3-9
Setting the Tone (Bass/Treble)
TONE: Press and release this button until BASS,
MID or TREB appears on the display. The SELECT
LED indicator will light to show that the tone control
can be adjusted. When adjusting BASS, MID or TREB,
turn the SELECT knob clockwise to increase or
counterclockwise to decrease. If a station is weak or
noisy, you may want to decrease the treble.
To adjust all of the tone controls to the middle position,
press and hold TONE until FLAT appears on the display.
EQ (Equalizer): This feature allows you to choose
preset bass, mid and treble equalization settings
designed for different program types. Press EQ to select
the desired preset equalization setting. Each time you
press EQ, another setting will appear on the display.You can preset up to six equalization settings by
performing the following steps:
1. Turn the radio on.
2. Use the TONE button and the SELECT knob to
select the desired equalization.
3. Press and hold EQ for two seconds. SELECT EQ #
will appear on the display. The EQ icon will flash.
4. Press EQ or turn the SELECT knob to select the
desired EQ number. Each time you press EQ or turn
the SELECT knob, another EQ setting will appear on
the display.
5. Press and hold the EQ button or push the SELECT
knob to store the equalization preset. You will hear a
beep and EQ SAVED will appear on the display.
6. Repeat the steps for each EQ setting.
EQ 5 has been programmed at the factory for use with
talk radio, but it can be preset to a different tone.

3-10
Adjusting the Speakers (Balance/Fade)
BAL (Balance): Press and release this button until BAL
appears on the display. The SELECT LED indicator will
light to show that the speakers can be adjusted. Turn the
SELECT knob to move the sound to the left or right
speakers. The middle position balances the sound
between the speakers.
FADE: Press and release this button until FADE appears
on the display. The SELECT LED indicator will light to
show that the speakers can be adjusted. Turn the
SELECT knob to move the sound to the front or rear
speakers. The middle position balances the sound
between the speakers.
Pressing and holding the BAL FADE button for
two seconds will return all speaker settings to the
middle position.
Using RDS
Your audio system is equipped with a Radio Data
System (RDS). RDS is a system that receives data
along with the audio of the FM station you are
currently tuned to.You can use RDS to display program information
and to control your radio. With RDS, the radio can
do the following:

Seek only to stations with the types of programs
you want to listen to,

seek to stations with traffic announcements,

receive announcements concerning local and
national emergencies, and

receive and display messages from radio stations.
RDS is always on. RDS features are only available for
use on FM stations which broadcast RDS information.
The RDS features of your radio rely upon receiving
specific RDS information from these stations. These
features will only work when the RDS information
is available. In rare cases, a radio station may broadcast
incorrect information that will cause the radio features
to work improperly. If this happens, contact the
radio station.
When you are tuned to an RDS station, the station name
will appear on the display, instead of the frequency.
Most RDS stations provide their station name, the time
of day and a Program Type (PTY) for their current
programming. Some stations also provide the name of
the current program.

3-11
Finding a PTY Station
PROG TYPE (Program Type): This button is used to
turn on and off Program Type (PTY) select. P
-TYPE
will appear on the display and the SELECT LED
indicator will light. The last selected PTY will appear on
the display for five seconds. Turn the SELECT knob to
select the PTY you want to listen to. Press the SEEK up
arrow and the radio will search for an RDS station that
is broadcasting the PTY that you have selected. The last
PTY selected will be used for seek or scan modes. When
the SELECT LED indicator is on and a PTY is not
displayed, the first time SEEK is pressed, the last
selected PTY will be displayed. Press the SEEK up
arrow again to seek. If a station with the selected PTY is
not found, NOT FOUND will appear on the display.
To use the PTY interrupt feature, press and hold PROG
TYPE until you hear a beep on the PTY you want to
interrupt. An asterisk will appear next to the PTY name,
for example (CLASSICAL*). The radio will also
display brackets around the PTY when the PTY
interrupt is active. To disable the PTY interrupt,
select the interrupt format and press and hold the
PROG TYPE button until you hear a beep. The
asterisk will be removed from the display and so will the
brackets. When you are listening to a compact disc, the
last selected RDS FM station will interrupt play if that
selected PTY format is broadcast.BAND (Alternate Frequency): Alternate frequency
allows the radio to switch to a stronger station with the
same programming. Press and hold BAND for two
seconds to turn alternate frequency on. AF ON will
appear on the display. The radio may switch to stronger
stations. Press and hold BAND again for two seconds to
turn alternate frequency off. AF OFF will appear on the
display. The radio will not switch to other stations.
Setting Preset PTY Stations
The six numbered pushbuttons let you return to
your favorite Program Types (PTYs). These
pushbuttons have factory PTY presets. You can
set up to 12 PTYs (six FM1 and six FM2) by
performing the following steps:
1. Press AM FM to select FM1 or FM2.
2. Press PROG TYPE, if it is not already on.
3. Turn the SELECT knob to select a PTY.
4. Press and hold one of the six numbered pushbuttons
until you hear a beep. Whenever you press that
numbered pushbutton, the PTY you set will return.
5. Repeat the steps for each pushbutton.

