m p t i o n
o f w h i c h e x c e e d s 1 0 m i l l i a m p s .
Fuse N° Rating Functions
1* 20 A Fan unit
2* 60 A ABS/ESP
3* 30 A ABS/ESP
4* 70 A Built-in systems interface supply
5* 70 A Built-in systems interface supply
6* - Not used
7* 30 A I g n i t i o n s w i t c h s u p p l y
8* 20 A A u d i o a m p l i i e r
Engine compartment fuse box
T o g a i n a c c e s s t o t h e b o x i n t h e e n g i n e c o m p a r t m e n t ( n e x t t o t
h e b a t t e r y ) , u n c l i p
the cover.
A f t e r c a r r y i n g o u t w o r k , c l o s e t h e c o v e r v e r y c a r e f u l l y .
* The maxi fuses provide additional protection for the elect rical systems. Any
w o r k o n t h e s e m u s t b e c a r r i e d o u t b y a P E U G E O T d e a l e r .
Page 114 of 127
103
PRACTICAL INFORMATION
-
Fuse N° Rating Functions
1 10 A P r e - h e a t u n i t ( d i e s e l ) - W a t e r i n d i e s e l s e n s o r - R e v e r s i n g l i g h t s s w
i t c h - S p e e d s e n s o r -
A i r l o w s e n s o r ( d i e s e l )
2 15 A Canister solenoid valve - Fuel pump
3 10 A A B S / E S P e n g i n e c o n t r o l u n i t - E S P b r a k e s w i t c h
4 10 A Automatic gearbox control unit - Engine control unit
5 - Not used
6 15 A Front fog lamps
7 - Not used
8 20 A Fan assembly relay - Engine control unit - Diesel injection pump
-
Diesel high pressure regulator - Engine management solenoid valve
9 15 A Left dipped beam
10 15 A Right dipped beam
11 10 A Left main beam
12 15 A Right main beam
13 15 A Horn
14 10 A F r o n t a n d r e a r w i n d s c r e e n w a s h p u m p s
15 30 A Throttle housing heater - Diesel injection pump - Oxygen senso
r - Engine control unit -
A i r l o w s e n s o r - I g n i t i o n c o i l - E n g i n e m a n a g e m e n t s o l e n o i d v a l v e - D i e s e l h e a t e r -
Injectors
16 30 A Air pump relay
17 30 A H i g h a n d l o w s p e e d w i n d s c r e e n w i p e r
18 40 A Air conditioning fan
Page 115 of 127
PRACTICAL INFORMATION
104 -
BATTERY
To charge the battery using a
battery charger:
- D i s c o n n e c t t h e b a t t e r y ,
- F o l l o w t h e i n s t r u c t i o n s f o r u s e
given by the battery charger
m a n u f a c t u r e r ,
- R e c o n n e c t s t a r t i n g w i t h t h e n e g a t i v e ( - ) t e r m i n a l ,
- Check that the terminals and connectors are clean. If they are
c o v e r e d w i t h s u l p h a t e ( w h i t e o r
g r e e n i s h d e p o s i t ) , d i s c o n n e c t
them and clean them.
- Wait for 2 minutes a f t e r s w i t c h i n g o f f
the ignition before
disconnecting the
battery.
- Never disconnect a terminal w h e n t h e e n g i n e i s r u n n i n g .
- Never charge a battery w i t h o u t i r s t d i s c o n n e c t i n g t h e
terminals.
- C l o s e t h e w i n d o w s a n d t h e roof before disconnecting the
battery.
- After every reconnection of t h e b a t t e r y , s w i t c h o n t h e
i g n i t i o n a n d w a i t 1 m i n u t e
b e f o r e s t a r t i n g t o a l l o w t h e
electronic systems to be
i n i t i a l i s e d . I f s l i g h t d i f i c u l t i e s
a r e e x p e r i e n c e d a f t e r t h i s ,
please consult a PEUGEOT
dealer.
It is advisable to disconnect the
battery if the vehicle is not to be
used for a period of more than
one month.
