INSTRUMENTS, CONTROLS and DISPLAYS
18 -


1.
Seat belt not fastened warning
light

2.
Front and side airbags warning
light

3.
Passenger airbag disarmed
warning light

4.
Front fog lamps indicator light

5.
Anti-lock braking system (ABS)
warning light

6.
Rear fog lamp indicator light

7.
Diesel pre-heat warning light

8.
Left hand direction indicator
9.
Total distance recorder, service
indicator and engine oil level
indicator

10.
Right hand direction indicator

11 .
Emission control system warning
light

12.

Main beam headlamps indicator light

13.
Handbrake, low brake fl uid
level and electronic brake force
distribution warning light

14.
Dipped beam headlamps
indicator light

15.
Battery charge warning light

16.
Engine oil pressure and
temperature warning light

17.
Water in diesel fi lter warning light
18.
Low coolant level warning light

19.
Coolant temperature indicator

20.
Total distance recorder button

21.
Central (STOP) warning light

22.
Speedometer

23.
Rev counter

24.
Lighting rheostat button

25.
Fuel level indicator

26.
Low fuel level warning light

27.
Speed limiter/cruise control
display

INSTRUMENT PANEL: PETROL - DIESEL

19 INSTRUMENTS, CONTROLS and DISPLAYS
-
WARNING LAMPS AND
INDICATORS
A warning lamp on fi xed or fl ashing,
with the engine running, indicates an
fault in the operation of the unit con-
cerned. The illumination of certain
warning lamps may be accompanied
by an audible signal and a message
in the screen. Do not ignore this
warning: consult a
PEUGEOT
dealer
as soon as possible.


If the central STOP warning lamp
comes on when you are driving,
stop your vehicle immediately,
where it is safe to do so.



Central (STOP)
warning lamp
Linked to the warning lamps for:


- ''engine oil pressure and temper-
ature'',

- ''low coolant level'',

- "parking brake'',

- ''low brake fl uid level'',

- ''electronic brake force distribu-
tion system fault''.
Linked with the "coolant tempera-
ture" gauge.

You must stop if the lamp fl ashes
with the engine running.

Consult a PEUGEOT dealer.


Engine oil pressure
and temperature
warning lamp
Linked to the central (STOP) warning
lamp.

You must stop.

This warning lamp indicates one of
the following:


- low oil pressure indicated by the
message "Oil pressure insuffi -
cient"
in the screen.

- low engine oil level. Top up the
level.

- oil temperature too high. To lower
the oil temperature, reduce your
speed.
Illumination of the warning lamp is
accompanied by an audible signal.
Consult a PEUGEOT dealer.


Low engine coolant
level warning lamp
Linked to the central (STOP)
warning lamp.
This comes on for a few seconds
when the ignition is switched on.
Illumination of this warning lamp is
accompanied by an audible signal
and the message "Top up engine
fl uid level"
in the screen.

You must stop as soon as it is safe
to do so.

Wait for the engine to cool before
topping up the level.
The cooling system is pressurised.



Parking brake, low
brake fluid level and
Electronic Brake Force
Distribution system
fault warning lamp
Linked to the central (STOP) warning
lamp.
This comes on each time the ignition
is switched on.
Illumination of this warning lamp is
accompanied by an audible signal
and a message in the screen indicat-
ing the cause of the warning:


- "Handbrake on",
if the parking
brake is applied or not fully re-
leased.

- "Brake fl uid level low"
if there is
an excessive drop in brake fl uid
level (if the warning lamp remains
on even when the parking brake
is released).

- "Braking fault"
is displayed to-
gether with the ABS warning
lamp, indicating a fault with the
Electronic Brake Force Distribu-
tion system. You must stop as
soon as it is safe to do so.


Consult a PEUGEOT dealer. If a check is required, to prevent
any risk of burns
unscrew the cap
by two turns to allow the pressure to
drop.
When the pressure has dropped, re-
move the cap and top up the level.
Consult a PEUGEOT dealer.

77 PRACTICAL INFORMATION
-
CHECKING THE LEVELS

Dipstick

Oil change
According to the information given in
the servicing booklet.

Note:
avoid used oil coming into
prolonged contact with the skin.
Empty the used oil into the contain-
ers intended for this purpose in the
PEUGEOT network.
Viscosity selection
In all cases, the oil selected must meet
the manufacturer's requirements.

Note:
the coolant does not need to
be changed.

For vehicles equipped with a parti-
cle fi lter, the engine fan may operate
after the ignition has been switched
off, even when the engine is cold.

There are two marks
on the dipstick:

A
= maximum
Never fi ll past this mark.

B
= minimum
To maintain the reli-
ability of engines and
emission control sys-
tems, the use of ad-
ditives in engine oil is
prohibited.


Brake fluid level:

The brake fl uid must be changed ac-
cording to the manufacturer's servicing
schedule.
Use fl uids recommended by the
manufacturer, which fulfi l DOT4
standards.

Note:
brake fl uid is harmful to health
and very corrosive. Avoid all contact
with the skin.


Cooling system

Use the fl uid recommended by the
manufacturer.
When the engine is warm, the tem-
perature of the coolant is controlled
by the engine fan. As this fan can op-
erate with the ignition key removed
and because the cooling system is
pressurised, wait for at least one hour
after the engine has stopped before
carrying out any work.
Slacken the cap by two turns to re-
lease the pressure to prevent any
risk of scalding. When the pressure
has dropped, remove the cap and
top up the level.

Used oil

Do not dispose of used oil, brake
fl uid or coolant into drains or onto
the ground.


Power steering reservoir



)
Open the reservoir, with the en-
gine at ambient temperature. The
level should always be above the
MIN. mark and close to the MAX.
mark.



Windscreen and headlamp
wash level
For best quality cleaning and for
your safety, we would advise that
you use products recommended by
PEUGEOT.
For optimum cleaning and to prevent
freezing, this fl uid must not be topped
up or replaced with water.


Oil level



)
Check the level regularly and top
up between changes. The maxi-
mum consumption is 0.5 l per
600 miles (1 000 km).
Check the level with the vehicle level,
engine cold, using the oil level gauge
on the instrument panel or the dipstick.
