Page 11 of 183
REAR PARKING
ASSISTANCE This system, installed in the rear
bumper, detects any obstacle
(person, vehicle, tree, barrier, ...)situated behind the vehicle. Activation With the engine running, the sys- tem is activated when reverse
gear is engaged. A bleep indi-cates that it is active. The proximity information is pro- vided by an audible signal,consisting of bleeps which beco-me faster as the vehicleapproaches the obstacle. When the distance between the rear of the vehicle and the obs-tacle is less than approximatelytwenty-five centimetres, theaudible signal becomescontinuous. Change to neutral to disarm the system.
11
OPENING THE BONNET Inside the vehicle: Push the
handle on the left side, under the fascia. Outside the vehicle: Lift
the catch, raise the bon- net and secure the strutto keep the bonnet open.
FILLING WITH FUEL This operation must be carried out with
the engine switched off .
The fuel to be used is indicated onthe inside of the flap. The capacity of the tank is approximately 60 litres. On filling, do not continue after the
third cut-off of the pump to avoidany malfunction. Low fuel level From the time this light comes on, the range remai-ning is approximately
30 miles ( 50 km).YOUR 307 SW AT A GLANCE
109109132
14-04-2003
Page 33 of 183
14-04-2003
YOUR 307 SW IN DETAIL
36
Parameter configuration Monochrome screen B Press button 1for two seconds to
gain access to the settings. Then, each press of this button per- mits scrolling of the various parame-ters.
- language of the information dis- played,
- unit of speed (km or miles),
- unit of temperature (degrees Celsius or Fahrenheit),
- time format (12 or 24 hours),
- hour,
- minute,
- year,
- month,
- day. Pressing button 2enables you to
change the parameter selected. Continue pressing the button for rapidscrolling. After ten seconds without action, the
screen returns to the usual display, themodified data are recorded.
- configuration (see corresponding
section).
- map (see section "Satellite naviga- tion system")
A few definitions Superimposed display: a window appears over the current application for a short while, toannounce a change of status of ano-ther application. Permanent application: main application currently in use, dis-
played in the main screen window. Contextual menu: limited menu associated with the main application currently in use,
displayed in the main screen window.
Colour screen DT General menu Press the
"MENU" button to access
the general menu and select one of
the following applications:
- navigation - guidance (see section "Satellite navigation system"),
- trip computer (see corresponding section),
- directory (see "RT3 audio/telepho- ne" section),
- telematics (see "RT3 audio/tele- phone" section),
Page 34 of 183
14-04-2003
YOUR 307 SW IN DETAIL
36
Parameter configuration Monochrome screen B Press button 1for two seconds to
gain access to the settings. Then, each press of this button per- mits scrolling of the various parame-ters.
- language of the information dis- played,
- unit of speed (km or miles),
- unit of temperature (degrees Celsius or Fahrenheit),
- time format (12 or 24 hours),
- hour,
- minute,
- year,
- month,
- day. Pressing button 2enables you to
change the parameter selected. Continue pressing the button for rapidscrolling. After ten seconds without action, the
screen returns to the usual display, themodified data are recorded.
- configuration (see corresponding
section).
- map (see section "Satellite naviga- tion system")
A few definitions Superimposed display: a window appears over the current application for a short while, toannounce a change of status of ano-ther application. Permanent application: main application currently in use, dis-
played in the main screen window. Contextual menu: limited menu associated with the main application currently in use,
displayed in the main screen window.
Colour screen DT General menu Press the
"MENU" button to access
the general menu and select one of
the following applications:
- navigation - guidance (see section "Satellite navigation system"),
- trip computer (see corresponding section),
- directory (see "RT3 audio/telepho- ne" section),
- telematics (see "RT3 audio/tele- phone" section),
Page 38 of 183
14-04-2003
GENERAL FUNCTIONSOn/off With the ignition key in the accessories or ignition position, press button Ato switch the set on or off.
The set can operate for 30 minutes without the vehicle ignition being switched on.
Anti-theft systemThe audio system is coded in such a way that it can operate only on your vehicle. It would not function if fitted to another vehicle. The anti-theft system is automatic and requires no action on your part. ADJUSTING THE VOLUME Press button Cto increase the volume, or button Bto decrease it.
Continuous pressure on buttons Cand Ballows a gradual adjustment of the volume.
