Peugeot Partner 2010 Owner's Manual
Manufacturer: PEUGEOT, Model Year: 2010, Model line: Partner, Model: Peugeot Partner 2010Pages: 185, PDF Size: 6.6 MB
Page 101 of 185
96
Opening the bonnet
OPENING THE BONNET
Bonnet strut
Secure the strut in its location,
i d e n t i fi e d b y a s t i c k e r o n t h e l e f t - h a n d
panel side of the vehicle, to hold the
bonnet open.
Before closing the bonnet, put the strut
b a c k i n i t s c l i p w i t h o u t u s i n g e x c e s s i v e
force.
On the outside
Raise the bonnet slightly by reaching
i n a fl a t h a n d , p a l m d o w n , t o m a k e
access to the lever easier.
With this hand, push the lever to the
left. Raise the bonnet.
On the inside
Pull the lever under the fascia panel
t o w a r d s y o u . T h e b o n n e t i s u n l o c k e d .
To close
Lower the bonnet and release it at the
e n d o f i t s t r a v e l . C h e c k t h a t t h e b o n n e t
i s l o c k e d .
Avoid manoeuvring the bonnet in
strong winds.
Page 102 of 185
97
CHECKS
6
Under the bonnet
PETROL ENGINE
1. Windscreen wash reservoir.
2. F u s e b o x .
3. Engine coolant reservoir.
4. B r a k e a n d c l u t c h fl u i d r e s e r v o i r .
5. A i r fi l t e r .
6. D i p s t i c k .
7. E n g i n e o i l fi l l e r c a p .
8. P o w e r s t e e r i n g fl u i d r e s e r v o i r .
Battery connections:
+ Positive metal point.
- N e g a t i v e m e t a l p o i n t ( e a r t h ) .
T a k e c a r e w h e n w o r k i n g u n d e r t h e
bonnet.
Page 103 of 185
98
Under the bonnet
DIESEL ENGINE
4. B r a k e a n d c l u t c h fl u i d r e s e r v o i r .
5. A i r fi l t e r .
6. D i p s t i c k .
7. E n g i n e o i l fi l l e r c a p .
8. P o w e r s t e e r i n g fl u i d r e s e r v o i r .
9. Priming pump.
1. Windscreen wash reservoir.
2. F u s e b o x .
3. Engine coolant reservoir.
Battery connections:
+ Positive metal point.
- N e g a t i v e m e t a l p o i n t ( e a r t h ) .
T a k e c a r e w h e n w o r k i n g u n d e r t h e b o n n e t .
Page 104 of 185
99
6
Levels
LEVELS
Oil change
It is imperative that this is carried
o u t a t t h e i n t e r v a l s s p e c i fi e d a n d t h e
viscosity grade of the oil selected must
f u l fi l t h e r e q u i r e m e n t s i n a c c o r d a n c e
with the manufacturer's servicing
schedule. Consult the instructions at a
PEUGEOT dealer.
R e m o v e t h e d i p s t i c k b e f o r e fi l l i n g .
C h e c k t h e l e v e l a f t e r fi l l i n g ( n e v e r
e x c e e d t h e m a x m a r k ) .
S c r e w t h e c a p b a c k o n t o t h e s u m p
before closing the bonnet. Changing the brake fluid
T h e b r a k e fl u i d m u s t b e c h a n g e d a t
the intervals stated, according to the
manufacturer's servicing schedule.
U s e fl u i d s r e c o m m e n d e d b y t h e
m a n u f a c t u r e r , w h i c h f u l fi l D O T 4
standards.
T h e l e v e l m u s t b e b e t w e e n t h e M I N
a n d M A X m a r k s o n t h e r e s e r v o i r .
I f fl u i d h a s t o b e a d d e d f r e q u e n t l y ,
this indicates a failure which must be
c h e c k e d b y a P E U G E O T d e a l e r a s
soon as possible.
Warning lights
I f y o u h a v e t o r e m o v e / r e fi t t h e
engine style cover, handle it with
c a r e t o a v o i d d a m a g i n g t h e fi x i n g
clips.
Oil level
C h e c k t h e l e v e l r e g u l a r l y a n d t o p u p
between changes.
C h e c k t h e l e v e l w i t h t h e v e h i c l e l e v e l ,
e n g i n e c o l d , u s i n g t h e d i p s t i c k .
