Setting NamesSetting Names Abbre-
viated (Left Submenu
Layer)Sub-Menus (Right Submenu Layer)
3 ParkSense ParkSense
•Notification — Sound Only; Sound & Display
•Front Volume — Low; Medium; High
•Rear Volume — Low; Medium; High
4 Tilt Mirror in
ReverseTilt Mirror in R On; Off
5 Rain Sensing
WipersAuto Wipers On; Off
6 Hill Start Assist Hill Start Assist On; Off
7 Headlights Off
DelayLights Off Delay 0 seconds; 30 seconds; 60 seconds; 90 seconds
8 Illuminated
ApproachLights w/ Unlock 0 seconds; 30 seconds; 60 seconds; 90 seconds
9 Headlights On
with WipersLights w/ Wipers On; Off4
UNDERSTANDING YOUR INSTRUMENT PANEL 349

Setting NamesSetting Names Abbre-
viated (Left Submenu
Layer)Sub-Menus (Right Submenu Layer)
10 Automatic
HighbeamsAuto Highbeams On; Off
11 Flash Lights
with LockLights w/ Lock On; Off
12 Auto Lock
DoorsAuto Lock Doors On; Off
13 Auto Unlock
DoorsAuto Unlock Doors On; Off
14 Sound Horn
with Remote
StartHorn w/ Rmt Start On; Off
15 Sound Horn
with Remote
LockHorn w/ Rmt Lock Off; 1st Press; 2nd Press
350 UNDERSTANDING YOUR INSTRUMENT PANEL

Setting NamesSetting Names Abbre-
viated (Left Submenu
Layer)Sub-Menus (Right Submenu Layer)
16 Remote Unlock
SequenceRemote Unlock Driver Door; All Doors
17 Key Fob Linked
to MemoryKey in Memory On; Off
18 Passive Entry Passive Entry On; Off
19 Remote Start
Comfort SystemRmt Start Comfort Off; Remoter Start; All starts
20 Easy Exit Seat Easy Exit Seat On; Off
21 Key-off Power
DelayPower Off Delay Off; 45 seconds; 5 minutes; 10 minutes
22 Air Suspension
Display AlertsAir Susp. Alerts All; Warnings Only
23 Aero Ride
Height ModeAero Mode On; Off
4
UNDERSTANDING YOUR INSTRUMENT PANEL 351

Setting NamesSetting Names Abbre-
viated (Left Submenu
Layer)Sub-Menus (Right Submenu Layer)
24 Tire/Jack Mode Tire/Jack Mode On; Off
25 Transport Mode Transport Mode On; Off
26 Wheel Align-
ment ModeWheel Alignment On; Off
27 Horn w/ Re-
mote LowerHorn w/ Rmt Lwr On; Off
28 Lights w/ Re-
mote LowerLights w/ Rmt Lwr On; Off
29 Trailer Select Trailer Select Trailer 1; Trailer 2; Trailer 3; Trailer 4
30 Brake Type Brake Type Light Electric; Heavy Electric; Light EOH; Heavy EOH
352 UNDERSTANDING YOUR INSTRUMENT PANEL

Setting NamesSetting Names Abbre-
viated (Left Submenu
Layer)Sub-Menus (Right Submenu Layer)
31 Trailer Name Trailer Name
•Trailer # (# is equal to slot position)
•Boat
•Car
•Cargo
•Dump
•Equipment
•Flatbed
•Gooseneck
•Horse
•Livestock
•Motorcycle
•Snowmobile
•Travel
•Utility
•5th Wheel
4
UNDERSTANDING YOUR INSTRUMENT PANEL 353

