Controls, Instruments
119
System fault
Go to workshopSeveral systems may have failed. Adjust your
driving style. Reduce speed.
Have the fault remedied at an authorized
Porsche dealer.
Failure of fuel level indicator
WorkshopHave the fault remedied at an authorized
Porsche dealer.
Service in km/days Service indicator
Bring the vehicle in for service no later than af-
ter the distance/time shown has elapsed.
However, it is the intervals in the “Guarantee
and Maintenance” booklet that are decisive.
Service now Service indicator
Have your vehicle serviced at an authorized
Porsche dealer.
Flat Tire Tire pressure monitoring system has detected a
serious pressure loss.
Stop in a suitable place and check tires for dam-
age. Fill in tire sealant if necessary.
Add air The tire pressure monitoring system has detect-
ed a gradual pressure loss. Correct tire pres-
sure at the next opportunity.
TPC inactive
System learningThe tire pressure monitoring system is learning
the wheels on the vehicle. The tire pressure
monitoring system is searching for the tires and
their position. During this period the current
pressure specifications are not available on the
on-board computer.
TPC inactive The tire pressure monitoring system is faulty.
Consult your authorized Porsche dealer.*
Instrument
panelOn-board
computerText display on on-board
computerMeaning/measure

Practical Tips, Emergency Service
213
Tire traction
Warning!
When driving on wet or slushy roads, a
wedge of water may build up between the
tires and the road. This phenomenon is
known as “hydroplane” and may cause par-
tial or complete loss of traction, vehicle
control or stopping ability.
fReduce speed on wet surface to prevent this. Tire life Tire life depends on various factors, i. e., road
surfaces, traffic and weather conditions, driving
habits, type of tires and tire care.
fInspect your tires for wear and damage before
driving off. If you notice uneven or substantial
wear, wheels might need alignment or tires
should be balanced or replaced.
Tire wear The original equipment tires on your Porsche have
built-in tire wear indicators. They are molded into
the bottom of the tread grooves and will appear as
approximately 1/2 in. (12 mm) bands when the
tire tread depth is down to 1/16 of an in.
(1.6 mm).
When the indicators appear in two or more adja-
cent grooves, it is time to replace the tires. We
recommend, however, that you do not let the tires
wear down to this extent.
Worn tires cannot grip the road surface properly
and are even less effective on wet roads.
In the United States, state laws may govern the
minimum tread depth permissible. Follow all such
laws.
Danger!
Driving on worn tires can result in loss of con-
trol of the vehicle and could cause serious
personal injuries or death.
fDo not drive with worn tires or tires showing
cuts or bruises as they may lead to sudden
deflation and loss of control which could cause
severe personal injury.
fSpecialized high performance tires on high
performance sports cars exhibit more wear
than those on a family sedan, or even a high
performance sedan.
Therefore, it is important to check your tire
pressure and condition at least every two weeks.
If you notice that tires are wearing unevenly, con-
sult your Porsche dealer.
Uneven wear may not always be due to improper
wheel alignment. It can be the result of individual
driving habits such as cornering at high speeds. If
the tire pressure is not checked and adjusted
regularly, abnormal tire wear can also occur.

Practical Tips, Emergency Service
253
Side marker lightChanging bulb
1. Remove cap in the wheel housing liner with the
screwdriver.
2. Insert the screwdriver into the opening in the
wheel housing liner at right angles to the
direction indicator housing.
By pressing with the screwdriver, disengage
the securing spring B of the direction indicator
housing. 3. Remove indicator light and undo bulb holder
(bayonet lock).
4. Remove the bulb from the holder and replace
it. Insert holder.
5. Insert the direction indicator’s retaining lugs A
into the side section at the front.
Push in direction indicator until the securing
spring B is felt to engage.
6. Press cap into the wheel housing liner.
Check operation of the light.

