Chassis 63
SPORT button.
The SPORT button enables you to select
a suspension setup where the emphasis
is on either comfort or sport y performance.
At the push of a button, the electronic
engine management system switches the
engine mapping to offer an even sharper
response and engine dynamics that are
more direct.
In vehicles with Porsche Doppelkupplung
(PDK), upshifts take place at higher engine
speeds and downshifts happen sooner.
In addition, coasting mode and the auto
start/stop function are automatically
deactivated. If fitted, the optional sports
exhaust system is also activated
automatically.
Sport Chrono Package.
Adrenaline at the push of a but ton, goose
bumps included: the functions of the
optional Sport Chrono Package enable
an even sportier tuning of the chassis,
engine and transmission – and launch
you to unprecedented sporty heights.
What ’s new is the mode switch on the
steering wheel, derived from the
918 Spyder to make you feel closer to
the racetrack. Without your hand leaving
the steering wheel, you can choose any
of four set tings: Normal, SPORT, SPORT
PLUS and Individual. Now you can adapt
the vehicle even more to the way you
want to drive. On activation of SPORT PLUS mode,
Porsche Active Suspension Management
(PASM) and, in the S models, optional
Porsche Dynamic Chassis Control (PDCC)
and optional rear-axle steering adapt for
enhanced roadholding performance by
switching to a sportier damper set ting
and offering more direct turn-in on
entering the corner.
In combination with PDK, the Sport
Chrono Package has three additional
functions. The first is ‘Launch Control’,
which can be used to achieve the best
possible standing start – a racing start.
The second function is the motorsport-
derived gearshift strategy. In this mode,
Another few seconds faster.
Under the skin.
High-performance systems.
PDK is geared up for extremely short
shift times and optimum shift points for
the maximum acceleration available.
This combination of uncompromising and
involving performance is ideal for the
racetrack.
The third function – SPORT Response –
is brand new to the 911. Pressing the
but ton in the centre of the mode switch
primes the engine and transmission for the
fastest possible unleashing of power. In
other words, maximum responsiveness –
for a period of approximately 20 seconds.
A timer graphic in the instrument cluster
tells you how long is left.

Engage SPORT.
Scan code or go to w w w.porsche.co.uk/spor t- chrono - package and star t the video.

Chassis 65
PASM sports suspension.
The PASM sports suspension is available
as an option for the S models of the
Coupé and only in conjunction with
20-inch wheels. The ride height is 10 mm lower than with
the PASM suspension. The springs are
harder and shorter, and the anti-roll bars
on the front and rear axles are stiffer.
The front spoiler lip has an even sportier
geometry, the rear spoiler extends even
more. Not only does this further reduce lift at the front axle, it also provides
downforce at the rear axle for improved
aerodynamics and even better performance
– combined with a surprisingly high level
of comfort.

Comfort 83
Sports seats.
The Sports seats are comfortable and
provide support even during performance
driving. They are equipped as standard
with electric seat height and backrest
adjustment and mechanical fore/aft
adjustment.
Optional fully electric Sports seats offer
a wider range of powered adjustments,
such as lumbar support and seat squab
angle and depth. A comprehensive
memory function and electric steering
column adjustment are also included.
Sports seats Plus.
Available as an option are Sports seats
Plus in leather with electric seat height
and backrest adjustment as well as
mechanical fore/aft adjustment. The side bolsters on the squab and backrest have
a firmer, sportier padding and offer even
better lateral support.
Adaptive Sports seats Plus in leather are
available on request. Featuring 18-way
electric adjustment of seat positions,
including side bolsters, they also come
with a comprehensive memory function
and electric steering column adjustment.
Sports bucket seats.*
Sports bucket seats featuring a folding
backrest, integral thorax airbag and
manual fore/aft adjustment are available
as optional equipment. The seat shells
are made from glass- and carbon-fibre
reinforced plastic with a carbon surface
finish.
Seat heating and ventilation.
Seat heating is available as an option for
all seats. Seats are heated in the squab,
the backrest and, for the front seats, the
side bolsters. Seat ventilation is also
available on request (excluding Sports
bucket seats) – for a pleasant and dry
seating environment, even in hot weather.
Rear seats.
The rear seats are remarkably
comfortable for a sports car and the
shelf behind offers additional storage
space. With the backrests folded down,
the luggage compartment volume in the
rear of the 911
Carrera models increases
to 260 litres and, with a capacity of
160 litres, the 911
Carrera Cabriolet and
911
Targa models offer plent y of space
for luggage, too.
We’ve been on a journey to new destinations for over 60 years.
So we’ve learnt the value of sitting comfortably.
Comfort.
Child seat preparation.*
ISOFIX child seat preparation including
top tether (Coupé models only) is
available on the rear seats as standard.
On request, we can equip the front
passenger seat with ISOFIX child seat
preparation and integrate an airbag
deactivation feature.
* Child seats are not compatible with the Spor ts bucket seats.
Luggage compartment.
The luggage compartment volume in the
911
models is 145 litres – 125 litres in
t h e 911
all-wheel drive models. The
luggage compartment is fully trimmed in
scratch-resistant materials.
Sit back and relax.
Scan code or go to w w w.porsche.co.uk/comfor t and star t the video.
1 Rear seats
2 Luggage compar tment
3 Seats (Spor ts seat, fully electric Spor ts seat, Spor ts seat Plus, adaptive Spor ts seat Plus, Spor ts bucket seat)