ECONOMY MODE FUNCTION
A f t e r t h e e n g i n e h a s s t o p p e d , c e r t a i n
f u n c t i o n s ( w i n d s c r e e n w i p e r , e l e c
-
t r i c w i n d o w s , c o u r t e s y l i g h t s , a u d i o
e q u i p m e n t , e t c . ) c a n o n l y b e u s e d f o r
a combined duration of approximately
t h i r t y m i n u t e s , t o p r e v e n t d i s c h a r g i n g
the battery.
O n c e t h e t h i r t y m i n u t e s a r e o v e r , a
s w i t c h i n g t o e c o n o m y m o d e m e s -
sage appears on the multi-function
display and the active functions are
put on standby.
These functions are reactivated au-
tomatically next time the vehicle is
driven.
In order to resume the use of these
f u n c t i o n s i m m e d i a t e l y , t h e e n g i n e
must be started and left to run for a
f e w m i n u t e s .
T h e t i m e a v a i l a b l e t o y o u w i l l t h e n b e
d o u b l e t h e d u r a t i o n f o r w h i c h t h e e n -
g i n e i s l e f t r u n n i n g . H o w e v e r , t h i s p e -
r i o d w i l l a l w a y s b e b e t w e e n i v e a n d
thirty minutes.
To start the vehicle from another
battery:
- Connect the red cable to the
positive (+) terminals of the
t w o b a t t e r i e s ,
- Connect one end of the green or black cable to the negative (-)
t e r m i n a l o f t h e s l a v e b a t t e r y ,
- Connect the other end of the green or black cable to an
e a r t h p o i n t o n t h e b r o k e n d o w n
v e h i c l e , a s f a r a s p o s s i b l e f r o m
t h e b a t t e r y ( f o r e x a m p l e , r i g h t -
h a n d e n g i n e m o u n t i n g ) ,
- O p e r a t e t h e s t a r t e r , l e t t h e e n g i n e r u n ,
- Wait for the engine to return to i d l e , t h e n d i s c o n n e c t t h e c a b l e s .
A l a t b a t t e r y p r e v e n t s t h e
engine from starting.
Page 116 of 127
105
PRACTICAL INFORMATION
-
FITTING SPEAKERS
T h e f a c t o r y - i t t e d e q u i p m e n t a l l o w s
t h e i t t i n g o f :
- 165 mm diameter speakers in
t h e f r o n t d o o r s ,
- 130 mm diameter speakers in t h e r e a r d o o r s ,
- 2 2 . 5 m m d i a m e t e r t w e e t e r s i n the mirror trims. Making the connections
A1: -
A2: -
A3: -
A4: -
A5: -
A6: (+ve) Ignition positive
A7: (+ve) Permanent
A8: Earth
B1: (+) Rear right speaker
B2: (-) Rear right speaker
B3: (+) Front right speaker and
t w e e t e r
B4: (-) Front right speaker and t w e e t e r
B5: (+) Front left speaker and t w e e t e r
B6: (-) Front left speaker and t w e e t e r
B7: (+) Rear left speaker
B8: (-) Rear left speaker
Consult a PEUGEOT deal-
er before installing audio
equipment or speakers in
your vehicle.
FITTING AUDIO EQUIPMENT
Y o u r v e h i c l e i s e q u i p p e d w i t h c e r t a i n
f a c t o r y - i t t e d a u d i o e q u i p m e n t :
- r o o f a e r i a l ,
- c o a x i a l a e r i a l c a b l e ,
- b a s i c i n t e r f e r e n c e s u p p r e s s i o n ,
- s u p p l y t o f r o n t s p e a k e r s ,
- s u p p l y t o r e a r s p e a k e r s ,
- t w o 8 - w a y c o n n e c t o r s .
Page 117 of 127
PRACTICAL INFORMATION
106 -
Front towing eye
TOWING YOUR VEHICLE
Never use the radiator
crossmember.
