display Peugeot 306 C Dag 2001 Owner's Manual

92
YOUR 306 CABRIOLET IN DETAIL
5 seconds after switching on the ignition the display resumes normaloperation and shows the total and tripdistances.
SERVICE INDICATOR This is a reminder of when the next service is due in accordance with the
manufacturerÕs maintenance sched-ule. Operation The spanner symbolising the service operations comes on for five seconds
when the ignition is switched on. Thetotal distance recorder displays the dis-tance remaining (rounded down) beforethe next service. When the distance remaining beforethe next service is less than 1000 km.
When a service is overdue. For five seconds after the ignition is switched on, the service symbol andthe excess distance flash.
Example: 4800 km remain before the
next service is due. For five secondsafter the ignition is switched on, thedisplay shows:
5 seconds after switching on the igni-tion, the display resumes normal oper-ation and the service symbol remains
lit. The display shows the total and tripdistances.
5 seconds after switching on the igni-tion, the display resumes normal oper-ation and the symbol remains lit. This indicates that a service should
be carried out shortly. The displayshows the total and trip distances. Example:
the service is overdue by
300 km. The vehicle should be serviced very soon. For five seconds after the ignition is switched on, the display shows:
Example:
900 km remain before the
next service is due. For five seconds after the ignition is switched on, the display shows:

193
YOUR 306 CABRIOLET IN DETAIL
- Switch on the ignition.
- The display begins a 10 second
countdown.
- Release the button before the countdown finishes.
- The service interval is displayed.
- Each brief press of button 1alter-
nates the service intervals.
To change the service interval
- Switch off the ignition.
- Press and hold button 1. Example:
- When the chosen service interval
is displayed, press button 1for
10 seconds (countdown) to confirm. Reset
Your PEUGEOT dealer carries out this operation after each service.
However, if you service the vehicleyourself, reset as follows:
- Switch off the ignition.
- Press and hold button
1.
- Switch on the ignition.
- The display begins a 10 second countdown.
- Keep button 1pressed for
10 seconds.
- The display shows [= 0]and the
service symbol disappears.
Service intervals If your vehicle is used in certain
particularly difficult conditions it is necessary to follow the "Arduous conditions" servicing schedule, whichinvolves shorter intervals between
services (see your Warranty andMaintenance Record booklet). Comment:
If the time limit between
two services is reached before the relevant mileage limit, the servicespanner symbol will light up and thedisplay will show 0.

193
YOUR 306 CABRIOLET IN DETAIL
- Switch on the ignition.
- The display begins a 10 second
countdown.
- Release the button before the countdown finishes.
- The service interval is displayed.
- Each brief press of button 1alter-
nates the service intervals.
To change the service interval
- Switch off the ignition.
- Press and hold button 1. Example:
- When the chosen service interval
is displayed, press button 1for
10 seconds (countdown) to confirm. Reset
Your PEUGEOT dealer carries out this operation after each service.
However, if you service the vehicleyourself, reset as follows:
- Switch off the ignition.
- Press and hold button
1.
- Switch on the ignition.
- The display begins a 10 second countdown.
- Keep button 1pressed for
10 seconds.
- The display shows [= 0]and the
service symbol disappears.
Service intervals If your vehicle is used in certain
particularly difficult conditions it is necessary to follow the "Arduous conditions" servicing schedule, whichinvolves shorter intervals between
services (see your Warranty andMaintenance Record booklet). Comment:
If the time limit between
two services is reached before the relevant mileage limit, the servicespanner symbol will light up and thedisplay will show 0.

YOUR 306 CABRIOLET IN DETAIL
60
GENERAL FUNCTIONS On / off
With the ignition key in the ACCESSORIES or IGNITION position, press the "ON/VOL"button to switch the set
on or off. ANTI-THEFT SYSTEM
The first time you use the set following disconnection of the set or the battery, you must enter the confidential code which was given to you on handover of your vehicle. Entering the code Switch the set on. The display shows "CODE"then the set changes over to code request mode and " - - - -" is displayed.
Enter your four-digitcode number using buttons " 1" to " 6".
For example: if your code is 5345 press buttons " 5", " 3", " 4" and " 5" in turn.
When the fourth number has been entered correctly, the radio starts automatically.
Error in entering the code
If an error is made when entering one of the first three digits, do not continue the operation and switch off the radio to prevent blocking it. Each incorrect code entry will result in the set being blocked for a period of from 5 seconds to 30 minutes, after
the 7th incorrect entry.
To unblock the set, leave it switched on during the waiting period. When " - - - -" is displayed, you can enter the
code again.
If the set is switched off during the waiting period, this waiting period will restart when the set is switched on again. After incorrectly inputting the code 14 times, the radio will be permanently locked and the display will read " END".
ADJUSTING THE SOUND Adjusting the volume
Turn the "ON/VOL" button to increase or decrease the volume of the set.
If the radio overheats, the volume reduces. If an attempt is made to increase the volume the message " TOO HOTÕÕ
appears on the display. Note If you have a telephone fitted with a Ò muteÓ signal output connected to the set, the set will automatically change
to Ò mute Ó when the telephone is used.

