PORSCHE 911 2014 6.G Information Manual

140141
911 C a r r e r a911 Carrera Cabriolet911 Carrera S911 Carrera S Cabriolet
Weights
Manual / PDK Manual / PDK Manual / PDK Manual / PDK
Unladen (DIN) 1,400 kg / 1,420 kg1,470 kg / 1,490 kg1,415 kg / 1,435 kg1,485 kg / 1,505 kg
Unladen (EC)
1)1,475 kg / 1,495 kg 1,545 kg / 1,565 kg1,490 kg / 1,510 kg1,560 kg / 1,580 kg
Permissible gross weight 1,795 kg / 1,815 kg1,850 kg / 1,870 kg1,830 kg / 1,850 kg1,885 kg / 1,905 kg
PerformanceManual / PDK Manual / PDK Manual / PDK Manual / PDK
Top speed 289 km/ h / 287 km/ h286 km/ h / 284 km/ h304 km/ h / 302 km/ h301 km/ h / 299 km/ h
0–100 km/h 4.8 secs / 4.6 secs5.0 secs / 4.8 secs4.5 secs / 4.3 secs4.7 secs / 4.5 secs
Sport Chrono Package (with PDK) 0 –100 km/ h – / 4.4 secs – / 4.6 secs– / 4.1 secs – / 4.3 secs
0 –16 0 k m / h 10.4 secs / 10.0 secs 10.8 secs / 10.4 secs9.4 secs / 9.0 secs 9.8 secs / 9.4 secs
Sport Chrono Package (with PDK) 0 –160 km/ h – / 9.7 secs – / 10.1 secs– / 8.7 secs – / 9.1 secs
Flexibilit y (80 –120 km/ h) in 5th gear 6.4 secs / –6.7 secs / –5.9 secs / –6.2 secs / –
Overtaking acceleration (80 –120 km) – / 2.8 secs – / 2.9 secs– / 2.4 secs – / 2.5 secs
Fuel consumption/emissions 2)Manual / PDK Manual / PDK Manual / PDK Manual / PDK
Urban in l/100 km 12.4 / 11.312.7 / 11.513.3/ 12.1 13.6/ 12.2
Extra urban in l/100 km 7.0 / 6.67.2 / 6.77.3/ 6.77.5/ 6.9
Combined in l/100 km 9.0 / 8.29.2 / 8.49.5 / 8.79.7 / 8.9
CO
2 emissions g/km 211 / 191216 / 195223 / 202228 / 207
Efficiency class3)Manual / PDK Manual / PDK Manual / PDK Manual / PDK
Efficiency class (Germany) G /
FG / F G / GG / F
Efficiency class (Switzerland) G / GG/ GG / GG / G
Dimensions/aerodynamics
Length 4,491 m m4,491 m m4,491 m m4,491 m m
Width 1,808 mm1,808 mm1,808 mm1,808 mm
Height 1,303 mm1, 2 9 9 m m1, 2 95 m m1, 2 92 m m
Wheelbase 2,450 mm2,450 mm2,450 mm2,450 mm
Luggage compartment volume
(German Car Manufacturers’ Assoc.) 14 5 l i t r e s
14 5 l i t r e s14 5 l i t r e s14 5 l i t r e s
Tank capacity (refill volume) 64 litres64 litres64 litres64 litres
Drag coefficient 0.290.300.290.30
911 Carrera / 911 Carrera Cabriolet 911 Carrera S / 911 Carrera S Cabriolet
Engine
Cylinders 6 6
Displacement 3,436 cm
33,800 cm3
Max. power (DIN)
at rpm257 kW (350 hp)
7, 4 0 0 294 kW (400 hp)
7, 4 0 0
Max. torque
at rpm 390 Nm
5,600 440 Nm
5,600
Compression ratio 12.5 : 1 12.5 : 1
Transmission
LayoutRear- wheel drive Rear- wheel drive
Manual gearbox 7 -speed 7 -speed
PDK (optional) 7 -speed 7 -speed
Chassis
Front a xle McPherson strut suspension McPherson strut suspension
Rear axle Multi -link suspension Multi -link suspension
Steering Variable steering ratio, power- assisted (electromechanical) Variable steering ratio, power-
assisted (electromechanical)
Turning circle 11.1 m 11.1 m
Brakes Four-piston aluminium monobloc fixed calipers front and rear,
discs internally vented and cross-drilled Six-

piston aluminium monobloc fixed calipers at front, four
-piston
aluminium monobloc fixed calipers at rear, discs internally vented
and cross- drilled
Vehicle stability system Porsche Stability Management (PSM) including ABS
with additional brake functions Porsche Stability Management (PSM) including ABS
with additional brake functions
Standard wheels Front: 8.5 J x 19 ET 54, Rear: 11 J x 19 ET 69 Front: 8.5 J x 20 ET 51, Rear: 11 J x 20 ET 70
Standard tyres Front: 235/40 ZR 19, Rear: 285/35 ZR 19 Front: 245/35 ZR 20, Rear: 295/30 ZR 20
Technical data.
