Page 4 of 257
9
1
FAMILIARISATION
Interior
12. Side adjustable vent.
13. B a t t e r y / F u s e b o x .
14. Passenger air bag.
15. Passenger’s lower glove box.
16. Air conditioning controls.
17. L i g h t e r / 1 2 V a c c e s s o r i e s s o c k e t .
18. Hazard warning lights switch.
19. Storage compartment or additional
telematics control.
20. Cooled compartment.
21. Ashtray/Can holder.
22. Seat adjustment control.
23. Storage compartment.
24. F u s e b o x .
1. E l e c t r i c m i r r o r c o n t r o l s .
- E l e c t r i c w i n d o w c o n t r o l s .
- Deactivation of the rear electric controls.
2. Driver’s upper glove box.
3. Central adjustable vents.
4. Audio equipment or GPS
multimedia audio equipment with
fl a p .
5. I n s t r u m e n t p a n e l / L a r g e c o l o u r
display.
6. Sunshine and passenger
compartment temperature sensor.
7. Passenger’s upper glove box.
8. Windscreen demisting vents.
9. Speaker (tweeter).
10. F r o n t w i n d o w d e m i s t i n g v e n t s .
11. Passenger air bag disarming
s w i t c h , i f fi t t e d o n y o u r v e h i c l e .
25. Handbrake - on the right.
26. B o n n e t r e l e a s e u n d e r c o v e r - o n
the left.
27. Acoustic windscreen.
INTERIOR OVERVIEW
SETTING THE DATE
AND TIME
F o r m o r e i n f o r m a t i o n a b o u t
this adjustment, refer to the "Setting
t h e d a t e a n d t i m e " s e c t i o n o f t h e " I n -
car technology" chapter.
ADDITIONAL HEATER
With the engine at idle
or when the vehicle is
stationary, it is normal
to notice a high-pitched
whistling and a slight emission of
smoke and odour.
Page 7 of 257
4
Interior
12
90
Seat with manual
adjustment
Seat with electric
adjustment Pull the button
placed at the end
of the handbrake
forwards.
The handbrake
lever lowers.
You can now
rotate the seat. To
return to normal
operation, pull the
lever up until it
clicks.
1.
F o r w a r d s - b a c k w a r d s
adjustment.
2. Angle.
3. Height.
4. Lumbar.
5. Head restraint
height and angle. Rotating the seat
SIT COMFORTABLY
Driver's seat
Page 10 of 257
4
2 4
4
7
6
4
3
3
415
1
FAMILIARISATION
Interior
Battery 122
Child monitoring mirror
106
Disarming the passenger's front air bag
100
Opening control Sliding side doors from the
inside. 25
Handbrake
90
Bonnet opening controls The bonnet opening control
is a red handle under a
cover. Release the bonnet
from inside the vehicle then
go to the front and insert
your hand under the badge
to open and raise the bonnet,
place the strut in its location
securely. 115
Safety auto-reverse. 101
106
88
87
Electric windows/Safety auto-reverse
CHILD SAFETY
Monitoring mirror.
Child seats.
Page 26 of 257
Instruments and controls
30
WARNING LIGHTS
Each time the engine is started: a series of warning lights comes on applying a self-test check. They switch off almost
i m m e d i a t e l y . W i t h t h e e n g i n e r u n n i n g : t h e w a r n i n g l i g h t b e c o m e s a w a r n i n g i f i t r e m a i n s o n c o n t i n u o u s l y o r fl a s h e s .
T h i s i n i t i a l w a r n i n g m a y b e a c c o m p a n i e d b y a n a u d i b l e s i g n a l a n d a m e s s a g e w h i c h a p p e a r s o n t h e d i s p l a y . " D o n o t
ignore these warnings."
Warning light is indicates Solution - action
STOP lit, associated
with another
warning
light and
accompanied
b y a m e s s a g e
on the display. m a j o r f a u l t s l i n k e d w i t h t h e
" B r a k e fl u i d l e v e l " , " E n g i n e
oil pressure", "Coolant
temperature", "Electronic
b r a k e f o r c e d i s t r i b u t i o n " ,
"Power steering" and
"Punctured tyre" warning
lights.
