Benchmark: the 911 Tur b o
Concept
Design
Engineering
The new 911 Tu r b o
The new 911 Tu r b o S
The new 911 Turbo Cab riolet and
911 Turbo S Cabriolet
Power
Engine
Transmission
Chassis
Lighting
Responsibility
Brakes
Environment
Personality
Comfort
Audio and communication
Personalization
Porsche Driving Experience
Panorama
The sum of our experience
Technical data
Index 4
6
10 14
15
18
21
25
28
35 47
57
60
62 67
72
74
84 89
10 7
10 9 11 1
11 3
115
2014 911 Turbo fnl 10 24.indd 211/6/13 8:19 PM

Benchmark: the 911 Turbo.
When Porsche unveiled the first 911 Turbo 40 years ago, it instantly
became the new benchmark of high performance. Through four decades
of engineering evolution, and through countless victories across the
world of motorsports, the 911
T
urbo has remained our benchmark—for
everything that Porsche builds. With each new 911 Turbo, the starting
point for getting to the very limit of what’s possible is reset. Once again.

56 911 Tu r b o | Concept
Given that the starting point is the
most recent 911 Turbo, how do
you make a new 911 Turbo that
performs at an even higher level?
How do you make its engine produce
more power with less fuel? Its
transmission shift more seamlessly,
its suspension grip the road with
more traction, and its brakes shed
speed with even more force and less
fade? Its exterior more aerodynamic
and its interior more functional and
comfortable? How do you make its
safety engineering more advanced? How do you, in other words, evolve
the legendary 911 Turbo and
enhance its capabilities—without
diluting its essential character?
It ’s a daunting challenge, yet
one Porsche engineers confront
with clear-eyed goals and race-
proven technical innovations.
There are measurable objectives:
improved g-force, horsepower, and
torque outputs, shorter braking
distances, and quicker zero-to-sixty
times. And there are more subjective considerations: the sound of the engine,
the support of the seats, the feeling of
confidence and control that results from
a total synergy bet ween car and driver.
It ’s a process that requires, above all,
patience. A new technology may take
time to translate its advantages to meet
the aims of a Porsche. A promising
idea may prove less so when subjected
to our test circuit at Weissach or to
the extreme demands of endurance
races like the 24 Hours of Le Mans
or the Twelve Hours of Sebring.
But the reward for following a highly
disciplined process is unquestionable.
With each successive 911 Turbo,
Porsche engineers have demonstrated
that ever-higher levels of performance
remain to be discovered.
And the new 911 Turbo is no exception.
With 90 percent of its components
redeveloped, it once again provides a
new reference for Porsche excellence.
At Porsche, we prefer to lead by example.
T h e 9 11
T

u r b o .
