Foldingindoormirrors
Warning!
Dangerofinjurytongersifthemirroraccidentallyipsbackwhenbeingfoldedin.
Exerciseextremecautionwhenfoldinginmirrorbyhand.Donotletgoofthemirrorbeforethelockingleverislockedorthemirrorisfullyunfolded.
1.Pushmirrortowardsthedoorwindowandcontinuetoholdit(highspringforce).
2.Swivelthelockingleveruptothestopandslowlyletgoofthemirror.
Unfoldingdoormirrors
1.Pushmirrortowardsthedoorwindowandcontinuetoholdit(highspringforce).Thelockingleverdisengagesautomatically.
2.Movemirrorbacktounfoldedpositionbyhand.Donotletgoofthemirrorbeforehand.
A-SensorB-Switchforautomaticanti-glareoperationC-Light-emittingdiode
Automaticanti-glareinteriormirrorand
doormirrors
Function
Sensorsonthefrontandrearsidesoftheinteriormirrormeasuretheincidentlight.Themirrorsautomaticallychangetoanti-glarepositionorreverttotheirnormalstate,dependingonthelightintensity.Whenreversegearisselected,automaticanti-glareoperationisswitchedoff.
Controls,Instruments37

Note
Theincidentlightintheareaofthesensorsmustnotberestricted,e.g.bystickersonthewindshield.
Switchingofftheautomaticanti-glare
operation
PressswitchB.Light-emittingdiodeCgoesout.
Switchingontheautomaticanti-glare
operation
PressswitchB.Light-emittingdiodeClightsup.
Warning!
Riskofinjury.Electrolyteuidcanemergefromabrokenmirrorglass.Thisuidirritatestheskinandeyes.
Iftheelectrolytefluidshouldcomeintocontactwiththeeyesorskin,immediatelyrinseitoffwithcleanwater.Seeadoctorifnecessary.
Warning!
Riskofdamagetothepaintwork,leatherandplasticparts.Electrolyteuidcanberemovedonlywhileitisstillwet.
Cleantheaffectedpartswithwater.
Heatedrearwindow/Doormirror
heating
Theheatedrearwindow/doormirrorheaterisreadyforoperationwhentheignitionison.
Switchingon
Pressbutton.Thelight-emittingdiodeinthebuttonlightsup.
Afterapprox.15minutes,theheaterswitchesoffautomatically.Theheatercanbeswitchedbackonbypressingthebuttonagain.
38Controls,Instruments

ABSBrakeSystem
(AntilockBrakeSystem)
TheABSsystemrepresentsamajorcontributiontotheenhancementofactivesafetyinyourvehicle.Thissystempreventsthewheelsfromlockinginapanicstoponalmostallroadsurfaces.
WiththeABSsysteminyourvehicle,the
followingareasareenhanced:
Steering,vehicleremainssteerableunderallbrakingforceswhenABSisengaged.
Gooddirectionalcontrol,noswervingcausedbylockingofwheelsunderbrakingconditions.
Shorterstoppingdistance,stoppingdistancesareusuallyreducedbecausecontrolledbrakingismaximized.
Preventionofwheellockup,nobrake-inducedslidingandthusnolocalizedtirewearfromemergencybraking.
ThecrucialadvantageoftheABSsystemoveraconventionalbrakesystemisintheareaofmaintainingdirectionalcontrolandmaneuverabilityofthecarinemergencysituations.
Warning!
Theincreasedcontrolthatisprovidedshouldnotinduceyoutotakegreaterriskswithyoursafety.Thelimitsdictatedbythelawsofphysicscannotbeovercome,evenwithABS.Theriskofaccidentsduetoinappropriatespeedcannotbereduced,evenbytheABS.Thedriverbearstheresponsibilityforalldrivingmaneuvers.
Adaptyourdrivingstyletotheprevailingroadandweatherconditions.
Obeyalltrafficlaws.
Warning!
OthervehiclesnotequippedwiththeABSsystemmaynotbeabletomaintaincontrol,especiallyonwetorpoorroadsurfacesandthusmaybemorelikelytoimpactyoufrombehind.
Tominimizethatrisk,useyourABSsystemtoincreaseyourabilitytomaneuvertoavoiddangeroussituationsandnotmerelytotrytostopintheshortestdistancepossible.
OperationoftheABSsystem
Awheelspeedsensorismountedtoeachofthefourwheels.Ifwheellock-upofeitherofthefrontwheelsortherearwheelsissensedduringbraking,thebrakepressureisadjustedautomaticallyuntilthewheelnolongerslips.
Ifbrakingforcesapproachthewheellock-uppointforallwheels(panicbraking)theABSsystemwillintervenetoprovidearapidrythmicbraking.TheproperoperationofABSisperceivedbythedriverasapulsatingbrakepedalinconjunctionwithaudiblenoiseandperhapssomevibration.
Ifyouexperiencethesesensationswhiledrivingoraroadsurfacewithquestionabletraction,reducevehiclespeedappropriatefortheprevailingroadconditions.
Iffullbrakingshouldbenecessary,pressthebrakepedalallthewaydownthroughouttheentirebrakingprocedure,regardlessofthepulsatingpedal.Donoteaseuponpressureappliedtothepedal.
ThefunctionalreadinessofallthemainelectricalcomponentsoftheABSischeckedbyanelectronicmonitoringsystembothbeforeandwhileyoudrive.
WarninglightUSA
WarninglightCanada
WhentheignitionisswitchedontheABSwarninglightwilllightupwhilethesystemiselectronically
Controls,Instruments67

