Ram 2500 2011 Owner's manual (Gas and Diesel)

JOBNAME: 288987 2011 Maint-Wa PAGE: 38 SESS: 68 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/02bintervals-diesel
❏Change the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 12,000 km
or 6 months whichever occurs first.*
❏Rotate tires.
❏Check the diesel exhaust fluid (DEF) tank, refill if
necessary.
❏Lubricate the front drive shaft fitting. (4x4)
❏Lubricate the outer tie rod ends. (Chassis Cab only)
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance At
228,000 km or 114 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 39 SESS: 68 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/02bintervals-diesel
Perform Maintenance At
240,000 km or 120 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 12,000 km or 6 months whichever occurs first.*
❏Rotate tires.
❏Check the diesel exhaust fluid (DEF) tank, refill if necessary.
❏Lubricate the front drive shaft fitting. (4x4)
❏Lubricate the outer tie rod ends. (Chassis Cab only)
❏Inspect the front suspension components, tie rod ends and boot seals; replace if
necessary.
❏Inspect the transfer case fluid level.(4x4)
❏Inspect the front (4x4) and rear axle fluid; change if using your vehicle for any of
the following: police, fleet, off-road or frequent trailer towing.
❏Replace the fuel filter element.
❏Inspect the front wheel bearings.
❏Change the automatic transmission fluid and filter. (Chassis Cab only)
❏Flush and replace the engine coolant at 120 months if not done at 156,000 km.
❏Adjust the valve lash clearance.
* Oil changes that are prompted by the oil change indicator system prior to this schedule maintenance interval can
be recorded in the oil change log section.
Perform Maintenance
At
120 Months or
240,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 40 SESS: 68 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/02bintervals-diesel
❏Change the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 12,000 km
or 6 months whichever occurs first.*
❏Rotate tires.
❏Check the diesel exhaust fluid (DEF) tank, refill if
necessary.
❏Lubricate the front drive shaft fitting. (4x4)
❏Lubricate the outer tie rod ends. (Chassis Cab only)
❏Inspect the front suspension components, tie rod ends and
boot seals; replace if necessary.
❏Inspect the transfer case fluid level.(4x4)
❏Inspect the front (4x4) and rear axle fluid; change if using
your vehicle for any of the following: police, fleet, off-
road or frequent trailer towing.
❏Replace the fuel filter element.
❏Inspect the front wheel bearings.
❏Change the automatic transmission fluid and filter. (Chassis
Cab only)
❏Flush and replace the engine coolant at 120 months if not
done at 156,000 km.
❏Adjust the valve lash clearance.
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance At
240,000 km or 120 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 1 SESS: 33 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/oilchange-filler-english
SERVICE # 1
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
SERVICE # 2
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
SERVICE # 3
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
SERVICE # 4
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
SERVICE # 5
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
SERVICE # 6
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
OIL CHANGE LOG

JOBNAME: 288987 2011 Maint-Wa PAGE: 2 SESS: 33 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/oilchange-filler-english
SERVICE # 7
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
SERVICE # 8
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
SERVICE # 9
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
SERVICE # 10
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
SERVICE # 11
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
SERVICE # 12
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
OIL CHANGE LOG

JOBNAME: 288987 2011 Maint-Wa PAGE: 3 SESS: 33 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/oilchange-filler-english
SERVICE # 13
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
SERVICE # 14
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
SERVICE # 15
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
SERVICE # 16
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
SERVICE # 17
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
SERVICE # 18
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
OIL CHANGE LOG

JOBNAME: 288987 2011 Maint-Wa PAGE: 4 SESS: 33 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/oilchange-filler-english
SERVICE # 19
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
SERVICE # 20
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
SERVICE # 21
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
SERVICE # 22
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
SERVICE # 23
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
SERVICE # 24
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
OIL CHANGE LOG
