Page 11 of 136
Moving Off
With the engine turning, to move off from position P:
press the brake pedal to change out of position P (shift lock),
select the required position ( R, D, 3, 2or 1) then gradually release the brake pedal; the vehicle moves off imme-
diately.
You can also move off from position N : release the handbrake, keeping your foot on the brake pedal,
select the required position ( R, D, 3, 2or 1) then gradually release the brake pedal; the vehicle moves off imme-
diately.
The four speed automaticgearbox offers a choice between the comfort of integral operation,enhanced by a
sport programme (switch A) and a snowprogramme (switch B).
Gear selection gate Move the lever in the gate to select a position.
Once the position is selected, the indicator light for that position illuminates on the instrument panel display.
P ark: for immobilising the vehicle and starting the engine , with the handbrake on or off.
R everse: for reversing (select this position with the vehicle stationary, engine at idle).
N eutral: for starting the engine and for parking, with the handbrake on.
D rive: for driving in autoadaptive mode (automatic changing of the four gears).
3 - for driving in townor on winding roads (automatic changing of the first 3 gears only).
2 - for driving in the mountainsor for towing a trailer (automatic changing of the first 2 gears only).
1 - for tackling steep gradients (selection of first gear only).
Special feature of the gearbox (2 litre petrol engine) Selection of first gear is by press- ing switch Cwith the selector
lever in position 2.
To change out of first gear, pressswitch Cagain or move
the gear lever.
AUTOMATIC AUTOADAPTIVE GEARBOX
2 litre engine
YOUR 406 COUPE AT A GLANCE
12
V6 engine
01-07-2002
11 9
Page 12 of 136
CRUISE CONTROL The cruise control makes it possible to maintain a constant vehicle speed
programmed by the driver, whatever the condition of the road and withoutaction on the accelerator or brake pedal.
To be memorised, the vehicle speed must be above approximately 25mph (40 km/h). Operation Place knob 1in the ONposition.
A speed can be memorised. Place knob 1in the OFFposition to deactivate the system.
Memorising a speed When you reach the required speed, press button 2or 3. The speed is
memorised and will be maintained automatically.Note: it is possible to accelerate temporarily without deactivating the
cruise control.
Deactivation of the memorised speedIf you wish to deactivate the memorised speed: press button 4or the clutch or brake pedal.
Recalling the memorised speedFollowing deactivation, press button 4. Your vehicle resumes
the last speed memorised. YOUR 406 COUPE AT A GLANCE
13
Do not use the cruise control on slippery roadsor in heavy traffic.
Modifying a memorised speed
To memorise a speed greater than the previous speed:
press button 3;
release it when you havereached the required speed.
To memorise a speed lower thanthe previous speed: press button 2;
release it when you reach therequired speed.
Cancelling the memorised speed Place knob 1in the OFFposi-
tion or switch off the ignition.
01-07-2002
122
Page 13 of 136
FUEL FILLER FLAP
To open:firmly pull the handle on
the floor to the outside of the driv- er's seat.
To close: from outside the vehi-
cle, push back the flap and check
that it is secured correctly. Filling with fuel Switch off the engine.
A filler cap hook is provided.
A label on the inside of the flap shows which fuels are permitted and which are not. The capacity of the tank is approximately 15.4 gallons (70 litres).
Low fuel level warning lightFrom the time this light comes on, the range remaining is approximately 30 miles (50 km). OPENING THE BONNET Inside the vehicle:
Pull the han-
dle. Outside the vehicle: Raise the catch andopen the bonnet.
YOUR 406 COUPE AT A GLANCE
14
01-07-2002
8888
Page 14 of 136
PEUGEOT SERVICING
Your vehicle benefits from extended service intervals.
¥ For petrol engines: every 20,000 miles (30 000 km) or every two years.
¥ For direct injection diesel engines: every 12,000 miles (20 000 km) or every two years. The extension of the service intervals means that the engine oil level must be checked regularly: topping up of the oil between oil changes is normal. It is for this reason that the PEUGEOT network invites you to an intermediate visit between each regular service.
The date of this service is not shown by the service indicator. It is to be carried out at least every 10,000 miles
( 15 000 km) for petrol engines and every 6,000 miles (10 000 km) for direct injection diesel engines. A Peugeotdealer will carry out a quick check, and will top up the levels if necessary (oil, coolant, screenwash up to 2 litres). If the oil level is too low there is a risk of serious damage to the engine: check the engine oil level at least every 2,000 miles (3 000 km) or 3,000 miles (5 000 km), depending on the conditions of use.
The extended service intervals have been made possible by technical modifications to the vehicles and lubricants: THUS
IT IS ESSENTIALTO ONLY USE ENGINE LUBRICANTS WHICH ARE APPROVED AND RECOMMENDED BY THE
MANUFACTURER
MAINTENANCE OF YOUR 406 COUPE
18
01-07-2002
Page 15 of 136
SPECIAL FEATURES Some of your vehicle's vital components have specific servicing schedules. The air bags and the pretensioning seat beltsmust be replaced every 10 years.
The brake fluid must be replaced every 36/40,000 miles (60 000 km) or every 2 years.
The pollen filter must be checked at each visit to the PEUGEOT dealer (intermediate visits and regular services).
Replacement of the timing belt: consult your Peugeot dealer.
MAINTENANCE OF YOUR 406 COUPE 19
Arduous conditions of use If the vehicle is used in certain particularly arduous conditions:
¥ Continuous door-to-door use.
¥ Town use (e.g. taxi).
¥ Repeated short journeys, with the engine cold in low temperatures. or for long stays in the following conditions:
¥ Hot countries with temperatures often above 30¡C.
