The following functions may be available if your
vehicle has the RKE system.
/(Remote Vehicle Start):If your vehicle has
this feature, the engine may be started from outside
the vehicle using the RKE transmitter. See “Remote
Vehicle Start” later in this section for more detailed
information.
Q(Lock):Press the lock button to lock all the
doors. The interior lamps will turn off after all of the
doors are closed. If enabled through the Driver
Information Center (DIC), the remote lock feedback
can be programmed to have the horn chirp and/or
the turn signals ash when the RKE transmitter is
used to lock the vehicle’s doors. See “LOCK
HORN” and “LIGHT FLASH” underDIC Vehicle
Personalization on page 216for more information.
Pressing the lock button may also arm the content
theft-deterrent system. SeeContent Theft-Deterrent
on page 118.
K(Unlock):Press the unlock button to unlock the
driver’s door. If the button is pressed again within
ve seconds, all remaining doors will unlock.
The interior lamps will turn on and stay on for
20 seconds or until the ignition is turned on. If
enabled through the DIC, the remote unlock
feedback can be programmed to have the horn
chirp and/or the turn signals ash when the RKE
transmitter is used to unlock the vehicle’s doors.
See “UNLOCK HORN” and “LIGHT FLASH” under
DIC Vehicle Personalization on page 216for more
information.
If enabled through the DIC, and it is dark enough
outside, the vehicle’s high-beam headlamps,
parking lamps, and back-up lamps will turn on each
time the unlock button on the transmitter is pressed.
These exterior lamps will stay on for 20 seconds,
or until a door is opened. See “EXT (Exterior)
LIGHTS” underDIC Vehicle Personalization on
page 216for additional information.
Pressing the unlock button on the RKE transmitter
will disarm the content theft-deterrent system. See
Content Theft-Deterrent on page 118.
102

V(Remote Trunk Release):Press and hold
this button for approximately one second to open
the trunk. The trunk will open using the transmitter
when the vehicle speed is less than 2 mph (3 km/h),
when the ignition is off, or when the vehicle shift
lever is in PARK (P), if your vehicle has an
automatic transaxle.
L(Vehicle Locator/Panic Alarm):This button
may be used to locate your vehicle. When you
press and release this button, the horn will sound
three times and the headlamps and turn signals will
ash three times. Press and hold the button for
approximately three seconds to sound the panic
alarm. The horn will sound and the headlamps and
turn signals will ash for 30 seconds. Press the
button again to cancel the panic alarm.
Matching Transmitter(s) to Your
Vehicle
Each RKE transmitter is coded to prevent another
transmitter from unlocking your vehicle. If a
transmitter is lost or stolen, a replacement can be
purchased through your dealer. Remember to
bring any additional transmitters so they can also
be re-coded to match the new transmitter.
Once your dealer has coded the new transmitter,
the lost transmitter will not unlock your vehicle.
Each vehicle can have up to four transmitters
matched to it.
103

Mirrors
Manual Rearview Mirror
While sitting in a comfortable driving position, adjust
the rearview mirror so you can see clearly behind
your vehicle. Grip it in the center to move it up or
down and side to side. The day/night control,
located at the bottom of the mirror, adjusts the
mirror to reduce headlamp glare from behind during
evening or dark conditions. Move the control to the
right for night conditions. Return it to the center for
daytime use.
Manual Rearview Mirror with
OnStar
®
Your vehicle may have a rearview mirror with the
OnStar®system.
Control buttons for the OnStar
®system are at the
bottom of the mirror. See your dealer for more
information on the OnStar
®system and how
to subscribe to OnStar®. Also, seeOnStar®
System on page 148for more information
about the services OnStar®provides.
Mirror Operation
The manual mirror operation works the same as
the manual mirror described previously, with
the exception that the mirror has OnStar
®.
142

Automatic Dimming Rearview Mirror
with Compass
Your vehicle may have an automatic dimming
rearview mirror with a compass. This feature
enables the mirror to sense nighttime glare from
vehicle headlamps from behind and automatically
dim to reduce the glare to a safe level.
The automatic dimming feature turns on each time
the vehicle is started. Press the OFF button once
and the green indicator light located to the left of the
button will go out indicating the feature is off. To
turn the feature back on, press and release the
AUTO button and the green indicator light will
come on.
Compass Operation
Press the on/off button once to turn the compass
on or off.
When the ignition and the compass feature are
on, the compass will show two character boxes for
a few seconds. After a few seconds, the mirror
will display the current compass direction.
Compass Calibration
If after a few seconds the display does not show a
compass direction, (N for North for example), there
may be a strong magnetic eld interfering with the
compass. Such interference may be caused by a
magnetic antenna mount, note pad holder, or
similar object. If the letter C appears in the compass
window, the compass may need to be reset or
calibrated.
The mirror can be calibrated by driving the vehicle
in circles at 5 mph (8 km/h) or less until the
display reads a direction.
145