Special features of the automatic
gearbox
W h e n t o w i n g w i t h a l l f o u r w h e e l s o n
t h e g r o u n d , t h e f o l l o w i n g r u l e s m u s t
be adhered to:
- gear lever in position N ,
- t o w t h e v e h i c l e a t a s p e e d l e s s than 30 mph (50 km/h) over
a distance of not more than
3 0 m i l e s ( 5 0 k m ) ,
- do not add oil to the gearbox. Rear towing eye
From the front or the rear
A t t a c h t h e t o w b a r t o t h e t o w i n g e y e .
By lifting (two wheels only on the
ground)
It is preferable to lift the vehicle by
t h e w h e e l s .
Without lifting (four wheels on the
ground)
Y o u m u s t a l w a y s u s e a t o w b a r .
VEHICLES FITTED WITH A
MANUAL GEARBOX
(diesel version)
I n t h e c a s e o f v e h i c l e s i t t e d w i t h a
m a n u a l g e a r b o x , t h e g e a r l e v e r m u s t
be in the "neutral" position. Failure to
observe this special condition may
result in damage to certain brak-
ing components and the absence of
braking assistance the next time the
engine is started.
Page 118 of 127
107
PRACTICAL INFORMATION
-
TOWING A TRAILER,
CARAVAN, BOAT, ETC.
We recommend the use of original
P E U G E O T t o w b a r s a n d t h e i r h a r-
nesses that have been tested and
approved from the design stage of
y o u r v e h i c l e a n d t h a t t h e i t t i n g o f t h e
t o w b a r i s e n t r u s t e d t o a P E U G E O T
dealer.
I f t h e t o w b a r i s n o t i t t e d b y a
P E U G E O T d e a l e r , i t i s i m p e r a t i v e
t h a t i t i s i t t e d u s i n g t h e e l e c t r i c a l
pre-equipment installed at the rear
o f t h e v e h i c l e , i n a c c o r d a n c e w i t h t h e
manufacturer's instructions.
Your vehicle is primarily designed
for transporting people and luggage
b u t i t m a y a l s o b e u s e d f o r t o w i n g a
trailer.
D r i v i n g w i t h a t r a i l e r s u b j e c t s t h e
t o w i n g v e h i c l e t o m o r e s i g n i i c a n t
stress and its driver must be particu-
larly careful.
A i r d e n s i t y d e c r e a s e s w i t h a l t i t u d e ,
thus reducing engine performance.
A b o v e 1 0 0 0 m e t r e s , t h e m a x i m u m
t o w i n g l o a d m u s t b e r e d u c e d b y 1 0 %
and so on for every 1 000 metres of
altitude. Driving advice
Distribution of loads:
Distribute the
load in the trailer so that the heaviest
items are as close as possible to the
a x l e a n d t h e n o s e w e i g h t a p p r o a c h -
e s t h e m a x i m u m p e r m i t t e d w i t h o u t
exceeding it.
Cooling: T o w i n g a t r a i l e r o n a s l o p e
increases the temperature of the
coolant.
A s t h e f a n i s e l e c t r i c a l l y c o n t r o l l e d ,
its cooling capacity is not dependent
on the engine speed.
O n t h e c o n t r a r y , u s e a h i g h g e a r t o
l o w e r t h e e n g i n e s p e e d a n d r e d u c e
your speed.
T h e m a x i m u m t o w i n g l o a d o n a l o n g
slope depends on the gradient and
the outside temperature. I n a l l c a s e s , p a y a t t e n t i o n t o t h e c o o l
-
ant temperature.
In certain cases of particularly arduous
u s e ( t o w i n g t h e m a x i m u m l o a d o n a
s t e e p g r a d i e n t i n h i g h t e m p e r a t u r e s ) ,
s w i t c h i n g o f f t h e a i r c o n d i t i o n i n g p e r -
m i t s t h e r e c o v e r y o f e n g i n e p o w e r a n d
t h e r e f o r e a n i n c r e a s e i n t h e t o w i n g c a -
pacity.
I f t h e w a r n i n g l i g h t c o m e s o n , s t o p
t h e v e h i c l e a n d s w i t c h o f f t h e e n g i n e
as soon as possible.
