204
Maintenance, Car Care
Washing The best method of protecting your car from the
damaging effects of the environment is frequent
washing and the application of a preservative. The
underside of your vehicle should also be thorough-
ly washed for cinders, salt or sanding at winter’s
end.
The longer salt, road du st and industrial dust,
dead insects, bird droppi ngs or substances from
trees (resin, pollen) are allowed to remain on the
bodywork, the more serious is their harmful ef-
fect.
New cars should be washed carefully with plenty
of clear water to protect the new paint work. Dark
paint finishes show up the smallest of surface
damage (e.g., scratches) more readily than lighter
colors.
Dark colors are also more susceptible to scratch-
ing because of the compos ition of their pigments
and require particularly careful paint care.
f Do not wash your car in bright sunlight or while
the bodywork is still hot.
f When washing by hand, use abundant water, a
soft sponge or wash brush, and Porsche car
shampoo.
f Begin by spraying the body thoroughly with wa-
ter to rinse away loose dirt. f
After washing, rinse the car with plenty of wa-
ter and then dry with a chamois leather.
Do not use the same chamois leather for dry-
ing as you use for cleaning the windshield and
windows.
Warning!
Moisture which gets on to the brakes during
a car wash can reduce braking efficiency or
make the brakes pull unevenly which could
increase the danger of an accident, causing
serious personal injuries or death.
f After washing the car, test the brakes and
steering and briefly brake the discs dry.
When doing this, take care not to hamper other
road users behind you (traffic conditions permitting).
Automatic car washes
f Please see the chapter “WIPER BLADES” on
Page 202.
Optional add-on parts or parts which project
beyond the contours of the vehicle may be
damaged by design features (e.g. brushes) of au-
tomatic car washes. The following parts are particularly
susceptible to damage:
– Windshield wipers (alw
ays switch them off to
prevent them wiping unintentionally in intermit-
tent or sensor operation)
– External antennas (always unscrew)
– Rear spoiler
– Wheels (the wider the rim and the lower the tire height, the greater the risk of damage)
– High-gloss wheels (to prevent these from get- ting scratched, do not clean with the wheel-
cleaning brushes of the car wash).
f Please consult the operator before using auto-
matic car washes.
f Wash and dry by hand all points not reached by
a car wash, such as door and lid seams or
door sills.
Note
Automatic car washes spray water at odd angles
and high pressures, which are not seen in normal
driving. Therefore, water can sometimes find its
way into the passengers compartment during or
shortly after the car wash.

Practical Tips, Emergency Service
219
Parking at the curb
Warning!
Hard impacts against curbs (or traffic
islands) are dangerous and may cause hid-
den tire damage which is not noticeable until
later. Such damage can result in accidents at
high speeds causing serious personal injury
or death.
Depending on the force of impact, the edge
of the rim can also be damaged.
f If you are in doubt, have the wheel checked by
an expert, particularly if you suspect damage
on the inside.
f If you must drive over a curb or other obstacle,
drive slowly and at an obtuse angle. Exercise care when parking along curbs.
Wheel alignment, wheel balancing As a precaution, have wheels with summer tires
balanced in the spring, and those with mud and
snow tires before winter.
Unbalanced wheels may affect car handling and
tire life.
Only the specified weight s may be used for wheel
balancing.
Self-adhesive weights must not come into contact
with cleaning agents, since they could drop off.
Uneven tread wear indicates wheel imbalance. In
this event, the vehicle should be checked at an au-
thorized Porsche dealer.
Warning!
If, during a trip, uneven running or vibrations
occur that could be caused by damage to
tires or the car, the speed must be reduced
immediately, but without braking sharply.
If you continue your trip without having the
cause of the fault reme died, you might lose
control of your vehicle which could cause se-
rious personal injury or death.
f Stop the vehicle and check the tires.
f If no cause for the fault can be found, drive
carefully to the nearest authorized Porsche dealer.
Wheels with Tire Pressure Monitoring
(TPM) sensorsBefore changing wheels, make sure that the
wheels are compatible with your vehicle's TPM.
f Check this with your authorized Porsche
dealer.Removing and storing tires fAfter changing, adjust tire pressure and torque
wheel bolts diagonally to 94 ftlb (130 Nm).
Tires must always remain on the same side of
the vehicle.
When wheels are removed, the direction of
rotation and position of each wheel should be
marked.
Example
FR (front right), FL, RR and RL.
Wheels must always be fitted in accordance with
their marking.
The perception that tire durability and perform-
ance are immune to the effects of storage and
age is unfounded.
Chemical additives, whic h make the rubber elas-
tic, lose their effectivene ss in the course of time
and the rubber becomes brittle and cracks.
Therefore, the tires should be inspected from
time to time.

