Switchingoff
Pressbutton.Thelight-emittingdiodeinthebuttongoesout.
Controls,Instruments39

SeatAdjustment
Generalinformation
Warning!
Theseatmaymoveunexpectedlyifyouattempttoadjustwhiledriving.Thiscouldcausesuddenlossofcontrol,resultinginseriouspersonalinjuryordeath.
Donotadjustseatswhilethevehicleisinmotion.Thebackrestlocksmustbeengagedatalltimeswhilethevehicleisinmotion.
Warning!
Safetybeltsonlyofferprotectionwhenthebackrestisuprightandthebeltsareproperlypositionedonthebody.Improperlypositionedsafetybeltsorsafetybeltswornbypassengersinanexcessivelyreclinedpositioncancauseseriouspersonalinjuryordeathinanaccident.
Donotoperatethecarwiththedriverorpassengerbackrestsexcessivelyreclined(see“Seatposition”).
Seatposition
Anergonomicallycorrectsittingpositionisimportantforsafeandfatigue-freedriving.Werecommendthefollowingprocedureforadjustingthedriver’sseattosuitindividualrequirements:
1.Vehicleswithmanualtransmission:Adjusttheseatuntil,withtheclutchpedalfullydepressed,yourlegremainsataslightangle.VehicleswithTiptronicS:Adjusttheseatuntil,withyourleftfootonthefootrest,yourleftlegremainsataslightangle.
2.Restyouroutstretchedarmonthesteeringwheel.Setthebackrestangleandthesteer-ing-wheelpositionsothatyourwristrestsontheouterrimofthesteeringwheel.Atthesametime,theshouldersmuststillbeinnoticeablecontactwiththebackrest.
3.Adjusttheseatheighttogiveyourselfenoughheadroomandagoodoverviewofthevehicle.
4.Electricallyadjustableseat:Adjusttheseatangleuntilyourthighsrestlightlyontheseatcushion.
Manuallyadjustablecomfortseat/sports
seat
A-Seatheight
UseleverAinapumpingmovement:
Upwards-seatmovesupwardsDownwards-seatmovesdownwards
B-Foreandaft
RaiselockingleverB.Moveseattodesiredpositionandreleaselever.Ensurethattheseatengagescorrectly.
40Controls,Instruments

C-Backrestangle
OperateswitchCuntilthedesiredbackrestangleisreached.
Electricallyadjustablecomfort
seat/sportsseat
Adjustment
Presstheswitchinthedirectionindicatedbythearrowuntilthedesiredsettingisreached.
A-Seatheightadjustment
B-Fore-and-aftpositionadjustment
C-Seatangleadjustment
D-Backrestangleadjustment
E-Lumbarsupport(pelvisandspinalcolumn
support)
Topermitarelaxedsittingposture,thebackrestcurvatureiscontinuouslyadjustableinverticalandhorizontaldirectionsforindividualpelvisandspinalcolumnsupport.
Presstheswitchinthedirectionindicatedbythearrowuntilthedesiredbackrestcurvatureisreached.
F-Adjustingthebackrestsidebolsters
(electricallyadjustablesportsseatonly)
PushforwardorpullbackwardswitchFuntilthesidebolstersareadjustedtotheshapeofthebody.
G-Adjustingtheseatcushionsidebolsters
(electricallyadjustablesportsseatonly)
PushforwardorpullbackwardswitchGuntilthesidebolstersareadjustedtotheshapeofthebody.
Controls,Instruments41

Seatbackrest
Foldingforward
PullupleverHinthesidepartofthebackrestandfoldthebackrestforward.
Foldingback
Tiltbackandengagethebackrestsothatitcannottipforwardwhenthecarisbraked.
42Controls,Instruments

M-Memorybutton1-Keybutton2,3-Personbuttons
SeatMemory
Individualseatanddoormirrorsettings
Individualseatanddoormirrorsettingscanbestoredandrecalledforthedriver’sposition.
FurtherindividualsettingoptionsareavailableinvehicleswiththeSportChronoPackagePlus.
Pleaseobservethechapter“IndividualMemory”intheseparatePCMoperatinginstructions.
Warning!
Riskofcrushingduetouncontrolledrecallofaseatsetting.
Cancelautomaticadjustmentbypressinganyoftheseatadjustmentbuttons.
Donotleavechildreninthevehicleunattended.
Operationwithpersonbuttons2,3
Storingseatposition
1.Switchonignition.Reversegearmustnotbeengaged.
2.Setthedesiredseatanddoor-mirrorpositions.
3.KeepmemorybuttonMdepressedandadditionallypresspersonbutton2or3.Theindividualsettingisnowstoredunderthedesiredpersonbutton.
Recallingseatposition
Theseatpositioncanonlybecalledupwhenthevehicleisstationary.
1.Switchontheignitionoropenthedriver’sdoor.
2.Presspersonbuttonuntiltheseathasreacheditsfinalposition.Thedoormirrorandthelumbarsupportsettingwillbecompletedevenifthepersonbuttonisnotkeptdepressed.
Note
Automaticseatadjustmentcanbeinterruptedimmediatelybyreleasingthebutton.
Controls,Instruments43

