PONTIAC GRAND AM 2002 Owners Manual

2-68 Security Light
This light will come on
when you turn the key to
ON and will stay on until
the vehicle starts.
If you're driving and the security light comes on and
remains on, your Passlock

system is not working
properly. Your vehicle is not protected by Passlock and
you should see your dealer.
Cruise Light (If Equipped)
The CRUISE light comes
on whenever you set your
cruise control.
Low Washer Light
This light will come on
briefly when you turn on
the ignition.
It will also stay on, or come on and a chime will sound,
if the windshield washer fluid reservoir is less than
one
-third full.
Service Vehicle Soon Light
This light will come on
briefly when you turn on
the ignition.
It will stay on, or come on and a chime will sound if
it detects a problem on the vehicle, such as a Daytime
Running Lamps (DRL) or an Automatic Light Control
(ALC) malfunction. If this happens, see your dealer as
soon as possible.

2-69 Fuel Gage
United States Canada
Your fuel gage tells you about how much fuel you
have left, when the ignition is on. When the indicator
nears empty, the light will come on and you will hear a
chime. You still have a little fuel left, but you should get
more soon.Here are four things that some owners ask about. None
of these show a problem with your fuel gage:

At the service station, the gas pump shuts off before
the gage reads full.

It takes a little more or less fuel to fill up than the
gage indicated. For example, the gage may have
indicated the tank was half full, but it actually took a
little more or less than half the tank's capacity to fill
the tank.

The gage moves a little when you turn a corner or
speed up.

The gage goes back to empty when you turn off
the ignition.

3-
3-1
Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle. Be
sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-2 Climate Control System with
Air Conditioning
3
-3 Air Conditioning
3
-4 Heating
3
-4 Defogging and Defrosting Windows
3
-5 Rear Window Defogger
3
-5 Ventilation System
3
-6 Audio Systems
3
-6 Setting the Clock
3
-7AM-FM Stereo with Compact Disc Player
with Programmable Equalization and Radio
Data System (RDS)3
-15 AM-FM Stereo with Cassette Tape and
Compact Disc Player with Programmable
Equalization and Radio Data System (RDS)
(If Equipped)
3
-26 Theft-Deterrent Feature (If Equipped)
3
-27 Audio Steering Wheel Controls (If Equipped)
3
-28 Understanding Radio Reception
3
-28 Tips About Your Audio System
3
-29 Care of Your Cassette Tape Player
3
-30 Care of Your Compact Discs
3
-30 Care of Your Compact Disc Player
3
-30 Fixed Mast Antenna
3
-30 Chime Level Adjustment

3-2
Comfort Controls
With this system, you can control the ventilation
and heating in your vehicle. Your vehicle also has
the flow
-through ventilation system described later
in this section.
Climate Control System with
Air Conditioning
Fan Knob
The left knob regulates the fan speed. To select the force
of air you want, turn the knob. The fan is always
running unless the fan knob is moved to OFF.Temperature Knob
The center knob regulates the temperature of the air
coming through the system.
Mode Knob
The right knob changes the functions of your system.
MAX (Maximum): Use this mode for
maximum cooling. This setting recirculates much of
the air inside your vehicle. It maximizes your air
conditioner's performance and your vehicle's fuel
economy. The air conditioning compressor will run
automatically in this position when it is needed to
help dry the air in the vehicle.
(Vent): In this mode most of the airflow comes
through the instrument panel outlets. A small amount of
air comes through the floor vents. Set the center knob to
the desired temperature for comfort.
(Bi-Level): In this position the airflow
comes through the instrument panel outlets and
through the floor outlets. Set the center knob to the
desired temperature.

