fuses Peugeot 3008 Hybrid 4 2013 Owner's Manual - RHD (UK. Australia)

CHECKS
167
DIESEL ENGINE
The various caps and covers allow access for checking the levels of the various fl uids, for replacing certain components and
for priming the fuel system.


1.
Power steering reservoir.

2.
Screenwash and headlamp wash
reservoir.

3.
Coolant reservoir.
4.
Brake fl uid reservoir.

5.
Battery / Fuses.

6.
Fusebox.

7.
Air fi lter.
8.
Engine oil dipstick.

9.
Engine oil fi ller cap.

10.
Priming pump.

11 .
Bleed screw.

PRACTICAL INFORMATION
186

Dashboard fuses

Fuse tables

The fusebox is placed in the lower
dashboard.
Fuse
N°

Rating
(A)


Functions



F1


15

Rear wiper.


F2


-

Not used.


F3


5

Airbag control unit.


F4


10
Electrochromatic rear view mirror, air conditioning,
switching and protection unit, rear multimedia,
traction battery control unit.


F5


30

Front one-touch electric windows.


F6


30

Rear one-touch electric windows.


F7


5
Front and rear courtesy lamps, map reading lamps,
rear reading lamps, sun visor lighting, glove box
lighting, centre armrest lighting, boot 12 V relay
control.

PRACTICAL INFORMATION
187

Access to the fuses


)
See "Access to the tools".
Fuse
N°

Rating
(A)

Functions



F8


20
Audio equipment, audio/telephone, CD changer,
multifunction screen, tyre under-infl ation detection,
alarm siren, alarm control unit, telematic unit.


F9


30
Front 12 V socket, cigarette lighter, rear 12 V
socket.


F10


15

Steering mounted controls.


F11


15

Low current ignition switch.


F12


15
Trailer presence, rain / sunshine sensor, supply
for fuses F32, F34, F35.


F13


5

Engine fusebox, airbag control unit.


F14


15
Instrument panel, instrument panel screen, supply
for fuse F33.


F15


30

Locking and deadlocking.


F17


40

Heated rear screen, supply for fuse F30.


SH


-

PARC shunt.

PRACTICAL INFORMATION
189

Engine compartment fuses


Access to the fuses


)
Unclip the cover.

)
Change the fuse (see corresponding
paragraph).

)
When you have fi nished, close the
cover carefully to ensure correct
sealing of the fusebox.


The fusebox is placed in the engine
compartment near the battery.
Fuse
N°

Rating
(A)


Functions



F1


20
Engine control unit supply, injection pump and
EGR electrovalves, injectors.


F2


15

Horn.


F3


10

Front / rear wash-wipe.


F4


10

Daytime running lamps.


F5


15
Air fl ow sensor, wiper, sensor heater, hybrid control
unit, hybrid selector dial, electronic thermostat,
variable valve timing electrovalves, turbo pressure
regulation electrovalves (Diesel), engine coolant
level sensor (Diesel).


F6


10
Diagnostic socket, directional headlamps, particle
emission fi lter pump (Diesel), mirror adjustment
control, network interface unit, head-up display.


F7


10
Power steering control unit, directional headlamps
height adjustment motor.


F8


20

Starter motor control.


F9


10

Clutch and brake pedal switches.


F10


30

Heaters (Diesel).


F11


40

Air conditioning blower.

PRACTICAL INFORMATION
191

Mini and midi-fuses above the battery

Maxi-fuses

Fuse

N°

Rating

(A)


Functions



MF1 *



30

Electric vacuum pump.


MF2 *



50

Trailer interface.


MF3 *



60

Passenger compartment fusebox.


MF4 *



80

Built-in systems interface.


MF5 *



80

Built-in systems interface.


MF6 *



30

Electric parking brake.


MF7 *



-

Not used.


MF8 *



25

Headlamp wash.
Fuse


N°

Rating

(A)

Functions



F1


5

Controlled air intake.


F2


5

Dual function brake switch.


F3


5

Battery charge unit.


F4


25

ABS/DSC electrovalves.


F5


5

ABS/DSC control unit.


F6


15

Electronic gear control gearbox.


F7 *



80

Power steering electropump assembly.


F8
*


60

Fan assembly.


F9 *



80

Pre-heat unit (Diesel).


F10 *



40

ABS/DSC electropump assembly.


F11 *



100

Switching and protection unit.


F12 *



30

Electropump unit, electronic gear control gearbox.

