Ram 1500 2016 Owner's Manual

Screen Setup
Push and release theUPorDOWNarrow
button until the Screen Setup display icon is
highlighted in the DID. Push and release theRIGHTarrow button to enter the Screen Setup submenu.
The Screen Setup feature allows you to change what
information is displayed in the instrument cluster as well
as the location that information is displayed.
Settings Options
1 Upper Left
•None
•Compass
•Outside Temp.
•Time
•Range
•Average MPG
•Current MPG
•Trip A
•Trip B
•Trailer Trip
•Trailer Brake Gain
4
UNDERSTANDING YOUR INSTRUMENT PANEL 369

Settings Options
2 Upper Right
•None
•Compass
•Outside Temp.
•Time
•Range
•Average MPG
•Current MPG
•Trip A
•Trip B
•Trailer Trip
•Trailer Brake Gain
370 UNDERSTANDING YOUR INSTRUMENT PANEL

Settings Options
3 Lower Left
•None
•Compass
•Outside Temp.
•Time
•Range
•Average MPG
•Current MPG
•Trip A
•Trip B
•Trailer Trip
•Trailer Brake Gain
4
UNDERSTANDING YOUR INSTRUMENT PANEL 371

Settings Options
4 Lower Right
•None
•Compass
•Outside Temp.
•Time
•Range
•Average MPG
•Current MPG
•Trip A
•Trip B
•Trailer Trip
•Trailer Brake Gain
5 Upper Gauge•None
•Trans Temp.
•Oil Temp.
•Oil Life
•Current MPG
•Trailer Brake Gain
372 UNDERSTANDING YOUR INSTRUMENT PANEL

Settings Options
6 Lower Gauge
•None
•Trans Temp.
•Oil Temp.
•Oil Life
•Current MPG
•Trailer Brake Gain
7 Odometer•000
•000.0
8 Restore Defaults•Cancel
•OK
Vehicles Settings (Customer-Programmable Features)
NOTE:This feature is only available on 5.0 and
8.4 Uconnect RadiosPersonal Settings allows the driver to set and recall
features when the transmission is in PARK.
Push and release theUPandDOWNbutton until Per-
sonal Settings displays in the DID.
Follow the prompts to display and set any of the follow-
ing Personal Settings.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 373

NOTE:Your vehicle may or may not be equipped with
all the following settings.
Setting NamesSetting Names Abbreviated
(Left Submenu Layer)Sub-Menus (Right Submenu
Layer)
1 Language Select Language English, Spanish, French, Italian,
German, Dutch
2 Units Units U.S.; Metric
3 ParkSense ParkSense
•Notification — Sound Only;
Sound & Display
•Front Volume — Low;
Medium; High
•Rear Volume — Low;
Medium; High
4 Tilt Mirror in Reverse Tilt Mirror in R On; Off
5 Rain Sensing Wipers Auto Wipers On; Off
6 Hill Start Assist Hill Start Assist On; Off
374 UNDERSTANDING YOUR INSTRUMENT PANEL

Setting NamesSetting Names Abbreviated
(Left Submenu Layer)Sub-Menus (Right Submenu
Layer)
7 Headlights Off Delay Lights Off Delay 0 seconds; 30 seconds; 60
seconds; 90 seconds
8 Illuminated Approach Lights w/ Unlock 0 seconds; 30 seconds; 60
seconds; 90 seconds
9 Headlights On with Wipers Lights w/ Wipers On; Off
10 Automatic Highbeams Auto Highbeams On; Off
11 Flash Lights with Lock Lights w/ Lock On; Off
12 Auto Lock Doors Auto Lock Doors On; Off
13 Auto Unlock Doors Auto Unlock Doors On; Off
14 Sound Horn with Remote Start Horn w/ Rmt Start On; Off
15 Sound Horn with Remote Lock Horn w/ Rmt Lock On; Off
16 Remote Unlock Sequence Remote Unlock Driver Door; All Doors
17 Key Fob Linked to Memory Key in Memory On; Off
18 Passive Entry Passive Entry On; Off
4
UNDERSTANDING YOUR INSTRUMENT PANEL 375

Setting NamesSetting Names Abbreviated
(Left Submenu Layer)Sub-Menus (Right Submenu
Layer)
19 Remote Start Comfort System Rmt Start Comfort On; Off
20 Easy Exit Seat Easy Exit Seat On; Off
21 Key-off Power Delay Power Off Delay Off; 45 seconds; 5 minutes; 10
minutes
22 Commercial Settings Commercial
•Aux Switches
•Power Take-Off
•PIN Setup
23 Air Suspension Display Alerts Air Susp. Alerts All; Warnings Only
24 Aero Ride Height Mode Aero Mode On; Off
25 Tire/Jack Mode Tire/Jack Mode On; Off
26 Transport Mode Transport Mode On; Off
27 Wheel Alignment Mode Wheel Alignment On; Off
376 UNDERSTANDING YOUR INSTRUMENT PANEL

Setting NamesSetting Names Abbreviated
(Left Submenu Layer)Sub-Menus (Right Submenu
Layer)
28 Horn w/ Remote Lower Horn w/ Rmt Lwr On; Off
29 Lights w/ Remote Lower Lights w/ Rmt Lwr On; Off
30 Trailer Select Trailer Select Trailer 1; Trailer 2; Trailer 3;
Trailer 4
31 Brake Type Brake Type Light Electric; Heavy Electric;
Light EOH; Heavy EOH
4
UNDERSTANDING YOUR INSTRUMENT PANEL 377

Setting NamesSetting Names Abbreviated
(Left Submenu Layer)Sub-Menus (Right Submenu
Layer)
32 Trailer Name Trailer Name
•Trailer # (# is equal to slot
position)
•Boat
•Car
•Cargo
•Dump
•Equipment
•Flatbed
•Gooseneck
•Horse
•Ta g
•Motorcycle
•Snowmobile
•Travel
•Utility
•5th Wheel
378 UNDERSTANDING YOUR INSTRUMENT PANEL