Dipstick
T h e r e a r e t w o m a r k s o n
t h e d i p s t i c k :
A = m a x i m u m
I f y o u fi l l p a s t t h i s m a r k ,
consult a PEUGEOT
dealer.
B = minimum
N e v e r a l l o w t h e l e v e l t o
f a l l b e l o w t h i s m a r k .
To maintain the reliability
of engines and emission
control systems, the use
of additives in engine oil
is prohibited. Viscosity selection
In all cases, the oil selected must meet
the manufacturer's requirements.
These regular maintenance
o p e r a t i o n s w i l l k e e p y o u r v e h i c l e
in good running order. Consult the
instructions at a PEUGEOT dealer or
i n t h e s e r v i c i n g b o o k l e t e n c l o s e d i n t h e
h a n d b o o k p a c k .
C h e c k i n g b y m e a n s o f t h e w a r n i n g
lights on the instrument panel is
described in chapter 2, refer to the
"Instruments and controls" section.
Page 105 of 185
100
Levels
Cooling system
O n l y u s e t h e fl u i d r e c o m m e n d e d b y t h e
manufacturer.
O t h e r w i s e , y o u r i s k s e r i o u s l y d a m a g i n g
your engine.
When the engine is warm, the
temperature of the coolant is controlled
by the engine fan. As this fan can
o p e r a t e w i t h t h e i g n i t i o n k e y r e m o v e d
and because the cooling system is
pressurised, wait for at least one hour
after the engine has stopped before
c a r r y i n g o u t a n y w o r k .
S l a c k e n t h e c a p b y 1 / 4 o f a t u r n t o
release the pressure to prevent any
r i s k o f s c a l d i n g . W h e n t h e p r e s s u r e
has dropped, remove the cap and top
up the level with coolant.
I f fl u i d h a s t o b e a d d e d f r e q u e n t l y ,
this indicates a failure which must be
c h e c k e d b y a P E U G E O T d e a l e r a s
soon as possible. Power steering fluid level
T h e v e h i c l e m u s t b e p a r k e d o n l e v e l
ground with the engine cold. Unscrew
the cap integrated with the gauge and
c h e c k t h e l e v e l w h i c h m u s t b e b e t w e e n
t h e M I N a n d M A X m a r k s .
I n o r d e r t o r e g e n e r a t e t h e fi l t e r , y o u
are advised to drive at a speed higher
t h a n 4 0 m p h ( 6 0 k m / h ) f o r a t l e a s t fi v e
minutes as soon as possible, when
t r a f fi c c o n d i t i o n s p e r m i t ( u n t i l t h e
message disappears and the service
w a r n i n g l i g h t i s s w i t c h e d o f f ) .
During regeneration of the particle
e m i s s i o n fi l t e r , r e l a y n o i s e m a y b e
heard under the fascia.
If the message is still displayed and if
the service warning light remains on,
consult a PEUGEOT dealer.
Topping up
T h e l e v e l m u s t b e b e t w e e n t h e M I N
a n d M A X m a r k s o n t h e e x p a n s i o n
b o t t l e . I f m o r e t h a n 1 l i t r e o f fl u i d i s
required to top up the level, have
t h e s y s t e m c h e c k e d b y a P E U G E O T
dealer. Windscreen wash and headlamp
wash level
For best quality cleaning and for your
safety, we would advise that you use
products of the PEUGEOT range.
For optimum cleaning and to avoid
f r e e z i n g , t h i s fl u i d m u s t n o t b e t o p p e d
up or replaced with water.
Capacity of the screenwash reservoir:
a p p r o x i m a t e l y 4 . 5 l i t r e s .
I f y o u r v e h i c l e i s fi t t e d w i t h h e a d l a m p
washers, the capacity of the reservoir
is 7.5 litres.
Diesel additive level
(Diesel with particle
emission filter)
The minimum level of this
additive is indicated by lighting of the
service warning light, accompanied by
an audible signal and a message on
the display.
When this occurs with the engine
running it is due to the start of
s a t u r a t i o n o f t h e p a r t i c l e e m i s s i o n fi l t e r
( e x c e p t i o n a l l y p r o l o n g e d u r b a n t y p e
driving conditions: low speed, long
t r a f fi c j a m s , . . . ) . Topping up
It is imperative that this additive is
topped up by a PEUGEOT dealer
without delay.