3-3
(Floor): In this mode most of the airflow comes
through the floor outlets. The rest of the air comes
through the windshield and side window vents. Set the
center knob to the desired temperature for comfort.
(Defog): This mode divides the airflow between
the floor outlets and the windshield defroster vent. The
air conditioning compressor will run automatically in
this mode when it is needed to help dry the air in
the vehicle.
(Front Defroster): This mode directs most of the
airflow through the windshield defroster vent. Some of
the air goes to the floor outlets. The air conditioning
compressor will run automatically in this mode when it
is needed to help dry the air in the vehicle.
Mode Button
A/C (Air Conditioning): Press A/C to operate the
air conditioning. The indicator light above the button
will glow when the button is pressed to indicate that the
air conditioning system has been turned on. The fan
knob must be set to a speed for the air conditioning
to operate.
Air Conditioning
The air conditioner and heater work best if you keep
your windows closed while using them. Your vehicle
also has the flow
-through ventilation system described
later in this section.
For normal cooling on hot days, use the vent mode with
the temperature knob in the blue area and the A/C
indicator light glowing. The system will bring in outside
air and cool it.
On very hot days, begin by opening the windows long
enough to let hot inside air escape. This reduces the time
it takes for your vehicle to cool down, which should
help fuel economy.
On cool, but sunny days, the sun may warm your upper
body, but your lower body may not be warm enough.
You can use bi
-level mode with the temperature knob in
the middle and the A/C indicator light glowing. The
system will bring in outside air and direct slightly
warmer air to your lower body.

3-4 Heating
On cold days, use floor mode with the temperature knob
all the way in the red area. The system will bring in
outside air, heat it and send it to the floor outlets.
Your vehicle has heat ducts that are directed toward
the rear seat. Keep the area under the front seats
clear of objects so the heated air can reach the rear
seat passengers.
If your vehicle has an engine coolant heater, you can use
it to help your system provide warm air faster when it's
cold outside (0
F (
-18
C) or lower). An engine coolant
heater warms the coolant in your engine and heating
system that is used to provide heat. See ªEngine Coolant
Heaterº in the Index.
Defogging and Defrosting Windows
Your system has two modes for clearing the front and
side windows. For each setting, adjust the temperature
control as desired.
To defrost the front window quickly, turn the
temperature knob all the way in the red area. Use front
defroster and adjust the fan to the highest speed. To
warm passengers while keeping the front window clean,
use defog.
Your vehicle is equipped with side window defogger
vents. The side window defogger vents are located on
the outside of the side instrument panel vents. To defrost
the side windows, turn the temperature knob all the way
in the red area. Use floor mode and adjust the fan to the
highest speed.
To defog the side windows while using air conditioning,
use bi
-level mode and adjust the fan to the highest speed
and press the A/C button so that the indicator light is
glowing. For added airflow to the side windows, aim
the side vents toward the windows and close the
center vents.

3-5 Rear Window Defogger
The rear window defogger uses a warming grid to
remove fog from the rear window.
The button is located
near the center of the
instrument panel.
Press the defogger button. The indicator light above the
button will glow. The rear window defogger will turn
itself off after about 10 minutes after the first time the
button is pressed, and after five minutes each additional
time the button is pressed. You can turn the defogger off
by pressing the button again or turning off the ignition.
Do not attach a temporary vehicle license across the
defogger grid on the rear window.
NOTICE:
Don't use a razor blade or anything else sharp on
the inside of the rear window. If you do, you
could cut or damage the warming grid, and the
repairs wouldn't be covered by your warranty.
Ventilation System
For mild outside temperatures when little heating or
cooling is needed, use the vent mode to direct outside
air through your vehicle. Your vehicle also has the
flow
-through ventilation system which supplies
outside air into the vehicle when it is moving. Outside
air will also enter the vehicle when the air conditioning
is running. Recirculation of the air is automatic in
MAX A/C.

3-6
Ventilation Tips

Keep the hood and the area around the windshield
wipers free of ice, snow or any other obstruction,
such as leaves. The heater and defroster will work
better, reducing the chance of fogging the inside
of your windows.

Keep the air path under the front seats clear of
objects, to help air circulate throughout your vehicle.