interrogatedandgoesoutwhentheengineisstartedifthecheckisnotyetcomplete.IftheABSwarninglampfailstogoout,thisindicatesthatABShasbeendeactivatedduetoafault.Ifthewarninglightsintheinstrumentpanelandon-boardcomputerlightupwhileyouaredriving,thisindicatesthatafaulthasoccurred.Inbothcases,normalbraking,asinvehicleswithoutABS,isstillretained.
TheABSsystemshould,however,beexaminedatanauthorizedPorschedealerimmediatelytopreventtheoccurrenceoffurtherfaults.
IftheABSsystembecomesinoperative,takeyourvehicletoyourauthorizedPorschedealerimmediately.
Warning!
Riskofanaccident,resultinginseriouspersonalinjuryordeath.ThecontrolunitoftheABSbrakesystemissetforstandardtiresize.Ifnon-standardtiresareinstalled,thecontrolunitmaymisinterpretthespeedofthevehicle,becauseofthevariantdataitreceivesfromthesensorsontheaxles.
UseonlytiremakesandtypestestedbyPorsche.
68Controls,Instruments

PorscheStabilityManagement
(PSM)
GeneralinformationregardingPSM
PSMisanactivecontrolsystemforstabilizationofthevehicleduringextremedrivingmaneuvers.
Warning!
Riskofanaccident,resultinginseriouspersonalinjuryordeath.Theincreasedcontrolthatisprovidedshouldnotinduceyoutotakegreaterriskswithyoursafety.Thelimitsdictatedbythelawsofphysicscannotbeovercome,evenwithPSM.Theriskofaccidentsduetoinappropriatespeedcannotbereduced,evenbyPSM.Thedriverbearstheresponsibilityforalldrivingmaneuvers.
Adaptyourdrivingstyletotheprevailingroadandweatherconditions.
Obeyalltrafficlaws.
AdvantagesofPSM
–Superiortractionandlane-holdingabilityinalldrivingsituations-evenonroadsurfaceswithvaryingfriction.
–Thesystemcompensatesforundesiredvehi-clereactions(Ferrariaeffect)whenthedriverreleasestheacceleratorpedalorbrakeson
bends.Thiscompensationfunctionsuptothemaximumlateralacceleration.
–PSMactivelystabilizesthevehicleduringdynamicdrivingmaneuvers(e.g.rapidsteeringmovements,duringlanechangesoronalternatingcurves).
–Improvedbrakingstabilityincurvesandondifferentorvaryingroadsurfaces.
Readinessforoperation
PSMisswitchedonautomaticallyeverytimeyoustarttheengine.
Function
Sensorsatthewheels,brakes,steeringsystemandenginecontinuouslymeasure:
–Speed
–Directionoftravel(steeringangle)
–Lateralacceleration
–Rateofturnabouttheverticalaxis
PSMusesthesevaluestodeterminethedirectionoftraveldesiredbythedriver.PSMintervenesandcorrectsthecourseiftheactualdirectionofmotiondeviatesfromthedesiredcourse(steering-wheelposition):Itbrakesindividualwheelsasneeded.Inaddition,theenginepowermaybemanipulatedinordertostabilizethevehicle.
TheeventsbelowinformthedriverofPSMcontroloperationsandwarnhimtoadapther/hisdrivingstyletotheroadconditions:
–Themulti-functionalinformationlightontheinstrumentpanelflashes.
–Hydraulicnoisescanbeheard.
–Thevehicledeceleratesandsteering-wheelforcesarealteredasthePSMcontrolsthebrakes.
–Reducedenginepower.
–Thebrakepedalpulsatesanditspositionischangedduringbraking.Inordertoachievefullvehicledeceleration,footpressuremustbeincreasedafterbeginningofthebrakepedalpulsing.
ExamplesofPSMcontroloperations
–Ifthefrontwheelsofthevehicledriftonabend,therearwheelontheinsideofthebendisbrakedandtheenginepowerisreducedifnecessary.
–Iftherearofthevehicleswingsoutonabend,thefrontwheelontheoutsideofthebendisbraked.
Controls,Instruments71