Used oil
Avoid prolonged contact of used oil
w i t h t h e s k i n .
B r a k e fl u i d i s h a r m f u l t o h e a l t h a n d
very corrosive.
D o n o t d i s p o s e o f u s e d o i l , b r a k e fl u i d
or coolant into drains or into the ground
but into the containers dedicated to this
use at PEUGEOT dealer.
Page 106 of 185
101
CHECKS
6
Checks
CHECKS
Carbon filter and passenger
compartment filter
A n a c c e s s fl a p b e l o w t h e g l o v e b o x
p e r m i t s r e p l a c e m e n t o f t h e fi l t e r s .
T h e c a r b o n fi l t e r p e r m i t s c o n t i n u o u s
a n d e f f e c t i v e fi l t e r i n g o f d u s t .
I f t h e p a s s e n g e r c o m p a r t m e n t fi l t e r
becomes clogged, this may reduce
the performance of the air conditioning
system and generate unpleasant
odours.
We recommend the use of a combined
p a s s e n g e r c o m p a r t m e n t fi l t e r . B y
means of its second special active
fi l t e r , i t c o n t r i b u t e s t o t h e p u r i fi c a t i o n
of the air breathed by the occupants
and the cleanness of the passenger
c o m p a r t m e n t ( r e d u c t i o n o f a l l e r g i c
symptoms, unpleasant odours and
g r e a s y d e p o s i t s ) . Particle emission filter (Diesel)
It is imperative that particle emission
fi l t e r m a i n t e n a n c e i s c a r r i e d o u t b y a
PEUGEOT dealer.
On acceleration after the vehicle has
been running for a prolonged period
at very low speed or at idle, you may,
i n e x c e p t i o n a l c i r c u m s t a n c e s , n o t i c e
the emission of water vapour at the
e x h a u s t . T h i s w a t e r v a p o u r d o e s n o t
have any adverse effect on vehicle
handling or the environment.
Battery
At the start of winter, have your battery
c h e c k e d b y a P E U G E O T d e a l e r .
Brake pads
B r a k e p a d w e a r d e p e n d s o n t h e s t y l e
of driving, in particular for vehicles
which are used in town, over short
distances. It may be necessary to
c h e c k t h e t h i c k n e s s o f t h e p a d s , e v e n
between services.
U n l e s s t h e r e i s a l e a k o n t h e c i r c u i t , a
d r o p i n t h e b r a k e fl u i d l e v e l i n d i c a t e s
t h a t t h e b r a k e p a d s a r e w o r n .
Brake disc/drum wear status
For any information relating to
c h e c k i n g t h e b r a k e d i s c / d r u m w e a r
status, consult a PEUGEOT dealer.
Handbrake
W h e r e t h e h a n d b r a k e t r a v e l i s t o o
great or there is a reduction in the
performance of the system, the
h a n d b r a k e s h o u l d b e a d j u s t e d , e v e n
between services.
H a v e t h e s y s t e m c h e c k e d b y a
PEUGEOT dealer.
Oil filter
C h a n g e t h e fi l t e r r e g u l a r l y i n
accordance with the servicing
schedule.
R e f e r t o t h e s e r v i c i n g b o o k l e t t o fi n d
out the replacement interval for these
components.
D e p e n d i n g o n t h e e n v i r o n m e n t ( d u s t y
a t m o s p h e r e . . . ) a n d t h e u s e o f t h e
v e h i c l e ( u r b a n d r i v i n g . . . ) , c h a n g e t h e m
twice as often if necessary.
Page 107 of 185
102
Checks T o c h e c k t h e m a i n l e v e l s
and certain components,
in accordance with the
manufacturer's servicing schedule,
refer to the pages of the Maintenance
and Warranty Guide which correspond
to your vehicle's engine.
Bleeding the water contained
in the diesel filter
Manual gearbox
H a v e t h e l e v e l c h e c k e d i n a c c o r d a n c e
with the manufacturer's servicing
schedule.
Only use products recommended
by PEUGEOT or products
of equivalent quality and
s p e c i fi c a t i o n .
In order to optimise the operation
o f u n i t s a s i m p o r t a n t a s t h e b r a k i n g
system, PEUGEOT selects and offers
s p e c i fi c p r o d u c t s .