When an objectionable odor outside the vehicle is
encountered, use MAX, with the temperature knob
at a comfortable setting to prevent the odor from
being drawn into the vehicle through the ventilation
system. For example, this usage of recirculation can
be helpful when driving through a long tunnel with
poor ventilation. However, extended usage of
recirculation in cold or cool weather can cause
window fogging.Audio Systems
Your audio system has been designed to operate easily
and give years of listening pleasure. You will get the
most enjoyment out of it if you acquaint yourself with it
first. Find out what your audio system can do and how
to operate all of its controls to be sure you're getting the
most out of the advanced engineering that went into it.
Your vehicle has a feature called Retained Accessory
Power (RAP). With RAP, you can play your audio
system even after the ignition is turned off. See
ªRetained Accessory Power (RAP)º in the Index.
Setting the Clock
Press and hold HR or MIN for two seconds. Then
press and hold HR until the correct hour appears. AM
will appear on the display. Press and hold MIN until the
correct minute appears. The clock may be set with the
ignition on or off.
To set the clock to the time of an FM station
broadcasting Radio Data System (RDS) information,
press and hold HR and MIN at the same time for
two seconds until TIME UPDATED and the clock
symbol appear on the display. If the time is not available
from the station, NO UPDATE will appear on the
display instead.

3-7 AM-FM Stereo with Compact Disc Player
with Programmable Equalization and
Radio Data System (RDS)
If your vehicle (coupe only) is equipped with the
Monsoon audio system, included are eight speakers
and an eight channel amplifier. The radio will display
MONSOON when the radio or the ignition is turned on.
See your dealer for details.
Playing the Radio
PWR (Power): Push this knob to turn the system on
and off.VOL (Volume): Turn the knob clockwise to increase
volume. Turn it counterclockwise to decrease volume.
SCV (Speed
-Compensated Volume): With SCV,
your audio system adjusts automatically to make up for
road and wind noise as you drive. Set the volume at the
desired level. Press this button to select MIN, MED or
MAX. Each higher choice allows for more volume
compensation at faster vehicle speeds. Then, as you
drive, SCV automatically increases the volume, as
necessary, to overcome noise at any speed. The volume
level should always sound the same to you as you drive.
If you don't want to use SCV, select OFF.
RCL (Recall): Push this knob to display the station
being played and to display the clock. Pressing this knob
with the ignition off will display the clock.
Finding a Station
BAND: Press this button to switch between AM, FM1
and FM2. The display shows your selection.
TUNE: Turn this knob to choose radio stations.
SEEK : Press the up or down arrow to go to the
next or previous station and stay there. The sound will
mute while seeking.

3-8
SCAN : Press and hold one of the SCAN arrows
for two seconds until SCAN appears on the display and
you hear a beep. The radio will go to a station, play for a
few seconds, then go on to the next station. Press one of
the SCAN arrows again to stop scanning. The sound will
mute while scanning.
To scan preset stations, press and hold one of the SCAN
arrows for more than four seconds until PSCAN and the
preset number appear on the display. You will hear a
double beep. The radio will go to the first preset station
stored on your pushbuttons, play for a few seconds, then
go on to the next preset station. This feature will only
scan the six presets that are in the selected band. Press
one of the SCAN arrows again to stop scanning presets.
The radio will scan preset stations with a strong signal
only. The sound will mute while scanning.Setting Preset Stations
The six numbered pushbuttons let you return to
your favorite stations. You can set up to 18 stations
(six AM, six FM1 and six FM2) by performing the
following steps:
1. Turn the radio on.
2. Press BAND to select AM, FM1 or FM2.
3. Tune in the desired station.
4. Press EQ to select the equalization.
5. Press and hold one of the six numbered pushbuttons
until you hear a beep. Whenever you press that
numbered pushbutton, the station you set will return
and the equalization that you selected will also be
automatically selected for that pushbutton.
6. Repeat the steps for each pushbutton.
