Peugeot 508 Hybrid Dag 2012.5 Owner's Manual

319
06
Press ‘
to display the audio settingsmenu.

The settin
gs available are:


-
Ambience,


- Bass,

-
Treble,

- Loudness,

- Distribution: Personalised or Driver,

- Left / ri
ght balance,

- Fader
(front / rear balance),

-
Auto. volume.

AUDIO SETTINGS


SCREEN C


The distribution (or spatialisation using the Arkamys© system), is©
an audio process which allows the sound quality to be improved
according to the setting chosen, corresponding to the position of the
listeners in the vehicle.
Select and confi rm " Other settings…"
to display the next setting in the list. The Ambience, Treble and Bass audio settin
gs are different andindependent for each sound source.


On-board Audio: Arkamys ©Sound Staging.
With Sound Sta
ging, the driver and passengers are immersed in an
"audio scene" recreating the natural atmosphere of an auditorium:
truly a part of the scene and its surroundings.
This new sensation is made possible b
y software in the audiosystem which processes the digital signals from the media players (radio, CD, MP3…) without changing the audio settings. This
processing takes account of the characteristics of the passenger compartment to produce optimum results.
The Arkam
ys©software installed in your audio system processes ©
the digital signal from the media players (radio, CD, MP3, ...) and
recreates a natural musical scene, with harmonious placement of
instruments and voices in the space in front of passengers, level
with the windscreen.

320
07
SCREEN C

Multimedia
Media parameters
Choice of playback mode
Choice of track listing


Telephone


Call
Dial
Directory
Calls list
Voice mail box


Directory management
Consult an entr
y
Delete an entry
Delete all entries

Telephone mana
gement
Telephone status


Hang up
Normal
Random
R
andom all
Repeat
B
y folders
B
y artists
B
y genres
By playlists
Radio
parameters

SCREEN MENU MAP









MAIN FUNCTION
Option A1
Option A2
OPTION A
OPTION B1
2
2
1
2
2
2
2
1
2
2
2
1
2
1
3
3
3
3
3
3
3
3
1
1
2
2
1

321
07 SCREEN MENU MAP

Personalisation-
configuration
Choice of language
Displa
y confi guration


Bluetooth connection
Connections management
Choice of units
Date and time adjustment
Display parameters
Brightness
1
1
2
2
2
2
1
1Search for a device

322
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWER SOLUTION

There is a difference in sound quality between
the different audiosources (radio, CD...). For optimum sound qualit
y, the audio settings (Volume, Bass, Treble,
Ambience, Loudness) can be adapted to the different sound sources,
which may result in audible differences when changing source (radio,
CD...).
Check that the audio settings (Volume, Bass,
Treble, Ambience, Loudness) are adapted to
the sources listened to. It is advisable to set
the AUDIO functions (Bass, Treble, Front-Rear Fader, Left-Right Balance) to the middle position, select the musical ambience "None" and set theloudness correction to the "Active" position in CD mode or to the "Inactive" position in radio mode.
When chan
ging the settings for treble andbass, the ambience setting is deselected.
When changing the
ambience settin
g, treble and bass are reset to zero.Choosin
g an ambience imposes settings for treble and bass. Modifyingone without the other is not possible. Modify the treble and bass settings or the
ambience setting to obtain the desired sound quality.
When chan
ging the
balance setting, distribution is deselected.
Choosing a distribution setting imposes a balance setting. Modifying one
without the other is not possible. Modify the balance setting or the distribution setting to obtain the desired sound quality. The
following tables contain answers to the most frequently asked questions.

323
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWER SOLUTION
The quality of receptionof the radio station
listened to gradually
deteriorates or the stored stations do not function(no sound, 87.5 MHz is
displayed...). The vehicle is too
far from the transmitter used by the station listened
to or there is no transmitter in the geographical area through which the
vehicle is travelling. Activate the RDS function to enable the system
to check whether there is a more powerful
transmitter in the geographical area.
The environment
(hills, buildings, tunnels, basement car parks...) block reception, including in RDS mode. This phenomenon is normal and does not indicate
a failure of the audio equipment.
The aerial is absent or has been damaged
(for example when going
through a car wash or into an underground car park). Have the aerial checked by a PEUGEOT dealer.

Sound cut-outs of 1 to2 seconds in radio mode.During this brief sound cut-out, the RDS searches for any frequency
permitting better reception of the station. Deactivate the RDS function if the phenomenon is
too frequent and always on the same route.
Th
e traffi c announcement(TA) is displayed. I donot receive any traffi c
information.Th
e radio station does not broadcast traffi c information. Tune to a radio station which broadcasts traffi c
information.

The stored stations arenot found (no sound, 87.5 MHz is displayed...).
An incorrect waveband is selected. Press the BAND button to return to the wavebandon which the stations are stored.

324
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWER SOLUTION
The CD is ejected
automatically or is not played by the player. The
CD is inserted upside down, is unplayable, does not contain any audio data or contains an audio format which the player cannot play.
The
CD is protected by an anti-pirating protection system which is not recognised by the audio equipment.
-
Check that the CD is inserted in the player the
right way up.

-
Check the condition of the CD: the CD cannot
be played if it is too damaged.

-
Check the content in the case of a recordedCD: consult the advice in the "Audio" section.

- The audio equipment's CD pla
yer does not
play DVDs.