You must stop, park, switch off the ignition
and call a PEUGEOT dealer.
Handbrake/
B r a k e fl u i d
level/EBFD lit.
h a n d b r a k e a p p l i e d o r n o t
released correctly. R e l e a s i n g t h e h a n d b r a k e s w i t c h e s o f f t h e w a r n i n g
light. Chapter 2, "Starting and stopping" section.
lit. l o w b r a k e fl u i d l e v e l . T o p u p u s i n g a fl u i d r e c o m m e n d e d b y P E U G E O T .
remaining on,
even though the
level is correct
and associated
with the ABS
warning light.
failure of the electronic
b r a k e f o r c e d i s t r i b u t i o n .
You must stop, park, switch off the ignition
and call a PEUGEOT dealer.
Engine oil
pressure lit while driving.
i n s u f fi c i e n t p r e s s u r e . Park, switch off the ignition and allow to cool.
Visually check the level. Chapter 6, "Levels"
section.
remaining on,
even though
the level is
correct. m a j o r f a u l t .
Call a PEUGEOT dealer.
Page 39 of 257
READY TO SET OFF
2
43
Starting and stopping
STARTING AND STOPPING
STOP position: steering lock.
The ignition is off.
Good practice when starting Handbrake
On the version with rotating front seat,
t h e h a n d b r a k e c a n b e d i s e n g a g e d .
P u l l i n g t h e h a n d b r a k e t o i m m o b i l i s e
the vehicle then lowering the lever
d o e s n o t r e l e a s e t h e b r a k e , i t p e r m i t s
rotation of the driver's seat.
P u l l t h e b u t t o n p l a c e d a t t h e e n d o f t h e
h a n d b r a k e f o r w a r d s .
T h e h a n d b r a k e l e v e r l o w e r s .
You can now rotate the seat.
To return to normal operation, pull the
lever up until it clicks.
I f t h e h a n d b r a k e i s o n o r h a s
n o t b e e n r e l e a s e d f u l l y , t h i s i s
i n d i c a t e d b y :
- a warning light which comes on on the instrument panel,
- a n a u d i b l e s i g n a l ,
- a message on the display.
Key
Take care not to place the key in
contact with grease, dust, rain or a
damp environment.
A h e a v y o b j e c t a t t a c h e d t o t h e k e y ( k e y
ring, ...) weighing down on the shaft
of the key in the ignition switch may
cause a malfunction.
Running and accessories position.
C e r t a i n a c c e s s o r i e s c a n b e u s e d .
Starting position.
The starter is operated. Diesel pre-heating warning
light
Turn the key to the Running
position.
In cold weather, wait for this warning
light to switch off then operate the
starter (Starting position) until the
engine starts.
If the temperature is high enough, the
warning light comes on for less than
one second, you can start without
waiting. Good practice when stopping
Minimise engine and gearbox wear
When switching off the ignition, let the
engine run for a few seconds to allow
t h e t u r b o c h a r g e r t o r e t u r n t o i d l e .
Do not press the accelerator when
switching off the ignition.
There is no need to engage a gear
after parking the vehicle.
Page 47 of 257
Steering wheel controls
ERGONOMICS and COMFORT
51
Selecting the function
- Place the switch in the CRUISE
position. The cruise control is
s e l e c t e d b u t i s n o t y e t a c t i v e a n d
n o s p e e d h a s b e e n p r o g r a m m e d .
First activation/
programming a
speed
- Reach the chosen s p e e d b y p r e s s i n g
the accelerator.
- Press the SET - or
SET + button .
T h i s p r o g r a m m e s / a c t i v a t e s t h e
r e f e r e n c e s p e e d a n d t h e v e h i c l e w i l l
m a i n t a i n t h i s s p e e d . Temporary exceeding of
the speed
It is possible
to accelerate a n d d r i v e
m o m e n t a r i l y a t a s p e e d g r e a t e r t h a n
t h e p r o g r a m m e d s p e e d . T h e v a l u e
p r o g r a m m e d fl a s h e s .