278
Index
JJumper cables ............................................ 245KKey codes ...................... .............................. 15
Keys ................. ......................... ............ 15, 16LLATCH System ............... .............................. 53
Launch Control ........................................... 181
Leather care .............. ................................ 208
License plate light................................... 78, 80
Lids ............................................... 93, 94, 100
Emergency unlocking .......................... 238
Lifting vehicle ............. ................................ 232
Light
Daytime driving ....... .............................. 78
Flasher....................... ...... 78, 80, 81, 127
Low beam .................. .............. 78, 80, 81
Sensor for instrument illumination 120, 122
Switch........................ .............. 78, 80, 81
Light alloy wheels
Inscription .............. ............................ 223
Light functions, indivi dual............................... 81
Lights ................................................. ......... 69
Care .................................................. 208
Headlight beam adju stment ................... 79
LIMIT Acoustic warning signal for speed limit 137
Load switch-off ........... ................................ 236
Loading information .... ................................ 224
Locking.......................... ........................ 20, 23
Low beam ...................... .............................. 81
Luggage compartment ............................ 94, 96 Lid warning light........
...................... 93, 95
Lids ..................................................... 93
Unlocking lid ......... ................................ 16
Luggage compartment, warning lights ............ 93
Luggage cover ............. ................................ 99
Luggage net ................. ................................ 96
MMaintenance ................. .............................. 186
Make-up mirror ............. ................................ 41
Maximum permitted engi ne speeds ................ 10
Manual transmission ............................ 176
Microphone ....................................... ......... 104
Mirror Folding in.............. ................................ 30
Heating .................... .................... 31, 117
Inside ................................................... 29
Mirrors ............................. ...................... 29, 71
Anti-glare ................................... ........... 30
Multi-functional steeri ng wheel ........................ 40NNavigation .................... .............................. 101
Selection field, on-board computer ....... 150
Notes on Car care ................... .......................... 203
Maintenance ............. .......................... 186
Number plate light ........ .......................... 78, 80
Changing bulb ....... .............................. 256OOctane rating................ ...................... 196, 197
Odometer.......................................... ......... 125Off delay ....................
............................79, 80
Oil...................... ............................. ...188, 271
Change........................ .......................190
Checking level.......... ...........................161
Consumption............ .............................10
Level checks............ ...........................189
Level indicator ......... ...........................161
Recommendation ......... .......................190
Topping off engine oi l ..........................189
OIL Display and measurement
of the engine oil leve l...................................161
On-board computer ..... ................................134
Basic settings .......... ...................135, 163
Calling on-board computer functions .....135
Functions and display possibilities ........135
General information . ............................164
Language versions ... ...........................163
Operation, controls... ...........................134
Selecting a radio station ......................150
Setting the clock ...... ...........................164
Switching daytime driving lights on/off ..164
Switching on navigation .......................150
Tire pressure warnings ........................156
Warnings and messag es ......................166
On-board literature ..........................................2
Operating voice contro l ...............................134
Operating your Porsche in other Countries ....194
Orientation light ...... ......................................69
Outside temperatur indicator........................131
Oxygen sensor............ ................................199

Index
279
PPaintCare .......................... ................ 203, 205
Data............... ......................... ........... 265
ParkAssistant ...................................... ......... 70
Parking
PDK transmission.... ............................ 183
Parking aids ............... ............................ 70, 71
Parking brake ............. .................................. 55
Warning light .......... .............................. 56
Parking light ............... ...................... 78, 80, 81
Particle filter ........... .................................... 201
Passenger compartment monitoring............... 25
PDK transmission ....... ................................ 178
Drive-Off Assistant... ............................ 177
Driving in winter .. ................................ 183
Faults................................................. 179
Kickdown ................... ........................ 181
Launch Control ....... ............................ 181
Manual selection mode ........................ 182
Reduced driving program .................... 184
Selector lever emerge ncy release ........ 259
Selector lever positi ons ....................... 180
Shifting gears on the steering wheel ..... 181
Sport mode ................ ........................ 180
Transmission fluid ............................... 201
Warning messages.. ............................ 184
Pen holder.................. .................................. 92
Plastic parts ............................................... 208 Care .................................................. 208
Platform lift ................ ................................ 232
Porsche Active Suspension Management
(PASM) ................................................ ......... 66
Sport mode ................ .......................... 66 Porsche Ceramic Composite Brake (PCCB) .......4
Porsche Communication Management (PCM).101
Porsche Doppelkupplung
(PDK) ....................178
Drive-Off Assistant . ..............................177
Driving in winter .... ..............................183
Faults ....................... ..........................179
Kickdown.................. ..........................182
Launch Control.......... ..........................178
Manual selection mo de ........................182
Reduced driving program.....................184
Selector lever emergency release ........259
Selector lever position .................178, 180
Shifting gears on the steering wheel .....181
Sport mode .............. ..........................180
Transmission fluid ...............................201
Porsche Stability Manage ment (PSM) ..............63
Information light .... ................................65
Power steering fluid le vel .....................201, 271
Power windows ............. ................................18
Practical tips ............ ..................................2
12
Putting vehicle into op eration