1) Weight is calculated in accordance with the relevant EC Directives and is valid for vehicles with standard specification only. Optional equipment increases this figure. The figure given includes 68 kg for the driver and 7 kg for luggage.2) Data determined in the NEDC (New European Driving Cycle) in accordance with the Euro 6 (715/2007/ EC, 195/2013/ EC and ECE- R 101.01) measurement method. The figures do not refer to an individual vehicle nor do they constitute
par t of the of fer. They are intended solely as a means of comparing dif ferent t ypes of vehicle. Fuel consumption calculated for vehicles with standard specification only. Actual consumption and per formance may var y with items of
optional equipment. A vehicle's fuel consumption and CO
2 emissions depend not only on its ef ficient use of fuel but also on driving st yle and other non -technical factors. The latest Porsche models with petrol engine are designed to
operate on fuels with an ethanol content of up to 10 %. You can obtain fur ther information about individual vehicles from your Porsche Centre.
3) Valid in countries listed only.

142143
911 Carrera 4911 Carrera 4 Cabriolet911 Carrera 4S911 Carrera 4S Cabriolet
Weights
Manual / PDK Manual / PDK Manual / PDK Manual/PDK
Unladen (DIN) 1,450 kg / 1,470 kg1,520 kg / 1,540 kg1,465 kg / 1,485 kg1,535 kg / 1,555 kg
Unladen (EC)
1)1,525 kg / 1,545 kg 1,595 kg / 1,615 kg1,540 kg / 1,560 kg1,610 kg / 1,630 kg
Permissible gross weight 1,845 kg / 1,865 kg1,900 kg / 1,920 kg1,875 kg / 1,895 kg1,935 kg / 1,955 kg
PerformanceManual / PDK Manual / PDK Manual / PDK Manual / PDK
Top speed 285 km/ h / 283 km/ h282 km/ h / 280 km/ h299 km/ h / 297 km/ h296 km/ h / 294 km/ h
0–100 km/h 4.9 secs / 4.7 secs5.1 secs / 4.9 secs4.5 secs / 4.3 secs4.7 secs / 4.5 secs
Sport Chrono Package (with PDK) 0 –100 km/ h – / 4.5 secs– / 4.7 secs– / 4.1 secs– / 4.3 secs
0 –16 0 k m / h 10.6 secs / 10.2 secs11.0 secs / 10.6 secs9.6 secs / 9.2 secs10.0 secs / 9.6 secs
Sport Chrono Package (with PDK) 0 –160 km/ h – / 9.9 secs– / 10.3 secs– / 8.9 secs– / 9.3 secs
Flexibilit y (80 –120 km/ h) in 5th gear 6.5 secs / –6.8 secs / –6.0 secs/ –6.3 secs/ –
Overtaking acceleration (80 –120 km/ h) – / 2.9 secs– / 3.1 secs– / 2.5 secs– / 2.7 secs
Fuel consumption/emissions 2)Manual / PDK Manual / PDK Manual / PDK Manual / PDK
Urban in l/100 km 12.9 / 11.713.1 / 11.8 13.8 / 12.4 13.9 / 12.5
Extra urban in l/100 km 7.4/ 6.87.5 / 6.97. 6 / 7. 0 7. 7 / 7. 1
Extra urban in l/100 km 9.3 / 8.69.5 / 8.79.9 / 9.1 10.0 / 9.2
CO
2 emissions g/km 218 / 200223 / 202233 / 212235 / 214
Efficiency class 3)Manual / PDK Manual / PDK Manual / PDK Manual / PDK
Efficiency class (Germany) G /
FG / F G / GG / F
Efficiency class (Switzerland) G / GG/ GG / GG / G
Dimensions/aerodynamics
Length 4,491 m m4,491 m m4,491 m m4,491 m m
