PONTIAC SOLSTICE 2009 Owners Manual

Convertible Top
For care and cleaning of the convertible top, see
Convertible Top on page 5-95under “Service and
Appearance Care”. High pressure car washes may
cause water to enter the vehicle.
A clear protective lm has been installed on the trunk lid
surface under the convertible top buttresses. This lm
is designed to help prevent paint damage to the trunk lid.
Do not remove this protective lm.
The following procedures explain the proper operation
of the manual convertible top.The parts of the manual convertible top that are used
when lowering and raising it are:
A. Front Edge
B. Side Edge
C. Lower Seal PinsD. Rear Buttresses
E. Trunk
Notice:Leaving the convertible top down and
exposing the interior of your vehicle to outdoor
conditions may cause damage. Always close
the convertible top if leaving your vehicle outdoors.
Notice:Lowering the convertible top when there
are objects in the storage area could damage
it or break the glass rear window. Always verify that
no objects are in the storage area before lowering
the convertible top.
2-37

Notice:Lowering the top if it is damp, wet, or dirty
can cause stains, mildew, and damage to the
inside of your vehicle. Dry off the top before
lowering it.
Notice:If you lower the top on your vehicle in cold
weather (0°F/-18°C or lower), you may damage
top components. Do not lower the top in cold
weather.
Notice:If you raise or lower the convertible top
while the vehicle is in motion, you could damage the
top or the top mechanism. The repairs would not
be covered by your warranty. Always put an
automatic transmission in (P) Park or a manual
transmission in (1) First or (R) Reverse, turn
the ignition off and engage the parking brake before
raising or lowering the convertible top.
{CAUTION:
Moving parts of the convertible top can be
dangerous. People can be injured by the
convertible top and its mechanism. Keep people
away from your vehicle when you are lowering or
raising the top.
Lowering the Manual Convertible Top
1. Empty the trunk of all contents.
2. Park on a level surface and set the parking brake.
Shift an automatic transmission into (P) Park. Shift
a manual transmission into (1) First or (R) Reverse.
3. Turn the ignition off.
4. Open the trunk.
5. Pull down on the convertible top front latch, located
above the inside rearview mirror, and turn it
counterclockwise to unlatch it.
Leave the latch open and turned to prevent damage.
2-38

6. Pull rearward on the side edge (B) of the convertible
top and pull it off of the windshield frame.
7. Push the convertible top down into the trunk (E).
8. After the top is stored, as shown, push on the
convertible top to ensure that the top is fully
retracted and securely stored.
9. Close the trunk (E) by pressing down from the rear
center of it with a swift, rm motion.
Do not operate the rear defogger when the convertible
top is down.Raising the Manual Convertible Top
1. Park on a level surface, set the parking brake rmly
and shift an automatic transmission into (P) Park.
Shift a manual transmission into (1) First or
(R) Reverse.
2. Turn off the ignition, and lower the windows.
3. Push the trunk release button located in the glove
box, or on the remote keyless entry, if equipped.
4. Open the trunk.
5. Pull the convertible top forward by rmly gripping the
side edge (B) and applying a brisk upward and
forward motion to get the top in the full-up position.
2-39

6. Pull the front edge (A) of the convertible top forward
from the outside of the vehicle, or push the front
edge (A) of the convertible top forward from
the inside of the vehicle.
7. Turn the top front latch handle clockwise to latch
the convertible top.
8. Make sure the lower seal pins (C) are correctly
aligned and inserted.
9. Close the trunk by pressing down on the rear
center with a swift, rm motion.
10. At the rear edge of the convertible top, press down
on the two buttresses (D) to latch them into the top
of the trunk.
2-40