W h e n t h e a c c e l e r a t o r p e d a l i s
r e l e a s e d , t h e v e h i c l e w i l l r e t u r n t o t h e
p r o g r a m m e d s p e e d . Reactivation
- F o l l o w i n g d e a c t i v a t i o n o f t h e c r u i s e
c o n t r o l , p r e s s t h i s b u t t o n .
Y o u r v e h i c l e w i l l r e t u r n t o t h e l a s t
p r o g r a m m e d s p e e d .
A l t e r n a t i v e l y , y o u c a n r e p e a t t h e " fi r s t
a c t i v a t i o n " p r o c e d u r e .
Deactivation (off)
- Press this button or the brake or clutch
p e d a l .
Page 60 of 257
64
Seats
3 - Driver's seat height adjustment
M a n o e u v r e t h e h a n d l e u p w a r d s o r
d o w n w a r d s u n t i l t h e d e s i r e d p o s i t i o n i s
r e a c h e d .
4 - Driver's seat lumbar adjustment
M o v e t h e l e v e r u p o r d o w n t o o b t a i n
t h e r e q u i r e d p o s i t i o n . 5 - Head restraint height and angle
adjustment
T o r a i s e o r l o w e r t h e r e s t r a i n t , p u l l i t
f o r w a r d s , t h e n s l i d e i t .
T h e a d j u s t m e n t i s c o r r e c t w h e n t h e
u p p e r e d g e o f t h e h e a d r e s t r a i n t i s
l e v e l w i t h t h e t o p o f t h e h e a d .
T o r e m o v e i t , s e t i t i n t h e h i g h p o s i t i o n ,
l i f t t h e t a b u s i n g a c o i n a n d p u l l
u p w a r d s a n d f o r w a r d s a t t h e s a m e
time.
T o r e - i n s t a l l , e n g a g e t h e h e a d r e s t r a i n t
r o d s i n t h e h o l e s , m a k i n g s u r e t h e y a r e
a l i g n e d w i t h t h e s e a t b a c k . 6 - Rotating of seats
I f y o u r v e h i c l e i s fi t t e d w i t h t h i s
function:
Place the seat back in the upright
position.
Place the seat in the highest
i n t e r m e d i a t e l o n g i t u d i n a l p o s i t i o n .
O n t h e d r i v e r ' s s i d e , p u s h t h e s t e e r i n g
w h e e l , a p p l y t h e h a n d b r a k e . T o
a l l o w r o t a t i o n o f t h e s e a t , l o w e r t h e
h a n d b r a k e h a n d l e p u l l i n g o n t h e e n d .
P u l l t h e c o n t r o l u p w a r d s a n d r o t a t e t h e
s e a t i n w a r d s .
N e v e r d r i v e w i t h t h e h e a d
r e s t r a i n t s r e m o v e d ; t h e y m u s t b e
i n p l a c e a n d c o r r e c t l y a d j u s t e d . F o r f u r t h e r i n f o r m a t i o n r e g a r d i n g
t h e d i s e n g a g i n g o f t h e h a n d b r a k e ,
refer to the "Driving Safety"
section of chapter 4.
This rotating operation must
b e c a r r i e d o u t w i t h t h e e n g i n e
s w i t c h e d o f f . T h e h a n d b r a k e ,
the lever of which is now in the lower
p o s i t i o n , r e m a i n s a p p l i e d .
D o n o t f o r g e t t o r a i s e t h e l e v e r a n d
release the brake before setting off.
D r i v i n g w i t h a p a s s e n g e r s e a t e d f a c i n g
t h e r e a r i s p r o h i b i t e d .
Page 87 of 257
90
Driving safety
HANDBRAKE
HAZARD WARNING LIGHTS
Press the button, the direction
i n d i c a t o r s fl a s h .
They can operate with the ignition off.
Automatic lighting of hazard
warning lights
Equipment conditioned according
to country: when braking in an
emergency, depending on the
deceleration, the hazard warning lights
come on automatically. They switch
o f f a u t o m a t i c a l l y t h e fi r s t t i m e y o u
accelerate.
It is also possible to switch them off by
pressing the button.
DRIVING SAFETY
Applying
When parking, pull the handbrake to
immobilize your vehicle. When parking
on a slope, direct your wheels towards
the pavement and pull the handbrake.