¥ Cold countries with temperatures often below minus 15¡C.
¥ Countries with a dusty atmosphere.
¥ Countries whose lubricants or fuels do not conform to our recommendations, it is necessary to follow an "Arduous conditions" servicing schedule, which includes special operations and shorter service intervals:
¥ Every 12,000 miles (20 000 km) or every year for petrol engine vehicles.
¥ Every 9,000 miles (15 000 km) or every year for Direct Injection Diesel engine vehicles.
01-07-2002
Page 16 of 136
SPECIAL FEATURES Some of your vehicle's vital components have specific servicing schedules. The air bags and the pretensioning seat beltsmust be replaced every 10 years.
The brake fluid must be replaced every 36/40,000 miles (60 000 km) or every 2 years.
The pollen filter must be checked at each visit to the PEUGEOT dealer (intermediate visits and regular services).
Replacement of the timing belt: consult your Peugeot dealer.
MAINTENANCE OF YOUR 406 COUPE 19
Arduous conditions of use If the vehicle is used in certain particularly arduous conditions:
¥ Continuous door-to-door use.
¥ Town use (e.g. taxi).
¥ Repeated short journeys, with the engine cold in low temperatures. or for long stays in the following conditions:
¥ Hot countries with temperatures often above 30¡C.
¥ Cold countries with temperatures often below minus 15¡C.
¥ Countries with a dusty atmosphere.
¥ Countries whose lubricants or fuels do not conform to our recommendations, it is necessary to follow an "Arduous conditions" servicing schedule, which includes special operations and shorter service intervals:
¥ Every 12,000 miles (20 000 km) or every year for petrol engine vehicles.
¥ Every 9,000 miles (15 000 km) or every year for Direct Injection Diesel engine vehicles.
01-07-2002
Page 17 of 136
SERVICE INDICATOR This is a visual reminder of when the
next service is due. This service is tobe carried out according to the man-ufacturer's servicing schedule. Operation As soon as the ignition is switched on and for 5 seconds, the spannersymbolising ''service operation'' is lit.The trip recorder display shows youthe distance remaining (in round fig-ures) before the next service. Example:4,800 km remain before
the next service is due. When the ignition comes on and for 5 secondsthe display indicates: 5 seconds after the ignition is switched on, the total distancerecorder resumes normal operationand the display shows the total or tripdistances. The distance remaining before the next service is less than 1,000 km. Example:
900 km remain before the
next service is due. When switching on the ignition and for 5 seconds, the display shows: 5 seconds after the ignition is switched on, the total distancerecorder resumes normal operationand the symbol remains lit. This indicates that a service should
be carried out shortly. The displayshows the total or trip distances. The service is overdue Each time the ignition is switched on and for 5 seconds, the symbol andthe excess distance flash. Example:
the service is overdue by
300 km. The service should be car-
ried out very shortly. When the ignition is switched on and for 5 seconds, the display shows: 5 seconds after the ignition is switched on, the total distancerecorder resumes normal operation
and the symbol remains lit. The dis-play shows the total or trip distances.
YOUR 406 COUPE IN DETAIL 109
01-07-2002
Page 18 of 136
Resetting the service indicator
Your PEUGEOT dealer carries out this operation after each service.
However, if you carry out the serviceyourself, the reset procedure is asfollows: - Switch off the ignition.
- Press and hold button 1.
- Switch on the ignition.
The display begins a 10 second countdown. - Keep button 1pressed for 10
seconds.
The display shows [= 0] and the ser-
vice symbol disappears.
YOUR 406 COUPE IN DETAIL
110
01-07-2002
Page 19 of 136
SERVICE LEVELS Each vehicle has its own servicing cycle, based upon the engine type.
The servicing cycle consists of alternating 2 types of service A and C, intermediate visits, and a few additional operations depending on your vehicle; these correspond to key stages in the life of your 406 CoupŽ. Level B service is designed for less recent vehicles.When the first service is carried out and at each subsequent service, your dealer will advise you of the type and content of the next service due.
MAINTENANCE OF YOUR 406 COUPE
20
These fixed operations are carried out with synthetic based oil; Fuel Economy
oil or synthetic oil may also be used.
* Whichever comes first. Intermediate visit.
THE MAINTENANCE CYCLE FOR YOUR 406 COUPE PETROL ENGINE
2 litre 16V Petrol Engine: Service every 20,000 miles (30 000 km) or 2 years
MILES (KM) 20,000 (30 000) 40,000 (60 000) 60,000 (90 000)
80,000 (120 000) 100,000 (150 000) 120,000 (180 000) 140,000 (210 000) 160,000 (240 000)
1st service at 6,000 miles
(10 000 km) or 6 months*. This is necessary
in order to benefit from the warranty.
01-07-2002
Page 20 of 136
80,000 (120 000) 100,000 (150 000) 120,000 (180 000) 140,000 (210 000) 160,000 (240 000)MILES (KM) 20,000 (30 000) 40,000 (60 000) 60,000 (90 000)
These fixed operations are carried out with
synthetic based oil; Fuel Economy oil
or synthetic oil may also be used.
* Whichever comes first. Intermediate visit.
THE MAINTENANCE CYCLE FOR YOUR 406 COUPE PETROL ENGINE
V6 24V Petrol injection Engine : Service every 20,000 miles (30 000 km) or 2 years
1st service at 6,000 miles
(10 000 km) or 6 months*. This is necessary
in order to benefit
from the warranty.
+ replacement of air filter
+ replacement of fuel filter
+ replacement of air filter
+ replacement of fuel filter
MAINTENANCE OF YOUR 406 COUPE 21
01-07-2002
