2-11 Operation
Three-Button Key Fob Four-Button Key Fob
Remote All Door Lock
LOCK: To lock all the doors, press LOCK on the
remote keyless entry transmitter. See ªPower Door
Locksº in the Index for more details on power door lock
features. If your vehicle is equipped with the content
theft
-deterrent system, the LOCK button may arm the
system. See ªContent Theft
-Deterrentº in the Index for
more details.Remote Driver's Door and All Door Unlock
UNLOCK: When you press UNLOCK on the remote
keyless entry transmitter, only the driver's door will
unlock. If you press UNLOCK again within five
seconds, all the doors will unlock. If you would like all
the doors to unlock the first time you press UNLOCK,
see ªLocks and Lighting Choicesº in the Index. If your
vehicle is equipped with the content theft
-deterrent
system, the UNLOCK button on the remote keyless
entry transmitter will disarm the system. See ªContent
Theft
-Deterrentº in the Index for more details.
Remote Trunk Release
(Open Trunk): Press the button with the trunk
symbol on your remote keyless entry transmitter to open
your trunk. The transaxle must be in PARK (P) for this
feature to operate.
Remote Panic Alarm (If Equipped)
(Panic Alarm): When you press the panic alarm
button with the horn symbol on the four
-button remote
keyless entry transmitter, the headlamps will flash and
the horn will sound. This will allow you to attract
attention if needed.

2-12
Remote Lock/Unlock Confirmation (If Equipped)
(Remote Lock/Unlock Confirmation): Press this button
to use this feature, if equipped, this feature provides
feedback to the holder of the remote keyless entry
transmitter that a command has been received by the
keyless entry receiver. To signal that a command has
been received, the headlamps will flash and the horn
may sound briefly. To program the various modes
available, see ªLocks and Lighting Choicesº in
the Index.
Matching Transmitter(s) to Your Vehicle
Each remote keyless entry transmitter is coded to
prevent another transmitter from unlocking your vehicle.
If a transmitter is lost or stolen, a replacement can be
purchased through your dealer. Remember to bring any
remaining transmitters with you when you go to your
dealer. When the dealer matches the replacement
transmitter to your vehicle, any remaining transmitters
must also be matched. Once your dealer has coded the
new transmitter, the lost transmitter will not unlock your
vehicle. Each vehicle can have a maximum of four
transmitters matched to it.
Battery Replacement
Under normal use, the battery in your remote keyless
entry transmitter should last about three years.
You can tell the battery is weak if the transmitter won't
work at the normal range in any location. If you have to
get close to your vehicle before the transmitter works,
it's probably time to change the battery.
NOTICE:
When replacing the battery, use care not to
touch any of the circuitry. Static from your
body transferred to these surfaces may damage
the transmitter.

2-20
Remote Lock and Unlock Confirmation
(If Equipped)
With the remote lock and unlock confirmation feature,
you can program your vehicle to do the following:

When you use the remote keyless entry transmitter to
unlock your vehicle, your headlamps will flash to let
you know the command has been received. If you
press LOCK on the remote keyless entry transmitter
again within five seconds, the horn will sound briefly
and the headlamps will flash to let you know your
vehicle is locked.

When you use the remote keyless entry transmitter to
unlock your vehicle, your headlamps will flash to let
you know the command has been received.
Programmable Modes
Mode 1: Both Features Off ± Remote lock and unlock
confirmation are disabled.
Mode 2: Exterior Lamps Flash Only

Remote Lock Confirmation: When you use the
remote keyless entry transmitter to lock the vehicle,
the headlamps will flash to let you know the
command is received.
Remote Unlock Confirmation: When you use the
remote keyless entry transmitter to unlock the
vehicle or open the trunk, the headlamps will flash to
let you know when the command is received.
Mode 3: Exterior Lamps Flash and Horn Sound

Remote Lock Confirmation: When you use the
remote keyless entry transmitter to lock the vehicle,
the horn will sound briefly and the headlamps will
flash to let you know the command is received.

Remote Unlock Confirmation: When you use the
remote keyless entry transmitter to unlock the
vehicle or open the trunk, the headlamps will flash to
let you know the command is received.
Mode 4: Exterior Lamps and Horn Sound ± on second
LOCK press only.