AUDIO SETTINGS Press button Hseveral times in succession to access the bass (BASS), treble (TREB), loudness (LOUD),
fader (FAD) , balance (BAL) and automatic volume correction settings.
Exit from audio mode is automatic after a few seconds without pressing any button, or by pressing button H
after configuration of the automatic volume correction. Note : bass and treble settings are specific to each source. It is possible to set them differently for radio,
cassette (RB3), CD ( RD3)and CD changer.
YOUR 307 SW IN DETAIL
42
Page 44 of 183
14-04-2003
CD CHANGER Selecting CD changer modeAudio RB3 :press the "SRC"button several times in succession.
Audio RD3 : press button P.
Selecting a disc Press buttons "1" to"5" on the radio to select the corresponding disc.
Selecting a track Press button Lto select the next track.
Press button Nto return to the start of the current track or to select the previous track.
Accelerated play Press and hold button Lor Nfor forwards or backwards accelerated play.
Accelerated play stops as soon as the button is released.
Shuffle (RDM)When the CD changer is selected: - audio RB3 : press and hold the "SRC" button for two seconds;
- audio RD3 : press and hold button Pfor two seconds.
The tracks will be played in random sequence. Pressing the button again for two seconds returns you to normal play.
YOUR 307 SW IN DETAIL
50
Page 62 of 183
14-04-2003
YOUR 307 SW IN DETAIL61
COMPACT DISC CHANGER Selecting CD changer mode Press the "SOURCE" button several times.
Selecting a disc Press one of the buttons ''1'' to''5'' on the audio/telephone to select the appropriate disc.
Buttons Hand Iallow you to select respectively the previous or following disc in the changer.
Selecting a track Press button Mto select the following track.
Press button Nto return to the start of the current track or to select the previous track.
Accelerated playPress and hold button Mor N for forwards or backwards accelerated play.
Accelerated play stops as soon as the button is released. Contextual menu
The contextual menu permits you to switch on or switch off the shuffle, playing the start of a track or repeat a track functions.
Page 70 of 183
14-04-2003
YOUR 307 SW IN DETAIL69
Voice commands The voice commands make it possible to use pre-recorded words or phrases to control a certain number of functions of the
RT3 audio/telephone. Activation of the voice commands Press the button on the end of the lights stalk to activate this function. Example: to recall the radio station stored on button 3, the key words are: "Radio" "Memory" "3" .
To use these key words, you must say the word "Radio", wait for the audible confirmation signal, then say the word
"Memory" , wait for the audible confirmation signal, then end with the word "3", wait for the audible confirmation signal which
will carry out the action requested. Notes: - between two key words, a screen indicates the time remaining and the key word recognised,
- in the absence of any voice commands, this function will be switched off after approximately five seconds,- if a command is not understood, the system transmits "Pardon" and displays "Word not recognised" on the screen.
Saying the phrase "Help" or"What can I say" displays all of the commands available on the screen.
List of commands available
- For the radio, say "RADIO", then : "PREVIOUS" / "FOLLOWING" / "MEMORY" + 1...6 / "AUTOSTORE"
- For the CD, say "CD PLAYER", then: " PREVIOUS TRACK" / "FOLLOWING TRACK" / "TRACK NUMBER" + 1..20 / "SHUFFLE" / "SCAN" / "REPEAT"
- for the CD changer, say "CD CHANGER", then: " PREVIOUS TRACK" / "FOLLOWING TRACK" / "TRACK NUMBER" + 1...20 / "PREVIOUS DISC" / "FOLLOWING DISC" /
"DISC NUMBER" + 1...5 / "SHUFFLE" / "SCAN" / "REPEAT"
- For the telephone, say "TELEPHONE", then: "LAST NUMBER" / "DIRECTORY" + DESCRIPTION / "SERVICES"
- For navigation, say "NAVIGATION", then: "STOP" / "RE-START" / "DIRECTORY" + DESCRIPTION
- To change the permanent application, say "DISPLAY", then: "AUDIO" / "TELEPHONE" / "NAVIGATION" / "TRIP COMPUTER"
- To call someone recorded in the directory directly, say "CALL" + DESCRIPTION
- To be guided to the address of someone recorded in the directory, say "GUIDE TO" + DESCRIPTION.
