YOUR 307 AT A GLANCE
1. Driver's airbag. Horn.
2. Lights and direction indicators stalk.
3. Audio remote control stalk.
4. Instrument dials.
5. Windscreen wash-wipe stalk.
Trip computer stalk.
6. Alarm button.
7. Central locking button.
8. Hazard warning lights switch.
9. Multifunction display.
10. Brightness sensor.
11. Dynamic Stability control (ESP/ASR) switch*.
12. Central adjustable hea- ting/ ventilation vent and air flow regulation. 13. Windscreen demisting
vents.
14. Speaker (tweeter) location.
15. Side window demisting vent.
16. Side adjustable heating/ ventilation vent and air flow regulation.
17. Passenger air bag.
18. Glove box.
19. RB3, RD3 audio equipment.
20. Heated seat switches.
21. CD changer.
22. Heating / air conditioning controls.
23. Front ashtray.
24. Rear footwell heating vent.
25. 12 V accessories socket. 26. Gear lever.
27. Cup / can holder.
28. Handbrake.
29. Rubbish container.
30. Coin storage.
Passenger air bag disarming switch.
31. Steering lock and ignition.
32. Steering wheel adjustment control.
33. Fuse box.
34. Electric mirror controls. Window controls. Rear window lockingcontrol.
35. Headlamp height adjustment.
36. Cruise control.
* During the year. 3

STEERING WHEEL
STALKS LIGHTING
Front and rear lights (ring A)Lights off. Side lights on.
Dipped/ main beam headlampson. Automatic switching on of lights*
Front fog lamps * and rear foglamp
Turn the ring towards the front to switch on and towards the rear to
switch off. The on/off status isshown by the indicator light onthe instrument panel. Vehicles fitted with a rear foglamp (ring B)
Rear fog lamp.
Vehicles fitted with front foglamps and a rear fog lamp(ring C) Front fog lamps (first rota-tion of the ring forwards).
Front fog lampsand rear fog lamp(second rotation ofthe ring
forwards)
* According to specification WINDSCREEN WIPERS Front
2 Rapid wipe (heavy rain)
1 Normal wipe (moderately heavy rain)
AUTO Automatic wipe*
0 Stop
Single wipe
Wash-wipe: pull the stalktowards you. Rear
Stop Intermittent W ash-
wipe wipe
Automatic wipe*In the AUTO position,
the system automatically adjusts the wiper timingto the intensity of therainfall.
7274
YOUR 307 AT A GLANCE5

PEUGEOT SERVICING25
PEUGEOT SERVICING: A AND C SERVICE LEVELS AND THE INTERMEDIATE VISIT
Level
Operations Description of operation 1st service
A C Intermediate
DRAIN/REFILL- Engine oil.- Bleed fuel filter (diesel).- Oil filter.- Fuel filter (petrol).REPLACE- Fuel filter element (diesel).- Air filter element.- Spark plugs (petrol).- Engine oil (check + top-up). - Manual gearbox oil (check + top-up).- Battery (check + top-up) if cap is removable.LEVEL- Screen wash (check + top-up).- Coolant (check + top-up).- Brake fluid (check + top-up).- Power steering fluid (check + top up according to specification).- Operation of lights and indicators.- Condition of glass, headlamp and light lenses and mirrors.- Horn.- Windscreen washer jets.- Condition of wiper blades.- Condition and tension of the ancillary drive belts.- Handbrake.- Condition of hydraulic circuits (hoses and covers).CHECK- Condition of rubber boots and gaiters.- Brake pads. - Play in hubs, link rods, ball joints, flexible mountings.- Shock absorbers.- Rear drum brake lining wear.- Condition and pressure of tyres (including spare wheel).- Emission control check as per current legislation (petrol).- Smoke opacity (diesel).- Pollen filter (according to specification). - Visual check of the whole vehicle.
SERVICE- Courtesy vehicle.
ROAD TEST
: All driving conditions: Arduous conditions

1 -Rev counter.
2 - Seat belt not fastened warning light.
3 - Engine autodiagnostics warning light.
4 - Handbrake and low brake fluidlevel warning light.
5 - Left-hand direction indicator.
6 - Coolant temperature indicator. 7 -
Battery charge warning light.
8 - Central (STOP) warning light.
9 - Engine oil pressure warning light.
10 - Low fuel level warning light.
11 - Right-hand direction indicator.
12 - Fuel gauge.
13 - ABS warning light. 14 -
Air bag warning light.
15 - Passenger air bag disarmingindicator light.
16 - Speedometer.
17 - Service indicator, oil level and
total distance recorder.
18 - Trip recorder zero reset.
19 - Rear fog lamp indicator light.
20 - (ESP/ASR) warning light*
21 - Front fog lamps indicator light*.
22 - Diesel engine preheating light.
23 -Main beam headlamps indicator light.
24 - Low coolant level warninglight*.
25 - Dipped beam headlampsindicator light.
26 - Water in diesel filter warninglight*.
27 - Lighting rheostat.
* According to specification.
INSTRUMENTS AND CONTROLS
28
INSTRUMENT PANEL DIALS: PETROL / DIESEL

