PORSCHE 911 CARRERA 2011 6.G Information Manual

8283
Composure
| Comfor t
Telephone module.
The optional quadband GSM telephone
module offers convenience and excellent
reception. By inserting a SIM card directly
into the PCM’s integral SIM card reader,
calls can be made using the hands-free
facility. For even more convenience, the
Bluetooth
® capability of a mobile phone
can be used to make calls via the SIM
Access Profile (SAP).* Once automatic
pairing is complete, the mobile phone’s
aerial is switched off to conserve bat tery
charge and the phone operates via
the car aerial. Depending on the mobile
phone model, this gives access not only
to the numbers on the SIM card, but also
to the phone’s internal memory. Depending
on the phone, it can also be controlled
using PCM, the optional multifunction
steering wheel or the optional voice
control system, without it ever leaving
your pocket.
the basic functions of the mobile phone.
The GSM connection is established
through the aerial of the mobile phone.
*
The telephone module also enables you
to establish a Bluetooth
® link with those
mobile phones that only support the
Handsfree Profile (HFP). In this case, the
GSM connection is always established
through the aerial of the mobile phone.*
PCM acts as a hands-free system and
you can leave the mobile phone tucked
a w ay.
On request, a cordless handset for the
telephone module is also available. Stored
in the centre console, it features a display
and keypad. However, the handset cannot
be used for Bluetooth
® links established
using the Handsfree Profile (HFP).
TV tuner.
The optional T V tuner is capable of
receiving unencrypted analogue and
digital television broadcasts (DVB -T) to
provide entertainment bet ween journeys.
For your safet y, the T V picture is
switched off while the car is in motion.
Mobile phone preparation.
To enable a Bluetooth® connection for
those mobile phones that only support
the Handsfree Profile (HFP),
* an optional
mobile phone preparation is available. It
enables you to leave your mobile phone
tucked away. PCM is able to control only
Universal audio interface.
With PCM, a USB port is included to
enable you to connect your iPod
® or any
other compatible audio source of your
choice. Recharging is also supported.
The iPod
® or USB stick can be controlled
conveniently and safely using PCM, the optional multifunction steering wheel or
the optional voice control system. Through
the USB port, it is also possible to down -
load data from the performance display
of the Sport Chrono Package as well as
data from the electronic logbook.
Universal audio interface
* Please refer to the notes on page 112.
T V tuner

8485
Composure
| Comfor t
The sound of a Porsche is a unique char
-
acteristic, and we’re not referring only to
the engine. The optional BOSE
® Surround
Sound System was specially developed for
the 911 and is therefore perfectly tuned
to the car’s specific interior acoustics.
It has a total output of 445 wat ts and
comprises 8 amplifier channels, 12 loud -
speakers and a patented integral 200 -
watt active subwoofer. The combined
effect is a balanced acoustic pat tern that
transforms your 911 into a fast-moving
concert hall.
The BOSE® Surround Sound System
enables audio playback of DVDs and
is thus able to make full use of the
impressive sound spectrum of 5.1 digital
recordings. Of course, you can still play
other audio sources, such as CDs and
MP3s, in stereo or, at the push of a but -
ton, in one of the virtual surround modes
generated by BOSE
® Centerpoint® 2.
The BOSE
®- patented AudioPilot®
noise compensation technology
uses a
microphone to continuously
measure
the ambient noise inside the vehicle and
adapts music playback
instantly and automatically so that
a consistent sound is maintained –
whatever the driving conditions.
The result is a balanced, faithfully
reproduced sound and captivating
360° acoustic experience.
Cue the applause.
Character is conveyed by a clear voice,
not a loud one.

BOSE
® Surround Sound System.

8687
Composure
| Comfor t
Words can barely describe the 911 experience.

Sound can.

Burmester
® High-End Surround Sound System.
When t wo iconic German manufacturers
join forces, the result is special. We’re
referring to Porsche and Berlin-based
Burmester
®, one of the most respected
manufacturers of high-end audio equip -
ment worldwide, and the Burmester
®
High-End Surround Sound System.
The technologies behind the system are
based on the finest premium home audio
systems Burmester
® has to offer.
The system owes its eminence to count -
less details, and one goal: perfection
in sound.
The system has 12 amplifier channels
with a total output of more than 821
watts, 12 loudspeakers including an
active subwoofer with 300 -wat t class D amplifier, a total diaphragm surface area
of more than 1,340 cm², and a frequency
response of 35 Hz to 20 kHz.
For the first time in a 911, Burmester
®

has introduced the patented integral
subwoofer, which replaces the familiar
separate subwoofer and loudspeaker
arrangement of other systems. This saves
weight and has a beneficial impact on
acoustic performance.
Crossover technology has been carried
over more or less unmodified from the
home audio sector. Analogue and digital
filters have been optimally defined for
their new installation location and finely
tuned af ter extensive in - car audio testing. The t weeters are ribbon-based air motion
transformers (AMT) that have been
designed specifically for the 911. For
unmistakably fine, clear and undistorted
high-frequency sound reproduction with
excellent level stability. All loudspeaker
housings are perfectly matched and deliv
-
er superior bass foundation, definition
and impulse accuracy. As yet unequalled
in the 911, the result is a natural and
richly textured spatial sound even at top
volume.
The pure, sport y design with galvanised
surrounds and Burmester
® logos on
selected loudspeakers make it clear that
the appeal of the Burmester
® High - End
Surround Sound System is as much about the visual as it is the audio.