YOUR 306 CABRIOLET IN DETAIL61
AUDIO SETTINGS Press the Ò AUDIOÓ button several times to select bass (BASS), treble (TREB) , loudness (LOUD), fader (FAD) and
balance (BAL).
Exit from audio mode is automatic after a few seconds, without pressing any button or by pressing the Ò AUDIOÓ
button after adjusting the balance. Note : bass and treble settings are specific to each source. It is possible to set them differently for radio,
cassette and CD. Bass setting When Ò BASSÓ is displayed, press the Ò GÓ or Ò HÓ buttons to vary the setting.
-Ò BASS -9 Ó for a minimum bass setting,
-Ò BASS 0 Ó for a normal position,
-Ò BASS +9 Ó for a maximum bass setting.
Treble settingWhen Ò TREBÓ is displayed, press the Ò GÓ or Ò HÓ buttons to vary the setting.
-Ò TREB -9 Ó for a minimum treble setting,
-Ò TREB 0 Ó for a normal position,
-Ò TREB +9 Ó for a maximum treble setting.
Adjusting the loudness
This function automatically emphasises bass and treble tones when the volume is low. Press the ÒGÓor ÒHÓ buttons to switch this function on or off.
Setting the front/rear sound distribution (Fader) When Ò FA DÓ is displayed, press the Ò GÓ or Ò HÓ buttons to vary the setting.
The Ò GÓ button increases the volume at the front.
The Ò HÓ button increases the volume at the rear.
Note : For vehicles fitted with speakers at the front only, it is possible to cancel or add this function. This
operation is carried out as follows:
- Ignition key in Accessories position,
- With the radio switched off,
- Simultaneously pressing buttons ÒIÓet ÒMÓ .

62
YOUR 306 CABRIOLET IN DETAIL
Setting the right/left sound distribution (Balance) When Ò BALÓ is displayed, press the Ò GÓ or Ò HÓ buttons to vary the setting.
The ÒGÓ button increases the volume on the right-hand side.
The ÒHÓbutton increases the volume on the left-hand side.
RADIO Notes on radio reception
Your car radio receiver is subject to phenomena which do not affect domestic sets. Both MW/LW and FM recep- tion are subject to various forms of interference which are not a reflection on the quality of your set, but are dueto the nature of the signals and the way in which they are transmitted.
On MW/LW, interference may be noticed when passing underneath high voltage power lines or bridges or in tunnels.
On FM, interference may be the result of distance from the transmitter, reflection of the signal by obstacles
(mountains, hills, buildings etc), or of being in an area which is not covered by a transmitter. Selecting the radio Press the "SRC"button, until the radio is selected.
Selecting a wavebandBy short presses on the " BND/AST" button, you can select the FMI, FM2, FM3, and AM wavebands.
Automatic station searchBriefly press button " J" or " K" to search for the next station up or down the waveband. By continuing to press the
button in the direction selected, you will obtain continous scrolling of the frequency. The scrolling stops at the first station found as soon as you release the button.
If the TA traffic programme is selected, only stations broadcasting this type of programme are selected.Searching for a station occurs first in " LO" sensitivity (selection of the most powerful transmitters), while scanning
the waveband, then in " DX" sensitivity (selection of weaker and more distant transmitters).

62
YOUR 306 CABRIOLET IN DETAIL
Setting the right/left sound distribution (Balance) When Ò BALÓ is displayed, press the Ò GÓ or Ò HÓ buttons to vary the setting.
The ÒGÓ button increases the volume on the right-hand side.
The ÒHÓbutton increases the volume on the left-hand side.
RADIO Notes on radio reception
Your car radio receiver is subject to phenomena which do not affect domestic sets. Both MW/LW and FM recep- tion are subject to various forms of interference which are not a reflection on the quality of your set, but are dueto the nature of the signals and the way in which they are transmitted.
On MW/LW, interference may be noticed when passing underneath high voltage power lines or bridges or in tunnels.
On FM, interference may be the result of distance from the transmitter, reflection of the signal by obstacles
(mountains, hills, buildings etc), or of being in an area which is not covered by a transmitter. Selecting the radio Press the "SRC"button, until the radio is selected.
Selecting a wavebandBy short presses on the " BND/AST" button, you can select the FMI, FM2, FM3, and AM wavebands.
Automatic station searchBriefly press button " J" or " K" to search for the next station up or down the waveband. By continuing to press the
button in the direction selected, you will obtain continous scrolling of the frequency. The scrolling stops at the first station found as soon as you release the button.
If the TA traffic programme is selected, only stations broadcasting this type of programme are selected.Searching for a station occurs first in " LO" sensitivity (selection of the most powerful transmitters), while scanning
the waveband, then in " DX" sensitivity (selection of weaker and more distant transmitters).