*
The maxi-fuses and certain other
fuses provide additional protection for
the electrical systems. All work on the
these fuses must be carried out by a
PEUGEOT dealer.

PRACTICAL INFORMATION
200

Removal



)
Pull on the very cold climate screen
using the cut-outs 1
then 2
at the
edges of the screen.
Do not forget to remove the very cold
climate screen:


- when the ambient temperature ex-
ceeds 10° C,

- when towing,

- at speeds above 75 mph (120 km/h).

ACCESSORIES

A wide range of accessories and genu-
ine parts is available from the PEUGEOT
dealer network.
These accessories and parts have been
tested and approved for reliability and
safety.
They are all adapted to your vehicle and
benefi t from PEUGEOT's recommenda-
tion and warranty.
Installation of radio
communication
transmitters
Before installing any after-market ra-
dio communication transmitter, you
can contact a PEUGEOT dealer for
the specifi cation of transmitters which
can be fi tted (frequency, maximum
power, aerial position, specifi c instal-
lation requirements), in line with the
Vehicle Electromagnetic Compatibility
Directive (2004/104/EC).



Depending on the legislation in force
in the country, it may be compulsory
to have a high visibility safety vest,
warning triangle and spare bulbs and
fuses available in the vehicle.
The fi tting of electrical equipment or
accessories which are not recom-
mended by PEUGEOT may result in
a failure of your vehicle's electronic
system and excessive electrical con-
sumption.
Please note this precaution. You are
advised to contact a PEUGEOT rep-
resentative to be shown the range
of recommended equipment and ac-
cessories.

ALPHABETICAL INDEX
328
Engine compartment fusebox ....... 185
Engine oil level indicator ......... 60, 168
Engines................................. 202, 203
Environment ......................... 8, 39, 89
ESC/ASR ...................................... 135Halogen headlamps...................... 181
Hands-free kit ....................... 278, 319
Hazard warning lamps .................. 134
Head-up display............ 152, 154, 156
Headlamp adjustment................... 104
Headlamp wash ............................ 106
Headlamp wash reservoir ............. 169
Head restraints, front ...................... 78
Head restraints, rear ....................... 80
Heated seats .................................. 78
Heating ........................................... 39
Height and reach adjustment,
steering wheel ............................. 82
High voltage...... 42, 43, 139, 165, 193
High voltage cable .......................... 43
Hill start assist .............................. 149
History ...................................... 41, 69
Hooks ............................................119
Horn .............................................. 134
Hybrid ................. 4, 6, 26, 31, 35, 192
Hybrid fl ow ............................ 4, 26, 35
Hybrid selector................................ 31
Hybrid system ....... 4, 26, 27, 217, 259 Filling with fuel .......................... 98, 99
Fitting a wheel .............................. 179
Fitting roof bars............................. 199
Fittings, boot ..................................118
Flashing indicators........................ 134
Flat bed lorry or trailer ............ 46, 197
Foglamps, rear ............................. 101
Folding the rear seats ..................... 80
Front foglamps...................... 101, 182
Front seats.......................... 76, 77, 79
Fuel..................................... 39, 98, 99
Fuel consumption ..................... 39, 41
Fuel consumption fi gures ............... 41
Fuel fi ller cap .................................. 98
Fuel fi ller fl ap ............................ 98, 99
Fuel gauge...................................... 98
Fuel tank ................................... 98, 99
Fusebox, dashboard ..................... 185
Fuses ............................................ 185Jack .............................................. 178
JACK socket ................. 295, 316, 318
Jukebox (copy) ............................. 236
Jukebox (playing) ......................... 237
Labels, identifi cation ..................... 206
Lamps, warning
and indicator .................... 49, 52, 53
LED daytime running lamps ......... 102
Level, brake fl uid .......................... 168
Level, headlamp wash .......... 106, 169
Level, power steering fl uid ............ 168
Levels and checks ................. 167-169
Lighting ..........................................110
Lighting, guide-me home .............. 103
Lighting, interior .................... 108, 109
Lighting bulbs
(replacement) ............ 181, 183, 184
Lighting control stalk ..................... 100
Lighting dimmer .............................. 61
Loading ................................... 39, 199
Load reduction mode .................... 195
Load space cover ......................... 120
Locating your vehicle ...................... 86
Locking from the inside................... 95
Long objects, transporting .......79, 116
Luggage retaining strap .................118 Keeping children
safe ............ 122, 123, 131, 132, 140
Key with remote control ....... 85-87, 89H
FJ
L K
G.P.S. ................................... 222, 264
Gearbox, electronic
gear control ....................... 158, 171
Gear lever, electronic gear
control gearbox .......................... 158
Glove box ......................................112
Grab handle on console ................ 111
Grab handles ................................. 111
Guidance ...................... 222, 262, 269
Guide-me-home............................ 103
G
Identifi cation plates ....................... 206
Indicator lamps, status.................... 51
Indicators, direction ...................... 134
Infl ating accessories
(using the kit) ............................. 172
Infl ating tyres .................................. 39
Inputs for audio
system ............... 238, 295, 316, 318
Instrument panel lighting ................ 61
Instrument panels ..................... 47, 48
Instrument panel screen ................. 47
Interior fi ttings ................................ 111
Interior mood lighting .................... 109
ISOFIX .......................................... 131
ISOFIX child seats ................. 130-132
ISOFIX mountings ........................ 130
I