In order to avoid damaging the
electrical units, high pressure washing
to clean the engine compartment is
strictly prohibited.
If this warning light comes
o n , b l e e d t h e fi l t e r . O t h e r w i s e
bleed regularly each time the
engine is drained.
To evacuate the water,
unscrew the bleed screw located on
t h e fi l t e r .
Operate until all of the water in the
transparent pipe has been drained out
then tighten the bleed screw.
HDi engines use advanced technology.
A l l w o r k r e q u i r e s a s p e c i a l q u a l i fi c a t i o n
which is guaranteed by a PEUGEOT
dealer.
According to country.
Page 108 of 185
103
CHECKS
6
Fuel
FILLING WITH FUEL
Low fuel level Filling
T h e f u e l t a n k m u s t b e fi l l e d
with the
engine off .
- O p e n t h e f u e l fi l l e r fl a p .
- I n s e r t t h e k e y , t h e n t u r n i t a q u a r t e r turn.
- R e m o v e t h e c a p a n d h o o k i t o n t o the clip located on the inside of
t h e fl a p .
W h e n fi l l i n g w i t h f u e l , w i t h t h e f u e l
fi l l e r fl a p o p e n , e n s u r e t h a t n o o n e
attempts to open the sliding side
door.
W h e n t h e m i n i m u m f u e l t a n k
level is reached, this warning
light comes on.
You then have approximately 8 litres
of fuel remaining. Fill up without delay
to avoid running out of fuel.
N e v e r r i s k d r i v i n g u n t i l y o u r u n o u t
of fuel as this may damage the
a n t i p o l l u t i o n a n d i n j e c t i o n s y s t e m s . Quality of the fuel used for
petrol engines
A l a b e l a f fi x e d t o t h e i n s i d e o f t h e fl a p
reminds you of the type of fuel to be
used.
Y o u m u s t fi l l w i t h a t l e a s t 5 l i t r e s o f f u e l
for it to be registered by the fuel gauge.
W h e n t h e f u e l fi l l e r c a p i s o p e n e d ,
there may be a slight air suction noise.
This vacuum is entirely normal and is
due to the sealing of the fuel circuit.
W h e n fi l l i n g t h e f u e l t a n k , d o n o t
c o n t i n u e a f t e r t h e 3 r d c u t - o f f o f t h e
nozzle. This could cause malfunctions.
T h e c a p a c i t y o f t h e f u e l t a n k i s
a p p r o x i m a t e l y 6 0 l i t r e s .
- A f t e r fi l l i n g t h e f u e l t a n k , l o c k t h e c a p a n d c l o s e t h e fl a p . The petrol engines are perfectly
compatible with E10 type petrol
b i o f u e l s ( c o n t a i n i n g 1 0 % e t h a n o l ) ,
conforming to European standards
E N 2 2 8 a n d E N 1 5 3 7 6 .
E 8 5 t y p e f u e l s ( c o n t a i n i n g u p t o 8 5 %
e t h a n o l ) a r e r e s e r v e d e x c l u s i v e l y f o r
v e h i c l e s m a r k e t e d f o r t h e u s e o f t h i s
t y p e o f f u e l ( B i o F l e x v e h i c l e s ) . T h e
quality of the ethanol must comply with
E u r o p e a n s t a n d a r d E N 1 5 2 9 3 .
For Brazil only, special vehicles are
m a r k e t e d t o r u n o n f u e l s c o n t a i n i n g u p
t o 1 0 0 % e t h a n o l ( E 1 0 0 t y p e ) .
Page 109 of 185
DIESEL
1 0 4
Fuel
FUEL CIRCUIT DISARMED
In a serious collision, a mechanism
automatically prevents fuel from
reaching the engine. T h e fl a s h i n g o f t h i s w a r n i n g
light is accompanied by a
message on the display.
C h e c k t h a t t h e r e i s n o o d o u r o r
l e a k a g e o f f u e l o u t s i d e t h e v e h i c l e a n d
r e - e s t a b l i s h t h e f u e l s u p p l y :
- s w i t c h o f f t h e i g n i t i o n
( S T O P p o s i t i o n ) .
- r e m o v e t h e k e y .
- p u t t h e k e y b a c k i n t h e i g n i t i o n .