3-12
RDS Messages
ALERT!: This type of announcement warns of national
or local emergencies. You will not be able to turn off
alert announcements. ALERT! appears on the display
when an alert announcement plays. When an alert
announcement comes on the current radio station, you
will hear it, even if the volume is muted or a compact
disc is playing. If the compact disc player is playing,
play will stop for the announcement and resume when
the announcement is finished.
This function will only work during actual emergency
broadcasts, and will not work during tests of the
emergency broadcast system. This feature is not
supported by all RDS stations.INFO (Information): If the current station has a
message, INFO will appear on the display. These text
messages are from the RDS broadcaster to the listening
public and may be general information such as artist and
song title, call in phone numbers, etc. Press this button
to see the message. If the whole message does not
appear on the display, parts of the message will appear
every three seconds until the message is completed.
To scroll through the message at your own speed press
the INFO button again for less than one second.
A new group of words will appear on the display.
Once the complete message has been displayed, INFO
will disappear from the display until another new
message is received.
The old message can be displayed by pressing the INFO
button until a new message is received or a different
station is tuned to. If the INFO button is pressed when
INFO is not displayed and an old message has not been
stored by the radio, the radio will display NO INFO.

3-13
TRAF (Traffic): Press this button to receive traffic
announcements. The traffic announcement brackets will
appear on the display. TRAF will appear on the display
if the current station broadcasts traffic announcements.
If the current station does not broadcast traffic
announcements, the radio will seek to a station that
does. When the radio finds a station that broadcasts
traffic announcements, it will stop. TRAF will appear on
the display. If no station is found, NO TRAFFIC will
appear on the display.
Your radio can be programmed to interrupt the playback
of a CD or FM radio by enabling the traffic interrupt
feature. Press the TRAF button once to turn on the
traffic feature, if supported by the current RDS station.
If the station does not support the traffic interrupt
feature, the radio will search for an RDS station that
does support the feature. When the traffic interrupt
feature is on, TRAF will appear on the display.
When a traffic announcement comes on the current radio
station or a related network station, you will hear it,
even if the volume is muted or a compact disc is
playing. If the compact disc player was being used, the
compact disc will stay in the player and resume play at
the point where it stopped.Radio Messages
CALIBRATE: Your audio system has been calibrated
for your vehicle from the factory. If CALIBRATE
appears on the display, it means that your radio has not
been configured properly for your vehicle and must be
returned to the dealership for service.
Playing a Compact Disc
With the ignition on, insert a disc partway into the slot,
label side up. The player will pull it in and the disc
should begin playing. If you want to insert a CD when
the ignition is off, first press the eject symbol or push
the RCL knob. If you insert a CD with the radio off and
the ignition on, it will start to play.
When the disc is inserted, the CD symbol will be
displayed. If you select an EQ setting for your CD, it
will be activated each time you play a CD.
As each new track starts to play, the track number will
appear on the display.
If an error appears on the display, see ªCompact Disc
Messagesº later in this section.

1 (Forward): Press and hold this pushbutton to
advance quickly within a track. You will hear sound at a
reduced volume. Release it to play the passage. The
display will show elapsed time.

3-14
RDM 3 (Random): Press this pushbutton to hear the
tracks in random, rather than sequential, order. RDM
and the track number will appear on the display.
4
(Reverse): Press and hold this pushbutton to
reverse quickly within a track. You will hear sound at a
reduced volume. Release it to play the passage. The
display will show elapsed time.
EQ (Equalizer): Press EQ to select the desired preset
equalization setting while playing a compact disc. The
equalization will be automatically set whenever you
play a compact disc. See ªEQº listed previously for
more information.
SEEK : Press the down arrow while playing a CD
to go to the start of the current track if more than eight
seconds have played. Press the up arrow to go to the
next track. If you hold the button or press it more than
once, the player will continue moving backward or
forward through the disc.
SCAN : Press and hold one of the SCAN arrows
for more than two seconds until SCAN appears on the
display and you hear a beep. The disc will go to the next
track, play for a few seconds, then go on to the next
track. Press this button again to stop scanning. The
sound will mute while scanning. SCAN and the track
number will appear on the display.RCL (Recall): Press this button to see how long the
current track has been playing. To change what is
normally shown on the display (track or elapsed time),
press the button until you see the display you want, then
hold the button until the display flashes. While elapsed
time is showing, CD TIME will appear on the display.
BAND: Press this button to listen to the radio when a
CD is playing. The inactive CD will remain safely inside
the radio for future listening.
CD AUX (Auxiliary): Press this button to play a
compact disc when listening to the radio. CD will appear
on the display when a compact disc is loaded.
(Eject): Press this button to eject a CD. Eject may
be activated with either the ignition or radio off. CDs
may be loaded with the radio and ignition off if this
button is pressed first.

3-15
Compact Disc Messages
CHECK CD: If this message appears on the radio
display and the disc comes out, it could be for one of the
following reasons:

The road is too rough. The disc should play when the
road is smoother.

The disc is dirty, scratched, wet or upside down.