Operatingwiththeremotecontrolofthe
vehiclekey
Individualassignmentoftheremotecontrol
Eachremotecontrol(uptosix)canbeassignedanindividualseatanddoormirrorposition.Thestoredseatanddoormirrorpositionissetautomaticallywhenthevehicleisunlockedusingthecorrespondingremotecontrol.
Storingseatposition
1.Switchtheignitiononwiththedesiredvehiclekey.Reversegearmustnotbeengaged.
2.Setthedesiredseatanddoor-mirrorpositions.
3.KeepmemorybuttonMdepressedandadditionallypresskeybutton1.Theindividualsettingisnowassignedtothisremotecontrolandtothekeybutton.
Storingindividualloweredpositionofthe
passenger’sdoormirrorasaparkingaid
Oncethedriver’sseatsettinghasbeenstored,anindividualloweredpositionofthepassenger’sdoormirrormaybestoredfordrivinginreverse:
1.Applythehandbrake.
2.Switchtheignitiononwiththedesiredvehiclekey.
3.Engagereversegear.
4.Selectpassengersidewithmirrorswitch.Thepassenger’smirrorswivelsdownwards.
5.Setpassenger’sdoormirrortodesiredfinalposition.
6.KeepmemorybuttonMdepressedandadditionallypresskeybutton1.Theindividualsettingisnowassignedtothisremotecontrolandtothekeybutton.
Recallingseatposition
Unlockthelockedvehicleortheluggagecompartmentwiththeremotecontrol.Thestoredseatpositionisautomaticallyset.
Theseatpositionassignedtoaremotecontrolcanalsoberecalledwiththekeybutton1ifthecorrespondingkeywasusedtoswitchontheignition.
Ifnoseatpositionhasbeenassignedtoaremotecontrol,thekeybuttonwillnotwork.
Noteonoperation
Automaticseatadjustmentcanbeinterruptedimmediately:
byswitchingontheignition,
bypressingthecentrallockingbutton,
bypressinganymemoryorseatadjustmentbutton.
Clearingthestoredseatposition
1.Switchtheignitiononwiththedesiredvehiclekey.
Pressmemorybuttontwiceandkeybutton1onceconsecutively.
44Controls,Instruments

A-Seatheating,leftB-Seatheating,right
HeatedSeats
Switchingon
Readinessforoperation
Two-stageseatheatingisreadyforoperationwhentheignitionison.
Highheatingpower
Pressbutton.Bothlight-emittingdiodesinthebuttonlightup.
Lowheatingpower
Presstherocker-switchsymbolagain.Onelight-emittingdiodeinthebuttonlightsup.
Switchingoff
Pressbutton.Light-emittingdiodesgoout.
Controls,Instruments45

SteeringWheelAdjustment
Adjustingsteeringwheelheightand
longitudinaldirection
Warning!
Riskofaccident.Thesteeringwheelmaymovefurtherthandesiredifyouattempttoadjustitwhendriving.Youcanlosecontrolofthevehicle,causingseriouspersonalinjuryordeath.
Donotadjustthesteeringwheelwhendriving.
1.Inserttheignitionkeyfullyintoignitionlock.
2.Pushthelockingleverdownwards.
3.Adjuststeeringwheeltofitthechosenbackrestangleandyourseatpositionbymovingthesteeringwheelupordownandlongitudinally.
4.Swivellockingleverbackuntilyoufeelitengage.Ifnecessary,movethesteeringwheelslightlyupordownandlongitudinally.
46Controls,Instruments

Multi-functionalsteeringwheel
Function
Warning!
Thereisadangerofaccidentifyousetoroperatetheon-boardcomputer,radio,navigationsystem,telephoneorotherequipmentwhendriving.Thiscoulddistractyoufromthetrafcandcauseyoutolosecontrolofthevehicle.Iflossofvehiclecontrolissevereenough,seriouspersonalinjuryordeathcouldresult.
Operatethesecomponentswhiledrivingonlyifthetrafficsituationallowsyoutodososafely.
Carryoutanycomplicatedoperatingorsettingproceduresonlywiththevehiclestationary.
Dependingontheequipmentinyourvehicle,youcanusethefunctionkeysofthemulti-functionalsteeringwheeltooperatethefollowingPorschecommunicationsystems:
–PCM,
–Telephone,
–RadiowithCDdrive,
–CDchanger.
Readinessforoperationof
multi-functionalsteeringwheel
Themulti-functionalsteeringwheelisreadyforoperationwhentheignitionandPCMareswitchedon.
Operatingthefunctionkeys
PleasereadtheseparatePCMoperatinginstructionsbeforeoperatingthefunctionkeys.
Therotaryknobsatthetopleftandrightofthesteeringwheelcanalsobepressed.
TurnvolumecontrolUpwards-increasevolume.Downwards-decreasevolume.PressvolumecontrolToswitchvolume/muteonandoff.
TurnrotaryknobToselect/markfunctioninthePCM.Todothis,turntherotaryknobupwardordownward.PressrotaryknobToactivateselectedfunction.
PressscreenbuttonTocallthestoredPCMfunction.ThebuttoncanbeassignedthedesiredfunctioninthePCM.
PressBackbuttonTomovebackinthePCMmenu.
PressHandsetPickupbuttonToacceptatelephonecall.
PressHandsetHangupbuttonToendorrefuseatelephonecall.
Controls,Instruments47

SunVisors
Swivelthesunvisors
Swingthesunvisorsdowntopreventglarefromthefront.
Topreventglarefromtheside,unclipthesunvisorfromtheinnerbracketandswivelroundsothatitisinfrontofthedoorwindow.
Vanitymirror
Thevanitymirrorontherearofthesunvisoriscoveredbyalid.
Warning!
Riskofinjuryorriskofdamagetomirrorlidinanaccident.
Keepthelidclosedwhiledriving.
Warning!
Riskofdamage.
Donotforcethelidbeyonditsendposition.
Inthecaseofanilluminatedvanitymirror,thelightisswitchedonwhenthelidisopened.