Tyres: Check the tyre pressures of
t h e t o w i n g v e h i c l e a n d o f t h e t r a i l e r ,
observing the recommended pres-
sures.
Braking: T o w i n g i n c r e a s e s t h e
braking distance.
Lights: Check the electrical signal-
ling on the trailer.
Side wind: Take into account the
i n c r e a s e d s e n s i t i v i t y t o s i d e w i n d .
Page 119 of 127
PRACTICAL INFORMATION
108 -
Fitting/removing the mat
When removing the mat on the driver’s
s i d e , p u s h t h e s e a t a s f a r b a c k a s p o s -
s i b l e a n d r e m o v e t h e i x i n g s .
W h e n r e i t t i n g , p o s i t i o n t h e m a t c o r r e c t -
l y o n t h e p i n a n d c l i p t h e i x i n g s . C h e c k
that the mat is secured correctly.
To prevent the mat from becoming
caught under the pedals:
- only use mats suited to the i x i n g s a l r e a d y p r e s e n t i n t h e
vehicle. It is imperative that
t h e s e i x i n g s a r e u s e d .
- n e v e r i t o n e m a t o n t o p o f another. - Clean off bird drop-
p i n g s , r e s i n o u s d e p o s -
i t s , t a r s t a i n s a n d g r e a s e
marks as soon as pos-
s i b l e ; ( t h e s e a l l c o n t a i n
s u b s t a n c e s w h i c h c a n
cause serious damage
t o t h e p a i n t w o r k ) .
- Do not use a dry or abrasive cloth or detergent or solvent
products to clean the double
l e n s , c o m p l e x s u r f a c e h e a d -
l a m p s a s t h e y a r e i t t e d w i t h
polycarbonate glass covered
i n a p r o t e c t i v e i n i s h .
- D o n o t u s e p e t r o l , o i l o r c l o t h stain removers to clean the
b o d y w o r k a n d p l a s t i c p a r t s o f
your vehicle.
- To prevent the development of b o d y w o r k c o r r o s i o n a s a r e s u l t
of accidental damage (stone
c h i p s , s c r a t c h e s , e t c . ) h a v e
t h e m r e p a i r e d s w i f t l y .
BODYWORK MAINTENANCE
T o p r e s e r v e t h e p a i n t w o r k a n d t h e
p l a s t i c t r i m o n y o u r v e h i c l e , w e r e c o m -
m e n d t h a t y o u w a s h t h e m r e g u l a r l y .
- b y h a n d : t h e r e a r e n o s p e c i i c p r e c a u t i o n s t o t a k e ;
- u s i n g a n a u t o m a t i c c a r w a s h : r e -
peated use of poorly maintained
a u t o m a t i c c a r w a s h e s c a n l e a d
to the appearance of microscopic
s c r a t c h e s w h i c h g i v e t h e p a i n t -
w o r k a m a t t a p p e a r a n c e ( e s p e -
c i a l l y v i s i b l e o n d a r k c o l o u r s ) ;
- u s i n g a h i g h p r e s s u r e w a s h e r : a l w a y s f o l l o w t h e r e c o m m e n d a -
tions on the equipment (pres-
sure and spraying distance).
If there are damaged areas on the
vehicle (painted bumpers or head-
l a m p s ) , i t i s n o t r e c o m m e n d e d t o
direct the high pressure jet onto
them. Wash these areas by hand.
A l s o a v o i d t h e e n t r y o f w a t e r i n t o
the locks.
For all questions relating to the main-
t e n a n c e o f y o u r v e h i c l e , c o n t a c t a n
a p p r o v e d d e a l e r w h o c a n a d v i s e y o u
on quality products selected by our
departments.
Page 120 of 127
109
PRACTICAL INFORMATION
-
206 ACCESSORIES
For your PEUGEOT only use acces-
sories and original parts approved by
the manufacturer.
These accessories and parts are all
a d a p t e d t o y o u r P E U G E O T , a f t e r b e-
ing tested and approved for reliability
a n d s a f e t y , w h i c h P E U G E O T c a n n o t
guarantee for other products.