ALPHABETICAL INDEX
329
Navigation..................... 222, 261, 262
Number plate lamps ..................... 184
Radio .................... 233, 287, 288, 313
RCA sockets ................................. 238
Reading lamps, rear ..................... 108
Ready ............................................. 30
Ready lamp .................................... 30
Rear foglamp ........................ 183, 184
Rear screen (demisting) ........... 72, 83
Recharging the battery .......... 192-194
Reduction of electrical load .......... 195 Paint colour code .......................... 206
Panoramic glass sunroof ...............117
Parking brake ............................... 171
Parking brake, electric .......... 144, 147
Parking sensors, front................... 163
Parking sensors, rear ................... 162
Particle emission fi lter........... 169, 170
Passenger compartment fi lter....... 170
PEUGEOT call button ................... 209
PEUGEOT CONNECT
ASSISTANCE ............................ 208
Peugeot Connect Media Navigation
(NG4 3D) ......48, 211, 214, 217, 244
Peugeot Connect Navigation
(RT6) ................................... 65, 255
PEUGEOT CONNECT
SOS ................................... 208, 209
Peugeot Connect Sound
(RD5) ........................... 62, 309, 322
PEUGEOT services ...................... 209
PIN code ....................................... 242
Player, CD MP3 ............................ 315
POIs (updating) ............................ 229
Port, USB...............113, 295, 316, 318
Power ............................................. 34
Priming the fuel system ................ 166
Protecting children ............... 122, 123,
128, 130-132, 140
Puncture ....................................... 172 Main beam .................................... 100
Maintenance ................................... 39
Map reading lamps ....................... 108
Markings, identifi cation ................. 206
Mat .................................................114
Menu, main ................................... 312
Mini fuel level ............................ 55, 98
Mirror, rear view .............................. 84
Mirrors, door ................................... 83
Misfuel prevention .......................... 99
Motorway function
(direction indicators) .................. 134
Mountings for ISOFIX seats ......... 130
MP3 CD ........................................ 315
Multimedia, rear .............................115
Music media players ............. 234, 290Regeneration of the particle
emissions fi lter ........................... 170
Reinitialising the electric windows ..... 92
Reinitialising the remote control ..... 88
Remote control ................... 85, 86, 89
Removable screen
(snow shield) ............................. 199
Removing a wheel ........................ 179
Removing the mat .........................114
Repair kit, puncture ...................... 172
Replacing bulbs ............ 181, 183, 184
Replacing fuses ............................ 185
Replacing the air fi lter ................... 170
Replacing the oil fi lter ................... 170
Replacing the passenger
compartment fi lter ...................... 170
Replacing wiper blades ........ 107, 196
Reset history............................. 41, 69
Resetting the service indicator ....... 59
Resetting the trip recorder .............. 61
Rev counter .................................... 47
Reversing lamp............................. 183
Risk areas (update) .............. 229, 266
Roof bars ...................................... 199
Routine checks ..................... 170, 171
Running out of fuel (Diesel) .......... 166
N
RP
M
Safety for children........... 92, 128, 133
Screen, colour 16/9 .............. 217, 244
Screen, colour and mapping .... 259, 298
Screen, monochrome ........... 312, 322
Screen, monochrome C.................. 68
Screen, multifunction
(with audio equipment) .... 62, 65, 67
Screen-wash reservoir.................. 169
Screen menu map ........ 244, 298, 322
Screenwash, front......................... 106
Screenwash fl uid level .......... 106, 169
Seat adjustment........................ 76, 77
Seat belts............................... 137-139
Seats, electric ................................. 77
Seats, rear ...................................... 80
S
Oil fi lter ......................................... 170
Oil level ................................... 60, 168
Opening the bonnet ...................... 165
Opening the boot ...................... 85, 96
Opening the doors .................... 85, 94
Opening the panoramic
sunroof blind ...............................117
Opening the retractable screen ...... 67
Opening the tailgate ................. 96, 97
Operation indicator lamps... 49, 51, 52
O