Typically Porsche.
Cue the encore.

spirited
alert
i
realistic
optimistic
pri
agile
Re
i

9091
Responsibility
|
Motorsport
On the racetrack, we’re fiercely committed.
Not least to the future.

Motorsport.
How does one book one’s place in motor -
sport history? By finishing that crucial
one hundredth of a second faster than
the competition, or a whole lap ahead of
the rest of the field? Either way, victory is
sweet. At Porsche, however, one goal
mat ters above all: turning to the next
chapter and shaping the future of motor -
sport using intelligent technologies and
unconventional ideas with the incentive of
increased power output and enhanced
efficiency, as well as the abilit y to incor -
porate these innovations into cars engi -
neered for the road.918 RSR race laboratory.
How powerful can a hybrid be? How sus-
tainable can a racecar be? If hybrid sports-
car
technology is to be taken seriously, we
believe it must prove its worth in the test -
ing environment of tomorrow – on the race-
track. The 918 RSR succeeds, lap after lap.
The drive system comprises a high-revving
combustion engine, two electric machines
on the front axle and enhanced fly wheel
energy storage derived from the 911 GT3
R Hybrid.
What did we wish to achieve? Extremely
high performance, of course, but we also
wanted a glimpse of the future. A lit tle bit
sooner and a lit tle bit faster.
911 GT3 R Hybrid.
It took a whole year’s work for just one
day: the 24 Hours of Nürburgring in
2010. With the 911 GT3 R Hybrid, our
engineers sent a 911 onto the track
equipped for the first time ever with
three drive units.
The principle is to recover unused kinetic
energy. Energy is stored by a fly wheel
accumulator that spins at up to 40,000
rpm. After braking, t wo electric motors
on the front axle enable the driver to
draw this power to boost acceleration out
of corners or for overtaking. In short: he
who brakes, wins. It is a principle that the 911 GT3 R Hybrid
brought to the front of the field at the
Nürburgring in 2010, where it remained
until the 23rd hour. Engine failure may
have forced it to retire from this particu
-
lar race, but this was not the end.
The 911 GT3 R Hybrid since went on to
compete in a number of major endurance
trials around the world. In Zhuhai in the
same year, it was recognised as the
fastest and most economical GT vehicle
in the field.
We don’t need to win to make progress.
The idea alone motivates us to achieve
greater things. Intelligent Per formance.

9293
Responsibility
|
Motorsport
GT-Sp o r t .
GT cars are pure-bred racing cars.
They must be based on road-registered
sportscars and modifications are
restricted to specific areas. In the early 1990s, Porsche was the

driving force behind the renaissance
of international GT motorsport. In the
meantime, Porsche has established
successful cooperation with customer
teams. Porsche supplies the race-ready cars and supports private teams with

further development, technical services
and the provision of factory drivers.
Whether it ’s in the Le Mans 24 Hours, the
ALMS, the International GT Open or at
national GT championships, Porsche
private teams are regular race and
championship winners.
Porsche one-make championships.
Porsche racing drivers are able to indulge
their passion for motorsport in 20
Porsche one-make championships on
5 continents. The philosophy is one of
equal opportunities and fairness through the use of technically identical racing
cars. The result is fiercely contested sprints of the highest standard.

Based directly on the 911 GT3 RS,
911 GT3 Cup cars compete in races
as part of high-level racing events. At each Porsche one-make championship,
Porsche supplies the cars to private teams
in race-ready condition and organises

the race series and provides support for
the drivers, teams and sponsors from
its trackside position.
Porsche GT-Sport Porsche Mobil 1 Supercup
Porsche Mobil 1 Supercup.
The Porsche Mobil 1 Supercup is the
world’s fastest international one-make
race series. With 11 races in total and an
average spectatorship of over 100,000,
it is held as part of the supporting
programme of the FIA Formula One World
Championship.
Porsche Carrera Cup Germany.
The Porsche Carrera Cup Germany is
one of the fastest national one-make
championships in the world. As a partner
series to the DTM (German Touring Car
Masters) – the most prominent touring
car series in Germany – it offers an
abundance of motorsport thrills and
an extremely attractive programme
of events.
For further information, please visit
www.porsche.com/motorsport.