Releasing
Pull on the handle and press the button
to release the handbrake. Pull the button located at the end of the
handbrake forwards.
The handbrake lever lowers.
You can now pivot the seat.
To return to normal operation, pull the
lever upwards until a click is heard.
If the handbrake is still on or has
not been released properly, this is
indicated by:
Disengaging
Apply the handbrake. a warning light which comes
on on the instrument panel,
an audible signal,
a message on the display.
Page 89 of 257
92
Driving safety
ANTI-LOCK BRAKING SYSTEM
(ABS) AND ELECTRONIC
BRAKE FORCE DISTRIBUTION
(EBFD)
The ABS, in conjunction with the
electronic brake force distribution,
increases the stability and
manoeuvrability of your vehicle on
braking, in particular on poor or
slippery road surfaces.
HORN
Press one of the spokes of the steering
wheel. When changing wheels (tyres and
rims), make sure that these are
approved.
The anti-lock braking system comes
into operation automatically when there
is a risk of wheel lock.
When this warning light
comes on, accompanied by
a buzzer and a message,
it indicates that there is a
malfunction of the ABS, which
can cause a loss of control of the
vehicle when braking.
When this warning light comes
on, connected to the STOP
warning light, accompanied
by a buzzer and a message,
it indicates that there is a
malfunction of the electronic brake force
distribution, which can cause a loss of
control of the vehicle when braking.
Stop immediately.
In both cases, consult a
PEUGEOT dealer .
Normal operation of the ABS may
make it self felt by slight vibrations of
the brake pedal.
In emergency braking, press very
fi r m l y w i t h o u t r e l e a s i n g t h e p r e s s u r e .
EMERGENCY BRAKING
ASSISTANCE SYSTEM (EBA)
In an emergency, this system enables
the optimum braking pressure to be
reached more quickly, press the pedal
fi r m l y w i t h o u t r e l e a s i n g i t .
It is triggered by the speed at which the
brake pedal is activated.
This alters the resistance of the brake
pedal under your foot.
To prolong the operation of the
emergency braking assistance system:
keep your foot on the brake pedal.
Page 90 of 257
SAFETY
93
Driving safety
4
TRACTION CONTROL (ASR)
AND DYNAMIC STABILITY
CONTROL (ESP)
Activation of the ASR and ESP
systems
When the ignition is on, the ASR and
ESP systems are always active. Disarming the ASR/ESP systems
In certain conditions (vehicle stuck in
mud or snow, or on loose ground...), it
could prove useful to disarm the ASR
and ESP systems to make the wheels
spin and regain grip.
- Press the switch, situated under the
steering wheel on the right of the
fascia.
The indicator light comes on
accompanied by a message:
the ESP and ASR systems
no longer act on the engine
operation, but continue to act
on the brakes.
Operation of the ASR and
ESP systems
T h e w a r n i n g l i g h t fl a s h e s i f
the ASR or ESP is activated.
These systems are linked and
complement the ABS.
The ASR system optimises drive to
prevent the wheels skidding, by acting
on the brakes of the drive wheels
and on the engine. It also allows the
directional stability of the vehicle to be
improved on acceleration.
If there is a variation between the
trajectory followed by the vehicle and
that required by the driver, the
ESP system automatically acts on the
engine and the brake of one or more
wheels, in order to put the vehicle back
on course, within the limits of the laws
of physics.
They engage again:
- automatically above 30 mph
(50 km/h),
- manually by pressing the switch
again.
Operating check When a malfunction of the
systems occurs, the indicator
light comes on, accompanied
by an audible signal and a
message on the display.
Contact a PEUGEOT dealer to have
the system checked.
The ASR/ESP systems offer
increased safety during normal
driving, but should not incite the
driver to take risks or to drive at high
speed.
The operation of these systems is
ensured if the recommendations
of the manufacturer regarding
the wheels (tyres and rims), the
braking components, the electronic
c o m p o n e n t s a n d t h e fi t t i n g a n d r e p a i r
procedures within the PEUGEOT
network are observed.
After an impact, have the system
checked by a PEUGEOT dealer.