-
Due to their quality level, certain writeableCDs will not be played by the audio system.
The CD pla
yer sound ispoor.The CD used is scratched or of poor quality. Insert good quality CDs and store them in suitable conditions.
The audio settin
gs (bass, treble, ambience) are unsuitable. Set the treble or bass level to 0, without selectingan ambience.
Th
e Bluetooth connectionis cut. The battery of the peripheral may not be suffi ciently charged. Recharge the battery of the peripheral device.
The message "U
SB
device error" is displayedon the screen.The U
SB memory stick is not recognised.
The memor
y stick may be corrupt. Re
format the memory stick (FAT 3 2).

325
QUESTIONANSWER SOLUTION
A telephone connects
automatically,
disconnecting another
telephone. Automatic connection overrides manual connection. Modify the telephone settings to remove automatic connection.

The Apple ®
player is®
not recognised whenconnecting to the USB port.
The Apple ®player is of a generation that is not compatible with the USB. Connect the Apple ®player to the AUX Jack socket using a suitable cable (not supplied).
Th
e hard disk or deviceis not recognised whenconnecting to the USBport. Some hard disks and devices need a power suppl
y greater than is
provided by the audio system. Connect the device to the 230 V socket, the 12 V socket or an external power supply.
Caution
:
ensure that the device does not transmit
a voltage greater than 5 V (risk of destruction of
the system).

When streaming, the sound cuts momentarily. Some telephones prioritise connection of the "hands-free" profi le. Delete the "hands-free" connection profi le toimprove streaming.
In "Random all" pla
y,not all of the tracks areplayed.In "Random all" pla
y, the system can only take into account up to 999 tracks.
With the en
gine off, the
audio system switches off after a few minutes of use. When the en
gine is switched off, the audio system operating timedepends on the battery charge.
The switch-o
ff is normal: the audio system switches to economy mode and switches off to prevent discharging the vehicle's battery.
Start the vehicle's engine to increase the batterycharge.
The messa
ge "the audio system is overheated"
appears on the display. In order to protect the installation if the surroundin
g temperature is too
high, the audio system switches to an automatic thermal protection mode leading to a reduction of the volume or stopping of the playing of the CD. Switch the audio s
ystem off for a few minutes to
allow the system to cool.

326

.
327 Alphabetical index
Accessories ..................................................214Accessory socket, 12 volt ...............................77Adjusting headlamps .................................... 144Adjusting head restraints..........................67,70Adjusting seat belt height..............................172Adjusting the steering wheel...........................76Airbags............................................................32Airbags, curtain .....................................176,177Airbags, front.........................................174,177Airbags, lateral......................................176,177Air conditioning.........................................20, 89Air conditioning, digital........................87,90, 98Air conditioning, manual...........................87, 88Air conditioning, quad-zone...............93, 96, 98Air filter..........................................................r225Air flow............................................................20Air vents ..........................................................86Alarm ...............................................................53Anti-theft........................................................102Armrest............................................................77Armrest, rear...................................................r78Assistance call......................................166,240Audible warning............................................166Audio streaming (Bluetooth).........284,310,312Audio system (radio).....................................297Automatic illumination
of headlamps .......................................137, 141Automatic operation of hazard
warning lamps.............................................165Automatic rain sensitive
windscreen wipers..............................147,149Auxiliary socket.............................................309
Backup switching off.....................................f102Battery..................................................204, 225Battery, charging ...........................................204Battery, remote control.............................50-52Blind................................................................61Bluetooth (hands-free)..........................267, 311Bluetooth (telephone)....................................267Boot...........................................................57-59Boot (opening).................................................46Brake discs ....................................................226Brake lamps ..........................................196,197Brake pads ....................................................226Brakes...........................................................226
Capacity, fuel tank..........................................64CD.................................................................304CD MP3 ................................................305, 306Central locking................................................47Changing a bulb ....................191, 196,197, 199Changing a fuse............................................200Changing a wheel ................................. 184,185Changing a wiper blade........................150,208Changing the date.....................................41,42Changing the remote control battery........50, 51Changing the time.....................................41,42Checking levels .....................................222-224Checking the engine oil level ..........................37Checking tyre pressures (using the kit) ........178Checks ..................................219-221, 225, 226Children ......................................... 157, 161,162Child seats ...........................153,154,156,159Child seats, conventional......................156, 157Closing the boot..............................................57Closing the doors............................................47Connectors, audio ...........................79, 307, 309
Date (setting).............................................41,42Daytime running lamps ......... 139, 191,193, 195Deactivating ESP..........................................170Deactivating the passenger airbag...............174Deadlocking....................................................48Defrosting........................................................98Diesel..............................................................25Diesel additive level......................................224
Diesel engine pre-heat warning lamp .............25Dimensions ...................................................236Dipped beam ..................................136,191-193Dipstick....................................................37, 222Directional lighting................................145, 146Direction indicators........140,165, 191,195-197Driving positions (memorising).......................69Dynamic emergency braking........................103Dynamic stability control (DSC) ..............30, 170
AB
C
D
Coolant level ...........................................33,223Coolant temperature indicator........................r33Cour tesy lamps .............................................151Cruise control........................................127,130Cup holder.......................................................r77
Eco-driving.....................................................20Eco-driving (advice)........................................20Economical driving .........................................20Economy mode.............................................207Electronic engine immobiliser.................r52, 102Electronic stability control (ESC)..................168Emergency boot release .................................60
E

328
Alphabetical index