9495
Responsibility
|
Motorsport
Porsche Sport Driving School.
At Porsche, we are working not only
on the evolution of the sportscar, but
also on the development of the drivers.
Safe driving on the road may be second
nature, but what about mastering control
of a sportscar at the limits of sport y performance? We will help you to

perfect your driving safet y as well as
your advanced skills and techniques
step by step.
Under the supervision of our experienced
Porsche instructors in your own car
or in one provided by the Porsche Sport Driving School, you can refine your ability
on-road or off-road, on international

racetracks or on ice or snow. We will be
by your side from the start and, if it is
your aim, we will accompany you through
every training level on the way to obtain -
ing your motorsport licence. To find out more, please call

+49 (0)711 911-78683 or go to
w w w.porsche.de/sportdrivingschool.
Porsche Sports Cup.
In 2011, the Porsche Sports Cup began
its seventh season. Six events on five
racetracks, including the Nürburgring,
Hockenheimring and Spa-Francorchamps,
deliver exhilarating excitement. Various
t ypes of race are open for entry.
From regularity rallies to sprints, you can

compete in the Porsche Sports Cup by
bringing your own road-approved Porsche
or a Porsche that has been race-modified.
To find out more, please call
+49 (0)711 911-12384 or go to
w w w.porschesportscup.de.
Porsche Sport Driving School Porsche Sports Cup
Porsche Club Sport.
Porsche Clubs organise a variet y of
one-off competitions or full series in
which drivers compete in various classes.
Founded in 1952, today there are
620 clubs in 68 countries with a total
membership of approximately 180,000 and the numbers keep growing. The

Porsche Club Organisation is one
of the largest and longest established
automotive associations in the world.
For further information, please call
+ 4 9 ( 0 ) 7 11 9 11 - 7 8 3 0 7
or go to w w w.porsche.com.

9697
Responsibility
|
Environment
Since 1963, we’ve defined the 911 in terms of sporty performance.
And we’ve scrutinised it daily for its efficiency-enhancing potential.

Porsche and the environment.
We’ve already spoken about our contribu -
tion to motorsport. To be more precise,
about our responsibility for the future of
motorsport. We meet this responsibility
with intelligent technology, unconventional
ideas and optimum performance.
Our approach to environmental protection
is no different. In an era of intensifying
debate about global climate change and
CO
2 emissions, every automotive manu -
facturer is asking what it has to offer
right now. Our answer has long been the
same: maximum ef ficiency. Porsche has managed to reduce fuel

consumption across all model ranges
by a double-digit percentage compared
with the respective previous model even
though performance has been increased.
This is made possible by an efficient
drive concept (e.g. DFI and VarioCam
Plus), lightweight construction, optimised
aerodynamics and low rolling resistance.
The environmental management team
at the Porsche Development Centre
in Weissach aims to demonstrate a high
level of environmental responsibility. Here, technological developments are
carried out with environmental protection
in mind. The goal is to enhance perfor
-
mance – but not at the expense of the
environment. We achieve this goal with
Intelligent Performance, as epitomised by
t h e 911.

9899
Responsibility
|
Environment
Exhaust emission control.
Vehicles manufactured by Porsche
demonstrate that even high-performance
sportscars can achieve moderate
fuel consumption and exhaust emission
values in their respective category.
This is achieved, on the one hand,
through the use of fuel-efficient technolo -
gies such as auto start/stop, thermal
management, electrical system recupera -
tion, direct fuel injection, coasting mode
and VarioCam Plus.
On the other hand, newly developed
cataly tic converters provide ef ficient
emission control.
The stereo Lambda control circuitr y
controls and monitors each cylinder bank
separately. For each exhaust tract,
oxygen sensors regulate the composition
of the exhaust gas, while another Lambda
sensor on each cylinder bank monitors pollutant conversion in the respective

cataly tic converter.
1)

Fuel economy and recycling.
Intelligent light weight construction has
been fundamental to the Porsche identit y
since 1948, for both economic and
ecological reasons. This forms the basis
for achieving low fuel consumption
values in conjunction with outstanding
performance.
It is economical thanks to the high
proportion of aluminium, magnesium,
plastics and super- high -strength sheet
steel used. This is substantially more
stable and lighter than conventional steel.
It is also ecological because all materials
used are meticulously selected. We use
only innovative and environmentally friendly
components. All light weight materials are
easily recyclable and each material is labelled to facilitate its separation for
recycling. The reduction in the number
of plastic variants helps to ensure more
ef ficient recycling. Recycled plastics
are used where they meet our exacting
technical requirements.
In short, the new 911 is up to around
95 % recyclable.
In addition, Porsche for the most part
uses environmentally friendly water-
based paints. For us, environmental

protection does not begin at the end
of a vehicle’s life. It starts at the planning
and development stage.

Fuel.
All Porsche models – including the new
911 – are already designed to operate
on fuels with an ethanol content of up
to 10 %, e.g. ‘E10’. Ethanol has a positive
impact on the CO
2 balance since the
plants grown for the production of
this biofuel also absorb CO
2 from the
atmosphere.
The release of hydrocarbons from the
fuel system has been minimised thanks
in no small part to the active carbon filter
and the multilayered material from which
the fuel tank is made. All fuel lines are
made from multilayered plastic, steel or
aluminium.
1) Not in markets with leaded fuel.

nonconformist
determi
mature
genui
P
clea
direct
subtle
perfectionist