ALPHABETICAL INDEX
330
Serial number, vehicle .................. 206
Service indicator ............................. 58
Service warning light ...................... 53
Servicing ......................................... 39
Setting the clock ............................. 62
Short-cut menus ................... 218, 260
Sidelamps ..................... 100, 102, 183
Side repeater ................................ 182
SIM card ................................112, 242
Ski fl ap ...........................................116
Snow chain ................................... 206
Spare wheel.................................. 178
Speed limiter................................. 154
Speedometer ............................ 34, 47
Spotlamps, side ............................ 109
Start .................................... 5, 29, 193
Starting the engine ......... 5, 29, 30, 37
Starting the vehicle ....... 5, 29, 87, 158
Steering mounted controls,
audio ...................................216, 311
Stopping the vehicle ..... 5, 29, 87, 158
Stop & Start .... 73, 165, 166, 168, 170
Storage ...................111, 113, 116, 118
Storage box ...................................112
Storage wells .................................118
Stowing rings .................................118
Sun visor................................112, 121
Switching off the engine ....... 5, 29, 30
Synchronising the remote control .... 88
Synthesiser, voice......................... 272
System, ASR ................................ 136
System, navigation ............... 222, 262Under fl oor storage ....................... 121
Unlocking ........................................ 85
Unlocking from the inside ............... 95
Update risk areas ................. 229, 266
Updating POIs .............................. 229
USB (Peugeot Connect) ........113, 316
U
Temporary tyre repair kit ............... 172
Third brake lamp........................... 184
TMC (Traffi c info) .................. 231, 275
Tools ............................................. 178
Total distance recorder ................... 61
Towbar .......................................... 198
Towed loads.................................. 204
Towing another vehicle..... 46, 196, 197
Traction control (ASR) ...... 52, 55, 136
Traffi c information
(TA) .................... 232, 276, 289, 314
Traffi c information
(TMC) ................ 231, 232, 275, 276
Trip computer ........................... 68, 70
Trip distance recorder ..................... 61
Tyre pressures .............................. 206
Tyres ............................................... 39Weights ......................................... 204
Welcome lighting .................. 103, 109
Window controls ............................. 92
Wiper, rear .................................... 106
Wiper control stalk ................. 105-107
Wipers .................................. 105, 107
Table of weights ............................ 204
Tables of engines.................. 202, 203
Tables of fuses.............................. 185
Tank, fuel ........................................ 99
Technical data........................ 202-204
Telephone ...... 209, 239-241, 278, 282
Telephone, hands-free ........... 239-241
Temperature, coolant ...................... 57
Temperature control for heated seats ..... 78
T
Vehicle identifi cation ..................... 206
Ventilation ..................... 43, 71, 72, 82
Voice commands .......................... 214
V
Warning lamps .................... 51, 53, 54
Wash-wipe, rear ........................... 106
Washing (advice) ............................ 45
W

VISUAL SEARCH
333

Courtesy lamps................... 108, 109
Seat belt / passenger's front airbag
warning lamps display ...... 138, 141
Rear view mirror ........................... 84
INSTRUMENTS AND CONTROLS


Dashboard fuses ................. 185-188

Electronic gear control
gearbox ............................. 158-161
Hill start assist ..................... 149-151
Peugeot Connect
Sound ................... 309-325

Setting the date/time .... 62-64

Front armrest .............................. 113
Peugeot Connect
USB .......................... 234, 290, 316
Sun visor..................................... 112

Opening the bonnet .................... 165

Electric parking
brake ..................144-148, 150-151
Interior fi ttings .......................111-114


- glove box

- driver's storage compartments

- mat


12 V accessory socket................ 113



Peugeot Connect Media
Navigation (NG4 3D) ... 211-253 Setting the date/time ..... 65-66

Ventilation ................................ 71-72
Digital air conditioning ............. 73-75
Peugeot Connect
Navigation (RT6) ... 255-307
Setting the date/time ...65-66