- Various: "CANCEL" / "HELP" / "WHAT CAN I SAY"
Page 75 of 183
14-04-2003
YOUR 307 SW IN DETAIL
74
elect the Navigation/Guidance icon using the dial, then validate by pres-sing the dial to access the main"Navigation - Guidance" menu.
General menu
Switch on the RT3 audio/telephone and insert the navigation CD-Rom. Press the "MENU"button to access
the general menu .
During guidance, if the navigation CD-Rom is present, the screen displays
different information depending on the manoeuvres to be carried out. 1. Current manoeuvre or compass.
2. Next manoeuvre to be carried out.
3. Next road to be taken.
4. Current road.
5. Estimated time of arrival at destination.
6. Distance to final destination.
7. Distance to next manoeuvre.
Notes:
- depending on the situation of the vehicle and on the reception of GPS information, this information may disappear from the screen temporarily,
- during guidance, it is only possible to listen to a CD if the vehicle is fitted with a CD changer.
General notes on the display
12
765
123
7654
4
3
Monochrome screen CT Colour screen DT
12
765
123
7654
4
3
Page 79 of 183
14-04-2003
YOUR 307 SW IN DETAIL
78
Select the ''Directory'' function to
access the file in which the address you are looking for is archived. Select a description by scrolling down the list by means of the dial,then confirm by pressing the dial.The directory file is then displayed. Select the "OK"function, then press
the dial to access the guidance acti- vation function. Follow the directions given by the system.
Selecting a destination stored inthe directory
Select the
"Most recent destina-
tions" function to access one of the
last ten addresses stored. Select a description by scrolling down the list by means of the dial,then confirm it by pressing the dial.The complete address is then dis-played. Select the "OK" function, then press
the dial to access the guidance acti- vation function. Follow the instructions given by the system.
Selection of one of the last tendestinationsActivate the function
''Changing the
route'' , then input the distance invol-
ved in the change required. Select the ''OK''function then valida-
te by pressing the dial. The system calculates the change which is closest to the value inputand gives you the option of whetheror not to use this change. Details of the route
You can consult the destination address at any time by activating the"Chosen destination" function.
Changing the initial route
Page 111 of 183
14-04-2003
THE ALARM This provides two types of protec- tion: Ðexterior protection: it sounds if
a door, the boot or the bonnet is opened.
Ð interior protection: it sounds if
the volume inside the passengercompartment changes (breakingof a window or a movement insi-de the vehicle).
Setting the alarm Switch off the ignition and get out of the vehicle.
Set the alarm within five minutesof getting out of the vehicle, bylocking or deadlocking using theremote control (button Aindica-
tor light flashes once persecond).
Note: if you wish to lock your vehicle
without setting the alarm, use thedoor lock. When the alarm is triggered, thesiren sounds and the direction indi-cator lights flash for thirty seconds. After triggering, the alarm remains set.
Warning:
if the alarm has been
triggered ten times in succession, on the eleventh time it becomesinactive. Note: if button Aindicator light
flashes rapidly, the alarm has been triggered while you were away fromyour vehicle.
Disarming Unlock the vehicle with the remote control key (button Aindicator light
goes out). Note: if the alarm has been triggered
while you were away from your vehicle, the rapid flashing of the indi-cator light will stop when you switchon the ignition.
To set the alarm with exterior protection only If, while you are away from the vehicle, you wish to leave a windowpartially open or a pet inside thevehicle, you should choose exterior
protection only. Switch off the ignition,
In the next ten seconds, press button Auntil the indicator light is
on continuously,
Get out of the vehicle,
Set the alarm by locking or dead-locking using the remote control(button Aindicator light flashes
once a second).
Note: when the alarm is set but the
remote control does not operate: Unlock the doors with the key
and open the door. The alarm istriggered.
Switch on the ignition in the next
ten seconds. The alarm is disar-med.
Incorrect operation When the ignition is switched on, if button Alights for ten seconds, there
is a fault in the siren connection.
Contact a PEUGEOT dealer to have the system checked. Automatic activation* The alarm is activated automatically two minutes after the last closure ofa door or the boot. In order to avoid accidental triggering of the alarm when a door or the bootis opened, it is essential to first pressthe unlocking button on the remotecontrol.
* According to destination.
YOUR 307 SW IN DETAIL
106