.......................241RRadiator fan..........................................76, 188
Radio reception ........ ..................................101
Rain sensor .............. ....................................82
Range on remaining fuel ......................135, 164
Rear fender
Retractable ........... ................................67
Rear lid ........................ ..........................94, 95
Unlocking ................. ............................16
Rear luggage compartm ent ...........................96
Rear spoiler .................. ..........................67, 68
Rear view mirrors...... ..............................29, 30 Rear window defogger
.......................... 31, 117
Rear window heating .................................. 117
Recirculating-air butt on ............................... 114
Refuelling ........................................ .......... 196
Relays ......................... .............................. 235
Remote control ............ ................................ 16
Readiness ................ ............................ 17
Replacing battery ..................... .......... 244
Standby funktion .. ................................ 17
Synchronization.... ................................ 17
Replacement key.......... ................................ 15
Replacing bulbs....... ................................... 247
Replacing wiper blades ............................... 202
Retractable spoiler .. ..................................... 67
Rims Diameter ................. .......................... 223
Rim width................. .......................... 223
TPM sensors............ .......................... 219
Roof transport system ................................ 105
Running in.................... ................................ 10
SSafety belts ............ ..................................... 42
Cleaning ............................................ 209
Tensioner ............................................ 42
Warning light ............ ............................ 43
Safety compliance sticker ........................... 264
Sealing set .................. .............................. 230
Seals .......................... .............................. 208
Care ........................ .......................... 208
Seat Adaptive sports se at............................. 33
Adjustment .......................................... 32
Comfort seat ........... ............................ 33

Index
281
Checking pressure .............................. 228
Inscription .......................................... 222
Loading information ............................ 224
New tires ............... .............................. 10
Pressure .................... ................ 214, 270
Pressure monitoring ............................ 151
Pressure plate ........ ............................ 265
Removing and storing.......................... 219
Sealant ...................... ................ 229, 230
Sidewall ..................... ........................ 222
Size ................................................... 222
Snow tires .............. ............................ 220
Tools ................ ........................................... 94
Towing ........................... .................... 259, 261
Towing hook............... ................................ 259
TPM Tire pressure moni toring ...................... 151
Track ............................. ............................ 268
Transmission Drive-Off Assistant... ............................ 176
Fluid........................... ................ 201, 271
Manual transmission ............................ 176
Porsche Doppelkupplung (PDK) .... 176, 178
Trip Odometer ............ ................................ 125
Trunk entrapment ....... ................................ 100
Turn signal Indicator light.......... ............................ 127
Turn signal light, front Changing bulb......... ............................ 253
Turn signals ......................................... 81, 127
UUndercoating ................ ......................198, 206VValves ........................................................218
Vanity mirror............. ....................................41
Vehicle Care......................... ..........................203
Engine number....................................265
Identification ......... ..............................264
Identification labe l ...............................264
Identification numbe r ...........................264
Lifting................... ..............................232
Load capacity ....... ..............................225
Putting into operat ion ..........................241
Safety compliance st icker ....................264
Washing ................... ..........................204
Vehicle identification number ........................264
Ventilation .................... ..............................113
Vents ................... ......................110, 113, 116
Viscosity, engine oil .....................................191
Voice control, button . ..................................134
Voice control, PCM ... ..................................134
WWarning lights and me ssages ...................... 166
Washer
Fluid ........................ .......................... 200
Fluid warning light. .............................. 200
Washer fluid ................................. .............. 271
Washer lever................................ ................ 82
Washing ...................... .............................. 204
Weights ........................................... .......... 272
Welcome Home Function ........................ 79, 80
Wheel ................. ................. 10, 213, 268, 269
Alignment ................ .......................... 219
Balancing........................................... 219
Bolts ....................... .......................... 226
Care ........................ .......................... 213
Changing ................. .......................... 229
Checking pressure ............................. 228
Inscription ............ .............................. 222
Loading information . ........................... 224
Securing bolts...... .............................. 226
Security wheel bolts ............................. 15
Sidewall ................... .......................... 222
Size .................................................. 222
Tire pressure ....... .............................. 214
Tire pressure plate ............... .............. 265
Tire sealant .............. .................. 229, 230
Wheels
Assembly aids for wheel changes ........ 227
Care ........................ .......................... 207
TPM sensors............ .......................... 219
Windows...................... .............................. 206
Anti-crushing protection ........................ 28
Care ........................ .......................... 206
Opening/Closing ...................... ............ 27