Remote Lock Confirmation: When you use the
remote keyless entry transmitter to lock the vehicle,
the headlamps will flash to let you know the
command is received. The horn will sound briefly
and the headlamps will flash if you press the LOCK
button again within five seconds.

Remote Unlock Confirmation: When you use the
remote keyless entry transmitter to unlock the
vehicle or open the trunk, the headlamps will flash to
let you know the command is received.

2-21
Before your vehicle was shipped from the factory, it was
programmed to Mode 4. The mode to which your
vehicle was programmed may have been changed since
it left the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Follow the instructions for ªEntering Programming
Modeº listed previously.
2. Press the LOCK button on the remote keyless
entry transmitter.
3. Count the number of chimes you hear. The number
of chimes tells you which mode the vehicle is set for.
If you do not wish to change the current mode, you
can either exit the programming mode by following
the instructions earlier in this section or program the
next feature available on your vehicle.
4. Press LOCK on the remote keyless entry transmitter
again to change the current mode.
5. Repeat Step 4 until you hear the number of chimes
that matches the number of the mode you want.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
earlier in this section or program the next feature
available on your vehicle.Content Theft-Deterrent System
(If Equipped)
Your vehicle may be equipped with a content
theft
-deterrent alarm system. Once armed, the system
will go off if someone tries to enter the vehicle without
using the remote keyless entry transmitter or the correct
key, or when someone turns the ignition on with an
incorrect key. The horn will sound, and your vehicle's
headlamps will flash for about two minutes.
Programmable Modes
Mode 1: Not Used
Mode 2: Content Theft On ± If anyone tampers with the
trunk lock or opens a door while the content
theft
-deterrent system is armed, an alarm will sound and
the headlamps will flash for up to two minutes.
Mode 3: Content Theft Off ± The content
theft
-deterrent system is always disarmed.
Mode 4: Not Used

2-28
Content Theft-Deterrent
(If Equipped)
The vehicle may have a theft-deterrent alarm system.
A red light located on top of the instrument panel
(toward the center of the vehicle, near the windshield)
will flash slowly when the system is armed.While armed, the doors will not unlock with the power
door lock switch. The alarm will sound if someone
tampers with the trunk lock, enters the vehicle (without
using the remote keyless entry transmitter or key to
unlock the doors), or turns the ignition on. The horn will
sound and the headlamps will flash for up to two
minutes. The system will also cut off the fuel supply,
preventing the vehicle from being driven.
Arming with the Power Lock Switch
Your alarm system can be programmed to arm when you
use either power lock switch to lock the doors while any
door is open and the key is removed from the ignition.
If you would like to arm the system with the power lock
switch see ªMultifunction Alarm Locks and Lighting
Choicesº in the Index. When programmed, the red light
will flash quickly to let you know that the system is
ready to arm with the power lock switches. When you
press the rear of a power door lock switch, the red light
will stop flashing and stay on to let you know that the
system is arming. After all the doors are closed and
locked, the red light will begin flashing at a very slow
rate to let you know the system is armed.

2-29 Arming with the Remote Keyless
Entry Transmitter
The alarm system will arm when you use the remote
keyless entry transmitter to lock the doors after the key
is removed from the ignition. The red light will turn on
to let you know the system is arming. After all doors are
closed and locked, the red light will begin flashing at a
very slow rate to let you know the system is armed.
Arming Confirmation
If the remote unlock confirmation is on, (see ªLocks
and Lighting Choicesº in the Index), the headlamps
will flash briefly to let you know when the alarm system
has armed.
Disarming with the Remote Keyless
Entry Transmitter
The alarm system will disarm when you use your remote
keyless entry transmitter to unlock the doors. The red
light will go off to let you know the system is disarmed.
Disarming with the Key
The alarm system will disarm when you use the key to
unlock the doors. The red light will stop flashing when
the system is disarmed. If you would like the key to
disarm the alarm system, see ªLocks and Lighting
Choicesº in the Index.

