Cavity Maxi Fuse Mini Fuse Description
F01 70 Amp Tan Body Controller
F03 20 Amp Yellow Ignition Switch
F04 40 Amp Orange Anti-Lock Brake Pump
F05 20 Amp Yellow Anti-Lock Brake Valve
F06 40 Amp Orange Radiator Fan - Low Speed
F07 50 Amp Red Radiator Fan - High Speed
F08 20 Amp Yellow Blower Motor
F09 5 Amp Tan Headlight beam switch (If Equipped)
F10 10 Amp Red Horn
F11 20 Amp Yellow Powertrain
F14 15 Amp Blue Alfa Twin Clutch Transmission
F15 15 Amp Blue Alfa Twin Clutch Transmission
F16 5 Amp Tan Alfa Twin Clutch Transmission, ECM
F17 10 Amp Red Powertrain
F18 5 Amp Tan Powertrain
7
MAINTAINING YOUR VEHICLE 289

Cavity Maxi Fuse Mini Fuse Description
F19 7.5 Amp Brown Air Conditioning Compressor
F21 20 Amp Yellow Fuel Pump
F22 20 Amp Yellow Engine Control Unit Power Supply
F24 5 Amp Tan Anti-Lock Brake System (ABS)
F30 10 Amp Red Water Pump, HVAC
F82 30 Amp Green Headlamp Washer (If Equipped)
F83 40 Amp Orange Alfa Twin Clutch Transmission Pump
F84 5 Amp Tan After Run Pump
F86 15 Amp Blue Rear Power Outlet 12V
F88 7.5 Amp Brown Heated Mirrors
Dashboard Fuse Box
The dashboard fuse box is part of the Body Control
Module (BCM) and is located on the passenger side
under the forward passenger floor. Remove the six
screws and the forward floor pan to access the BCM.
290 MAINTAINING YOUR VEHICLE

CavityVehicle Fuse
NumberMini Fuse Description
3 F53 7.5 Amp Brown Instrument Panel Node
4 F38 15 Amp Blue Central Door Locking
5 F36 10 Amp Red Diagnostic Socket, Car Radio, TPMS, Alarm
6 F43 20 Amp Yellow Bi-Directional Washer
7 F48 20 Amp Yellow Passenger Power Window
9 F50 7.5 Amp Brown Airbag
10 F51 7.5 Amp Brown Headlamp Washer Relay, A/C Compressor Relay,
High Beam Relay, Parking ECU, Car Radio, Stop
Lamp Switch
11 F37 7.5 Amp Brown Stop Light Switch, Instrument Panel Node
12 F49 5 Amp Tan Transmission Shifter Module, Cigar Lighter Light,
Drive Style Unit, Heated Mirrors Relay
13 F31 5 Amp Tan Climate Control, Body Controller
14 F47 20 Amp Yellow Driver Power Window
7
MAINTAINING YOUR VEHICLE 291

VEHICLE STORAGE
If you are leaving your vehicle dormant for more than 21
days, you may want to take these steps to protect your
battery.
•Disconnect the negative cable from the battery.
•Anytime you store your vehicle, or keep it out of
service (e.g., vacation) for two weeks or more, run the
air conditioning system at idle for about five minutes
in the fresh air and high blower setting. This will
ensure adequate system lubrication to minimize the
possibility of compressor damage when the system is
started again.
REPLACEMENT BULBS
Interior Bulbs
Bulb Number
Overhead Lamp C10W
Luggage Compartment W5W
Exterior Bulbs
Bulb Number
Parking Lights/Daytime
Running Lights (DRL)LED (See Authorized
dealer)
Rear Tail Lights LED (See Authorized
dealer)
Font and Rear Side
LightsW3W
292 MAINTAINING YOUR VEHICLE

Bulb Number
Dipped/Main Beam
Headlights (Versions
With Bi-Halogen Head-
lights) — If EquippedHIR2
Dipped/Main Beam
Headlights (Versions
With Bi-Xenon Head-
lights) — If EquippedD5S (See Authorized
dealer)
Dipped/Main Beam
Headlights (Versions
With Bi-Led Headlights)
— If EquippedLED (See Authorized
dealer)
Front Direction Indicators PY24W
Rear Direction Indicators P21W
Side Direction Indicators WY5WBulb Number
Brake Lights LED (See Authorized
dealer)
Third Brake Light LED (See Authorized
dealer)
License Plate Lamps W5W
Reversing light W16W
NOTE:Numbers refer to commercial bulb types that
can be purchased from your authorized dealer.
If a bulb needs to be replaced, visit your authorized
dealer or refer to the applicable Service Manual.
7
MAINTAINING YOUR VEHICLE 293

BULB REPLACEMENT
NOTE:Lens fogging can occur under certain atmo-
spheric conditions. This will usually clear as atmospheric
conditions change to allow the condensation to change
back into a vapor. Turning the lamps on will usually
accelerate the clearing process.
Front Light Clusters
The front head lamp contains bulbs for the parking
lights/daytime running lights (DRL), low beam head-
lights, high beam headlights and direction indicators.
If bulb replacement is required, please see an authorized
dealer.
1 — Daytime Running Lights
2 — Direction Indicator
3 — High/Low Beam Lights 294 MAINTAINING YOUR VEHICLE

Side Lights/Daytime Running Lights (DRL)
These are LEDs. For the replacement, contact the your
authorized dealer.
Low/High Beam Bi-Halogen Headlights
To change the bulb, proceed as follows:
1. Turn the steering wheel completely.
2. Open the protective flap by rotating the screw.
1 — Direction Indicator Bulb Protective Flap
2 — Headlamp Bulb Protective Flap
7
MAINTAINING YOUR VEHICLE 295

3. Remove the electric connector (1) and then rotate the
bulb holder (2) clockwise and remove it.4. Extract the bulb and replace it.
5. Refit the new bulb, making sure that it is locked
correctly, and reconnect the electrical connector.
6. Close the protective flap.
Low/High Beam HID & LED Headlights
For the replacement, contact the your authorized dealer.
Direction Indicators
Front:
1. Turn the steering wheel completely.
2. Open the protective flap by rotating the screw.
1 — Electrical Connector
2 — Bulb Holder 296 MAINTAINING YOUR VEHICLE

3. Rotate the bulb holder counterclockwise and remove
it.4. Rotate the bulb assembly counter clockwise to remove
from bulb holder.
5. Install the new bulb, making sure that it is locked in
correctly, and reinstall into headlamp assembly.
6. Close the protective flap.
1 — Direction Indicator Bulb Protective Flap
2 — Headlamp Bulb Protective Flap
Bulb Holder
7
MAINTAINING YOUR VEHICLE 297

Side:
1. Adjust the lens in the point shown in to compress the
retaining clip, then pull the cluster outwards.
2. Turn the bulb holder counterclockwise, remove the
bulb and replace it.
3. Install the bulb holder in the lens and turn it clock-
wise.
4. Install the cluster making sure that the internal clip
clicks into position.
1 — Lens
2 — Bulb Holder 298 MAINTAINING YOUR VEHICLE