Technical data 147
911 Carrera911 Carrera Cabriolet911 Carrera S911 Carrera S Cabriolet
Weights
M a n u a l / P D K M a n u a l / P D K M a n u a l / P D K M a n u a l / P D K
Unladen weight (DIN) 1,4 3 0 k g / 1,45 0 k g1,500 kg /1,520 kg1,440 kg / 1,460 kg1,510 kg / 1,530 kg
Unladen weight (EC)
1)1,505 kg /1,525 kg 1,575 kg /1,595 kg 1,515 kg / 1,535 kg1,585 kg / 1,605 kg
Permissible gross weight 1,875 kg / 1,890 kg1,925 k g / 1,9 4 0 k g1,900 kg / 1,915 kg1,950 kg / 1,965 kg
PerformanceM a n u a l / P D K M a n u a l / P D K M a n u a l / P D K M a n u a l / P D K
Top speed 183 mph /182 mph 181 m p h / 18 0 m p h 191 m p h / 19 0 m p h190 mph/189 mph
0–62 mph 4.6 secs/ 4.4 secs 4.8 secs/ 4.6 secs 4.3 secs/ 4.1 secs 4.5 secs / 4.3 secs
Spor t Chrono Package
(in conjunction with PDK)
0– 62 mph with Launch Control –
/ 4.2 secs – / 4.4 secs – / 3.9 secs – / 4.1 secs
0 –99 mph 9.8 secs / 9.5 secs10.2 secs/ 9.9 secs 8.9 secs / 8.5 secs 9.3 secs/ 8.9 secs
Spor t Chrono Package
(in conjunction with PDK)
0–99 mph with Launch Control –
/ 9.2 secs – / 9.6 secs – / 8.2 secs – / 8.6 secs
Flexibilit y (49 –74 mph), 5th gear 5.5 secs / – 5.8 secs/ – 4.8 secs/ – 5.1 secs / –
Over taking acceleration (49 –74 mph) – / 2.7 secs – / 2.8 secs – / 2.3 secs – / 2.4 secs
Fuel consumption/emissions2)M a n u a l / P D K M a n u a l / P D K M a n u a l / P D K M a n u a l / P D K
Urban in mpg 24.1/ 28.523.7/28.523.2/28.02 3 . 0 / 2 7. 7
Extra urban in mpg 4 4 . 8 / 4 7. 143.5/45.642. 8/4 4.142. 2 /4 3.5
Combined in mpg 34.0/38.23 3 . 2 / 3 7. 732.5/ 3 6.732.1/ 3 6.2
CO
2 emissions in g / km 19 0/ 16919 5 / 17 219 9/ 174202/178
Dimensions/aerodynamicsM a n u a l / P D K M a n u a l / P D K M a n u a l / P D K M a n u a l / P D K
Length 4,499 mm4,499 mm4,499 mm4,499 mm
Width (including exterior mirrors) 1,808 mm (1,978 mm)1,808 mm (1,978 mm)1,808 mm (1,978 mm)1,808 mm (1,978 mm)
Height 1,294 mm1,289 mm1,296 mm / 1,295 mm 1,291 mm /1,290 mm
Wheelbase 2,450 mm2,450 mm2,450 mm2,450 mm
Luggage compartment volume
(German Car Manufacturers’ Assoc.) 14 5 l i t r e s
14 5 l i t r e s14 5 l i t r e s14 5 l i t r e s
Tank capacity (refill volume) 64 litres (64 litres)64 litres (64 litres)64 litres (64 litres)64 litres (64 litres)
Drag coefficient 0.290.300.300.30