- s w i t c h o n t h e i g n i t i o n a n d s t a r t .
DIESEL REPRIMING PUMP
If you should run out of fuel, it is
n e c e s s a r y t o r e - p r i m e t h e c i r c u i t :
- fi l l t h e f u e l t a n k w i t h a t l e a s t fi v e l i t r e s o f d i e s e l ,
- s q u e e z e a n d r e l e a s e t h e m a n u a l r e - p r i m i n g p u m p , u n d e r t h e b o n n e t
under the protective cover,
- o p e r a t e t h e s t a r t e r u n t i l t h e e n g i n e starts.
Refer to the "Under the bonnet"
section of chapter 6.
Quality of the fuel used for
Diesel engines
The Diesel engines are perfectly
compatible with biofuels which conform
to current and future European
s t a n d a r d s ( D i e s e l f u e l w h i c h c o m p l i e s
w i t h s t a n d a r d E N 5 9 0 m i x e d w i t h a
biofuel which complies with standard
E N 1 4 2 1 4 ) a v a i l a b l e a t t h e p u m p s
( c o n t a i n i n g u p t o 7 % F a t t y A c i d M e t h y l
E s t e r ) .
The B30 biofuel can be used in certain
Diesel engines; however, this use
i s s u b j e c t t o s t r i c t a p p l i c a t i o n o f t h e
special servicing conditions. Consult a
PEUGEOT dealer.
T h e u s e o f a n y o t h e r t y p e o f ( b i o ) f u e l
( v e g e t a b l e o r a n i m a l o i l s , p u r e o r
d i l u t e d , d o m e s t i c f u e l . . . ) i s s t r i c t l y
p r o h i b i t e d ( r i s k o f d a m a g e t o t h e
e n g i n e a n d f u e l s y s t e m ) .
Page 110 of 185
DIESEL
1 0 4
Fuel
FUEL CIRCUIT DISARMED
In a serious collision, a mechanism
automatically prevents fuel from
reaching the engine. T h e fl a s h i n g o f t h i s w a r n i n g
light is accompanied by a
message on the display.
C h e c k t h a t t h e r e i s n o o d o u r o r
l e a k a g e o f f u e l o u t s i d e t h e v e h i c l e a n d
r e - e s t a b l i s h t h e f u e l s u p p l y :
- s w i t c h o f f t h e i g n i t i o n
( S T O P p o s i t i o n ) .
- r e m o v e t h e k e y .
- p u t t h e k e y b a c k i n t h e i g n i t i o n .
- s w i t c h o n t h e i g n i t i o n a n d s t a r t .
DIESEL REPRIMING PUMP
If you should run out of fuel, it is
n e c e s s a r y t o r e - p r i m e t h e c i r c u i t :
- fi l l t h e f u e l t a n k w i t h a t l e a s t fi v e l i t r e s o f d i e s e l ,
- s q u e e z e a n d r e l e a s e t h e m a n u a l r e - p r i m i n g p u m p , u n d e r t h e b o n n e t
under the protective cover,
- o p e r a t e t h e s t a r t e r u n t i l t h e e n g i n e starts.
Refer to the "Under the bonnet"
section of chapter 6.
Quality of the fuel used for
Diesel engines
The Diesel engines are perfectly
compatible with biofuels which conform
to current and future European
s t a n d a r d s ( D i e s e l f u e l w h i c h c o m p l i e s
w i t h s t a n d a r d E N 5 9 0 m i x e d w i t h a
biofuel which complies with standard
E N 1 4 2 1 4 ) a v a i l a b l e a t t h e p u m p s
( c o n t a i n i n g u p t o 7 % F a t t y A c i d M e t h y l
E s t e r ) .
The B30 biofuel can be used in certain
Diesel engines; however, this use
i s s u b j e c t t o s t r i c t a p p l i c a t i o n o f t h e
special servicing conditions. Consult a
PEUGEOT dealer.
T h e u s e o f a n y o t h e r t y p e o f ( b i o ) f u e l
( v e g e t a b l e o r a n i m a l o i l s , p u r e o r
d i l u t e d , d o m e s t i c f u e l . . . ) i s s t r i c t l y
p r o h i b i t e d ( r i s k o f d a m a g e t o t h e
e n g i n e a n d f u e l s y s t e m ) .