ParkingAids
ParkingAssistant(ParkAssistant)
Functionoftheparkingassistant
Whenthedriverbacksup,theparkingassistantsystemindicatesthedistancebetweenthecarandalargeobstaclebehindit,bymeansofsignaltones.
Danger!
Riskofseriouspersonalinjuryordeath.ParkAssistantcannotdetectsmallobjectssuchaschildrenandpets.Despiteuseoftheparkingassistantsystem,thedriverisstillresponsiblefortakingduecareandassessingobstacleswhenbackingup.
Makesurethatnopersons,especiallysmallchildren,animalsorobstaclesarewithinthemaneuvringarea.
Theparkingassistantsystemisactivatedautomati-callywhenreversegearisselectedandtheignitionison.
Note
Beawarethattheparkingassistantsystemisnotswitchedonifthecarrollsbackwardwithoutreversegearbeingengaged.
Ultrasoundsensors
Sensors
Fourultrasoundsensorsintherearbumpermeasurethedistancetotheclosestobstacle.
–Rangemiddlesensorsaround60in./150cm
–Rangeoutersensorsaround24in./60cm
Obstaclescannotbedetectedinthe“blind”sensorarea(e.g.neartheground).
Note
Thesensorsmustalwaysbekeptfreeofdust,iceandsnowinordertoensurethattheyarefullyfunctional.
Caution!
Toavoiddamagingthesensors:
Maintainsufficientdistancewhencleaningwithsteam-jetunits.
Signaltones/function
Whenreversegearisselected,theparkingassistantconfirmsthatitisswitchedonbyissuingashortsignaltone.Adetectedobstacleissignalledbyanintermittenttone.Theintervalsdecreaseastheobstacleisapproached.Acontinuoustonesoundswhenthedistancebecomeslessthanonefoot.Thiscontinuoustonecanstopiftheobstacleisapproachedcloserthanonefoot.Theradiovolumeshouldnotbesoloudastodrownoutthesignaltones.
Limitsofultrasonicmeasurement
Theparkingassistantsystemcannotdetect:
–sound-absorbingobstacles(e.g.winteroperation,powdersnow),
–sound-reflectingobstacles(e.g.glasssurfaces,flatpaintedsurfaces)
–andverythinobstacles.
Otherultrasoundsources(e.g.pneumaticbrakesofothervehicles,jackhammers)caninterferewithdetectionofobstacles.
Controls,Instruments77

Faultindication
Theparkingassistantsystemindicatesafaultintwoways:
–Afterreversegearhasbeenselected,theshortsignaltoneisfollowedbyacontinuoustoneofthesamepitch:Thisindicatesthatsensorsaresoiledorcoveredwithice.
–Afterreversegearhasbeenselected,theshortsignaltoneisfollowedbyacontinuoustonewithamuchlowerpitch:Thisindicatesageneralsystemfault.PleasehavethefaultremediedatanauthorizedPorschedealer.
A-Controlswitchfordoormirroradjustment
Swivellingdownmirrorglassonthe
passenger’sside
Function
Onvehicleswithseatmemoryyoucanactivateanadditionalparkingaid.
Pleaseobservethechapter”SEATMEMORY”onpage43.
–Whenreversegearisengaged,themirrorglassonthepassenger’ssideswivelsdownslightlytoshowthecurbarea.
Preconditions
–Vehiclemustbeequippedwithseatmemory.
–SetthecontrolswitchAto“passenger’sside”.
–Reversegearmustbeengaged.
Returningmirrorglasstoitsoriginalposition
Driveforwardswithaspeedofover4mph(6km/h)or
–SetthecontrolswitchAto“driver’sside”.
78Controls,Instruments