Index
277
Warning light ........................................ 86
Cooling system .....................................86
, 176
Cruise control ............................................... 82
Cupholder .................................................. 143
DDashboard ................................................... 72
Data bank .................................................. 264
Defrosting windows .............................130
, 133
Diagnostic socket .................................15, 233
Diagrams ................................................... 274
Dimensions ................................................ 273
Dipped beam .............................................. 246
Door ............................................................ 23
Handles................................................ 23
Locks...........................................23, 197
Mirror heating ....................................... 31
Windows ............................... 23
, 26, 199
Doors
Guard lights ........................................ 257
Driving hints ................................................. 12
Driving in winter .......................................... 170
Driving performance ................................... 270
Drop-center rim .......................................... 220
DVD Navigation........................................... 149
EElectrical system ........................................ 232
Emergency flasher ...................................... 137
Emergency operation
Central locking................................19
, 20
Lids ................................................... 234
Tank cap ............................................ 187Emergency program, Tiptronic .....................170
Emergency service......................................206
Emergency starting with jump leads .............242
Emergenzy operation....................................20
Emission control system ........... 7
, 90, 190
, 191
Engine
Checking the oil level ...........................110
Compartment............................. 172, 206
Compartment blower ...................... 77, 86
Exhaust ..................................................8
Number ..............................................265
Oil consumption ....................................14
Oil level indicator.................................110
Oils ....................................................271
Speeds ................................................14
Starting ................................................74
Switching off.........................................74
Environment ...................................................6
FFire extinguisher .........................................145
Flat tire ......................................................224
Floor mats ..................................................202
Fog lights .......................................... 122
, 256
Footwell light ..............................................257
Front lid......................................................147
Trunk entrapment................................146
Front luggage compartment.........................149
Fuel ................................................ 4
, 88, 186
Containers ..............................................8
Economy ............................................184
Evaporation ........................................191
Level gauge ..........................................88
Level warning light................................88Portable Containers ............................ 189
Recommendation ....................... 188
, 189
Tank.......................................... 186, 187
Function keys ............................................... 38
Fuses ........................................................ 233
GGarage door opener................................... 159
Garage lift ................................................. 223
Gearchanging ............................................ 163
Glove compartment .................................... 142
Gong .............................. 75
, 76, 94, 120
, 122
Ground clearance ........................................... 8
HHandbrake ................................................... 55
Hands-free microphone................................. 72
Headlights ......................................... 124
, 246
Adjusting ................................... 258, 259
Cleaning system ................. 125
, 192
, 271
Heated rear window...................................... 31
Heating ............................................. 130, 133
High beam
Indicator light ....................................... 85
Lever......................................... 122, 124
Home mode............................................... 123
HomeLink .................................................. 159
Hoods ....................................... 146
, 148
, 150
Horn ..................................................... 15, 19
IIdentifikation number.................................. 264

Index
279
Rear fog light .....................................122
, 256
Rear lid ...................................................... 150
Rear view mirrors ......................................... 29
Rear window defogger.................................. 31
Rear wiper ................................................. 127
Replacing ........................................... 175
Relays ........................................................ 232
Release button ........................................... 165
Remote control ............................................. 18
Replacement key .......................................... 17
Replacing bulbs .......................................... 245
Replacing wiper blades................................ 173
Retractable rear spoiler ................................. 66
Rims
Diameter ............................................ 220
Rim width ........................................... 220
Roof load ................................................... 162
Roof Transport System........................162, 272
Running in .................................................... 14
SSafety belts ..........................................40
, 202
Warning light ........................................ 41
Safety compliance sticker ........................... 264
Sealing set ................................................. 225
Seals, care of ............................................. 200
Seat ............................................................ 32
Adjustment ........................................... 32
Heating ................................................ 36
Memory ............................................... 34
Selector lever ............................................. 165
Selector lever position indicator .............87, 167
Service flap ................................................ 151
Shifting gear............................................... 164Shiftlock .....................................................165
Side lights ..................................................256
Side marker light ............................... 122
, 253
Side storage compartments ........................144
Side vents ..................................................136
Snow chains .............................. 218
, 268
, 269
Snow tires ......................................... 217, 268
Sockets .....................................................140
Spacers .....................................................230
Spare key .....................................................17
Spare wheel ...............................................269
Speed code letter .......................................219
Speed control .............................. 82
, 129
, 130
Speed limit .......................................... 94, 219
Speedometer................................................84
Spoiler .........................................................66
Sport mode ..................................... 61
, 64, 65
Sports seat ..................................................32
Stability management system (PSM) ...............62
Starting ................................................. 74, 75
Starting and stopping the engine ....................74
Steering wheel
Adjustment ...........................................37
Buttons ................................................38
Lock ................................. 74
, 75, 76, 77
Rocker switches..................................165
Toggle switches ..................................165
Stopwatch ....................................................98
Storage options ..........................................141
Storing your Porsche..................................203
Sun visors ....................................................39
TTachometer ..................................................85Tail light ..................................................... 255
Tank .................................................. 186
, 187
Cap ................................................... 187
Ventilation system.............................. 191
Telephone .................................................. 157
Temperature setting........................... 130, 133
Temperature, outside indicator ...................... 89
Test stand, measurements ............................ 64
Theft protection ........................................... 16
Tie-down rings ........................................... 151
Tiptronic .................................................... 165
Indicator .............................................. 87
Tire filling compressor ................................ 149
Tire pressure monitoring ............................. 103
Tires ........................................... 14
, 207
, 268
Checking pressure............................. 227
Inscription .......................................... 219
Loading information ............................ 221
Pressure................................ 5
, 210
, 269
Pressure plate.................................... 265
Sealant .............................................. 225
Sidewall ............................................. 219
Size .................................................. 219
Tires and tire care ...................................... 207
Tools ......................................................... 149
Towing .............................................. 260, 261
TPC Tire pressure monitoring ...................... 103
Track ........................................................ 268
Transmission ............................. 163
, 164
, 267
Fluid .......................................... 194, 271
Trunk entrapment ....................................... 146
Turn signals ......................................... 85, 124