INSTRUMENTS AND CONTROLS29
1 -
Rev counter.
2 - Seat belt not fastened warning light.
3 -
Engine autodiagnostics warning light.
4 - Handbrake and low brake fluid level warning light.
5 - Left-hand direction indicator.
6 - Coolant temperature indicator. 7 -
Battery charge warning light.
8 - Central (STOP) warning light.
9 - Engine oil pressure warning light.
10 - Low fuel level warning light.
11 - Right-hand direction indicator.
12 - Fuel gauge.
13 - ABS warning light. 14 -
Air bag warning light.
15 - Passenger air bag disarming indicator light.
16 - Speedometer.
17 - Service indicator, oil level and
total distance recorder.
18 - Trip recorder zero reset.
19 - Rear fog lamp indicator light.
20 - (ESP/ASR) warning light*
21 - Front fog lamps indicator light*.
22 -
Main beam headlamps indicator light.
23 - Low coolant level warninglight*.
24 - Dipped beam headlampsindicator light.
25 - Lighting rheostat.
26 - Sport programme.
27 - Snow programme.
28 - Gear lever position indicator.
* According to specification
INSTRUMENT PANEL DIALS: AUTOMATIC GEARBOX

Dipped/Main beam change Pull the stalk towards you. Note:with the ignition off, if the dri-
ver's door is opened, a buzzer sounds if you have left your lights on. Front fog lamps* and rear fog lamp Rotate the ring forwards to switch on
and backwards to switch off. The statusis confirmed by the light on the instru-ment panel.
Vehicles fitted with a rear fog lamp (ring B)
Rear fog lamp
This operates with the dipped/main beam headlamps.
Vehicles fitted with front fog lamps and a rear fog lamp (ring C)* Front fog lamps (first rota- tion of the ring forwards)
These operate with the side lightsand the dipped beam lamps.
THE LIGHTS STALK Front and rear lights Selection is by turning ring
A.
Lights off Side lights on Dipped/Main beam headlamps Automatic switching on of lights* Front and rear foglamps (2nd rotation ofthe ring forwards). These operate with the
side lights and the dipped/main beam headlamps. Note: to switch off the rear fog lamp
and the front fog lamps, turn the ring backwards twice in succession.
Direction indicators (flashers) Left : downwards.
Right : upwards.
YOUR 307 IN DETAIL
72
In good or rainy weather, both day and night, therear fog lamp is dazzlingand is prohibited. Do not forget to switch
the fog lamp off when it is no lon- ger needed.
* According tospecification

Automatic timed windscreen wipers* In the AUTOposition, the wind-
screen wipers operate automatically and adapt their speed to the intensi-ty of the rainfall.
Operating check ActivationWhen the function is activated, the message "Automatic windscreen
wiping active" appears on the mul-
tifunction display. Switching off
Switching off the function is accom- panied by an audible signal. In the event of malfunction, the driver is informed by an audible signal andthe message "Auto windscreen
wiper faulty" on the multifunction
display. In the event of malfunction in the
AUTO position, the windscreen
wiper will operate in intermittentmode.
Contact a PEUGEOT dealer to have the system checked.
* According to specification
WINDSCREEN WIPER STALK Front windscreen wipers
2 Fast wipe (heavy rain)
1 Normal wipe (moderately heavy rain)
AUTO Automatic wipe*
0 Off
Single wipe (press downwards) Operation In position
1or 2, when the vehicle
stops, the windscreen wiper changes to a lower wiping speed, then resumesits initial speed when the vehicle startsagain. When the ignition has been swit- ched off for more than a minute with
the control in the AUTO* position, itis necesary to reactivate this func-tion. To do this, move the control to any
position, then move it back to the
AUTO* position.
Screenwash and headlamp wash* Pull the windscreen wiper stalk towards you. The windscreen wash then the wind- screen wipers operate for a fixed
period. The headlamp wash ope-rates simultaneously for a fewseconds, only if the dipped beam
or main beam headlamps are on.
YOUR 307 IN DETAIL
74

ADJUSTING THE HEADLAMPS Depending on the load in your vehicle, adjusting the beam of theheadlamps is recommended as fol-lows. 0 1 or 2 people in the front seats.
- 3 people.
1 5 people.
2 5 people + maximum authorised load.
3 Driver + maximum authorisedload.
Initial setting is position 0. HAZARD WARNING LIGHTS Press the button, the direction indi- cators flash. They can operate with the ignition
off. Automatic lighting of hazard warning lights* When braking in an emergency (depending on the force of decelera-tion), the hazard warning lights come
on automatically. They switch offautomatically the first time you acce-lerate.
However, it is also possible to switch
them off by pressing the button.
* According to specificationSTEERING WHEEL HEIGHT
AND DEPTH ADJUSTMENT
When the vehicle is stationary, unlock the steering wheel by pullinghandle
A.
Adjust the height and depth of thesteering wheel, then lock it bypushing handle Adown fully.
HORN Press one of the spokes or the centre of the steering wheel.
YOUR 307 IN DETAIL
80

1.4 LITRE PETROL ENGINE 1 -Power steering reservoir
2 - Windscreen/headlamp wash reservoir*
3- Coolant reservoir 4 -
Brake fluid reservoir
5 - Battery
6 - Fuse box
7 - Air filter 8 -
Dipstick
9 - Engine oil filler cap
* According to specification
PRACTICAL INFORMATION
94

PRACTICAL INFORMATION95
1.6 LITRE 16V
PETROL ENGINE 1 -
Power steering reservoir
2 - Windscreen/headlamp wash reservoir* 3 -
Coolant reservoir
4 - Brake fluid reservoir
5 - Battery
6 - Fuse box 7 -
Air filter
8 - Dipstick
9 - Engine oil filler cap
* According to specification