2-49
Tilt Wheel
A tilt steering wheel allows you to adjust the steering
wheel before you drive. You can raise it to the highest
level to give your legs more room when you exit and
enter the vehicle, or you can lower it so that you're more
comfortable while driving.
The lever to adjust it is located on the left side of the
steering column, below the turn signal/multifunction lever.
To tilt the wheel, hold the
steering wheel and pull the
lever. Move the steering
wheel to a comfortable
level, then release the lever
to lock the wheel in place.
Turn Signal/Multifunction Lever
The lever on the left side of the steering column
includes the following:

Turn and Lane Change Signals

Headlamp High/Low
-Beam Changer

Flash
-to-Pass Feature

Windshield Wipers

Windshield Washer

Cruise Control
For information on the exterior lamps, see ªExterior
Lampsº later in this section.

2-50
Turn and Lane Change Signals
The turn signal has two upward (for right) and two
downward (for left) positions. These positions allow you
to signal a turn or a lane change.
To signal a turn, move the lever all the way up or down.
When the turn is finished, the lever will return to its
original position automatically.
An arrow on the instrument
panel cluster will flash
in the direction of the turn
or lane change.
To signal a lane change, just raise or lower the lever
until the arrow starts to flash. Hold it there until you
complete your lane change. The lever will return to its
original position when you release it.
As you signal a turn or a lane change, if the arrow
flashes faster than normal, a signal bulb may be burned
out and other drivers won't see your turn signal.If a bulb is burned out, replace it to help avoid an
accident. If the arrows don't go on at all when you
signal a turn, check for burned
-out bulbs and then check
the fuse. See ªFuses and Circuit Breakersº in the Index.
A chime will sound if you leave the turn signal on for
more than 3/4 mile (1.2 km).
Headlamp High/Low-Beam Changer
To change the headlamps from low beam to high beam,
or high to low, pull the multifunction lever all the way
toward you. Then release it.
When the high beams
are on, this light on the
instrument panel cluster will
appear. While the high
-beam
headlamps are on, the fog
lamps will not illuminate.
If your vehicle is equipped with the Head
-Up-Display
(HUD), an arrow will appear in the display area to
indicate that the high beams are on. See
ªHead
-Up-Display (HUD)º in the Index for
more information.

2-51 Flash-to-Pass Feature
This feature lets you use the high-beam headlamps to
signal a driver in front of you that you want to pass.
It works even if your headlamps are in the automatic or
off position.
To use it, pull the turn signal lever toward you, then
release it.
If the headlamps are in the automatic position or on low
beam, the high
-beam headlamps will turn on and the
high
-beam indicator on the instrument panel cluster
will come on. They will stay on as long as you hold the
lever toward you. Release the lever to return to the
initial position.
If your vehicle is equipped with the Head
-Up-Display
(HUD), an arrow will appear in the display area to
indicate that the high beams are on.
Windshield Wipers
To operate the windshield wipers, turn the band
marked WIPER located on the multifunction lever,
upward or downward.MIST:Turn the band to MIST for a single wiping cycle.
Hold it there until the windshield wipers start, then let it
go. The windshield wipers will stop after one cycle. For
more cycles, hold the band on MIST longer.
OFF:Turn the band to OFF to turn to windshield
wipers off.
DELAY (Delayed Wiping): Turn the band upward to
choose one of the five delay settings. For longer periods
of time between wiper blade cycles, select a low setting.
For shorter periods of time between wiper blade cycles,
select a higher setting. The further the band is turned
upward, the longer the delay between wiper cycles.
LOW: Turn the band to LOW for steady wiping at a
low speed.
HIGH: Turn the band to HIGH for steady wiping at a
high speed.
Be sure to clear ice and snow from the wiper blades
before using them. If they're frozen to the windshield,
carefully loosen or thaw them. If the blades do become
damaged, get new blades or blade inserts.
Heavy snow or ice can overload the wipers. A circuit
breaker will stop them until the motor cools. Clear away
snow or ice to prevent an overload.

2-55
Exterior Lamps
The exterior lamp control is located on the lower
left side of the instrument panel, to the left of the
steering wheel.The exterior lamp has three positions.
OFF: Turning the control to this position, turns off all
lamps, except the Daytime Running Lamps (DRL).
(Parking Lamps): Turning the control to
this position turns on the parking lamps, together
with the following:

Sidemarker Lamps

Taillamps

License Plate Lamp

Instrument Panel Lights
(Headlamps): Turning the control to this position
turns on the headlamps, together with the previously
listed lamps and lights.
A warning chime will sound if you open the driver's
door when you turn the ignition switch to LOCK or
ACCESSORY with the lamps on.