Instrument Panel Overview...............................3-4
Hazard Warning Flashers................................3-5
Horn .............................................................3-5
Tilt Wheel.....................................................3-6
Turn Signal/Multifunction Lever.........................3-6
Turn and Lane-Change Signals........................3-7
Headlamp High/Low-Beam Changer..................3-7
Flash-to-Pass.................................................3-7
Windshield Wipers..........................................3-8
Windshield Washer.........................................3-9
Cruise Control................................................3-9
Headlamps..................................................3-12
Headlamps on Reminder................................3-13
Daytime Running Lamps (DRL).......................3-13
Fog Lamps ..................................................3-13
Instrument Panel Brightness...........................3-14
Entry/Exit Lighting.........................................3-14
Mirror Reading Lamps...................................3-14
Battery Run-Down Protection..........................3-14
Accessory Power Outlet(s).............................3-14
Ashtray(s) and Cigarette Lighter......................3-15
Climate Controls............................................3-16
Climate Control System.................................3-16
Outlet Adjustment.........................................3-19Warning Lights, Gages, and Indicators............3-19
Instrument Panel Cluster................................3-20
Speedometer and Odometer...........................3-21
Tachometer.................................................3-21
Safety Belt Reminders...................................3-22
Airbag Readiness Light..................................3-23
Passenger Airbag Status Indicator...................3-24
Charging System Light..................................3-25
Brake System Warning Light..........................3-25
Antilock Brake System (ABS) Warning Light.....3-26
Electronic Stability Control (ESC)/Traction
Control System (TCS) Indicator/Warning
Light........................................................3-27
Engine Coolant Temperature Warning Light......3-28
Low Coolant Warning Light............................3-28
Tire Pressure Light.......................................3-29
Malfunction Indicator Lamp.............................3-29
Oil Pressure Light.........................................3-32
Security Light...............................................3-32
Highbeam On Light.......................................3-33
Trunk Ajar Light............................................3-33
Fuel Gage...................................................3-33
Low Fuel Warning Light.................................3-34
Section 3 Instrument Panel
3-1

Driver Information Center (DIC).......................3-34
DIC Operation and Displays...........................3-35
DIC Warnings and Messages.........................3-37
DIC Vehicle Personalization............................3-41
Audio System(s).............................................3-46
Setting the Clock..........................................3-47
Radio(s)......................................................3-49
Using an MP3..............................................3-60XM Radio Messages.....................................3-67
Bluetooth®...................................................3-68
Theft-Deterrent Feature..................................3-78
Audio Steering Wheel Controls.......................3-79
Radio Reception...........................................3-80
Fixed Mast Antenna......................................3-81
XM™ Satellite Radio Antenna System.............3-81
Chime Level Adjustment................................3-81
Section 3 Instrument Panel
3-2

✍NOTES
3-3

Instrument Panel Overview
3-4

The main components of the instrument panel are the
following:
A. Side Window Outlets. SeeClimate Control System
on page 3-16.
B.Outlet Adjustment on page 3-19.
C.Turn Signal/Multifunction Lever on page 3-6.
D.Cruise Control on page 3-9(If Equipped).
E.Instrument Panel Cluster on page 3-20.
F.Audio Steering Wheel Controls on page 3-79
(If Equipped).
G.Instrument Panel Brightness on page 3-14.
H.Passenger Airbag Status Indicator on page 3-24.
I.Hazard Warning Flashers on page 3-5.
J.Fog Lamps on page 3-13(If Equipped).
K. Electronic Stability Control (ESC)/Traction Control
System (TCS) Button (If Equipped). SeeElectronic
Stability Control (ESC) on page 4-6orTraction
Control System (TCS) on page 4-8.
L.Driver Information Center (DIC) on page 3-34.
M.Horn on page 3-5.
N.Windshield Wipers on page 3-8andWindshield
Washer on page 3-9.
O.Climate Control System on page 3-16.P. Cigarette Lighter (If Equipped).Ashtray(s) and
Cigarette Lighter on page 3-15andAccessory Power
Outlet(s) on page 3-14(If Equipped).
Q. Shift Lever. SeeManual Transmission Operation on
page 2-22. SeeAutomatic Transmission Operation
on page 2-19(If equipped with automatic
transmission).
R.Parking Brake on page 2-23.
S.Audio System(s) on page 3-46.
T.Cupholders on page 2-33.
U. Trunk Release. SeeTrunk on page 2-8.
V.Glove Box on page 2-33.
Hazard Warning Flashers
|(Hazard Warning Flasher):Press this button
located on the instrument panel, to make the front and
rear turn signal lamps ash on and off. This warns
others that you are having trouble.
Press
|again to turn the ashers off.
Horn
To sound the horn, press the center pad on the steering
wheel.
3-5

Tilt Wheel
A tilt wheel lets the steering wheel be adjusted.
The tilt lever is located on the left side of the steering
column.
To tilt the wheel, pull the lever down. Raise or lower the
wheel to a comfortable position, then pull the lever up
to lock the wheel in place.
Turn Signal/Multifunction Lever
The lever on the left side of the steering column
includes the following:
G:Turn and Lane-Change Signals
53:Headlamp High/Low-Beam Changer
O:Exterior Lamp Control
Flash-to-Pass.
Information for these features is on the pages following.
3-6