Operation,Instruments
Overviewofthefunctions
1.Lightswitch
2.Turnsignals/headlightdimmer/flasherlever
3.IgnitionLock/lockingthesteeringcolumn
4.Hands-freemicrophonefortelephone
5.Horn
6.Windshieldwiper/washerlever
7.PorscheCommunicationManagement/Radio
8.Interiortemperaturesensor,GPSantenna
9.Emergencyflasherswitch
10.Centrallockingbutton,Readinessdisplayforalarmsystem
11.Cupholder
12.Operatingleverforon-boardcomputer
13.Lockingleverforsteering-wheeladjustment
14.Operatingleverforcruisecontrol
15.Controlpanelforheating,ventilationandairconditioningsystem
16.Buttonsforrearspoiler,PorscheActiveSuspensionManagement(PASM),SportMode,PorscheStabilityManagement(PSM),Sportsexhaustsystem
17.Seatheating,left/right
Controls,Instruments79

StartingandStoppingEngine
StartingProcedures
Pleaseobservethechapter”IMMOBILIZER”onpage22.
Pleaseobservethechapter”EMISSIONCONTROLSYSTEM”onpage225.
Warning!
Seriouspersonalinjuryordeathmayresultifyouareinvolvedinacollisionwithouthavingfastenedthesafetybelts.
Fastensafetybeltsbeforedrivingaway.
Beforestartingtheengine
Applythefootbrake.
Manualtransmission:Movethegearshiftleverintoneutral.Theclutchpedalmustbedepressedfullybeforethestarterwillengage.
Tiptronic:MovetheselectorlevertoPorN.
Temperaturesensorsontheengineautomaticallyprovidethecorrectfuel/airmixturerequiredforstarting.Therefore,itisnotnecessarytodepresstheacceleratorpedalwhilestartingacoldorawarmengine.
Startingtheengine
Turnignitionkeytoignitionlockposition2.
Assoonastheenginestarts,releasetheignitionkey.
Thefirstoperationofthestarterisendedautomat-icallywhentheenginestarts.Iftheenginedoesnotstart,subsequentstarteroperationswillnotbeendedautomatically.
Iftheenginefailstostartafter10or15secondsofcranking:
Waitabout10secondsbeforeengagingthestarteragain.
Whenstartingtheengine,bereadytodriveimmediately.Drivevehicleatmoderatespeedsandavoidenginespeedsabove4200rpmduringthefirst5minutes.
Donotlettheengineidletowarmup.
Danger!
Engineexhaustfumeshavemanycompo-nentswhichyoucansmell.Theyalsocontaincarbonmonoxide(CO),whichisacolorlessandodorlessgas.Carbonmonoxidecancauseunconsciousnessandevendeathifinhaled.
Neverstartorlettheengineruninanenclosed,unventilatedarea.Itisnotrec-ommendedtositinyourcarforprolongedperiodswiththeengineonandthecarnotmoving.
Danger!
Anunattendedvehiclewitharunningengineispotentiallyhazardous.Ifwarninglightsshouldcomeontoindicateimproperopera-tion,theywouldgounnoticed.
Neverleavetheengineidlingunattended.
Danger!
Dangerofre.
Donotparkoroperatethevehicleinareaswherethehotexhaustsystemmaycomeincontactwithdrygrass,brush,fuelspillorotherflammablematerial.
Controls,Instruments83

InstrumentPanelUSAModels
Overview
AlsorefertothecorrespondingchapterintheOwner’sManual.
1.Speedometerwithanaloguedisplay
2.Tirepressurewarninglight
3.Turnsignalindicatorlightleft/right
4.Tachometer
5.Highbeamindicatorlight
6.ABSwarninglight
7.CoolingsystemTemperaturegauge,warninglight
8.FuelLevelgauge,warninglight
9.Adjustingbuttonforinstrumentilluminationandtripcounter
10.Odometeranddailytripmileagedisplay
11.Automaticspeedcontrolindicatorlight
12.Lightsensorforinstrumentillumination
13.Airbagwarninglight
14.Emissioncontrolwarninglight(CheckEngine)
15.Centralwarninglight
16.On-boardcomputerdisplay
17.PorscheStabilityManagementMultifunctionalPSMlight
18.Brakewarninglight
19.Safetybeltwarninglight
20.Tiptronicindicator
21.Clockandoutsidetemperaturedisplay
22.Adjustmentbuttonforclock
Whentheignitionisswitchedon,thewarninglightslightupforalampcheck.
Note
WarningsthathavebeengivenarestoredintheappropriatecontrolunitmemoryandcanbereadoutatanauthorizedPorschedealer.
Thisinformationcanhelptowarnyouaboutsituationswhichmaybehazardoustoyouoryourcar.
Controls,Instruments85