A w i d e c h o i c e o f o r i g i n a l a c c e s s o r i e s ,
a p p r o v e d b y P E U G E O T , i s a v a i l a b l e
t h r o u g h t h e d e a l e r n e t w o r k . T h e y a l l
carry the PEUGEOT guarantee:
Travel and Leisure: T o w b a r , boot
luggage rack , b o o t t r a y , r o o f b a r s ,
r o o f b o x e s , s k i c a r r i e r , b i c y c l e c a r r i e r
( d o n o t i t t h e b i c y c l e c a r r i e r o n t h e
s p o i l e r o r o n t h e r e a r s c r e e n ) , s n o w
c h a i n s , . . .
Exterior style: A l l o y w h e e l s , t r i m s ,
m u d l a p s , s u n r o o f ( i t i s i m p e r a t i v e
that only genuine PEUGEOT prod-
u c t s a r e u s e d f o r t h e i t t i n g o f a s u n -
r o o f ) , f r o n t f o g l a m p s , t a i l g a t e s p o i l -
e r , s p o r t s e x h a u s t , a l u m i n i u m a n d
w o o d p a n e l t r i m , d o o r s i l l s , b o d y k i t ,
w i n g e x t e n d e r s , t w o - t o n e s t e e r i n g
w h e e l , . . . Interior equipment:
C e n t r a l a r m r e s t ,
w r i t i n g t a b l e , p a s s e n g e r s e a t p r o t e c -
t o r , s e a t c o v e r s s u i t a b l e f o r s i d e a i r
b a g s , m a t s , b o o t t r a y , c a n h o l d e r , C D
s t o r a g e , a u d i o / t e l e p h o n e c o n s o l e ,
d o o r d e l e c t o r s , u n d e r - s h e l f s t o r a g e ,
s u n b l i n d s , . . .
Technology: A u d i o / t e l e p h o n e , h a n d s -
f r e e k i t , s a t e l l i t e n a v i g a t i o n s y s t e m , C D
c h a n g e r s , a u d i o s y s t e m s , s p e a k e r s ,
a u d i o t r i m , r e a r s h e l f i t t e d w i t h
4 s p e a k e r s , . . .
Safety: A n t i - t h e f t a l a r m , w i n d o w e n -
g r a v i n g , w h e e l l o c k s , w a r n i n g t r i a n -
g l e , i r s t a i d k i t , s a f e t y j a c k e t , b o o s t e r
s e a t s a n d c h i l d s e a t s , I s o i x K i d d y
s e a t , . . .
Van: K i t f o r c o n v e r s i o n i n t o a v a n , . . . Depending on the coun-
t r y i n w h i c h t h e v e h i c l e
i s s o l d , i t i s c o m p u l s o r y
t o h a v e a s a f e t y j a c k e t ,
w a r n i n g t r i a n g l e a n d s p a r e b u l b s
available in the vehicle.
Installation of radiocommunica-
tion transmitters
You are advised to contact a rep-
resentative of the PEUGEOT
marque before installing acces-
sory radiocommunication trans-
m i t t e r s w i t h e x t e r n a l a e r i a l o n y o u r
vehicle.
T h e P E U G E O T n e t w o r k w i l l i n f o r m
you of the characteristics (frequen-
c y b a n d , m a x i m u m o u t p u t p o w e r ,
a e r i a l p o s i t i o n , s p e c i i c i n s t a l l a -
tion conditions) of the transmitters
w h i c h c a n b e i t t e d , i n a c c o r d a n c e
w i t h t h e M o t o r V e h i c l e E l e c t r o -
magnetic Compatibility Directive
(2004/104/CE).
T h e i t t i n g o f e l e c t r i c a l e q u i p m e n t
o r a c c e s s o r i e s w h i c h a r e n o t r e c -
ommended by PEUGEOT may
result in a failure of your vehicle's
electronic system.
P l e a s e n o t e t h i s s p e c i i c w a r n i n g .
You are advised to contact a rep-
resentative of the Marque to be
s h o w n t h e r a n g e o f r e c o m m e n d e d
equipment and accessories.