The air is very humid. If so, wait about an hour and
try again.
If the CD is not playing correctly, for any other reason,
try a known good CD.
If any error occurs repeatedly or if an error can't be
corrected, contact your dealer. If your radio displays an
error message, write it down and provide it to your
dealer when reporting the problem.AM-FM Stereo with Cassette Tape and
Compact Disc Player with Programmable
Equalization and Radio Data System (RDS)
(If Equipped)
If your vehicle is equipped with this Monsoon audio
system, included are eight (coupe only) speakers and an
eight channel amplifier. The radio will display
MONSOON when the radio or the ignition is turned on.
Please see your dealer for details.

3-16
Playing the Radio
PWR (Power): Press this knob to turn the system on
and off.
VOL (Volume): Turn the knob clockwise to increase
volume. Turn it counterclockwise to decrease volume.
SCV (Speed
-Compensated Volume): With SCV, your
audio system adjusts automatically to make up for road
and wind noise as you drive. Set the volume at the
desired level. Press this button to select MIN, MED or
MAX. Each higher choice allows for more volume
compensation at faster vehicle speeds. Then, as you
drive, SCV automatically increases the volume, as
necessary, to overcome noise at any speed. The volume
level should always sound the same to you as you drive.
If you don't want to use SCV, select OFF.
RCL (Recall): Push this knob to display the station
being played or to display the clock. Pushing this knob
with the ignition off will display the clock.
Finding a Station
BAND: Press this button to switch between AM, FM1
and FM2. The display shows your selection.TUNE: Turn this knob to choose radio stations.
SEEK : Press the up or down arrow to go to the
next or previous station and stay there. The radio will
seek to stations with a strong signal only. The sound will
mute while seeking.
SCAN : Press and hold one of the SCAN arrows
for two seconds until SCAN appears on the display and
you hear a beep. The radio will go to a station, play for a
few seconds, then go on to the next station. Press one of
the SCAN arrows again to stop scanning. The radio will
scan to stations with a strong signal only. The sound will
mute while scanning.
To scan preset stations, press and hold one of the SCAN
arrows for more than four seconds until PSCAN and the
preset number appear on the display. You will hear a
double beep. The radio will go to the first preset station
stored on your pushbuttons, play for a few seconds, then
go on to the next preset station. This feature will only
scan the six presets that are in the selected band. Press
one of the SCAN arrows again to stop scanning presets.
The radio will scan preset stations with a strong signal
only. The sound will mute while scanning.

3-17
Setting Preset Stations
The six numbered pushbuttons let you return to
your favorite stations. You can set up to 18 stations
(six AM, six FM1 and six FM2) by performing the
following steps:
1. Turn the radio on.
2. Press BAND to select AM, FM1 or FM2.
3. Tune in the desired station.
4. Press EQ to select the equalization.
5. Press and hold one of the six numbered pushbuttons
until you hear a beep. Whenever you press that
numbered pushbutton, the station you set will return
and the equalization that you selected will also be
automatically selected for that pushbutton.
6. Repeat the steps for each pushbutton.Setting the Tone (Bass/Treble)
TONE: Press and release this button until BASS,
MID or TREB appears on the display. The SELECT
LED indicator will light to show that the tone control
can be adjusted. When adjusting BASS, MID or TREB,
turn the SELECT knob clockwise to increase or
counterclockwise to decrease. If a station is weak or
noisy, you may want to decrease the treble.
To adjust all of the tone controls to the middle position,
press and hold TONE until FLAT appears on the display.

3-18
EQ (Equalizer): This feature allows you to choose
preset bass, mid and treble equalization settings
designed for different program types. Press EQ to select
the desired preset equalization setting. Each time you
press EQ, another setting will appear on the display.
You can preset up to six equalization settings by
performing the following steps:
1. Turn the radio on.
2. Use the TONE button and the SELECT knob to
select the desired equalization.
3. Press and hold EQ for two seconds. SELECT EQ #
will appear on the display. The EQ icon will flash.
4. Press EQ or turn the SELECT knob to select the
desired EQ number. Each time you press EQ or turn
the SELECT knob, another EQ setting will appear on
the display.
5. Press and hold the EQ button or push the SELECT
knob to store the equalization preset. You will hear a
beep and EQ SAVED will appear on the display.
6. Repeat the steps for each EQ setting.
EQ 5 has been programmed at the factory for use with
talk radio, but it can be preset to a different tone.Adjusting the Speakers (Balance/Fade)
BAL (Balance): Press and release this button until BAL
appears on the display. The SELECT LED indicator will
light to show that the speakers can be adjusted. Turn the
SELECT knob to move the sound to the left or right
speakers. The middle position balances the sound
between the speakers.
FADE: Press and release this button until FADE appears
on the display. The SELECT LED indicator will light to
show that the speakers can be adjusted. Turn the
SELECT knob to move the sound to the front or rear
speakers. The middle position balances the sound
between the speakers.
Pressing and holding the BAL FADE button for two
seconds will return all tone settings to flat regardless
of tone selected. FLAT will appear on the display.