Width 1,8 52 m m1,8 52 m m1,8 52 m m1,8 52 m m
Height 1,3 0 4 m m1,3 0 0 m m1, 2 9 6 m m1, 2 9 4 m m
Wheelbase 2,450 mm2,450 mm2,450 mm2,450 mm
Luggage compartment volume
(German Car Manufacturers’ Assoc.) 125 l i t re s
125 l i t re s125 l i t re s125 l i t re s
Tank capacity (refill volume) 68 litres68 litres68 litres68 litres
Drag coefficient 0.300.310.300.31
911 Carrera 4 / 911 Carrera 4 Cabriolet 911 Carrera 4S / 911 Carrera 4S Cabriolet
Engine
Cylinders 6 6
Displacement 3,436 cm
33,800 cm3
Max. power (DIN)
at rpm257 kW (350 hp)
7, 4 0 0 294 kW (400 hp)
7, 4 0 0
Max. torque
at rpm 390 Nm
5,600 440 Nm
5,600
Compression ratio 12.5 : 1 12.5 : 1
Transmission
LayoutAll-wheel drive All-wheel drive
Manual gearbox 7-speed 7-speed
PDK (optional) 7-speed 7-speed
Chassis
Front a xleMcPherson strut suspension McPherson strut suspension
Rear axle Multi-link suspension Multi-link suspension
Steering Variable steering ratio, power-assisted (electromechanical) Variable steering ratio, power-assisted (electromechanical)
Turning circle 11.1 m 11.1 m
Brakes Four-piston aluminium monobloc fixed calipers front and rear,
discs internally vented and and cross-drilled Six-piston aluminium monobloc fixed calipers at front, four-piston
aluminium monobloc fixed calipers at rear, discs internally vented
and cross-drilled
Vehicle stability system Porsche Stability Management (PSM) including ABS
with additional brake functions Porsche Stability Management (PSM) including ABS
with additional brake functions
Standard wheels Front: 8.5 J X 19 ET 54, Rear: 11 J X 19 ET 48 Front: 8.5 J X 20 ET 51, Rear: 11 J X 20 ET 52
Standard tyres Front: 235/40 ZR 19, Rear: 295/35 ZR 19 Front: 245/35 ZR 20, Rear: 305/30 ZR 20
1) Weight is calculated in accordance with the relevant EC Directives and is valid for vehicles with standard specification only. Optional equipment increases this figure. The figure given includes 68 kg for the driver and 7 kg for luggage.2) Data determined in the NEDC (New European Driving Cycle) in accordance with the Euro 6 (715/2007/ EC, 195/2013/ EC and ECE- R 101.01) measurement method. The figures do not refer to an individual vehicle nor do they constitute
par t of the of fer. They are intended solely as a means of comparing dif ferent t ypes of vehicle. Fuel consumption calculated for vehicles with standard specification only. Actual consumption and per formance may var y with items of
optional equipment. A vehicle's fuel consumption and CO
2 emissions depend not only on its ef ficient use of fuel but also on driving st yle and other non -technical factors. The latest Porsche models with petrol engine are designed to
operate on fuels with an ethanol content of up to 10 %. You can obtain fur ther information about individual vehicles from your Porsche Centre.
3) Valid in countries listed only.