Setting NamesSetting Names Abbre-
viated (Left Submenu
Layer)Sub-Menus (Right Submenu Layer)
32 Compass
VarianceCompass Var 1-15 increments of 1
33 Calibrate
CompassCompass Cal Cancel; Calibrate
34 Fuel Saver
DisplayFuel Saver On; Off
Turn Menu OFF
Push and release the RIGHT arrow button to exit the
main menu.
Push and release any EVIC control button to enter the
EVIC main menu again.
354 UNDERSTANDING YOUR INSTRUMENT PANEL

DRIVER INFORMATION DISPLAY (DID)
The Driver Information Display (DID) features a driver-
interactive display that is located in the instrument
cluster.The DID Menu items consists of the following:
•Digital Speedometer
•Vehicle Info
•Fuel Economy Info
•Trip A
•Trip B
•Stop/Start Info (If Equipped)
•Trailer Tow
•Audio
•Stored Messages
•Screen Setup
•Vehicle Settings (Not Equipped with a Uconnect 5.0 &
8.4 radio)
Driver Information Display (DID)
4
UNDERSTANDING YOUR INSTRUMENT PANEL 355

Vehicle Information (Customer Information Features)
The system allows the driver to select information by
pushing the following buttons mounted on the steering
wheel:•UP Arrow Button
Push and release theUParrow button to scroll
upward through the main menu and
submenus.
•DOWN Arrow Button
Push and release theDOWNarrow button to
scroll downward through the main menu and
submenus.
•RIGHT Arrow Button
Push and release theRIGHTarrow button to
access/select the information screens or sub-
menu screens of a main menu item. Push and
hold theRIGHTarrow button for two seconds
to reset displayed/selected features that can be reset.
DID Controls
356 UNDERSTANDING YOUR INSTRUMENT PANEL

•LEFT Arrow Button
Push and release theLEFTarrow button to
return to the main menu from an info screen or
submenu item.
Driver Information Display (DID) Displays
The DID displays are located in the center portion of the
cluster and consists of eight sections:
1. Main Screen — The inner ring of the display will
illuminate in grey under normal conditions, yellow for
non critical warnings, red for critical warnings, and
white for on demand information.
2. Audio / Phone Information and Sub-menu Informa-
tion — Whenever there are sub-menus available, the
position within the sub-menus is shown here.
3. Selectable Information (Compass, Temp, Range to
Empty, Trip A, Trip B, Average MPG, Trailer Trip
(distance only), Trailer Brake Gain, Time)
4. Telltales/Indicators
5. Shift Lever Status (PRNDL)
6. Selectable Menu Icons
7. Air Suspension Status – If Equipped
4
UNDERSTANDING YOUR INSTRUMENT PANEL 357

8. 4WD Status
9. Selectable Gauge 2 (Trans Temp, Oil Temp, Oil Life,
Trailer Brake, Current MPG)
10. Selectable Gauge 1 (Trans Temp, Oil Temp, Oil Life,
Trailer Brake, Current MPG)
The main display area will normally display the main
menu or the screens of a selected feature of the main
menu. The main display area also displays “pop up”
messages that consist of approximately 60 possible warn-
ing or information messages. These pop up messages fall
into several categories:
•Five Second Stored Messages
When the appropriate conditions occur, this type of
message takes control of the main display area for five
seconds and then returns to the previous screen. Most of
the messages of this type are then stored (as long as the
condition that activated it remains active) and can bereviewed from the “Messages” main menu item. As long
as there is a stored message, an “i” will be displayed in
the DID’s compass/outside temp line. Examples of this
message type are “Right Front Turn Signal Lamp Out”
and “Low Tire Pressure.”
•Unstored Messages
This message type is displayed indefinitely or until the
condition that activated the message is cleared. Examples
of this message type are “Turn Signal On” (if a turn signal
is left on) and “Lights On” (if driver leaves the vehicle).
•Unstored Messages Until RUN
These messages deal primarily with the Remote Start
feature. This message type is displayed until the ignition
is in the RUN state. Examples of this message type are
“Remote Start Aborted - Door Ajar” and “Press Brake
Pedal and Push Button to Start.”