YOUR 306 CABRIOLET IN DETAIL63
Manual station search Press the Ò MANÓ button.
Briefly press button ÒJÓ orÒKÓ respectively to increase or reduce the frequency displayed.
By continuing to press the button in the direction selected, you will obtain continuous scrolling of the frequency. Scrolling stops as soon as you release the button.Pressing the ÒMANÓbutton again returns you to automatic station search.
Manual storing of stations in the memory Select the station required. Press for more than two seconds one of the buttons Ò 1Ó to Ò 6Ó.
The sound stops then becomes audible again, confirming that the station has been stored in memory. Automatic storing of FM stations in the memory (autostore) Press the Ò BND/ASTÓ button for more than two seconds, to automatically store the 6 stations with the strongest
signal in FM. These stations are stored in the FMIII waveband.
- If it is not possible to find 6 stations, the remaining memories are empty. Recalling stations stored in the memory For each waveband, briefly pressing the buttons Ò1Óto Ò6Ó recalls the corresponding stored station.
RDS FUNCTION Using the RDS (Radio Data System) function on FM RDS allows you to continue to listen to the same station, whatever frequency it is using for the region you are going through.
Switch the function on or off by briefly pressing the Ò RDSÓ button.
RDS station following
The display indicates the name of the station selected. The radio is continually searching for the station which has the best reception and which is transmitting the same programme.

64
YOUR 306 CABRIOLET IN DETAIL
Traffic information programmes Press the Ò TAÓ button to switch the function on or off.
Any traffic information flash will be given priority, whatever source you are listening to (radio, cassette or CD). If you wish to interrupt a message, press the Ò TAÓ button; this switches off the function.
Note : the volume of the traffic information announcements is independent of the volume of normal radio
listening. You can adjust it using the volume button. The setting will be stored and will be used when thenext messages are broadcast.
While traffic information is being broadcast, the display will alternately show Ò TRAFFICÓ and the name of the
station.
When the station selected cannot broadcast traffic information, the display shows Ò NO TAÓ.
Regional following mode (REG) When they are part of a network, certain stations broadcast regional programmes in the various areas they serve. With regional following mode you can keep listening to the same programme.
To do this press the ÒRDSÓbutton for more than two seconds to switch this function on or off.

70
YOUR 306 CABRIOLET IN DETAIL
GENERAL FUNCTIONS On / off
With the ignition key in the ACCESSORIES or IGNITION position, press the "ON/VOL"button to switch the set
on or off. The set can operate for 30 minutes without switching the ignition on. ANTI-THEFT SYSTEM
The first time you use the set following disconnection of the set or the battery, you must enter the confidential code which was given to you on handover of your vehicle. Entering the code Switch the set on. The display shows Ò CODEÓ then the set changes over to code request mode and " - - - -" is displayed.
Enter your four-digitcode number using buttons " 1" to " 6".
For example: if your code is 5345 press buttons " 5", " 3", " 4" and " 5" in turn.
When the fourth number has been entered correctly, the radio starts automatically. Error in entering the code
If an error is made when entering one of the first three digits, do not continue the operation and switch off the radio to prevent blocking it. Each incorrect code entry will result in the set being blocked for a period of from 5 seconds to 30 minutes, after
the 7th incorrect entry.
To unblock the set, leave it switched on during the waiting period. When " - - - -" is displayed, you can enter the code again.
If the set is switched off during the waiting period, this waiting period will restart when the set is switched on again. After incorrectly inputting the code 14 times, the radio will be permanently locked and will display the message ADJUSTING THE SOUND Adjusting the volume
Turn the " ON/VOL" button Mto increase or decrease the volume of the set.
In the event of the radio overheating, the volume level decreases.
Note
If you have a car-phone fitted with a Ò muteÓ signal output connected to the set, the set will automatically change
to Ò mute Ó when the car-phone is used.