144145
#
‘911’ logo 126
A
Adaptive cruise control 91
Airbags 78
Anti-theft protection 95
Audio interface, universal 96, 98
AudioPilot
® 101
Auto start/stop function 41
B
Bi-Xenon headlights 81
Body 52
BOSE
® Surround Sound System 101
B r a k e s 74
Burmester
® High-End Surround
Sound System 102
C
Cataly tic converter 44, 115
CD/ DVD autochanger 96
CDR audio system 96
CDR Plus audio system 96
Chassis 52
Climate control 90
Coasting 49
Colours
Exterior 120
Interior 122
Comfort 82
Communication 96
Cruise control 90
D
Digital radio 98
Direct fuel injection (DFI) 42
Dry-sump lubrication, integrated 44
Dynamic engine mounts 67
E
Electrical system recuperation 41
Emission control 115
Engine management, electronic 45
Engineered body design 54
Engines 36
3.4-litre boxer engine 38
3.8-litre boxer engine 38
E n v i r o n m e n t 112
Exhaust system 44
Exterior mirrors and rear-view mirror 92
F
Factory collection 135
Front axle 55
Fu e l 115
Fuel consumption 115
Fuel system 115
H
Headlight cleaning system 81
HomeLink
® (programmable
garage door opener) 90
Hood 56
I
I numbers 126
Instruments 85
Intake manifold 44
K
Knock control, cylinder-specific 45
L
Leather 122, 131
LED main headlights 81
Light design package 90
Lights 80
Logbook, electronic 99
Luggage compartment 94
M
Manual gearbox 46
M a t e r i a l s 115
Memory package 88
Mobile phone preparation 99
Models 18
Motorsport 106
O
On-board computer 85
On-board diagnostics 45
Online services 100
P
Panorama 136
Park Assist 92
Parking brake, electric 78
Performance display 67
Personalisation 118
Porsche Active Suspension
Management (PASM) 60
Porsche Ceramic Composite Brake
(PCCB) 76
Porsche Communication
Management (P CM) 97
Porsche Doppelkupplung
(PDK) 48
Porsche Dynamic Chassis Control
(PDCC) 62
Porsche Dynamic Light System
(PDLS) 81
Porsche Dynamic Light System Plus
(PDLS +
) 81
Porsche Entry & Drive 94
Porsche Side Impact Protection
System (POSIP) 79
Porsche Stabilit y Management (PSM) 69
Porsche Torque Vectoring (PT V) 70
Porsche Torque Vectoring Plus
(PT V Plus) 70
Porsche Traction Management (PTM) 50
Porsche Vehicle Tracking System
(PV TS) 95
Power steering 64
Power steering Plus 64
R
Rain sensor 92
Rear axle 55
Rear differential lock 70
R e c y c l i n g 115
Reversing camera 92
Roll-over protection 79
Roof transport system 94
S
S a f e t y 74
Seat heating 89
Seat ventilation 89
Seats
Adaptive Sports seats Plus 88
Child seats 89
Fully electric Sports seats 88
Rear seats 89
Sports bucket seats 89
Sports seats 88
Sports seats Plus 88
Slide/tilt sunroof 93
Slide/tilt sunroof, glass 93
Sound Package Plus 96
Speed limit indicator 99
SPORT but ton 65
Sports chassis 61
Sport Chrono Package 65
SportDesign exterior mirrors 127
Sports exhaust system 44
SPORT PLUS but ton 65
Steering 64
Steering wheel heating 87
Steering wheels
Multifunction steering wheel 86
SportDesign steering wheel 87
Sports steering wheel 86
Stereo Lambda control circuits 115
Surround sound system 101
T
Technical data 140
Telephone module 98
TFT display 85
Thermal management 41
Transmission 46
Trim strip in a high-gloss finish 126
T V tuner 99
Tyre Pressure Monitoring (TPM) 68
Index.
V
VarioCam Plus 42
Voice control system 99
W
‘Welcome Home’ lighting 90
Wheels 68
Wind deflector, electrically powered 58

The models featured in this publication
are approved for road use in Germany.
Some items of equipment are available as
extra-cost options only. The availabilit y of
models and options may vary from
market to market due to local restrictions
and regulations. For information on
standard and optional equipment, please
consult your Porsche Centre. All
information regarding construction,
features, design, performance,
dimensions, weight, fuel consumption
and running costs is correct to the best
of our knowledge at the time of going to
print (11/13). Porsche reserves the right
to alter specifications, equipment and
delivery scopes without prior notice.
Colours may differ from those illustrated.
Errors and omissions excepted.
© Dr. Ing. h.c. F. Porsche AG, 2014
All text, illustrations and other
information in this publication
subject to the copyright of
Dr. Ing. h.c. F. Porsche AG.Any reproduction, duplication or

other use is prohibited without the
prior written consent of
Dr. Ing. h.c. F. Porsche AG.
Dr. Ing. h.c. F. Porsche AG supports the
use of paper from sustainable forests.
The paper for this brochure is certified
in accordance with the strict regulations
of the PEFC (Programme for the
Endorsement of Forest Certification).
Porsche, the Porsche Crest, 911,
Carrera, PCCB, PCM, PSM, PDK,
Tequipment and other marks
are registered trademarks of
Dr. Ing. h.c. F. Porsche AG.
Dr. Ing. h.c. F. Porsche AG
Porscheplatz 1
70435 Stut tgart
Germany
www.porsche.com
Ef fective from: 03/2014
Printed in Germany
WSLC1501000120 EN/ WW