Technical data 149
911 Carrera 4911 Carrera 4 Cabriolet911 Carrera 4S911 Carrera 4S Cabriolet
Weights
M a n u a l / P D K M a n u a l / P D K M a n u a l / P D K M a n u a l / P D K
Unladen weight (DIN) 1,480 kg / 1,500 kg1,550 kg /1,570 kg1,490 kg / 1,510 kg1,560 kg / 1,580 kg
Unladen weight (EC)
1)1,555 kg / 1,575 kg 1,625 k g / 1,6 45 k g1,565 kg / 1,585 kg1,635 kg / 1,655 kg
Permissible gross weight 1,925 kg / 1,940 kg1,975 k g / 1,9 9 0 k g1,950 kg / 1,965 kg2,000 kg / 2,015 kg
PerformanceM a n u a l / P D K M a n u a l / P D K M a n u a l / P D K M a n u a l / P D K
Top speed 181 m p h / 18 0 m p h17 9 m p h / 17 8 m p h189 m p h / 18 8 m p h18 8 m p h / 187 m p h
0–62 mph 4.5 secs / 4.3 secs4.7 secs / 4.5 secs4.2 secs / 4.0 secs4.4 secs / 4.2 secs
Spor t Chrono Package
(in conjunction with PDK)
0–62 mph with Launch Control –
/ 4.1 secs – / 4.3 secs – / 3.8 secs – / 4.0 secs
0 –99 mph 9.7 secs / 9.3 secs10.1 secs / 9.7 secs8.7 secs / 8.3 secs9.1 secs / 8.7 secs
Spor t Chrono Package
(in conjunction with PDK)
0–99 mph with Launch Control –
/ 9.0 secs – / 9.4 secs – / 8.0 secs – / 8.4 secs
Flexibilit y (49 –74 mph), 5th gear 5.6 secs / – 5.9 secs / – 4.9 secs / – 5.2 secs / –
Over taking acceleration (49 –74 mph) – / 2.8 secs – / 2.9 secs – / 2.4 secs – / 2.5 secs
Fuel consumption/emissions2)M a n u a l / P D K M a n u a l / P D K M a n u a l / P D K M a n u a l / P D K
Urban in mpg 23.2/28.022.8/27.422.8/27.422.4/27.2
Extra urban in mpg 42. 2 /4 4. 84 0.9/4 3.541. 5/4 2. 841. 5/4 2. 2
Combined in mpg 32.5/ 3 6.73 1 . 7/ 3 5 . 83 1 . 7/ 3 5 . 831.4/35.3
CO
2 emissions in g / km 2 01 / 17 720 6/ 18220 4/ 18 020 8/ 18 4
Dimensions/aerodynamicsM a n u a l / P D K M a n u a l / P D K M a n u a l / P D K M a n u a l / P D K
Length 4,499 mm4,499 mm4,499 mm4,499 mm
Width (including exterior mirrors) 1,852 mm (1,978 mm)1,852 mm (1,978 mm)1,852 mm (1,978 mm)1,852 mm (1,978 mm)
Height 1,295 mm1,290 mm1.298  m m1,293 mm /1,292 mm
Wheelbase 2,450 mm2,450 mm2,450 mm2,450 mm
Luggage compartment volume
(German Car Manufacturers’ Assoc.) 125 l i t re s
125 l i t re s125 l i t re s125 l i t re s
Tank capacity (refill volume) 68 litres (67 litres)68 litres (67 litres)68 litres (67 litres)68 litres (67 litres)
Drag coefficient 0.290.300.300.30

Technical data 151
911 Ta r g a 4911 Targa 4S
Weights
M a n u a l / P D K M a n u a l / P D K
Unladen weight (DIN) 1,570 kg / 1,590 kg 1,580 kg / 1,600 kg
Unladen weight (EC)
1)1,645 kg / 1,665 kg 1,655 kg / 1,675 kg
Permissible gross weight 2,000 kg / 2,015 kg 2,025 kg / 2,040 kg
PerformanceM a n u a l / P D K M a n u a l / P D K
Top speed 17 9 m p h / 17 8 m p h 18 8 m p h / 187 m p h
0–62 mph 4.7 secs / 4.5 secs 4.4 secs / 4.2 secs
Spor t Chrono Package (in conjunction with PDK)
0–62 mph with Launch Control – / 4.3 secs – / 4.0 secs
0 –99 mph 10.1 secs / 9.7 secs 9.1 secs / 8.7 secs
Spor t Chrono Package (in conjunction with PDK)
0–99 with Launch Control – / 9.4 secs – / 8.4 secs
Flexibilit y (49 –74 mph), 5th gear 5.9 secs / – 5.2 secs / –
Over taking acceleration (49 –74 mph) – / 2.9 secs – / 2.5 secs
Fuel consumption/emissions2)M a n u a l / P D K M a n u a l / P D K
Urban in mpg 22.8/27.4 22.4/27.2
Extra urban in mpg 4 0.9/4.3 5 41. 5/4 2. 2
Combined in mpg 3 1 . 7/ 3 5 . 8 31.4/35.3
CO
2 emissions in g / km 20 6/ 182 208 / 184
Dimensions/aerodynamicsM a n u a l / P D K M a n u a l / P D K
Length 4,499 mm 4,499 mm
Width (including exterior mirrors) 1,852 mm (1,978 mm) 1,852 mm (1,978 mm)
Height 1, 28 8  m m 1,293 mm / 1,291 mm
Wheelbase 2,450 mm 2,450 mm
Luggage compartment volume
(German Car Manufacturers’ Assoc.) 125 l i t re s
125 l i t re s
Tank capacity (refill volume) 68 litres (67 litres) 68 litres (67 litres)
Drag coefficient 0.30 0.30
