Peugeot 508 Dag 2010.5 Owner's Manual

297
3
2
4
041
AUDIO
AUXILIARY SOCKET (AUX)
AUXILIARY JACK SOCKET
Do not connect a device to the USB port and to the auxili
ary Jack socket at the same time.
The auxiliary Jack socket permits the connection of a portable non mass storage device or an iPod ® if not recognised by the USB port.
Connect the portable device to the auxiliary Jack socket using a suitable cable (not supplied).
Press the SOURCE button several times in succession and select " AUX ".
First adjust the volume on your portable device.
Then adjust the volume of the audio system.
The display and management of controls is on the portable device.

298
04
1
2
1
2
3
4
5
AUDIO
STREAMING - PLAYING AUDIO FILES
VIA BLUETOOTH
Depending on the compatibility of the phone
Connect the telephone: see the "USING THE TELEPHONE" section.
Streaming allows music fi les on a telephone to be heard via the vehicle's speakers.
The telephone must support the appropriate bluetooth profi les (Profi les A2DP/AVRCP).
Activate the streaming source by pressing SOURCE . Control of playback is via the audio system. The contextual information can be displayed on the screen.
In certain cases, playing of the audio fi les must be initiated from the telephone.
The audio quality depends on the quality of the transmi ssion from the telephone.
PLAY MODE
The play modes available are:
- Normal: the tracks are played in order, depending on th e classifi cation of the selected fi les.
- Random: the tracks in an album or folder are played in a random order.
- Random all: all of the tracks saved in the media ar playe d in random order.
- Repeat: the tracks played are only those from the current album or folder.
Press OK for access to the contextual menu.
or
Press MENU .
Select " Multimedia " and confi rm.
Select " Media parameters " and confi rm.
Select " Read mode " and confi rm.
Select the desired play mode and confi rm OK to save the modifi cations.

299
05
1
2
5
3
4
6
USING THE TELEPHONE
PAIRING A TELEPHONE
The services offered depend on the network, the SIM card and the compatibility of the Bluetooth telephone used.
Consult your telephone's manual and your operator to fi nd out which services are available to you. A list of mobile telephones which offer the best range of services is available from the PEUGEOT dealer network.
Activate the telephone's Bluetooth function.
Press MENU . A window is displayed " Search in progress… ".
Select the telephone to be connected from the list. Only one telephone can be connected at a time.
Select " Search for a device ".
For safety reasons and because they require prolonged attenti on on the part of the driver, the operations for pairing of the Bluetooth mobile telephone with the Bluetooth hands-free system of your audio system must be carried out with the vehicle stationary and the ig nition on.
Select " Bluetooth connection " and confi rm.

300
05
7
8
Saisir code authentification01
OK Del 2 3 4 5 6 7 8 9_
9
10
USING THE TELEPHONE
A virtual keypad is displayed on the screen: enter a code with at least4 digits and conform with OK .
A message is displayed on the screen of the telephone: enter the same code and confi rm.
A message appears in the screen to confi rm the result of the connection.
Pairing can also be initiated from the telephone by searchi
ng for detected Bluetooth devices.
Accept the connection to the telephone.
If pairing fails, try agin; the number of attempts is not limited.
The directory and the calls list can be accessed after the synchronisation period (if the telephone is compatible).
Automatic connection must be confi gured in the telephone to allow the connection each time the vehicle is started.
In some cases, the reference number of the telephone may appe ar instead of the name of the telephone.

301

05
1
2
4
3
USING THE TELEPHONE
To see the telephone status, press MENU .
Select " Telephone " and confi rm.
Select " Telephone management " confi rm.
Select " Telephone status " and confi rm.
TELEPHONE STATUS
The screen displays: the name of the telephone, the name of the network, network signal strength, confi rmation of the Bluetoot h connection and the streaming connection.

302


1
2
3
4
05
5
USING THE TELEPHONE
The telephone connection automatically includes hands free operation and audio streaming.
Press MENU .
Select " Bluetooth connection " and confi rm.
Indicates connection of the audio steaming profi le.
MANAGING CONNECTIONS
Select " Connections management " and confi rm. The list of paired telephones is displayed.
Select a telephone and confi rm.
Indicates connection of the hands-free profi le.
Then select and confi rm:
- " Connect telephone "/" Disconnect telephone ": to connect/disconnect the telephone or the hands-free connection only.
- " Connect media player "/Connect media player" Disconnect media player ": to Disconnect media playerconnect/disconnect only streaming.
- " Connect telephone + media player "/" playerDisconnect telephone + media player ": to connect/disconnect media playerthe telephone (hands-free and streaming).
- " Delete connection ": to delete the pairing.
Indicates that a device is connected.

303


1
2
1
4
2
33
05
USING THE TELEPHONE
To display the " TELEPHONE " menu: - Make along press on SOURCE . - Or, press OK to display the contextual menu. Select " Call " and confi rm. - Or, press MENU , select " Telephone " and confi rm. Select " Call " and confi rm.
Select " Dial " to enter a number and confi rm.
Repeat the previous step 1 to display the " TELEPHONE " menu.
Select OK and confi rm to start the call.
Select " Calls list " and confi rm.
MAKING A CALL - DIALLING
Select numbers one at a time using the  and  buttons and confi rm.
MAKING A CALL - RECENTLY CALLED
NUMBERS *
Select the number and confi rm to start the call.
The calls list includes calls sent and received in the vehicle
using the connected telephone.
* Depending on the compatibility of the telephone.
Correction allows numbers to be deleted one at a time.

304


1
2
1
4
2
3
05 USING THE TELEPHONE
Repeat the previous step 1 to display the " TELEPHONE " menu.
Select " Directory " and confi rm.
An incoming call is announced by a ring and a superimposed di splay in the multifunction screen.
Mobile
(depending on the information available in the contact records of the telephone connected).
" YES " " " to accept the call is selected by default.
Press OK to accept the call.
Select " NO " and confi rm to reject the call.
or
Press SOURCE to accept the call.
MAKING A CALL - FROM THE
DIRECTORY
Select a contact then confi rm.
RECEIVING A CALL
Select the number and confi rm. A long press on ESC or on SOURCE also rejects an incoming call.
Business
Home

305

1
2a2c
2b
05 USING THE TELEPHONE
During a call, press OK to display the contextual menu.
Hang up
In the contextual menu:
- select " Telephone mode " to transfer the call to the telephone.
- deselect " Telephone mode " to transfer the call to the vehicle.
In the contextual menu:
- select " Micro OFF " to switch off the microphone.
- deselect " Micro OFF " to switch the microphone on.
In certain cases, the combined mode has to activated from the telephone.
If the contact has been cut off, when you reconnect on returning to the vehicle, the Bluetooth connection will be restored automatically (depending on the compatibility of the telephone).
MANAGING CALLS
A long press on SOURCE or TEL also ends the call.
In the contextual menu, select " Hang up " to end the call.
Secret - Mute
(so that the caller cannot hear)
Combined mode
(to leave the vehicle without ending the call)

306

2e
2d05
USING THE TELEPHONE
From the contextual menu, select " DTMF tones " and confi rm to use the digital keypad to navigate in the interactive voice response menu.
From the contextual menu, select " Switch " and conform to return to a call left on hold.
Interactive voice response
Consultation call