Instrument Panel Overview........................ 164
Hazard Warning Flashers.......................... 166
Other Warning Devices............................. 166
Horn.......................................................... 167
Tilt Wheel.................................................. 167
Turn Signal/Multifunction Lever.................. 168
Turn and Lane-Change Signals................. 168
Headlamp High/Low-Beam Changer.......... 169
Flash-to-Pass............................................ 169
Windshield Wipers..................................... 169
Windshield Washer.................................... 171
Cruise Control........................................... 171
Headlamps................................................ 174
Headlamps on Reminder........................... 175
Headlamps Off in PARK (P)...................... 175
Delayed Headlamps.................................. 176
Daytime Running Lamps (DRL)................. 176
Automatic Headlamp System..................... 177
Fog Lamps................................................ 178
Instrument Panel Brightness...................... 178
Courtesy Lamps........................................ 178
Dome Lamp.............................................. 179
Entry/Exit Lighting...................................... 179
Parade Dimming........................................ 180Overhead Console Reading Lamps........... 180
Trunk Lamp............................................... 180
Battery Run-Down Protection..................... 181
Accessory Power Outlet(s)........................ 181
Climate Controls......................................... 182
Climate Control System............................. 182
Automatic Climate Control System............. 187
Outlet Adjustment...................................... 191
Warning Lights, Gages, and Indicators..... 192
Instrument Panel Cluster........................... 193
Speedometer and Odometer...................... 194
Trip Odometer........................................... 194
Tachometer............................................... 194
Safety Belt Reminder Light........................ 195
Passenger Safety Belt Reminder Light....... 195
Airbag Readiness Light............................. 196
Passenger Airbag Status Indicator............. 197
Charging System Light.............................. 199
Brake System Warning Light..................... 199
Anti-Lock Brake System Warning Light...... 200
Traction Control System (TCS)
Warning Light........................................ 201
Traction Control System Active Light......... 201
Section 3 Instrument Panel
161

Turn Signal/Multifunction Lever
The lever on the left side of the steering column
includes the following:
GTurn and Lane-Change Signals. See
Turn and Lane-Change Signals on page 168.
23Headlamp High/Low-Beam Changer.
SeeHeadlamp High/Low-Beam Changer on
page 169.
Flash-to-Pass. SeeFlash-to-Pass on
page 169.
OExterior Lamp Control. SeeHeadlamps on
page 174.
Turn and Lane-Change Signals
The turn signal has two upward (for right) and
two downward (for left) positions. These positions
allow you to signal a turn or a lane change.
To signal a turn, move the lever all the way up or
down. When the turn is nished, the lever will
return automatically.
An arrow on the
instrument panel cluster
will ash in the
direction of the turn or
lane change.
To signal a lane change, just raise or lower the
lever until the arrow starts to ash. Hold it
there until you complete your lane change. The
lever will return by itself when you release it.
As you signal a turn or a lane change, if the arrows
ash rapidly, a signal bulb may be burned out
and other drivers won’t see your turn signal.
168

If a bulb is burned out, replace it to help avoid an
accident. If the arrows don’t go on at all when
you signal a turn, check for burned-out bulbs and
then check the fuse. SeeFuses on page 415.
Headlamp High/Low-Beam Changer
To change the headlamps from low beam to
high beam, push the turn signal/multifunction lever
away from you.
When the high beams
are on, a light on the
instrument panel cluster
also will be on if the
ignition is on.
To change the headlamps from high beam to low
beam, pull the turn signal lever toward you.
Flash-to-Pass
This feature lets you use your high-beam
headlamps to signal a driver in front of you that
you want to pass.
To use it, pull the turn signal/multifunction lever
toward you until the high-beam headlamps
come on, then release the lever to turn them off.
Windshield Wipers
Use this lever, located on the right side of the
steering wheel, to operate the windshield wipers.
169

9(Off):Move the lever to this position to turn off
the windshield wipers.
&(Intermittent; Speed Sensitive
Wipers):Move the lever to this position for
intermittent or speed sensitive operation. When
you select this position, the delay will vary
depending on the vehicles speed, as well as, the
manually selected delay.
x(Delay):When the lever is in the intermittent
position, turn the intermittent adjust band with
this symbol on it up or down to set for a shorter or
longer delay between wipes. To the left of the
adjust band are bars, increasing in size from
bottom to top, that indicate the frequency of the
wipes. Smaller bars mean the wipers movement is
less frequent. Larger bars mean the movement
is more frequent.
6(Low Speed):Move the lever up to the
rst setting past intermittent, for steady wiping at
low speed.
1(High Speed):Move the lever up to the
second setting past intermittent, for wiping at high
speed.
8(Mist):Move the lever all the way down to
this position for a single wiping cycle. Hold it there
until the windshield wipers start; then let go.
The windshield wipers will stop after one wiping
cycle. If you want additional wiping cycles, hold the
lever down longer.
Damaged wiper blades may prevent you from
seeing well enough to drive safely. To avoid
damage, be sure to clear ice and snow from the
wiper blades before using them.
If the wiper blades are frozen to the windshield,
carefully loosen or thaw them. If your blades
do become damaged, get new blades.
Heavy snow or ice can overload your wiper motor.
A circuit breaker will stop the motor until it
cools. Clear away snow or ice to prevent an
overload. If the motor gets stuck, turn the wipers
off, clear away the snow or ice, and then turn
the wipers back on.
As an added safety feature, if the wipers are on
for more than 15 seconds, the vehicle’s headlamps
will turn on automatically. They will turn off
15 seconds after the wipers are turned off.
170

Passing Another Vehicle While Using
Cruise Control
Use the accelerator pedal to increase your speed.
When you take your foot off the pedal, your
vehicle will slow down to the cruise control speed
you set earlier.
Using Cruise Control on Hills
How well your cruise control will work on hills
depends upon your speed, load, and the
steepness of the hills. When going up steep hills,
you may have to step on the accelerator pedal
to maintain your vehicle’s speed. When going
downhill, you may have to brake or shift to a lower
gear to keep your vehicle’s speed down. Of
course, applying the brakes ends cruise control.
Many drivers nd this to be too much trouble
and do not use cruise control on steep hills.
Ending Cruise Control
There are three ways to disengage the cruise
control:
Step lightly on the brake pedal; when cruise
control disengages, the cruise symbol in the
instrument panel cluster will go out.
Press the on/off button, this will turn off the
cruise control system.
Press the cancel button. When cruise control
disengages, the cruise symbol in the
instrument panel cluster will go out.
Erasing Speed Memory
When you turn off the cruise control or the
ignition, your cruise control set speed memory is
erased.
Headlamps
The lever on the left side of the steering column
operates the exterior lamps.
174

The exterior lamp switch has the following four
positions:
2(Headlamps):This position turns on the
headlamps, parking lamps, and taillamps.
;(Parking Lamps):This position turns on the
parking lamps and taillamps only.
AUTO (Automatic Headlamp System):This
position automatically turns on the Daytime
Running Lamps during daytime, and the
headlamps, parking lamps, and taillamps at night.
P(Off/On):This position turns on the Automatic
Headlamp System. In Canada, this only works
when a vehicle with an automatic transaxle
is in PARK (P).
To turn on the Automatic Headlamp System, turn
the switch to off/on. To turn them off, turn the
switch to off/on again. This is a momentary control
switch that will spring back when released. The
Automatic Headlamp System is always turned on
at the beginning of an ignition cycle.
Headlamps on Reminder
A reminder tone will sound when your headlamps
or parking lamps are manually turned on, if the
driver’s door is open and your ignition is in
the OFF or ACC position. To turn the tone off, turn
the knob all the way counterclockwise. In the
automatic mode, the headlamps turn off once the
ignition key is in the OFF position.
Headlamps Off in PARK (P)
This feature works when the ignition is ON and it
is dark outside. To turn the headlamps off
when it is dark outside but keep other exterior
lights on, turn the exterior lamp control to
the parking lamp position. In this position, the
parking lamps, sidemarker lamps, taillamps,
license plate lamps and instrument panel lights will
be on, but the headlamps will be off.
To turn on the headlamps along with the other
lamps when it is dark outside, turn the exterior
lamp control to the AUTO or headlamp position.
This feature will not work for Canadian vehicles.
175
